CENG 342 – Digital Systems

Regular Sequential Circuit Larry Pyeatt

SDSM&T

Mealy vs Moore

Moore machine is a finite-state machine whose output values are determined solely by its current state. Mealy machine is a finite-state machine whose output values are determined both by its current state and the current inputs.

Combinational Logic Circuit (Next State) Memory Devices (Flip−Flops) Combinational Logic Circuit (Output Logic) Inputs Outputs Combinational Logic Circuit (Next State) Memory Devices (Flip−Flops) Combinational Logic Circuit (Output Logic) Inputs Outputs

Basic Memory Elements

Latch and Flip Flop: 1-bit storage element. Comes in J-K, D, and S-R varieties. We focus on D. Characteristics of D Latch and D Flip Flop (FF):

clk d q

c q* q 1 d

d q clk

c q* q 1 q d

d q clk

c q* q 1 q d D Latch Positive edge triggered D FF Negative edge triggered D FF D latch depends on the level of the clock, so it is level sensitive. D FF depends on the rising (changes from 0 to 1) or falling (changes from 1 to 0) edge of the clock, so it is edge triggered. A small triangle is used to show that the storage device is edge-triggered. Note: q* represents the next value of q.

Finite State Machine Design Methodology

Two main types: synchronous and asynchronous. Synchronous: uses a global clock to drive all latches/flip-flops in the circuit. Asynchronous: does not use a global clock signal. The combinational logic blocks of each layer drive the clocks of the following layers (and possibly their

• wn clocks). Very tricky, but can give very high performance.

Synchronous Design Methodology assumes that all storage elements are controlled by a global clock signal and the data is sampled at the rising or falling edge of the clock signal. Our design will follow this synchronous design methodology. The storage components can be separated from the combinational logic circuit(s) and this will significantly simplify the development process.

Synchronous System

Block diagram of a 2-state synchronous system: State register: a D FF (register) Next-state logic: combinational logic to determine the new value of the register Output logic: combinational logic to generate the output

d q clk

• u

t p u t lo g ic

• u

t p u t n e x t

• st

a t e lo g ic st a t e _n e x t st a t e _re g e x t e rn a l in p u t clk

Mealy or Moore?

Timing Constraints for Flip-Flops – Part 1

Flip-flops have timing constraints. The most important ones are: Tsetup: the time interval in which the d signal must be stable before the clock edge Thold: the time interval in which the d signal must be stable after the clock edge. Tcq: clock-to-q delay, the propagation delay required for the d input to show up at the q output after the sampling edge of clock. If the d signal changes within the setup or hold time window, the value stored may not be the one intended. These situations are known as setup time violations or hold time violations.

setup time violation Tsetup clk d q Thold Tcq

Timing Constraints for Flip-Flops – Part 2

Tclock is the minimal time clock (period between two sampling edges). The next value must be generated and stabilized during this period. fmax is the maximal clock frequency for a sequential circuit using the flip-flop. It is the reciprocal of T clock. fmax = 1 Tclock The Nexys A7 board provides a 100MHz system clock (10ns period). Timing information can be found from the View Design Summary after synthesis. Coding strategy: separate the memory component (D flip-flop) from the combinational

• logic. View as two pieces: register and combinational circuit

Regular sequential circuit (Chapter 4): the state transition follows regular pattern like counter or shift register FSM (Chapter 5): does not follow simple regular pattern FSMD (Chapter 6): FSM + regular sequential circuit

D Flip Flop

We focus on positive edge triggered FF because that is what the Xilinx chip has. The value of D is transferred to Q at the rising edge (from 0 to 1) of clock signals. There are variants:

D FF without reset D FF with asynchronous reset: reset signal (independent of clk) to clear FF to ‘0’. D FF with enable: maintain synchronism between a fast subsystem and a slow subsystem. Not shown is a D FF with synchronous reset: reset signal is synchronized with clock to clear FF to ‘0’. In FPGA design, this is preferred to asynchronous reset.

Nexys A7 board has a dedicated button for use as a system reset. It is labeled “CPU Reset”

• n the board and appears as “reset” in the master xdc file.

d q clk c q* q 1 q d d q rst clk rst clk q* 1

• q

1 q d d q rst clk en rst clk en q* 1

• q

1

• q

q 1 d

D FF D FF with asynchronous reset D FF with enable

Representing Clock Edges in VHDL

Within a process, a clock change is represented using: CLK’event Which is ‘true’ if the clock is changing at the current time. For a positive edge:

1 CLK’event and CLK=’1’

• r

1 rising_edge(CLK)

Which is ‘true’ if the clock is changing to ‘1’. For a negative edge:

1 CLK’event and CLK=‘0’

• r

1 falling_edge (CLK)

rising_edge and falling_edge are functions defined in the std_logic_1164 Package

VHDL code for D flip-flop - Part 1

D FF without reset signal: at rising edges of clock signal, the value of D is transferred to Q,

• therwise Q is unchanged.

1 library ieee; 2 use ieee.std_logic_1164.all; 3 4 entity d_ff is 5

port(

6

clk: in std_logic;

7

d: in std_logic;

8

q: out std_logic

9

);

10 end d_ff; 11 12 architecture arch of d_ff is 13 begin 14

process(clk)

15

begin

16

if (clk’event and clk=’1’) then

17

q <= d;

18

end if;

19

end process;

20 end arch;

d q clk c q* q 1 q d

VHDL code for D flip-flop - Part 2

D FF with asynchronous reset signal: Reset signal can clear the FF at any time.

1 library ieee; 2 use ieee.std_logic_1164.all; 3 4 entity d_ff_reset is 5

port(

6

clk, rst: in std_logic;

7

d: in std_logic;

8

q: out std_logic

9

);

10 end d_ff_reset; 11 12 architecture arch of d_ff_reset is 13 begin 14

process(clk,rst)

15

begin

16

if (rst=’1’) then

17

q <=’0’;

18

elsif (clk’event and clk=’1’) then

19

q <= d;

20

end if;

21

end process;

22 end arch;

d q rst clk rst clk q* 1

• q

1 q d

VHDL code for D flip-flop - Part 2

D FF with enable signal: If en is zero, clock is ignored.

1 library ieee; 2 use ieee.std_logic_1164.all; 3 4 entity d_ff_en is 5

port(

6

clk, reset: in std_logic;

7

en: in std_logic;

8

d: in std_logic;

9

q: out std_logic

10 ); 11 end d_ff_en; 12 13 architecture arch of d_ff_en is 14 begin 15

process(clk,reset)

16

begin

17

if (reset=’1’) then

18

q <=’0’;

19

elsif (clk’event and clk=’1’) then

20

if (en=’1’) then

21

q <= d;

22

end if;

23

end if;

24

end process;

25 end arch;

d q rst clk en rst clk en q* 1

• q

1

• q

q 1 d

D FF with enable signal – 2nd approach

The enable signal is synchronous, the circuit can be built with a D FF and simple next-state logic

q d clk q re se t 1 r_n e x t re se t e n clk d r_re g d q rst clk en

rst clk en q* 1

• q

1

• q

q 1 d

Coding development: separate memory from combinational circuits:

1

Use an individual VHDL code segment to infer memory elements. The segment should be a standard description of D FF or register

2

Use the suffix _reg to represent the output of a D FF or a register.

3

Use the suffix _next to indicate the next value (the d input) of a D FF or a register.

VHDL

1 architecture two_seg_arch of d_ff_en is 2

signal r_reg, r_next: std_logic;

3 begin 4

• - D FF

5

process(clk,reset)

6

begin

7

if (reset=’1’) then

8

r_reg <=’0’;

9

elsif (clk’event and clk=’1’) then

10

r_reg <= r_next;

11

end if;

12

end process;

13

• - next-state logic

14

r_next <= d when en =’1’ else r_reg;

15

• - output logic

16

q <= r_reg;

17 end two_seg_arch;
