SLIDE 1
CENG 342 – Digital Systems
Algorithmic State Machine with Datapath (ASMD) Larry Pyeatt
SDSM&T
CENG 342 Digital Systems Algorithmic State Machine with Datapath - - PowerPoint PPT Presentation
CENG 342 Digital Systems Algorithmic State Machine with Datapath - - PowerPoint PPT Presentation
CENG 342 Digital Systems Algorithmic State Machine with Datapath (ASMD) Larry Pyeatt SDSM&T Finite State Machine Review Any Finite state machine with two inputs, two Mealy outputs, two Moore outputs, and up to four states can be
SLIDE 2
SLIDE 3
FSM – Review
Finite state machines may be described in more detail using a state diagram. The state diagram is a graph, which means that it is composed of
a set of nodes and a set of arcs.
Each node has a set of incoming arcs and a set of outgoing arcs. Moore outputs are associated with nodes. Mealy outputs are associated with arcs. The following diagram shows a single node with one incoming arc and two outgoing arcs.
To other state To other state MO ← value MO: Moore output ME: Mealy output . . . State_Name Logical expression {/ ME ← value {, . . . }} Logical expression {/ ME ← value {, . . . }} Logical expression {/ ME ← value {, . . . }}
SLIDE 4
FSM – Review
To other state To other state MO ← value MO: Moore output ME: Mealy output . . . State_Name Logical expression {/ ME ← value {, . . . }} Logical expression {/ ME ← value {, . . . }} Logical expression {/ ME ← value {, . . . }}
Each node has a list of Moore outputs, which are asserted whenever that state is the current state. Each arc has a Logical Expression, which specifies the condition under which that arc is taken, and a set of Mealy Outputs, which are asserted whenever that condition becomes true in the state represented by the source node. We often define “default” values for both Moore and Mealy outputs. If a value is not explicitly listed, then the default value is assumed.
SLIDE 5
FSM – Review
Example from “The Designer’s Guide to VHDL.” – An FSM with both Mealy and Moore
- utputs:
S1 y1 ← 1 S2 a ab/y0 ← 1 S0 a a
SLIDE 6
FSM – VHDL Implementation
A methodical approach makes it much easier and less error-prone. Use the VHDL enumerated data type to represent the states. Use three section coding method:
1
A process which updates the current state.
2
A process or concurrent statement(s) to generate the next state.
3
A process or concurrent statement(s) to generate the outputs.
SLIDE 7
FSM – VHDL Implementation
1 library ieee; 2 use ieee.std_logic_1164.all; 3 4 entity fsm_eg is 5
port(
6
clk, reset: in std_logic;
7
a, b : in std_logic;
8
y0, y1 : out std_logic;
9
);
10 end fsm_eg; 11 12 architecture mult_seg_arch of fsm_eg is 13
type eg_state_type is (s0, s1, s2);
14
signal state_reg, state_next : eg_state_type;
15 begin 16
- - state update
17
process(clk,reset)
18
begin
19
if reset = ’1’ then -- asynchronous reset
20
state_reg <= s0;
21
elsif rising_edge(clk) then
22
state_reg <= state_next;
23
end if;
24
end process;
S1 y1 ← 1 S2 a ab/y0 ← 1 S0 a a Combinational Logic Circuit (Next State) Memory Devices (Flip−Flops) Combinational Logic Circuit (Moore Outputs) Combinational Logic Circuit (Mealy Outputs) Inputs Moore Outputs Mealy Outputs
SLIDE 8
FSM – VHDL Implementation
26
- - next state logic
27
process (state_reg, a, b)
28
begin
29
case state_reg is
30
when s0 =>
31
if a = ’1’ then
32
if b = ’1’ then
33
state_next <= s2;
34
else
35
state_next <= s1;
36
end if;
37
else
38
state_next <= s0;
39
end if;
40
when s1 =>
41
if a = ’1’ then
42
state_next <= s0;
43
else
44
state_next <= s1;
45
end if;
46
when s2 =>
47
state_next <= s0;
48
end case;
49
end process;
S1 y1 ← 1 S2 a ab/y0 ← 1 S0 a a Combinational Logic Circuit (Next State) Memory Devices (Flip−Flops) Combinational Logic Circuit (Moore Outputs) Combinational Logic Circuit (Mealy Outputs) Inputs Moore Outputs Mealy Outputs
SLIDE 9
FSM – VHDL Implementation
51
- - Moore output logic
52
process(state_reg)
53
begin
54
case state_reg is
55
when s0 | s2 =>
56
y1 <= ’0’;
57
when s1 =>
58
y1 <= ’1’;
59
end case;
60
end process;
61 62
- - Mealy output logic
63
process(state_reg,a,b)
64
begin
65
case state_reg is
66
when s0 =>
67
if a = ’1’ and b = ’1’ then
68
y0 <= ’1’;
69
else
70
y0 <= ’0’;
71
end if;
72
when s1 | s2 =>
73
y0 <= ’0’;
74
end case;
75
end process
76 end mult_seg_arch;
S1 y1 ← 1 S2 a ab/y0 ← 1 S0 a a Combinational Logic Circuit (Next State) Memory Devices (Flip−Flops) Combinational Logic Circuit (Moore Outputs) Combinational Logic Circuit (Mealy Outputs) Inputs Moore Outputs Mealy Outputs
SLIDE 10
FSM – VHDL Implementation
Much simpler implementation of output logic:
78
- - Moore output logic
79
y1 <= ’1’ when state_reg = s1 else ’0’;
80 81 82
- - Mealy output logic
83
y0 <= ’1’ when (state_reg = s0
84
and a =’1’
85
and b = ’1’) else ’0’;
S1 y1 ← 1 S2 a ab/y0 ← 1 S0 a a Combinational Logic Circuit (Next State) Memory Devices (Flip−Flops) Combinational Logic Circuit (Moore Outputs) Combinational Logic Circuit (Mealy Outputs) Inputs Moore Outputs Mealy Outputs
SLIDE 11
Example – Edge Detector
Moore Mealy
The zero and one states indicate that the input signal has been 0 or 1 For a while level ZERO level ZERO EDGE tick ← 1 level ONE level ONE level level level level level/tick ← 1 level
SLIDE 12
FSMD
Finite state machine with datapath Uses an FSM to drive another sequential circuit
Data Register(s) Routing Network Functional Units Routing Network Data Input Output Data Next State Logic Output Logic Register State Status Output Command Internal Status Control Signals
SLIDE 13
Register Transfer Level
The FSMD is used to implement systems that are described at the Register Transfer Level (RTL). An RT operation specifies data manipulation and transfer for a single destination
- register. Example:
rdest ← f(rsrc1, rsrc2, . . . , rsrcn) Elementary operations are called microoperations. Some examples are:
load: rx ← ry, count: rx ← rx + C where C is a constant, shift: rx ← lsl(rx, amt), bitwise “or”: rx ← rx ∨ ry, etc.
There is a fairly well established syntax for RTL operations. You can extend the syntax, if you explain what your operations mean, and be consistent.
SLIDE 14
Common RTL Syntax
The ← symbol indicates data transfer into a register. R1 ← R2 Brackets [] specify an operation on memory. The memory address goes inside the brackets, and the memory device name precedes the brackets. R0 ← M[AR] M[AR] ← R5 A comma is used to separate parallel operations. rx ← ry, ra ← rb + rc A colon specifies a condition under which the transfer occurs. K1 : rx ← ry, ra ← rb + rc ab : rx ← rx + 1
SLIDE 15
RTL
It is assumed that all RT operations are synchronized by a shared clock. The results from the operation are not stored until the next rising (or falling, if you design it that way) edge of the clock. The following figures show two ways to achieve the same results. The figure on the left takes one clock cycle to get the result. The one on the right takes two clock cycles, but is more flexible. It uses a “routing network” shown previously. Can you design a circuit that can perform the unified a − b + 1 operation in one clock cycle, but is also capable of performing either the a − b or the a + 1 operation individually?
d q clk d q clk +1 − d q clk d q clk +1 − a ← a − b + 1 a b a b a ← a − b a ← a + 1
SLIDE 16
Algorithmic State Machine
For designing the state machine, it is often easier to use an Algorithmic State Machine (ASM) chart. The ASM chart is a network of ASM blocks.
State blocks represent the states and Moore outputs. Decision blocks represent condition tests. Conditional output blocks represent Mealy outputs.
Condition Expression Moore Outputs Mealy Outputs Conditional Output Block Decision Block State Block 1 State
SLIDE 17
Algorithmic State Machine
ASM with datapath The clock is assumed to drive state transitions. The ASM chart specifies operations that must be implemented by the datapath.
8 d q clk d q clk s0 s1 s2 s3 r1 ← 8 r1 ← r1 + r2 r1 ← r1 r1 ← r1<<2 r1 r2 <<2 +
SLIDE 18
Algorithmic State Machine
It is common to use one or more multiplexers as a routing network to provide input to the registers and/or the functional units. The following ASM chart is equivalent to one circle in the state diagram. The dashed lines show an ASM block. The clock causes transition from one ASM block to the next. Some decision nodes can be handled completely within the datapath.
−1 + s0 a > b r2 ← r2 + b r2 ← r2 + a F T r1 r2 a b a > b en en Control Signals d q d q r1 ← r1 − 1
SLIDE 19
ASMD Timing
The destination register(s) get updated when exiting the current ASMD block, but not within the block. Each ASMD block represents one clock cycle. There can be errors when that fact is forgotten.
s1 s1 r = 0 T F r ← r − 1 r ← r_next r_next := r − 1 r_next ← r − 1 r_next = 0 T F r ← r_next T F s1 The := symbol can be used to specify a local signal that is assigned immediatly r_next = 0
SLIDE 20
State Diagram and ASM Equivalence
a = 1 b = 1 y0 ← 1 s2 a = 1
S1 y1 ← 1 S2
F T T F y1 ← 1 s1 F T
a ab/y0 ← 1 S0 a a
s0
SLIDE 21
Calculating the ith Number in the Fibonacci Sequence
The Fibonacci sequence is defined as: fib(i) = if i = 0, 1 if i = 1, fib(i − 1) + fib(i − 2)
- therwise.
n ← F ⊲ Load the input value into n t0 ← 0 ⊲ Initialize t0 t1 ← 1 ⊲ Initialize t1 repeat if n = 0 then ⊲ Original input is zero t1 ← 0 ⊲ Initialize t1 else if n = 1 then ⊲ Skip update on last time through loop n ← n − 1 ⊲ Decrement counter t3 ← t1 + t0 ⊲ Calculate new value for t1 t0 ← t1 ⊲ Copy t1 to t0 t1 ← t3 ⊲ Assign value to t1 end if Result ← t1 until n < 2 ⊲ Go through the loop n times
SLIDE 22
ASM Chart
Temporary variables (registers): t0, t1 Index variable (register): n Inputs:
i indicates that we want the ith number in the Fibonacci sequence start commands the circuit to begin the operation
Outputs:
F is the ith number in the Fibonacci sequence (held in t1) ready indicates that the circuit is idle and ready to take input. Default value is 0. done-tick is asserted for one clock cycle when the operation is complete. Default value is 1.
t0 ← 0 t1 ← 1 n ← i IDLE ready ← 1 F T start = 1 t1 ← 0 n = 1 t0 ← t1 t1 ← t1 + t0 n ← n − 1 OP F T T F n = 0 DONE done_tick ← 1
SLIDE 23
VHDL
1 -- The Fibonnaci circuit.
Make sure the ready line is high, then
2 -- input the index of the Fibonacci number you want on the i bus and 3 -- pull the start line high for one clock cycle, then wait for it to 4 -- calculate the corresponding Fibonacci number. The done_tick signal 5 -- will go high for one clock cycle when the computation is done. 6 library ieee; 7 use ieee.std_logic_1164.all; 8 use ieee.numeric_std.all; 9 10 entity fib is 11
port(
12
clk, reset : in std_logic;
13
start : in std_logic;
14
i : in std_logic_vector(4 downto 0);
15
ready, done_tick : out std_logic;
16
F : out std_logic_vector(13 downto 0)
17
);
18 end fib; 19 20 -- It is implemented as an FSMD. 21 architecture arch of fib is 22
type state_t is (IDLE, OP, DONE);
23
signal state, state_next : state_t;
24
signal t0, t0_next, t1, t1_next: unsigned(13 downto 0);
25
signal n, n_next: unsigned(4 downto 0);
26 begin
SLIDE 24
VHDL
26 begin 27
- - FSMD state and data registers.
Everything is clocked together.
28
process(clk,reset)
29
begin
30
if reset = ’1’ then
31
state <= idle;
32
t0 <= (others => ’0’);
33
t1 <= (others => ’0’);
34
n <= (others => ’0’);
35
elsif rising_edge(clk) then
36
state <= state_next;
37
t0 <= t0_next;
38
t1 <= t1_next;
39
n <= n_next;
40
end if;
41
end process;
SLIDE 25
VHDL
43
- - Next state and datapath logic.
All mushed together.
44
process(state,n,t0,t1,start,i,n_next)
45
begin
46
state_next <= state;
- - provide defaults
47
t0_next <= t0;
48
t1_next <= t1;
49
n_next <= n;
50
case state is
51
when IDLE =>
52
if start = ’1’ then
53
t0_next <= (others => ’0’);
54
t1_next <= (0=>’1’, others => ’0’);
55
n_next <= unsigned(i);
56
state_next <= OP;
57
end if;
58
when OP =>
59
if n = 0 then
60
t1_next <= (others => ’0’);
61
state_next <= DONE;
62
elsif n = 1 then
63
state_next <= DONE;
64
else
65
t1_next <= t1 + t0;
66
t0_next <= t1;
67
n_next <= n - 1;
68
end if;
69
when DONE => state_next <= IDLE;
70
end case;
SLIDE 26
VHDL
73
- - Output logic
74
F <= std_logic_vector(t1);
75
done_tick <= ’1’ when state = DONE else ’0’;
76
ready <= ’1’ when state = IDLE else ’0’;
77 78 end architecture arch;
SLIDE 27
VHDL
79 80
- - Alternate next state and datapath logic. Easier to read and debug.
81 82
state_next <= OP when state = IDLE and start = ’1’ else
83
DONE when state = OP and n < 2 else
84
IDLE when state = DONE else
85
state;
86 87
t0_next <= (others => ’0’) when state = IDLE and start = ’1’ else
88
t1 when state = OP and n > 1 else
89
t0;
90 91
t1_next <= (0=>’1’, others => ’0’) when state = IDLE and start = ’1’ else
92
(others => ’0’) when state = OP and n = 0 else
93
t1 + t0 when state = OP and n > 1 else
94
t1;
95 96
n_next <= unsigned(i) when state = IDLE and start = ’1’ else
97
n - 1 when state = OP and n > 1 else
98
n;
SLIDE 28
VHDL Testbench
1 library IEEE; 2 use IEEE.STD_LOGIC_1164.ALL; 3 4 entity Fibonacci_testbench is 5 end Fibonacci_testbench; 6 7 architecture Behavioral of Fibonacci_testbench is 8
signal i: std_logic_vector(4 downto 0);
9
signal f: std_logic_vector(19 downto 0);
10
signal clk, start, ready, done, reset: std_logic := ’0’;
11 begin 12
clk <= not clk after 10 ns;
13
uut: entity work.fib(arch)
14
port map( i => i, F=> f, reset => reset,
15
clk => clk, start => start,
16
ready => ready, done_tick => done);
17
test: process
18
begin
19
start <= ’0’;
20
i <= "00111";
21
reset <= ’1’;
22
wait for 21 ns;
23
reset <= ’0’;
24
if ready /= ’1’ then
25
wait until ready = ’1’;
26
end if;
27
start <= ’1’;
28
wait for 20 ns;
29
start <= ’0’;
30
wait until done = ’1’;
31
wait;
32
end process;
33 end Behavioral;
