SLIDE 1

DIV 26000 AND HEAT TRACE FOR MECHANICAL SYSTEMS

ACE/ASM

SLIDE 2

DO’S AND DON’TS OF HEAT TRACE IN CHAPTER 149 FROM A DIV 26000 ELECTRICAL CONTRACTOR PROSPECTIVE

Do’s:

Give us a heat trace spec in DIV26
Give us a heat trace E drawing with

mechanical piping shown

Include details
Include a heat trace schedule
Include any pertinent design information

(size and material of pipe) Don’ts:

Double spec it with mechanical and

electrical

Bind us to a mechanical section
Make us look at mechanical drawings
Force us to make assumptions

SLIDE 3

THIS WAS DONE FOLLOWING ALL OF THE DO’S!

Now DIV26 knows exactly what is being heat traced and how to do it

SLIDE 4

DIV 26000 AND HEAT TRACE FOR MECHANICAL SYSTEMS

DO’S AND DON’TS OF HEAT TRACE IN CHAPTER 149 FROM A DIV 26000 ELECTRICAL CONTRACTOR PROSPECTIVE

THIS WAS DONE FOLLOWING ALL OF THE DO’S!

THIS IS A DON’T
