CENG 342 – Digital Systems

Simplified Floating-point Adder Larry Pyeatt

SDSM&T

Binary Floating Point Representation

Floating point number consists of three components: sign bit, exponent, and mantissa. Example: 12.75: sign is +, exponent is 102, and mantissa is .1275. Stored in a normalized representation, in binary: (−1)s × .m × 2e , where s and e represent the sign and exponent, and m is the mantissa. Floating-point adder for 13 bit format:

1 bit for sign, 4 bits for exponent, and 8 bits for mantissa.

Assumptions:

Both exponent and fraction are unsigned. Normalized representation: the MSB of the fraction must be 1. If the magnitude is smaller than 0.100000002 × 20, it needs to be converted to 0. Ignore the round-off error (lower bits will be discarded when shifted out)

Major steps

Sorting: find the bigger and smaller numbers Alignment: align two numbers so that they have the same exponent, if necessary, adjust the exponent of the smaller number Add/Subtract: perform addition when both have the same sign, otherwise perform subtraction Normalization: After a subtraction, the result may have leading zeros in front.

Count number of leading 0s (n), then shift fraction n bits, and adjust exponent by n.

If after a subtraction, the result is too small to be normalized, make both exponent and fraction 0. If after an addition, the result generates a carry out bit, shift mantissa to right 1 bit and increment exponent.

Examples in Decimal

Entity Declaration

Design uses a similar algorithm for decimal addition The suffixes ’b’, ’s’, ’a’, ’r’ and ’n’ are used in signal names represent big number, small number, aligned number, result of addition/subtraction and normalized number, respectively.

1 library ieee; 2 use ieee.std_logic_1164.all; 3 use ieee.numeric_std.all; 4 5 entity fp_adder is 6

port (

7

sign1, sign2: in std_logic;

8

exp1, exp2: in std_logic_vector(3 downto 0);

9

frac1, frac2: in std_logic_vector(7 downto 0);

10

sign_out: out std_logic;

11

exp_out: out std_logic_vector(3 downto 0);

12

frac_out: out std_logic_vector(7 downto 0)

13

);

14 end fp_adder ;

Architecture – Part 1

16 architecture arch of fp_adder is 17 -- suffix b, s, a, n for big, small, aligned, 18 -- normalized number 19

signal signb, signs: std_logic;

20

signal expb, exps, expn: unsigned(3 downto 0);

21

signal fracb, fracs, fraca, fracn: unsigned(7 downto 0);

22

signal sum_norm: unsigned(7 downto 0);

23

signal exp_diff: unsigned(3 downto 0);

24

signal sum: unsigned(8 downto 0); -- extra bit for carry-out

25

signal lead0: unsigned(2 downto 0);

26 begin 27

• - 1st stage: sort to find the larger

28

number

29

process (sign1, sign2, exp1, exp2, frac1,

30

frac2)

31

Exponent and fraction both need

32

begin

33

comparison, combine these two together

34

if (exp1 & frac1) > (exp2 & frac2) then

35

signb <= sign1;

36

signs <= sign2;

37

expb <= unsigned(exp1);

38

exps <= unsigned(exp2);

39

fracb <= unsigned(frac1);

40

fracs <= unsigned(frac2);

Architecture – Part 2

41

else

42

signb <= sign2;

43

signs <= sign1;

44

expb <= unsigned(exp2);

45

exps <= unsigned(exp1);

46

fracb <= unsigned(frac2);

47

fracs <= unsigned(frac1);

48

end if;

49

end process;

50 51

• - 2nd stage: align smaller number

52

exp_diff <= expb - exps;

53

• -with exp_diff select

54

lefraca <=

55

fracs when "0000",

56

"0" & fracs(7 downto 1) when "0001",

57

"00" & fracs(7 downto 2) when "0010",

58

"000" & fracs(7 downto 3) when "0011",

59

"0000" & fracs(7 downto 4) when "0100",

60

"00000" & fracs(7 downto 5) when "0101",

61

"000000" & fracs(7 downto 6) when "0110",

62

"0000000" & fracs(7) when"0111",

63

"00000000" when others;

64 65

• - 3rd stage: add/substract

66

sum <= (’0’ & fracb) + (’0’ & fraca) when

67

signb=signs else

68

(’0’ & fracb) - (’0’ & fraca);

Architecture – Part 3

70

• - 4th stage: normalize

71

• - 4a - count leading 0s

72

lead0 <= "000" when (sum(7)=’1’) else

73

"001" when (sum(6)=’1’) else

74

"010" when (sum(5)=’1’) else

75

"011" when (sum(4)=’1’) else

76

"100" when (sum(3)=’1’) else

77

"101" when (sum(2)=’1’) else

78

"110" when (sum(1)=’1’) else

79

"111";

80 81

• - 4b - shift significand according to leading 0

82

with lead0 select

83

sum_norm <=

84

sum(7 downto 0)

85

when "000",

86

sum(6 downto 0) & ’0’

87

when "001",

88

sum(5 downto 0) & "00"

89

when "010",

90

sum(4 downto 0) & "000" when "011",

91

sum(3 downto 0) & "0000" when "100",

92

sum(2 downto 0) & "00000" when "101",

93

sum(1 downto 0) & "000000" when "110",

94

sum(0) & "0000000" when others;

Architecture – Part 4

96

• - 4c - special conditions

97

process(sum,sum_norm,expb,lead0)

98

begin

99

if sum(8)=’1’ then -- w/ carry out; shift frac to right

100

expn <= expb + 1;

101

fracn <= sum(8 downto 1);

102

elsif (lead0 > expb) then -- too small to normalize;

103

expn <= (others=>’0’); -- set to 0

104

fracn <= (others=>’0’);

105

else

106

expn <= expb - lead0;

107

fracn <= sum_norm;

108

end if;

109

end process;

110 111

• - form output:

112

sign_out <= signb;

113

exp_out <= std_logic_vector(expn);

114

frac_out <= std_logic_vector(fracn);

115 end arch;

Testing Circuit – Part 1

The floating-point adder needs 13-bit operands. For two inputs, it needs 26-bit in total. The S3 board cannot provide enough physical inputs to test the circuit. We must assign constants or duplicated switch signals to the adder’s inputs. The addition result is passed to hexadecimal decoders and results are shown on the 7-segment LEDs.

Exponent (4-bit) is displayed on the rightmost LED LSB of mantissa (4-bit) is displayed on the left of the exponent. MSB (4-bit) is displayed to the left of the LSB. The“sign” is displayed on the leftmost LED

1 library ieee; 2 use ieee.std_logic_1164.all; 3 use ieee.numeric_std.all; 4 5 entity fp_adder_test is 6

port(

7

clk: in std_logic; -- will be used in 7-seg LED display time-multiplexing module

8

sw: in std_logic_vector(7 downto 0);

9

btn: in std_logic_vector(3 downto 0);

10

an: out std_logic_vector(3 downto 0);

11

sseg: out std_logic_vector(7 downto 0)

12

);

13 end fp_adder_test;

Testing Circuit – Part 2

14 15 architecture arch of fp_adder_test is 16

signal sign1, sign2: std_logic;

17

signal exp1, exp2: std_logic_vector(3 downto 0);

18

signal frac1, frac2: std_logic_vector(7 downto 0);

19

signal sign_out: std_logic;

20

signal exp_out: std_logic_vector(3 downto 0);

21

signal frac_out: std_logic_vector(7 downto 0);

22

signal led3, led2, led1, led0: std_logic_vector(7 downto 0);

23 24 begin 25

• - set up the fp adder input signals

26

sign1 <= ’0’;

27

exp1 <= "1000";

28

frac1<= ’1’ & sw(1) & sw(0) & "10101";

29

sign2 <= sw(7);

30

exp2 <= btn;

31

frac2 <= ’1’ & sw(6 downto 0);

32

• - instantiate fp adder

33

fp_add_unit: entity work.fp_adder

34

port map(

35

sign1=>sign1, sign2=>sign2, exp1=>exp1, exp2=>exp2,

36

frac1=>frac1, frac2=>frac2,

37

sign_out=>sign_out, exp_out=>exp_out,

38

frac_out=>frac_out

39

);

Testing Circuit – Part 3

40

• - instantiate three instances of hex decoders

41

• - exponent is shown on the rightmost LED

42

sseg_unit_0: entity work.hex_to_sseg

43

port map(hex=>exp_out, dp=>’0’, sseg=>led0);

44

• - 4 LSBs of fraction

45

sseg_unit_1: entity work.hex_to_sseg

46

port map(hex=>frac_out(3 downto 0),

47

dp=>’1’, sseg=>led1);

48

• - 4 MSBs of fraction

49

sseg_unit_2: entity work.hex_to_sseg

50

port map(hex=>frac_out(7 downto 4),

51

dp=>’0’, sseg=>led2);

52

• - sign

53

led3 <= "11111110" when sign_out=’1’ else -- middle bar

54

"11111111";

• - blank

55

• - instantiate 7-seg LED display time-multiplexing module

56

disp_unit: entity work.disp_mux

57

port map(

58

clk=>clk, reset=>’0’,

59

in0=>led0, in1=>led1, in2=>led2, in3=>led3,

60

an=>an, sseg=>sseg

61

);

62 end arch;
