SLIDE 1
www.fugro.com 2
60
Mapping the World
years
We are an all-terrain mapping provider.
We are Fugro 60 years Mapping the World We are an all-terrain - - PowerPoint PPT Presentation
We are Fugro 60 years Mapping the World We are an all-terrain - - PowerPoint PPT Presentation
We are Fugro 60 years Mapping the World We are an all-terrain mapping provider. 2 www.fugro.com Texas Coastal Lidar Project Delivering high-resolution lidar elevation data surrounding Houston and the coast to Bay City, covering
SLIDE 2
SLIDE 3
www.fugro.com 3
Delivering high-resolution lidar elevation data surrounding Houston and the coast to Bay City, covering approximately 10,000 sq. miles.
Texas Coastal Lidar Project
Floodplain management and planning Feature extraction Water quality modeling Stream restoration potential analysis Change detection Emergency management services
APPLICATION
SLIDE 4
www.fugro.com 4
Fugro USA Land, Inc. (FUSALI) Harris County Flood Control District (HCFCD) Houston Galveston Area Council (HGAC) Texas Natural Resource Information Systems (TNRIS) United States Geological Survey (USGS)
Texas Coastal Lidar Project
Participants
SLIDE 5
www.fugro.com 5
HGAC project was developed prior to Hurricane Harvey, although since Harvey the need for high-resolution lidar has increased Data will be used for post-storm studies and restoration
The Coastal Project
SLIDE 6
www.fugro.com 6
SLIDE 7
www.fugro.com 7
SLIDE 8
www.fugro.com 8
981 Flight Lines 30,831 Flight Line Miles (not including turns) 1.238 trips around the earth at the equator 4 Aircraft 3 Months 13 Production Blocks 227 Ground Control Points
Texas Coastal Lidar Project
SLIDE 9
www.fugro.com 9
Texas Coastal Lidar Project
Challenging flight operations within one of the busiest airspaces in the country: Houston Area A Houston Area B Houston Area C Houston Area D Jump Area: PTX027 College Station PTX012 Eagle Lake PTX014 Hobby PTX013 Navasota Houston, Ellington AFB Restricted Airspace Matagorda, R6320 Multiple Balloon and Tower Obstructions
SLIDE 10
www.fugro.com 10
Added Flight Lines: Building Shadowing Elevated Bridge Decks
Texas Coastal Lidar Project
SLIDE 11
www.fugro.com 11
Building shadow calculations determined prior to flight for better acquisition results
Texas Coastal Lidar Project
SLIDE 12
www.fugro.com 12
Additional flight lines within urban area for better results surrounding tall buildings
Texas Coastal Lidar Project
SLIDE 13
www.fugro.com 13
2018
Today Dec 2018 Feb Mar Apr May Jun Jul Aug Sep Oct Nov
Phase 1 Deliverables
12/28/2017
Phase 2 Deliverables
3/19/2018
Phase 3 Deliverables
9/24/2018
Phase 4 Deliverables
11/26/2018 1/3/2018 3/22/2018
Data Acquisition
1/15/2018 3/29/2018
GPS IMU Processing
2/26/2018 4/23/2018
Boresight
3/26/2018 9/10/2018
Point Classification
6/18/2018
Intensity Image Production
7/16/2018 3/26/2018 8/13/2018
Hydro Breaklines
10/22/2018
Bare Earth DEM
11/19/2018 11/19/2018
Metadata
11/22/2018
TNRIS Acceptance 12/14/2018 HCFCD Re-project 2/28/2019
Project Schedule
SLIDE 14
www.fugro.com 14
Project Schedule Flight Plan Sensor Calibration Reports Flight Trajectories Survey Report All-return Classified Point Cloud Hydro-flattened Breaklines Intensity Images Hydro-flattened Bare Earth Raster DEM Metadata 3rd Party QAQC Report QAQC Checkpoint Survey
Deliverables
SLIDE 15
www.fugro.com 15
Point Cloud
“Every lidar point that is post- processed can have a classification that defines the type of object that has reflected the laser pulse. Lidar points can be classified into a number of categories including bare earth or ground, top of canopy, and
- water. The different classes
are defined using numeric integer codes in the LAS files.” … arcgis.com
Products
SLIDE 16
www.fugro.com 16
Fugro acquired 4ppsm lidar
- ver San Antonio in 2017
Lidar classified point cloud for vegetation cover raster products Lidar classified point cloud for 1-foot contours
Product Use Case: San Antonio River Authority
SLIDE 17
www.fugro.com 17
Hydro-flattened Artificially flattening the water surface within hydro break line data to represent hydro features and proper flow direction Hydro-enforced Used for hydraulic and hydrologic modeling where
- bjects (culverts, bridges,
etc.) are cut away to remove artificial pooling
Products
SLIDE 18
www.fugro.com 18
New 2018 lidar data collection over Houston Galveston Area for up-to- date map of changed rivers, streams, ponds, lakes and shoreline
Product Use Case: USGS
SLIDE 19
www.fugro.com 19
Intensity “The return strength of the laser pulse that generated the lidar point.” … arcgis.com
Products
SLIDE 20
www.fugro.com 20
2017 lidar data collection
- ver Austin Area
Horizontal accuracy Feature extraction
Product Use Case: TNRIS Central Texas
SLIDE 21
www.fugro.com 21
Digital Elevation Model (DEM) Bare earth DEM used to represent the ground free of vegetation, buildings, and
- ther non-ground objects
Products
SLIDE 22
www.fugro.com 22
Following Hurricane Harvey, Ft Bend County compared Fugro’s 2014 lidar to the 2017 lidar to show areas where the bare earth had changed and impacted water quality along the canal
Product Use Case: Fort Bend County Drainage District
SLIDE 23
www.fugro.com 23
Comparing 2014 4ppsm Lidar to 2018 4ppsm lidar
Bare Earth Change Detection
SLIDE 24
www.fugro.com 24
Showing areas of ground change along the canal.
Bare Earth Change Detection
SLIDE 25
www.fugro.com 25
Showing areas of ground change along canal supported by 1-foot contours
Bare Earth Change Detection
SLIDE 26
SLIDE 27
SLIDE 28
SLIDE 29
SLIDE 30
SLIDE 31
www.fugro.com 31
Contours from Lidar 1-foot contours using lidar data with a better-than 10cm vertical accuracy RMSE Added breakline collection for: Single-line streams Barriers Walls
Value Added Products and Services
SLIDE 32
www.fugro.com 32
Building Footprints from Lidar Automated vs. Manual Enhanced Point Classification Edited Building Footprints Added 3D Attributes: HAG LAG Building Height (highest points – ground)
Value Added Products and Services
SLIDE 33
www.fugro.com 33
Enhanced Point Classification Additional time to manually clean the lidar point cloud to include added features like: Utility data Roads Buildings Vegetation Hydro Specifications
Value Added Products and Services
SLIDE 34
www.fugro.com 34
Rooftop Solar Potential Building roof analysis for solar potential to include vegetation and feature obstruction
Value Added Products and Services
SLIDE 35
www.fugro.com 35
FugroViewer Download Fugro’s free lidar viewer at: www.fugroviewer.com
Value Added Products and Services
SLIDE 36
www.fugro.com 36
Annual updates to the City’s GIS data including impervious surface layers for proper storm water
- management. The effort supports
accurate fee calculations and minimizes disputes.
Other Texas Drainage Projects: City of Austin Planimetric Update
SLIDE 37
www.fugro.com 37
10,400 square miles for: CAPCOG City of Austin City of Bee Cave City of Burnett City of Marble Falls City of Pflugerville City of Round Rock City of Waco City of West Lake Hills Hays County McLennan County McLennan County 9-1-1
Other Texas Projects: TNRIS/CAPCOG 4-band Imagery
SLIDE 38
www.fugro.com 38
USGS Lidar @ 2ppsm Matagorda Bay @ 4ppsm CAPCOG Orthoimagery Brazos County Orthoimagery Imagery at 6-inch and 12-inch Resolutions delivered as 4-band Tiff and JPG2000 formats
2019 Projects in Texas
SLIDE 39
www.fugro.com 39
AOI A – 6-inch 1,452 DO4Qs AOI A – 12-inch 7,633 DO4Qs AOI B – 6-inch 957 DO4Qs (Brazos)
2019 Orthoimagery AOI For Capital Area TX
SLIDE 40
www.fugro.com 40
Keith Owens k.owens@fugro.com www.fugro.com/geospatial Direct: (775) 287-2661
Ask Me What You Want to Know
SLIDE 41
We are Fugro
Proud to provide geo-intelligence and asset integrity solutions to contribute to a safe, liveable world.
