ETL Systems RSCC Dubna July 2015 Global Leaders in Satellite RF Engineering & Custom Build ROUTE AMPLIFY SPLIT SWITCH Heritage Custom Build & Design Specialist RF equipment for 25 years 80% International Sales

slide-1
SLIDE 1

ROUTE AMPLIFY SPLIT SWITCH

ETL Systems

Global Leaders in Satellite RF Engineering & Custom Build

RSCC Dubna– July 2015

slide-2
SLIDE 2

ROUTE AMPLIFY SPLIT SWITCH

Heritage Custom Build & Design

ROUTE AMPLIFY SPLIT SWITCH

  • Specialist RF equipment for 25 years
  • 80% International Sales
  • 95 staff in 3 global offices (UK, US, ME)
  • Cover R&D, Production & Test
slide-3
SLIDE 3

ROUTE AMPLIFY SPLIT SWITCH ROUTE AMPLIFY SPLIT SWITCH

ETL facilities in UK, US & Dubai: global sales

  • We ship to 97 countries, and have a team of experts handling

your equipment through customs and shipping

slide-4
SLIDE 4

ROUTE AMPLIFY SPLIT SWITCH

The challenge:

ROUTE AMPLIFY SPLIT SWITCH

  • More and more space crafts orbiting the earth
  • Bigger and more teleports with many different sizes and

designs of antennas

slide-5
SLIDE 5

ROUTE AMPLIFY SPLIT SWITCH

Importance of Signal Handling

ROUTE AMPLIFY SPLIT SWITCH

  • GEO orbiting satellites well exceed 420 (currently 403)
  • Increasing traffic density, as well as capacity means

broader IF bands (E.G HTS Satellites)

  • Antennas designed to handle multiple RF links of different

frequencies; Ka, Ku and C-bands

slide-6
SLIDE 6

ROUTE AMPLIFY SPLIT SWITCH

The top satcoms users choose ETL

10% Telecoms

40% Broadcast

10% Satellite Operators

40% Government & Defence

slide-7
SLIDE 7

ROUTE AMPLIFY SPLIT SWITCH

ETL in the RF chain

ROUTE AMPLIFY SPLIT SWITCH

Components and power supplies

slide-8
SLIDE 8

ROUTE AMPLIFY SPLIT SWITCH

Received signal transport and distribution

ROUTE AMPLIFY SPLIT SWITCH

Splitting and distribution Fibre Connectivity to distribution matrix

slide-9
SLIDE 9

ROUTE AMPLIFY SPLIT SWITCH

Signal handling and retransmission

ROUTE AMPLIFY SPLIT SWITCH

Amplification, Monitoring and Combining

slide-10
SLIDE 10

ROUTE AMPLIFY SPLIT SWITCH

Helping to deliver the service!

ROUTE AMPLIFY SPLIT SWITCH

slide-11
SLIDE 11

ROUTE AMPLIFY SPLIT SWITCH

Helping to deliver the service!

ROUTE AMPLIFY SPLIT SWITCH

slide-12
SLIDE 12

ROUTE AMPLIFY SPLIT SWITCH

ETL products

LNB Redundancy Switches Power Supplies LNB & DC PSUs Fibre Optic Links Amplifiers Fixed, variable, AGC Splitters Active & passive Switch Matrix / Router IF to SHF Switches Carrier monitoring & redundancy Hybrid modular chassis system Redundancy switch, amplifiers, combiners & splitters Hybrid Splitter / Combiner Active & passive Fibre Optic Links Amplifiers n+1, redundant & variable gain Combiners Active & passive Switch Matrix / Router IF to SHF Modem Redundancy Switches IRD / Modem Encoder / Modem

DOWNLINK UPLINK

Components

slide-13
SLIDE 13

ROUTE AMPLIFY SPLIT SWITCH

What’s new – RF over Fibre

Excelling in RF Engineering

slide-14
SLIDE 14

What’s new – RF over Fibre 1000 links sold this year

Vortex

slide-15
SLIDE 15

ROUTE AMPLIFY SPLIT SWITCH

Cable

About our Stingray Fibre solution

ROUTE AMPLIFY SPLIT SWITCH

  • 40 to +60 Deg heating

10MHz sync LNB Power Fibre

slide-16
SLIDE 16

ROUTE AMPLIFY SPLIT SWITCH

StingRay- RF over Fibre: 100 series

  • Ultra compact design
  • High isolation
  • Hot-swap
  • Wide dynamic range and output MGC

Benefits & Basics

  • L-band (850-2450 MHz), broadband (50-2450MHz) and 10 MHz modules
  • Up to 16 RX or TX modules in a 1U hot-swap chassis for high capacity

applications, with optional LNB power

  • Part populate and / or mix TX and RX modules for downlink and uplink

with VSAT or small number of terminals

  • High Isolation between modules and good RF performance
  • Front panel local control and ethernet remote control
  • Automatic link optimisation
slide-17
SLIDE 17

ROUTE AMPLIFY SPLIT SWITCH

StingRay- RF over Fibre: 200 series

  • Single TX or RX modules with monitor ports
  • Dual TX, Dual RX & hybrid TXRX modules
  • Hot-swap of PSU’s, CPU, fans, fibre modules
  • 1+1 redundancy system (in chassis)
  • 10 MHz modules and injection ports

Benefits & Basics

  • L-band (850-2450 MHz), broadband (50-2450MHz) and 10 MHz

modules

  • Up to 16 single or dual RX or TX modules in a 2U hot-swap chassis

for high capacity applications (so up to 32 links per 2U chassis)

  • Can be mixed with 100 series modules
  • Broadband modules available
  • Monitor ports on modules
  • Automatic link optimisation
slide-18
SLIDE 18

ROUTE AMPLIFY SPLIT SWITCH ROUTE AMPLIFY SPLIT SWITCH

StingRay- 200 series ODU

  • IP65 Out Doors Unit for mounting by antenna
  • Up to 10 x 200 Series TX/RX modules
  • 20 to +60 ºC operation
  • -40 to 60 ºC operation with heater
  • Internal optical and RF patch panels
  • Ethernet over fibre option
  • Removable base panel for connectors
  • Dual redundant hot swap PSU
  • Single hot swap CPU
  • LNB powering
  • 10 MHz modules / injection
  • 1+1 & 4+1 redundant options
slide-19
SLIDE 19

ROUTE AMPLIFY SPLIT SWITCH ROUTE AMPLIFY SPLIT SWITCH

StingRay- RF over Fibre: ODU

  • IP65 ODU
  • Capacity up to 10 modules (200 series)
  • Hot-swap

Hot Swap CPU Short patch cables Dual redundant power supplies Optional local control module Hot swap fan trays Ethernet over fibre Monitor and control

slide-20
SLIDE 20

ROUTE AMPLIFY SPLIT SWITCH

Stingray Fly-Away cases

  • For SNG or tactical satcoms in

hostile regions, rapid deployment ruggedised solution..

Local control

settings controlled by DIP switch for operation without a control module

Compact enclosure

Ruggedised, IP65-rated enclosure comprising up to 4, single, field-replaceable RX or TX fibre modules

Resilience

from dual redundant field- serviceable power supplies

Simple interface

Single Neutrik OpticalCON Quad fibre interface for interface with 4 single mode fibres in a single cable

LNB powering

13/18V LNB powering & 22KHz tone (provided on TX modules)

BUC powering

18V BUC powering (provided

  • n RX modules)

Portable

Fitted with heavy-duty injection moulded carrying handles

slide-21
SLIDE 21

Custom outdoor fibre cabinet

The brief: A Major contractor required 104 x RF

  • ver Fibre Links for an antenna array. ETL

supplied StingRay 200 Series fibre chassis with redundant 10MHz distribution housed in a environmentally controlled 42U custom outdoor cabinet.

slide-22
SLIDE 22

CBC Fibre installation

ETL solution & roles:

  • 9 ODU enclosures, with total of 47

200 series TX modules, control panel and cables / fibre management.

  • 2 x 2U Stingray fibre chassis with total

24 dual RX fibre modules. Each chassis has local and remote control, and full hot swap.

  • Customer particularly like the

ODU202 enclosure with remote control monitoring and communications (indoor functionality but in an ODU). Heater included.

  • Ethernet over fibre may be added

later.

The brief: CBC wanted to connect via fibre 13 antennas from their Toronto broadcast centre, with minimum number of ODU’s. LNB powering required.

  • 35 to +40 deg C. Ethernet monitoring via fibre (ability). Total 47 links.

ODU202 – click for link

slide-23
SLIDE 23

Redundant Fibre installation

ETL solution & roles:

  • ETL’s Scorpion passive 2 way splitters are at the front end of each system.

1U chassis holding 4 x 2-ways.

  • Stingray 1U chassis – each populated with 4 x RX OR TX modules. Total 6

chassis to give redundancy.

  • 26128 modular system chassis with 2x1 redundancy switches with auto-

switchover (total 3 chassis with 4 cards in each).

The brief: Etisalat needed 12x 1+1 redundant fibre links for downlink and uplink for some new antennas in Jebel Ali. Requirements included ability to disable (fix) AGC on the uplink & redundant fibre chassis for added resilience.

slide-24
SLIDE 24

ROUTE AMPLIFY SPLIT SWITCH

Case Studies & applications

Excelling in RF Engineering

slide-25
SLIDE 25

ROUTE AMPLIFY SPLIT SWITCH

Case Study

The brief: Upgrading and expanding L-band switch matrices and need 64x384 with specific RF performance; compact space and simple cable installation

Vulcan based 64x384 system in comfortable 3 racks ETL solution & roles:

  • Rack layouts and cabling agreed,

with particular regard to concerns

  • ver total cabling requirements to

modems and antennas

  • Customisation: cable management

and termination panels (standard RF performance)

  • Supply of complete system from

termination panel in to termination panel out.

  • Supply and integration into racks.
slide-26
SLIDE 26

ROUTE AMPLIFY SPLIT SWITCH

Formula 1 - Case Study

ROUTE AMPLIFY SPLIT SWITCH

slide-27
SLIDE 27

ROUTE AMPLIFY SPLIT SWITCH

Case Study 3-Enigma RF Matrix for F1

  • 32x32 matrix (expandable)
  • Fan-out, fan-in, and FIFO options
  • high resilience applications; custom

requirements & asymmetric systems (n>>m)

  • NEW: NGM-40: 1200-3000 MHz and vari gain;

NGM-34: excellent RF specs to 2450 MHz for Ka-band; NGM-35 low noise variant

ROUTE AMPLIFY SPLIT SWITCH Benefits & basics:

  • IF, wideband ,L-band & XL-band options
  • 1 RF card for each RF input & output adding resilience
  • Hot swap of all active components
  • Dual redundant CPU’s & PSU’S
  • On board monitoring & diagnostics
slide-28
SLIDE 28

ROUTE AMPLIFY SPLIT SWITCH

Formula 1 Case Study

ROUTE AMPLIFY SPLIT SWITCH

slide-29
SLIDE 29

ROUTE AMPLIFY SPLIT SWITCH

RF L-band matrix with dual input receivers

ROUTE AMPLIFY SPLIT SWITCH

A1M A1B A2M A2B A3M A3B

CAM 1 RX CAM 3 RX CAM 2 RX

CAM 1 CAM 2

Matrix Size Calculation

  • No of Camera’s = No of Diversity Receivers
  • 1 Receiver per camera
  • 2 matrix outputs per camera
  • 2 Matrix inputs per antenna
  • For 18 antenna sites = 36 antenna’s = 36 matrix inputs
  • For 20 camera’s there are 40 receiver inputs = 40

matrix outputs

slide-30
SLIDE 30

ROUTE AMPLIFY SPLIT SWITCH ROUTE AMPLIFY SPLIT SWITCH

Routing Your Satellite Signal – some examples

slide-31
SLIDE 31

ROUTE AMPLIFY SPLIT SWITCH ROUTE AMPLIFY SPLIT SWITCH

Routing Your Satellite Signal – Old vs New

slide-32
SLIDE 32

ROUTE AMPLIFY SPLIT SWITCH

Спасибо!
