Purple Line Extension Section 1 Community Meeting October 18, 2018 1 Agenda Section 1 Art Program Update MOW 64 Facility Project Construction Updates: Project-wide Tunneling Wilshire/Western Wilshire/La Brea
Section 1 Community Meeting October 18, 2018
1
Section 1
2
Oct ctober 1 18, 8, 201 2018
Enhance the customer experience Connect people, sites & neighborhoods through site-specific artworks Provide opportunities for a range of emerging, mid-career & established contemporary artists Contribute to LA County’s artistic vibrancy & cultural legacy through a diverse program of temporary & permanent artworks Commission durable, maintainable artworks that strengthen neighborhood pride
"Arrival is everything” “Create an art 'environment’…a holistic approach” "Transform the entire space" “Sophisticated design” “Elevate the conversation” "World class, well established artists” “Let the artist surprise us”
“Art & architecture to work together” “Bright colors” “Encouraging and inspirational quotes” “Movies and music" “Natural history” “Kids collaboration art enrichment programs” “Love and hope” “Relax and breathe reminders”
MUNGO T THOMSON Nega gative S Spa pace Yal aletown wn- Round ndhou
Station
uver er
PASCAL L DOMBI BIS & GIL P L PERCAL Irra rrational Geo Geometri rics Pert erth, Aus Australia
JOHN BALDE LDESSARI READ AD/WR WRITE/T /THINK/DREAM AM Stuart C Coll llection,
CATHERINE WIDGERY Arbor bor W Winds ds Ann n Arbor bor, MI MI
ERWIN REDL DL Inside Out ut - Out utsid ide In - Inside Out ut Expo/Crenshaw Sta tati tion, Me Metr tro LA LA
10/15/2018 15
10/15/2018 16
SAR ARAH S SZE ZE Blueprint nt f for a Lands ndscape 96 96th
th Str
treet S Sta tati tion, NY MT MTA
10/15/2018 17
DA DANIEL BU BUREN The Big Wall, l, U Up and d Down, D Diamonds
les, Black and d White te To Tottenham Court Road S d Station
ndon
10/15/2018 18
ANNE LINDBE DBERG Curt urtain Wall Rich chard Bolling Federal Buildi ding ng, Kansas, G GSA
SOL LEWIT Whirls and Twirls (MTA) 59th Street-Columbus Circle, NY MTA
NOBU BUHO NAGASAWA Landi nding ngs Soto to Sta tati tion, Me Metr tro, LA LA
DOUG & MIKE KE STAR ARN Se See it split, see it ch change Sout uth Ferry erry Station,
MTA
VI VICK K MUNIZ Perfec ect S Strangers ers Second
treet S Sta tati tion, NY MT MTA
SH SHIN INIQUE SM SMIT ITH Mage gesti stic Heigh ghts ts Mart rtin in Lut uther Kin King J
tati tion, Me Metr tro, LA LA
ROY LICHEN ENSTEI EIN Tim imes es Squa uare M Mura ural Times Square Sta tati tion, NY MT MTA
JENNY LYNN Drea reams in in Tra ransit 9th
th Stree
reet S Station, N New ew J Jers ersey T Tra ransit it
FRAN ANZ AKE AKERMAN The e Great Journ rney ey Georg rg Bra rauc uchle Ring ng S Station,
ahn, DE
30
GEORGE LEGRAD ADY Kinetic Fl Flow Vermont
Santa Moni nica Station
Metr tro, LA LA
DEANNA ERDMA DMANN Unti titl tled Leimert ert Park S Station
Metr tro, LA LA
– Craft and Folk Art Museum – Original Farmers’ Market – Beverly Hills Farmer’s Market
Gretchen Baker, Natural History Museum of Los Angeles County Doris Berger, Museum of the Academy of Motion Picture Sciences Heeseon Choi, Korean Cultural Center Harry Gamboa Jr., Artist Rita Gonzalez, Los Angeles County Museum of Art Suzanne Isken, Craft and Folk Museum Naima J. Keith, California African American Museum Stephanie Vahn, Beverly Hills Arts Commissioner
Project Alignment
3
4 *Subject to change. The PLE project team is working to deliver the project consistent with Measure M
Forecasted Schedule Section
Section 1 Section 2 Section 3
Length
3.92 Miles 2.59 Miles 2.56 Miles
New Stations
Wilshire/La Brea Wilshire/Fairfax Wilshire/La Cienega Wilshire/Rodeo Century City/ Constellation Westwood/UCLA Westwood/VA Hospital
Pre-Construction Activities
2014 – 2015 2016 – 2018 2018 – 2020
Construction
2015 – 2023 2018 – 2025 2019 – 2026
Operations
2023 2025 2026
Section 1 Alignment
5
Section 1 Schedule
6 *As of October 2018, subject to change
7
Maintenance nance Facili lity ty
Curr rrent nt Work k
continues
8
Installing window frames
9
The second floor houses
conference rooms
10
TBM machines ready to head east from Wilshire/La Brea
Elsie and Soyeon are tunneling!
TBMS in tunneling position
11
Assembling tunnel boring machine cradles
Schedule
12 *As of October 2018, subject to change
Upcoming Work
13
Construction activities between Wilshire Bl/Manhattan Pl and Wilshire Bl/Western Av behind work zone:
Work zone will be in place until January 2019
Location of construction on Wilshire Bl at Western Av, instrumentation and dewatering work will intermittently extend onto Manhattan Pl
Work Zone
14
Work Zone at Wilshire/Western looking southwest
Excavation
15
A look down into the Wilshire/Western excavation shaft
16
17
Rendering shows length of the Wilshire/La Brea underground station box on Wilshire Bl from Orange Dr to Detroit St
Schedule
18 *As of October 2018, subject to change
Deliverie ies to Suppor
ing g
Brea staging yard (the property south of Wilshire Bl) will enter off
St
right turns only from the property to Wilshire Bl
day, Monday through Saturday
deliveries during tunneling (October 2018 to Fall 2020)
South La Brea Staging Yard Deliveries
19
Map shows ingress/egress plan for deliveries during tunneling
Deli liver veries es to Suppor port t Tunne neling ng
be used as an exit only
street sweeper truck and sweeping by hand, will be implemented
Detroit St will be restricted
2018
the yard 7am – 11pm
South La Brea Staging Yard Deliveries
Typical delivery vehicle View of Detroit St looking north
21
22
Rendering shows length of the Wilshire/Fairfax underground station box on Wilshire Bl from west of Fairfax Av to just west of Ogden Dr
*As of October 2018, subject to change 23
Excavation
24
View of the Fairfax muck shaft
Concrete and Rebar – Fall 2018/Winter 2019
Wilshire/Fairfax station is anticipated to start in November 2018
control on the south side of Wilshire Bl from Orange Grove Av to Ogden Dr
construction notices and briefings
capacity during nighttime hours for safety of workers and to continue excavation.
Concrete work shown from the street level at Wilshire/La Brea. Concrete is being pumped underground from the street level. Similar
work will be done at the Fairfax station
Tunnel Investigation, January 2019
26
Approximate work locations at Wilshire/Crescent Heights.
tunneling is anticipated at Wilshire Bl/Crescent Heights Bl beginning January 2019
reductions on Wilshire Bl
Wilshire Bl. and/or Crescent Heights Bl
pedestrian detours
Bus Pads and Water Crossings
Beginning October 2018, the design- builder, will restore bus pads and water crossings at the following locations:
The following traffic control will be in place:
reduced to one lane
Saturday mornings and will be removed
construction notices Example of bus pad on Wilshire Bl
28
29
Rendering shows length of the La Cienega underground station box on Wilshire Bl from La Cienega Bl to Tower Dr
*As of October 2018, subject to change 30
Construction Staging Yards
Typical Activities/Equipment:
yard use is permitted 24/7
compliance with MOA and FEIR requirements
31
Welding metal ladder in La Cienega muck shaft
Mitigation Measures
Recent nt Mitigations
Additiona
gated
32
Excavation
33
Installing ventilation in the center of the station
Instrumentation Work & Street Maintenance
When: : Octobe ber r 2018 Instrume ument ntation ion drilling ng on La Cienega ga Bl Bl at at Wilshire re Bl Bl
Bl anticipated during off-peak hours
Street Maintenanc nce on Wilshire re Bl Bl
peak hours (non-rush hour)
34
Example of instrumentation drilling
New Metro Bus Service locations:
re Bl Bl: :
Cienega Bl, in front of 8484 Wilshire
re Bl Bl: :
Dr, in front of 8370 Wilshire
d Wilshire re Bl Bl:
existing 20 stop at Willaman Dr
Bus Stop Update
35
Metro bus stop locations
und d Wilshire ire Bl Bl: :
Wilshire
front of 8501 Wilshire Bl.
B B B B B B
36
3790 Wilshire Bl Los Angeles, CA 90036 213.388.1400
The Wiltern
A fun, live music venue
8582 Wilshire Bl Beverly Hills, CA 90211 310.300.4004
Help lping g loca cal l bu busines esses ses as we bu build. Update te as o
f 10/1/18 /18
> Financial assistance to small “mom & pop” businesses with 25 or fewer employees directly impacted by Metro Rail construction along three project areas > Businesses must be located immediately adjacent to the rail corridor and meet other eligibility requirements > Grant amount determined by loss of business revenue related to period of construction disruption > To date, 748 grants have been awarded with a total value of more than $17.0 million along all three projects
> Purp rple le Lin ine Ext xten ensio sion, n, Secti tion
> BIF Grants Awarded: 177 > BIF Grant Amount Awarded: $4,444,161.83 > Number of small businesses awarded: 69 > BIF Business Advisor: Brian Lazo > Pacific Coast Regional Small Business Development Corporation (PCR) > Phone: 213.739.2999
> Purp rple le Lin ine Ext xten ensio sion, n, Secti tion
> BIF Grants Awarded: 18 > BIF Grant Amount Awarded: $510,778.16 > Number of small businesses awarded: 16 > BIF Business Advisor: Darrell Smith > Pacific Coast Regional Small Business Development Corporation (PCR) > Phone: 213.739.2999
42
Purp rple le Lin ine Ext xten ensio sion 24/7 Project Hotline - 213.922.6934 Email – purplelineext@metro.net On Metro ro Tra ransit See Something, Say Something 888.950.SAFE (7233) Constru ruct ction
fety y Aware renes ness s Pro rogr gram Glyssa Alcazar, Community Relations Officer Email: alcazarg@metro.net Phone: 323.900.2192 Cit ity of f Beve verl rly y Hil ills PurpleLine@beverlyhills.org Public Works Customer Service: 310.285.2467
43
Beverly Hills
44
Section 1
45
