Exponential increase of scientific interest in CRISPR-Cas9 iGEM Projects PubMed Entries per 100 000 2 Cas as9 Protein cleaves DNA Target DNA PAM Sit ite allows sg sgRNA binds target DNA Cas9 binding 3 I was standing there with some

slide-1
SLIDE 1
slide-2
SLIDE 2

Exponential increase of scientific interest in CRISPR-Cas9 PubMed Entries per 100 000 iGEM Projects

2

slide-3
SLIDE 3

Target DNA Cas as9 Protein cleaves DNA sg sgRNA binds target DNA PAM Sit ite allows Cas9 binding

3

slide-4
SLIDE 4

“I was standing there with some biologists... and they started to lose their s---, like genuinely lose their s---, about this thing called CRISPR.”

Jad Abumrad, Radiolab, Antibodies Part 1: CRISPR

4

slide-5
SLIDE 5

sgRNA Efficiency Different sgRNA have difficult-to-predict biochemical efficiencies PAM Seq equence Only sgRNA target with an adjacent NGG PAM site can be chosen

5

slide-6
SLIDE 6

6

slide-7
SLIDE 7

Re-engineering sgRNA structure with restriction sites that allow target sequence exchange

7

slide-8
SLIDE 8

Re-engineering sgRNA structure with restriction sites that allow target sequence exchange Original sgRNA Modified sgRNA

8

Re-engineering sgRNA structure with restriction sites that allow target sequence exchange

slide-9
SLIDE 9

9

sgRNA Targeting Nucleotide Preference

Reproduced from Rational design of highly active sgRNAs for CRISPR-Cas9–mediated gene inactivation, Figure 3. Doench et al., 2014

sgRNA optimization still requires testing in the lab e.g. Wang et al. 2015

slide-10
SLIDE 10

10

Original sgRNA Modified sgRNA

sgRNA secondary structure modules determined by Briner et al. 2014

slide-11
SLIDE 11

11 +sgRNA +sgRNA

Original sgRNA: targeting RFP Modified sgRNA: targeting RFP Control: Used BBa-K1645999 without dCas9 Expect low RFP Expect low RFP Expect high RFP

slide-12
SLIDE 12

12

Original sgRNA Modified sgRNA Identical decrease in RFP expression with each sgRNA structure

slide-13
SLIDE 13

13

  • Designed a new sgRNA scaffold that

allows easy exchange of target sites

  • Verified that the scaffold does not

interfere with dCas9 binding and expression control

  • Foundation of a functional prototype,

next steps include full verification of exchange

slide-14
SLIDE 14

Overcoming NGG PAM limit on target selection through molecular dynamics models

14

slide-15
SLIDE 15

Found a 3D dCas9 structure (Nishimasu et al. 2014) Modeled using PyRosetta molecular dynamics software

15

Modeling background: 3D protein structure

slide-16
SLIDE 16

Suite of Python scripts to rank PAM specificity for Cas9 mutants

16

Mutate Cas9 structure Cluster and rank scores Generate 256 PAM variants AAAA AAAC AAAG AAAT ... TTTT Determine binding score 27.1 27.3

  • 10.1

27.8 ... 200.6

 

slide-17
SLIDE 17

Docking energy minimization as a measure of binding affinity

17

slide-18
SLIDE 18

Available data: Cas9 with altered PAM specificity

18

Ju June 2015: Empirical validation: Cas9 mutants that bind NGAG and NGA PAMs found by Kleinstiver et al. (Nature, 2015) using directed evolution

N G G N N G A G

slide-19
SLIDE 19

19

Wild-type NGAG Mutant

NGGN

Wild-type reproduces fairly well, mutant less so

NGNG

R = 0.4 .46 p = 1.1 .1e-14 14 R = 0.6 .66 p = 2.2 .2e-16 16

slide-20
SLIDE 20

Investigating binding profile of Kleinstiver mutant dCas9

20 TARGET

NGG

+ TARGET

NGAG

+

slide-21
SLIDE 21

5000 10000 15000 20000 25000 30000 35000 40000 45000 50000 NGG PAM Site NGAG PAM Site GFP Intensity

Mutant dCas9 does not produce expected binding profile

21

NGAG NGG

GFP Intensity

slide-22
SLIDE 22
  • Explored dCas9-DNA binding affinities in

silico

  • Created framework for testing sgRNAs

computationally

  • Results suggest more work and a

reassessment of assumptions

  • Framework & documentation

available online

22

slide-23
SLIDE 23

sgRNA Efficiency PAM Seq equence

Applications: gene editing gene drives expression control

23

slide-24
SLIDE 24

CRISPieR Application: engineered plants with CRISPR-Cas9 antiviral defense

24

slide-25
SLIDE 25

25

Model Plant: Arabidopsis thaliana Model Virus: Cauliflower Mosaic Virus (CaMV)

slide-26
SLIDE 26

How does CaMV affect plant cells?

26

CaMV Production without CRISPR Defense

slide-27
SLIDE 27
  • NetLogo models available on
  • Agent-based stochastic modeling
  • Incorporates intracellular ODEs via

Euler’s method

27

How does CaMV infection spread among plant cells?

slide-28
SLIDE 28

28

slide-29
SLIDE 29

Using protoplasts as a model

29

slide-30
SLIDE 30

Can we express our CRISPR-Cas9 defense system in plant cells?

30

Trial #1 Trial #2

slide-31
SLIDE 31

Mathematical models are not bound by the same constraints

31

slide-32
SLIDE 32

How does CRISPR-Cas9 deactivate viral genomes?

32

slide-33
SLIDE 33

33

Results for Plant Tissue

Results for Single Cell

slide-34
SLIDE 34

Could improved sgRNA efficiency or PAM flexibility aid defense?

34 CRISPR (t1/2 = 1.8h) CRISPieR (t1/2 = 0.9h)

slide-35
SLIDE 35

CRISPR Plant Defense

35

slide-36
SLIDE 36

36

CRISPR Plant Defense → CRISPieR Plant Defense

slide-37
SLIDE 37

37

slide-38
SLIDE 38

121 121 Person sample size 60 60 GMO surveys 61 61 Gene editing surveys

38

Do people respond differently to different wording?

Similar questions using the words:

GMO versus CRISPR-Cas9 Technology

Ran a survey at the university and a local farmer’s market

slide-39
SLIDE 39

39

Do people respond differently to different wording?

How do you feel about eating food with [GMO or CRISPR-Cas9] ingredients?

slide-40
SLIDE 40

40

Why do people oppose the sale of GM foods?

slide-41
SLIDE 41

41

slide-42
SLIDE 42

42

WOULD YOU SUPPORT SCIENTIFIC

RESEARCH INTO THE FIELD OF GM FOODS?

YES 96%

slide-43
SLIDE 43

CRISPieR Application

CRISPR Plant Defense

  • Cas9 expression in Arabidopsis

protoplasts

  • Viral models suggesting system will

work

  • Models also suggest CRISPieR will work

Gold Requirements

  • Additional Practices work (IP, business)
  • uOttawa, Aalto-Helsinki collaborations
  • Improved characterization of xylose

(BBa_K1323014 and BBa_K1323002)

43

CRISPieR

Simple sgRNA Exchange

  • Added restriction sites to sgRNA

scaffold

  • Showed modified scaffold didn’t

affect dCas9 activity

Cas9 PAM Flexibility

  • Python suite using PyRosetta
  • Correlated affinities for wild type
  • Inconclusive results for NGAG and

NGAN PAMs

  • Potentially due to different dCas9
slide-44
SLIDE 44

Elementary School High School University iGEM Academy Digest Calculator PyRosetta Suite + GitHub Commercialization iGEM Critique Floral Dip

44

slide-45
SLIDE 45
  • Dr. Marc Aucoin
  • Dr. Trevor Charles
  • Dr. Andrew Doxey
  • Dr. Barbara Moffatt
  • Dr. Brian Ingalls

Radmila Kovac Julia Manalil

  • Dr. Jiujun Cheng

Maya D’Alessio John Heil Kathy Lam

  • Dr. Simon Chuong
  • Dr. Susan Lolle
  • Dr. Pearl Chang

Cherry Chen Maye Saechao

  • Dr. Aiming Wang

Destin Sigurdson Jamie McNeil Lauren Kennedy Suzie Alexander Pavel Shmatnik Dragos Chiriac

45

slide-46
SLIDE 46

46

slide-47
SLIDE 47

1. Briner, A. E., et al., Guide RNA Functional Modules Direct Cas9 Activity and Orthogonality, Molecular Cell, vol. 56, no. 2, pp. 333-339 (Oct. 2014). 2. Kleinstiver, B. P., et al. Engineered CRISPR-Cas9 nucleases with altered PAM specificities. Nature, 523, pp. 481-485 (Jun. 2015). 3. Nishimasu, H. Crystal structure of Streptococcus pyogenes Cas9 in complex with guide RNA and target DNA. Cell, 156, pp. 935-949, (2014). 4. Doench, J. G., et al. Rational design of highly active sgRNAs for CRISPR- Cas9–mediated gene inactivation. Nature Biotechnology, 32, 12, pp. 1262–1267 (Sep. 2014). 5. Wang, X. et al. Efficient CRISPR/Cas9-mediated biallelic gene disruption and site-specific knockin after rapid selection of highly active sgRNAs in

  • pigs. Sci. Rep. 5, 13348; doi: 10.1038/srep13348 (2015).

47
