SLIDE 1

COLUMBIA COOPER iGEM 2011

Dot Dot Dot

Environmentally friendly manufacture

  • f quantum dots in E.coli

dot

columbia cooper iGEM

slide-2
SLIDE 2

COLUMBIA-COOPER iGEM 2011

COLUMBIA COOPER iGEM 2011

Dot Dot Dot

dot

columbia cooper iGEM

slide-3
SLIDE 3

OUR RESEARCH FACILITES THE COOPER UNION

dot

columbia cooper iGEM

slide-4
SLIDE 4

OUR RESEARCH FACILITES GENSPACE

dot

columbia cooper iGEM

slide-5
SLIDE 5

WHAT ARE QUANTUM DOTS?

dot

columbia cooper iGEM

slide-6
SLIDE 6

WHY QUANTUM DOTS ARE COOL

Fluorescent up to1000x brighter than GFP detection is unsophisticated Resistant to photo bleaching long lasting - can be shipped or used in live cells over time Narrow emission wavelength allows multiple colors - great for identification of many contaminants simultaneously Quantum Confinement applications may include qbits in quantum comupters dot

columbia cooper iGEM

slide-7
SLIDE 7

PROJECT GOALS

MAIN DIAGRAM

1

Engineer E.coli to nucleate quantum dots from heavy metal salts dot

columbia cooper iGEM

slide-8
SLIDE 8

MAIN DIAGRAM

2

Use antibiotic selection to tune system for specific colors

PROJECT GOALS

dot

columbia cooper iGEM

slide-9
SLIDE 9

CHEMICALLY SYNTHESIZED QUANTUM DOTS Served two purposes

  • Characterization of Blue Light Promoter
  • Control vs. biologically produced Quantum Dots

dot

columbia cooper iGEM

slide-10
SLIDE 10

CHEMICALLY SYNTHESIZED QUANTUM DOTS

dot

columbia cooper iGEM

slide-11
SLIDE 11

CHEMICALLY SYNTHESIZED QUANTUM DOTS

  • Cadmium
  • Selenium
  • tri-n octylphosphine
  • trioctylphoshine oxide
  • 1-octadecene
  • Reaction temperature: 225°C.

dot

columbia cooper iGEM

slide-12
SLIDE 12

CHEMICALLY SYNTHESIZED QUANTUM DOTS

dot

columbia cooper iGEM

slide-13
SLIDE 13

STANDARDS FOR BIODOTS

dot

columbia cooper iGEM

slide-14
SLIDE 14

CHARACTERIZATION VIA FLUORESCENCE SPECTROSCOPY

dot

columbia cooper iGEM

slide-15
SLIDE 15

dot

columbia cooper iGEM

slide-16
SLIDE 16

Low Energy Production Possibility for Self Assembly Greater Biocompatibility WHY BIOLOGICALLY MADE QDs ARE EVEN COOLER?

1 3 2 1 dot

columbia cooper iGEM

slide-17
SLIDE 17

BIOLOGICAL MECHANISM

Metallophilic peptides stabilize heavy metal wurtz- ite crystals

1 dot

columbia cooper iGEM

slide-18
SLIDE 18

BIOLOGICAL MECHANISM

Peptides Coat the Crystal

  • Stabilize the structure
  • Control dot size
  • Coat with biocompatible organic

material

1 2 dot

columbia cooper iGEM

slide-19
SLIDE 19

OUR EXPERIMENT OUTLINE

Express and characterize QD nucleating peptides Use blue QDs to activate blue light sensing promoter Use blue light sensing promoter to transcribe antibiotic resistance

1 3 2 1 dot

columbia cooper iGEM

slide-20
SLIDE 20

STRATEGY

CDS-7 (Cadmium Sulfide)

Biosynthesis and characterization of CdS quantum dots in genetically engineered Escherichia coli (2011)

Congcong Mi, Yanyan Wang, Jingpu Zhang, Huaiqing Huang, Linru Xu, Shuo Wang, Xuexun Fang , Jin Fang, Chuanbin Mao, Shukun Xu,

A7 (Zinc Sulfide) Z8 (Zinc Sulfide) J140 (Cadmium Sulfide)

Viral assembly of oriented quantum dot nanowires (2003)

Chuanbin Mao, Christine E. Flynn, Andrew Hayhurst, Rozamond Sweeney, Jifa Qi, George Georgiou, Brent Iverson, and Angela M. Belcher

dot

columbia cooper iGEM

slide-21
SLIDE 21

METHODS - CDS-7 N-GDVHHHGRHGAEHADI-C

  • Ordered from Invitrogen
  • Added Nco1 site (containing start codon)

and BamH1 site for ligation into pET28, flanked by biobrick ends.

dot

columbia cooper iGEM

slide-22
SLIDE 22

METHODS - OLIGO ANNEALING A7 - N-SLTPLTTSHLRS-C Z8 - N-VISNHAESSRRL-C J140 - N-TGCAACAACCCGATGCACCAGAACTGC-C

  • Tiny sequences of 70 bp or less. We

used oligo annealing with sticky ends for ligation into biobrick vector pSB1C3 A7 - N-SLTPLTTSHLRS-C Z8 - N-VISNHAESSRRL-C J140 - N-TGCAACAACCCGATGCACCAGAACTGC-C

  • Tiny sequences of 70 bp or less. We

used oligo annealing with sticky ends for ligation into biobrick vector pSB1C3 A7 - N-SLTPLTTSHLRS-C Z8 - N-VISNHAESSRRL-C J140 - N-TGCAACAACCCGATGCACCAGAACTGC-C

  • Tiny sequences of 70 bp or less. We

used oligo annealing with sticky ends for ligation into biobrick vector pSB1C3 A7 - N-SLTPLTTSHLRS-C Z8 - N-VISNHAESSRRL-C J140 - N-TGCAACAACCCGATGCACCAGAACTGC-C

  • Tiny sequences of 70 bp or less. We

used oligo annealing with sticky ends for ligation into biobrick vector pSB1C3

dot

columbia cooper iGEM

slide-23
SLIDE 23

METHODS - OLIGO ANNEALING

  • Used “Gene Synthesis

Optimization Program”,

  • riginally developed by

the 2006 iGEM team from Davidson College

  • Ordered 4 overlapping

primers which were then annealed

dot

columbia cooper iGEM

slide-24
SLIDE 24

METHODS - EXPRESSION CDS7 Did not appear on any gels, so we could not gel purify it. We assumed this could be size related and decided to design primers for PCR extraction instead. This was successful.

dot

columbia cooper iGEM

slide-25
SLIDE 25

METHODS - LIGATION AND EXPRESSION

CDS7 pET-28

METHODS - LIGATION AND EXPRESSION

dot

columbia cooper iGEM

slide-26
SLIDE 26

AND ZINC SULFIDE

dot

columbia cooper iGEM

slide-27
SLIDE 27

INCUBATION WITH CADMIUM CHLORIDE AND SODIUM SULFIDE

dot

columbia cooper iGEM

slide-28
SLIDE 28

2

Use antibiotic selection to tune system for specific colors

PART 2: THE BLUE LIGHT SENSOR

dot

columbia cooper iGEM

slide-29
SLIDE 29

NEGATIVE FEEDBACK INHIBITION YcgF/YcgE System

  • YcgF is sensitive to blue light
  • Release of YcgF/YcgE dimer allows

for transcription

dot

columbia cooper iGEM

slide-30
SLIDE 30

DIMERIZATION CAUSES RELEASE OF INHIBITOR

In the presence of blue light, chloramphenicol resistance is transcribed when YcgF/YcgE dimerizes and releases.

DIMERIZATION CAUSES RELEASE OF INHIBITOR

dot

columbia cooper iGEM

slide-31
SLIDE 31

...WHICH ACTIVATES ANTIBIOTIC RESISTANCE

dot

columbia cooper iGEM

slide-32
SLIDE 32

DESIGN OF BBa_K643001 Composite part

  • Blue Light Promoter Gene

From BBa_K238013, designed by K.U. Leuven in 2009

  • Chloramphenicol Resistance Gene

From BBa_P1004, designed by Knight Lab at MIT in 2006

dot

columbia cooper iGEM

slide-33
SLIDE 33

DESIGN OF BBa_K643001 Used psB1A3 instead of the psB1C3 backbone

  • Prevents redundant Chloramphenicol

resistance, which would have made the part impossible to characterize

dot

columbia cooper iGEM

slide-34
SLIDE 34

BLUE LIGHT BOX

dot

columbia cooper iGEM

slide-35
SLIDE 35

DESIGN OF BLUE LIGHT BOX

  • Dimensions 8X6x5 inches
  • Light tight
  • Interior lined with aluminum

foil

  • 72 blue LEDs (emitting at 472

nm)

dot

columbia cooper iGEM

slide-36
SLIDE 36

RESULTS - OD 600nm CONFIRMATION

dot

columbia cooper iGEM

slide-37
SLIDE 37

HUMAN PRACTICES: MAKER FAIRE

dot

columbia cooper iGEM

slide-38
SLIDE 38

dot

columbia cooper iGEM

slide-39
SLIDE 39

dot

columbia cooper iGEM

slide-40
SLIDE 40

Editor’s Choice

dot

columbia cooper iGEM

slide-41
SLIDE 41

WHY QDs ARE GREAT FOR IGEM

Can be easily combined with ligands to make composites. High color specificity within a wide

  • range. Good for multiple site tagging.

QDs don’t photobleach like fluorescent proteins.

1 3 2 1 3 2 1 dot

columbia cooper iGEM

slide-42
SLIDE 42

APPLICATIONS - Adding to the SynBio toolbox

dot

columbia cooper iGEM

slide-43
SLIDE 43

dot

columbia cooper iGEM

slide-44
SLIDE 44

dot

columbia cooper iGEM

slide-45
SLIDE 45

NEXT STEPS

  • Fully characterize all potential quantum dot nucleating peptides.
  • Test additional light-sensitive promoters to improve color sensitivity

tuning system

  • Test light-sensitive promoter system alongside quantum dot production
  • Conjugate QDs with antibodies (now producible in bacteria!) for one-

stop-shop tagging

  • Experiment with combining quantum dot production with other

biobrick systems and devices (like the biocircuit example)

dot

columbia cooper iGEM

slide-46
SLIDE 46

WE ARE GRATEFUL FOR YOUR SUPPORT!

Stanley Lapidus and Allan Kuchinsky

Our Moms and Dads
