Nine Dot Solutions

Consulting Mechanical Engineers

Pieter van Zyl

About Nine Dot

Nine Dot is a consulting engineering company that specialises in structural analysis and design Specialities include

• Structural audits and failure analyses by means of Finite Element Analysis
• Wireless engineering data measurements and data manipulation
• Bulk material structure refurbishments and capacity upgrades
• Detail designs and manufacturing data packs
• Conceptual layouts and order of magnitude calculations
• New product design and development

Structural and design auditing

• Structural audits to ISO, FEM, SANS or

Similar

• Failure investigations and root cause

analyses

• Capacity upgrades and refurbishment

procedures

• Stackers
• Reclaimers
• Shiploaders
• Spreaders
• Trippers
• Train loading stations
• Wagon tipplers
• Conveyor gantries
• Take-up towers
• General equipment

Wireless measurements

• Can measure the following:
• Stress/Strain
• Pressure
• Measurements can be taken for

evaluation or continuous monitoring purposes

Refurbishments, capacity upgrades and modifications

• Finite Element Analysis results and

supporting calculations are used as base line for refurbishment plans and possible capacity upgrades

Bucket Wheel Reclaimer capacity upgrade 1775tph – 2250tph

Detailed installation procedure Manufacturing drawings of new/modified equipment

Addition of Tippler top stop mechanism

Slew bearing analysis

• Analysis techniques are used to

accurately simulate slew bearing element forces

• Results are used to calculate expected

bearing life based on structural configuration and construction details

Equipment replacement studies

• Bulk material structures have

finite life, due to harsh

• perational environments
• Finite Element Analysis

results and structural inspection reports are used to estimate expectancies

3 Cracks 20, 50, 30mm S&F 2010 O’Connor Corrosion on cab support S&F 2010 O’Connor 3 Cracks on take up 35, 15, 15mm S&F 2010 O’Connor Corrosion luff connection S&F 2010 O’Connor Corrosion on mast pivot S&F 2010 O’Connor 4 Cracks 25, 30, 30, 25mm Corrosion S&F 2010 Corrosion S&F 2010 2 Cracks 90, 30mm S&F 2010 Corrosion S&F 2010 Corrosion S&F 2010 1 Cracks 60mm S&F 2010 1 Crack 40mm S&F 2010 Corrosion S&F 2010 Corrosion S&F 2010 Corrosi

• n

180, 90, 80 Cracks 20, 20mm S&F 2010 Corrosion S&F 2010 Corrosion 1 Crack 40mm 3 Cracks 30, 25mm S&F 2010 Corrosion

• n tow

bar 3 Cracks 20, 20mm S&F 2010 6 Cracks 100, 80, 80, 50, 100, 80, 50, 20mm S&F 2010 Several cracks 30, 30, 30mm S&F 2010 Corrosion Corrosion Corrosion Corrosion Corrosion Corrosion on boom tip S&F 2010 O’Connor Severe corrosion on boom S&F 2010 O’Connor

Structural and machine design

• Detail structural designs completed to

client requirements

• Designs consist of:
• Detailed layouts
• Supporting calculations to design

specifications including, ISO, SANS and FEM

• Finite Element analyses of complete

structures/ identified components

• Detailed manufacturing data packs

ROM Sizing structures for MMD

220 m3 bin – fixed installation

ROM Sizing structures for MMD

GMEP – Semi Mobile ROM tip

Tipplers and Chargers

Rotaside to unit train tippler designs and upgrades

Bulk flow analysis

• Material flow analyses
• Bin layouts
• Chute designs

Matching of wear patterns Material flow pattern and build-up Material spillage

Simulation for different Equipment orientations Simulate equipment movement Throughput assessment and blockage elimination

Other interesting projects

Thank you

Visit us at: www.ninedot.co.za Tel: 086 100 9DOT
