iGEM SupBiotech Paris Project The Double Vector System First Observation Genes Galenic Vectorization DVS Genes Galenic Vectorization DVS iGEM SupBiotech Paris Project 1 st Observation Double targeting for gene therapy SupBiotech

slide-1
SLIDE 1

iGEM SupBiotech Paris Project

The Double Vector System

slide-2
SLIDE 2

iGEM SupBiotech Paris Project

1st Observation Double targeting for gene therapy

First Observation

Genes Galenic Vectorization DVS

2

Galenic Vectorization DVS Genes Sup’Biotech Paris DVS Project

2

slide-3
SLIDE 3
  • Viral Disease

 Insertion of foreign genome

  • Cancer

 Genome modification

  • Genetic disease

 Dysfunctional genome

Identified Problem : The Genome

First Observation :

Problem identification

Galenic Vectorization DVS Genes Sup’Biotech Paris DVS Project

3

slide-4
SLIDE 4
  • Chemical drugs

 No specificity so Toxic

  • Bio-drugs

 Specific but Temporary (protein, siRNA, etc)

  • Gene insert

 Highly specific and Permanent

Best agent : gene sequence

Galenic Vectorization DVS Genes

First Observation :

Action on the genome

Sup’Biotech Paris DVS Project

4

slide-5
SLIDE 5
  • Very low toxicity
  • Specificity
  • Need to reach the nucleus
  • Low stability outside the cell

√ √ Protection

Galenic Vectorization DVS Genes

First Observation :

Gene characteristics

Sup’Biotech Paris DVS Project

5

Specific sequence

slide-6
SLIDE 6
  • Ex vivo Gene action

 Personal treatment COST

  • Classical galenic

 Low protection DEGRADATION

  • Vectorization

 Encapsulation GENE PROTECTION

Ideal galenic : gene vectorization

6

Galenic Vectorization DVS Genes

First Observation :

How to protect it ?

Sup’Biotech Paris DVS Project Galenic

6

slide-7
SLIDE 7
  • Components:

– Reservoir – Targeting system – Stealth system

  • Types of vectors :

– Virus – Phages – Bacteria – Lipidic nanoparticles – Polymer nanoparticles

Galenic DVS Genes

First Observation :

What is a vector ?

Sup’Biotech Paris DVS Project Vectorization

7

slide-8
SLIDE 8

Stability Toxicity Target Passage through membranes Immune system resistance Industrialization Virus Good High Cell Very good Null Difficult Phages Good Null Cell Very low Null Easy Bacteria Good Low/High Tissue Low Null/ High Easy Lipidic NPs Low Low Cell Good Low Medium polymer NPs Good Medium Cell Low Low Medium

  • The 6 major issues of vectorization

 Technological barrier

Galenic DVS Genes

First Observation :

Vectorization issues

Sup’Biotech Paris DVS Project Vectorization

8

slide-9
SLIDE 9
  • Each issue can be resolved by a vector
  • Three types of vectors have a genome
  • Synthetic Biology :

Possible to mix genomes  Solution : the Double Vector System (DVS)

Galenic Genes

First Observation :

Solution !

Sup’Biotech Paris DVS Project Vectorization DVS

9

slide-10
SLIDE 10

Characteristics :

  • Tissue targeting
  • Immune system resistance
  • Produces phages under control

Characteristics :

  • Cell targeting
  • Passage through membranes
  • Encapsidates an

exogenous plasmid Tissue Vector : Specific bacterium Cell Vector : Recombinant phage

+

10

Galenic Genes

First Observation :

Double Vector System

Sup’Biotech Paris DVS Project Vectorization

10

DVS

slide-11
SLIDE 11

Tissue Vector :

– Mycobacterium avium subspecies avium – (a) Phage genome – (b) System of phage production control (a) (b)

tetP/O RBS Terminator Ampicillin ORI Tetracyclin cassette pSBA3T5

TetR LacI

Repressor

Phage genome LacP/O Galenic Genes

First Observation :

Double Vector System

Sup’Biotech Paris DVS Project Vectorization

11

RBS DVS

slide-12
SLIDE 12

Doxycyclin

inhibition tetP/O RBS

LacI TetR

Lac P/O

cI repressor

cI synthesis inhibition

No Doxycyclin

tetP/O RBS

LacI TetR

Lac P/O

cI repressor

cI synthesis inhibition

cI inhibition  Production of recombinant phages

Galenic Genes

First Observation :

Control of the Cell vector synthesis

Sup’Biotech Paris DVS Project Vectorization

12

RBS RBS DVS

slide-13
SLIDE 13

Cell Vector :

– Lambda Phage – Controlled lysogeny – Viral Proteins on the capsid

cI repressor

Lac P/O

Protein D Protein J

Lambda genome Lambda genome Lambda genome

Kanamycin Cassette pL pR

Targeting Protein Polypeptide III

Galenic Genes

First Observation :

Double Vector System

Sup’Biotech Paris DVS Project Vectorization

13

DVS

slide-14
SLIDE 14

Type III polypeptide

  • From adenovirus penton base
  • Fused with the D protein
  • Contain RGD motives recognize integrins
  • Clustering of integrins
  • Internalization of the cell vector into the eukaryotic cell

Galenic Genes

First Observation :

Protein of cell internalization

Sup’Biotech Paris DVS Project Vectorization

14

DVS

slide-15
SLIDE 15

Therapeutic Plasmid:

– COS sequence for encapsidation – DTS sequence for nucleus targeting – Sequence of therapeutic aim

Sequence cos DTS

Therapeutic sequence

Azithromycine Cassette Galenic Genes

First Observation :

Double Vector System

Sup’Biotech Paris DVS Project Vectorization

15

DVS

slide-16
SLIDE 16
  • Double targeting

Highly specific

  • Penetration into tissues then into cells

Vectorized gene

  • Encapsulated gene

Protected

  • Living organism

Stability

  • Prokaryotic organisms

Low Cost

  • Immune system resistance

Low clearance

  • Use of a dangerous bacterium

Hazardous Injection of doxycyclin  induces bacterial lysis

Galenic Genes

First Observation :

DVS advantages

Sup’Biotech Paris DVS Project Vectorization

16

DVS

slide-17
SLIDE 17

iGEM SupBiotech Paris Project

2nd observation Cancer is only wrong information !

Sup’Biotech Paris DVS Project

slide-18
SLIDE 18
  • Cell containing an issue
  • Problem of genetic information
  • Wrong information blocking a system
  • Often apoptosis system

Solution : To bring the right information !

Sup’Biotech Paris DVS Project

18

Gene Presentation

Second Observation :

Cancer

Promoter

slide-19
SLIDE 19
  • Right information is the non-mutated version of a gene.

What happens if you bring this information ?

  • Cell can activate the gene pathway.

Anticancer Solution : To provide the missing genetic information

Sup’Biotech Paris DVS Project

19

Presentation Gene

Second Observation :

What is right information ?

Promoter

slide-20
SLIDE 20
  • Promoters control genetic information response.
  • Genetic information is expressed only if required.

Providing wild type promoter allows cells to choose the right regulation

Sup’Biotech Paris DVS Project

20

Presentation Gene

Second Observation :

How to control the genetic information?

Promoter

slide-21
SLIDE 21

iGEM SupBiotech Paris Project DVS application on Lung Cancer

Sup’Biotech Paris DVS Project

slide-22
SLIDE 22

Tissue vector:

  • Pulmonary tropism

Cell vector:

  • Unspecific targeting

Therapeutic plasmid :

  • « Wild type » version of tumor suppressor gene +

« wild type » promoter

Sup’Biotech Paris DVS Project

22

Tissue Presentation

Implementation:

DVS versus Lung Cancer

Cell Apoptosis

slide-23
SLIDE 23

Penetration into the lung

Blood vessel

Sup’Biotech Paris DVS Project

23

Tissue Vector Macrophage Macrophage infected by Tissue Vector

Lung

slide-24
SLIDE 24

Blood vessel

Dispersion in the Lung

Sup’Biotech Paris DVS Project

24

Lung

slide-25
SLIDE 25
  • 3 murine models: immunodeficient, normal, cancerous.
  • Cell suspension is analyzed by flow cytometry.

Size and granularity: eukaryotic murine cells ≠ M.avium

Day -7 Day 0 Day 7

  • Inoculation of

fibroblastic cancer cells

  • subcutaneously
  • normal mice

Inoculation of 10^6 CFU.ml-1 of M.avium,

  • IV route in the tail
  • 3 mice models

Mice sacrifice,

  • rgans extraction and

cell suspension from the lungs, tumors Sup’Biotech Paris DVS Project

25

Tissue Presentation

Implementation:

Tissue Targeting

Cell Modeling Tissue Presentation Cell Apoptosis

slide-26
SLIDE 26

Sup’Biotech Paris DVS Project

26

Implementation:

Tissue Targeting

Tissue Presentation Cell Modeling Tissue Presentation Cell Apoptosis

slide-27
SLIDE 27
  • Our

experiments

  • Literature

Too short to prove the presence

  • f M. avium in lung

Proven many times

 DVS can be used on lung cancer

Sup’Biotech Paris DVS Project

27

Tissue Presentation

Implementation:

Tissue Targeting

Cell Modeling Tissue Presentation Cell Modeling Tissue Presentation Cell Apoptosis

slide-28
SLIDE 28

Cell Vector Release

Sup’Biotech Paris DVS Project

28

Cell Vector

slide-29
SLIDE 29

Cell Vector Dispersion and Cancer Cells Targeting

Sup’Biotech Paris DVS Project

29

Cell Vector

slide-30
SLIDE 30

Membrane Receptor Targeting

Cancer Cell Cell Vector

30

Sup’Biotech Paris DVS Project

30

Integrin

slide-31
SLIDE 31

Cell Vector Internalization

Sup’Biotech Paris DVS Project

31

Nucleus

slide-32
SLIDE 32

Nucleus

Insertion of the gene into the target cell

Paradigm of therapeutic plasmid release is not elucidated

Sup’Biotech Paris DVS Project

32

acidification acidification

slide-33
SLIDE 33
  • Wild Type Lambda phage
  • Recombined Lambda phage with penton bases on D proteins

Source: Stefania Piersanti et al., 2004 Sup’Biotech Paris DVS Project

33

Tissue Presentation

Implementation:

Cell Targeting

Cell Modeling Tissue Presentation Cell Modeling Tissue Presentation Cell Apoptosis

slide-34
SLIDE 34
  • Fusion of adenovirus 5 penton base with D protein

From Lambda phage genome From a plasmid coding for the virus Sup’Biotech Paris DVS Project

34

Tissue Presentation

Implementation:

Cell Targeting

Cell Modeling Tissue Presentation Cell Modeling Tissue Presentation Cell Apoptosis

slide-35
SLIDE 35
  • Fusion protein not built in time.
  • Capacity to infect eukaryotic cells and to quit endosomes.
  • RGD fragment alone: higher efficiency of interaction with integrins
  • f eukaryotic cells.
  • In our application: use of the complete sequence

Possible to use a recombined Lambda phage to insert therapeutic genes

Sup’Biotech Paris DVS Project

35

Tissue Presentation

Implementation:

Cell Targeting

Cell Modeling Tissue Presentation Cell Modeling Tissue Presentation Cell Apoptosis

slide-36
SLIDE 36

Nucleus

NLS recrutement by DTS sequence

Gene insert

36

Sup’Biotech Paris DVS Project

36

slide-37
SLIDE 37

Nucleus

Nuclear insertion

37

Sup’Biotech Paris DVS Project

37

slide-38
SLIDE 38

Chromosome

Therapeutic gene expression

Nucleus

p53 wt

Apoptosis pathway induction

38

Sup’Biotech Paris DVS Project

38

slide-39
SLIDE 39
  • Cell population: Prostatic cancer mutated p53 DU-145
  • Kinetic monitoring of apoptosis induction : annexin V

assay every 6 hours for 48 hours after electroporation

– Control population – pcDNA3 CMV+p53wt

Sup’Biotech Paris DVS Project

39

Tissue Presentation Cell Modeling Tissue Presentation Cell Modeling Tissue Presentation Cell

Implementation:

Apoptosis Induction

Apoptosis

slide-40
SLIDE 40
  • Apoptosis detection

Specific fixation of the annexin V coupled with a fluorophore and analysis by flow cytometry.

Source: Chunlin Yang et al Adenovirus-mediated Wild-Type p53 Expression Induces Apoptosis and Suppresses Tumorigenesis of Prostatic Tumor Cells 1995

Sup’Biotech Paris DVS Project

40

Tissue Presentation Cell Modeling Tissue Presentation Cell Modeling Tissue Presentation Cell

Implementation:

Apoptosis Induction

Apoptosis

slide-41
SLIDE 41

Application of DVS in non small cell lung cancer is confirmed

p53 wild- type p53 mutated cell population

  • Apoptosis
  • Decreased

tumor population

Sup’Biotech Paris DVS Project

41

Tissue Presentation Cell Modeling Tissue Presentation Cell Modeling Tissue Presentation Cell

Implementation:

Apoptosis Induction

Apoptosis

slide-42
SLIDE 42

Blood vessel

Apoptosis Induction

42

Sup’Biotech Paris DVS Project

42

Lung

slide-43
SLIDE 43

Lung: natural tropism of Mycobacterium avium DVS: reactivation of apoptotic pathway in tumor cells by bringing the wild-type version

  • f tumor suppressor genes.

DVS is a straight alternative to current treatments.

Sup’Biotech Paris DVS Project

43

Conclusion

slide-44
SLIDE 44

To confirm the concept on lung cancer To adapt it on other diseases

Sup’Biotech Paris DVS Project

44

Perspectives

slide-45
SLIDE 45

Our compilation system is not easy but really useful! This new concept brings new outlooks for synthetic biology

Sup’Biotech Paris DVS Project

45

iGEM innovation

slide-46
SLIDE 46

Sup’Biotech Paris DVS Project

46

slide-47
SLIDE 47
  • Our instructors:
  • Pierre Ougen, Project director at Sup’Biotech Paris
  • Gavin Browne, in charge of international relationship
  • Scientists:

Our sponsors:

  • Lluis M Mir
  • Karim Benhioud
  • Bassim Al-sakere
  • Brian D Roberston
  • Nicolas Veziris
  • Srinivas Kaveri
  • Vladimir Lazar
  • Benyoussef Naimi
  • Franck Griceli
  • Claudie Bourgaux
  • Claudia Nobrega
  • Jean-Yves Trosset
  • And the others…

Sup’Biotech Paris DVS Project

47

Acknowledgements

slide-48
SLIDE 48

48

Sup’Biotech Paris DVS Project

48

Annexs

slide-49
SLIDE 49

Doxycyclin

inhibition tetP/O RBS

LacI TetR

Lac P/O

cI repressor

cI synthesis inhibition

No Doxycyclin

tetP/O RBS

LacI TetR

Lac P/O

cI repressor

cI synthesis inhibition

cI inhibition  Production of recombinant phages

Galenic Genes

First Observation :

Control of the Cell vector synthesis

Sup’Biotech Paris DVS Project Vectorization

49

RBS RBS DVS

slide-50
SLIDE 50

50

Galenic Genes

About:

Mycobacterial membrane

Sup’Biotech Paris DVS Project Vectorization DVS

50

slide-51
SLIDE 51

51

Galenic Genes

About:

Side effects of bacterial lysis

Sup’Biotech Paris DVS Project Vectorization DVS

51

slide-52
SLIDE 52
  • Insertion sequences: insertion of both the phage

genome and the control plasmid into the bacterial genome

  • Just one plasmid, the therapeutic one, replicated and

transmitted to the daughter bacterial cells

52

Galenic Genes

About:

Plasmid repartition after cell division

Sup’Biotech Paris DVS Project Vectorization DVS

52

Repressor

Phage genome

LacP/O

tetP/O RBS Terminator Ampicillin ORI Tetracyclin cassette pSBA3T5

TetR LacI

tetP/O RBS Terminator Ampicillin ORI Tetracyclin cassette pSBA3T5

TetR LacI

Repressor

Phage genome LacP/O RBS Int attP

slide-53
SLIDE 53

Galenic Genes

About:

Encapsidation mechanism of COS sequences

Sup’Biotech Paris DVS Project Vectorization DVS

53

slide-54
SLIDE 54
  • Bioluminescence protocol, which allows the real-time

monitoring.

  • Good reporter system to analyze the mycobacterial

implantation and the clearance in vivo.

Sup’Biotech Paris DVS Project

54

Tissue Presentation

Experimental perspective

Tissue targeting

Cell Modeling Tissue Presentation Cell Modeling Presentation Cell Apoptosis

Luciferase Kanamycin resistance int attP High Promoter Provided by Dr.Brian D.Robertson

Tissue

slide-55
SLIDE 55

Sup’Biotech Paris DVS Project

55

Tissue Presentation

Experimental perspective

Tissue targeting

Cell Modeling Tissue Presentation Cell Modeling Presentation Cell Apoptosis

  • Exemple of obtained images by the CCD camera:

Tropisms: Implantation in different tissue Quantification:

Extracted from: Bioluminescent Monitoring of In Vivo Colonization and Clearance Dynamics by Light-Emitting Bacteria, Brian D.Rob

Tissue

slide-56
SLIDE 56
  • Introduction of the fusion protein in a BioBrick plasmid.

+ Antibiotic resistance to confirm the transfection into bacteria + GFP reporter gene with CMV promoter to confirm the transfection into eukaryotic cells Sup’Biotech Paris DVS Project

56

Tissue Presentation

About:

Cell Targeting

Cell Modeling Tissue Presentation Cell Modeling Tissue Presentation Cell Apoptosis

slide-57
SLIDE 57

Sup’Biotech Paris DVS Project

57

Tissue Presentation

About:

Therapeutic plasmid

Cell Modeling Tissue Presentation Cell Modeling Tissue Presentation Cell Apoptosis

slide-58
SLIDE 58

Sup’Biotech Paris DVS Project

58

Tissue Presentation

About:

Treatment efficiency Modeling

Cell Modeling Tissue Presentation Cell Modeling Tissue Presentation Cell Modeling With :

  • Nc (t), the number of cancer cells depending time,
  • V (t), tumor volume,
  • V1 and V2, two tumors volumes respectively times t1 and t2,
  • Vcc, the volume of a cancer cell,
  • Nbi, the number of injected tissue vectors,
  • Pp, the lung percentage of tissue vectors relative to the injected dose,
  • DTB, the doubling time of tissue vector,
  • tinj, injection time of the tissue vectors],
  • Npl, the number of cell vectors released by bacteria.
  • λ, phage efficiency
slide-59
SLIDE 59

Sup’Biotech Paris DVS Project

59

Tissue Presentation

iGEM for us !

Cell Modeling Tissue Presentation Cell Modeling
