I L ROUT E 60/ 83

Co mmunity Adviso ry Gro up Me e ting No . 2 July 28, 2009

Outline Ag e nda

• Introduction to Participants
• Recap of Community Advisory Group Meeting No. 1

– July 13, 2009

• Drainage
• Traffic Safety
• Traffic Operations
• Refine Problem Statement from Meeting No. 1
• Identify Specific Issues for Segment No. 1
• Next Meeting – August 11, 2009

Who Are We ?

Introductions

Co mmunity Adviso ry Gro up Me e ting No . 1

• The July 13, 2009 meeting was attended by

11 people representing:

– Residents – Business Owner – Area Church – Fire Protection District – Police Department – Park District – School District – County and Village Municipal Agencies

Co mmunity Adviso ry Gro up Me e ting No . 1

Summary of Community Context Audit

• Pedestrian Safety
• Lack of Roadway Lighting
• Lack of Alternate Transportation Modes
• Traffic Operational Issues
• Residential and Emergency Vehicle Access

Issues

Co mmunity Adviso ry Gro up Me e ting No . 1

Summary of Community Context Audit

• Potential Property Acquisition Issues
• Environmental Issues
• Railroad Crossing Delays
• Preservation of Existing Neighborhood and

Cultural Features

I L Ro ute 60/ 83

Segment No. 1 Schank Road/IL Route 176 Triangle to Midlothian Road

Schank Rd/IL 176 Triangle to Midlothian Rd

• Identified Outlets
• See photo handouts
• Other Outlets
• 1 Major Crossing
• Seavey Drainage Ditch

I L 60/ 83 Dra ina g e Study

I L 60/ 83 Dra ina g e Study

Seavey Drainage Ditch Headwall Discharging to S.D.D.

I L 60/ 83 Dra ina g e Study

24” Culvert Golf Course Wetland Seavey Drainage Ditch Outlet #6 24” x 24” Box Culvert

I L 60/ 83 Dra ina g e Study

• Other Drainage Concerns?

Overall Corridor Crash Summary

• 3-year analysis period from 2004 to 2006
• Study area from IL 176 to IL 60 (Town Line Road)
• 12 study zones, segments/intersections (5 North)
• IL 176 intersection
• Segment between IL 60/83 & Hawley Street
• Hawley Street intersection
• Segment between Hawley Street & Midlothian Road
• Midlothian Road intersection
• No five percent crash locations

I L 60/ 83 T ra ffic Sa fe ty

I L 60/ 83 T ra ffic Sa fe ty

Overall Corridor Crash Statistics

• 639 total crashes
• No fatality crashes
• 139 (22%) crashes occurred with injuries
• 12 incapacitating type
• 27% of crashes weather related (rain, ice, snow)
• 23% of crashes occurred during nighttime hours

I L 60/ 83 T ra ffic Sa fe ty

Rear End, 403, 64% Turning, 118, 18% Angle, 44, 7% Sideswipe-Same Direction, 24, 4% Fixed Object, 21, 3% Bike, 6, 1% Sideswipe-Opposite Direction, 9, 1% Other, 11, 2% Pedestrian, 2, 0% Head On, 1, 0%

IL 60/83 TOTAL CRASHES BY TYPE 2004 - 2006

LEGEND Crash Type, Number of Crashes, Percentage

I L 60/ 83 T ra ffic Sa fe ty

• Total Crashes by Location (North)

I L 60/ 83 T ra ffic Sa fe ty

• Conclusions

– Predominantly rear end, turning & angle collisions – Most crashes during daytime hours – More crashes observed at locations where the roadway does not have adequate capacity – Primary countermeasures include:

• Increasing roadway and intersection capacities
• Providing larger turning radii
• Improving sight distance
• Increasing storage lengths
• Providing left and right turn lanes where warranted

I L 60/ 83 E xisting / Pro je c te d T ra ffic

+1.9% +1.9% +0.04% +0.04% +0.3% +0.3% +1.4% +1.4% +1.3% +1.3% +0.2% +0.2% + . 5 % + . 5 % +1.4% +1.4% +0.5% +0.5% +0.7% +0.7% +0.9% +0.9% Annual Growth Rates Annual Growth Rates

NORTH PORTION

I L 60/ 83 E xisting T ruc k T ra ffic

7% 7% 10% 10% 6% 6% 9% 9% 10% 10% 9% 9% Average Daily Truck Percentages Average Daily Truck Percentages

NORTH PORTION

I L 60/ 83 T ra ffic Prima ry Ro ute

I L 8 3 I L 8 3 IL 60 IL 60 IL 60/83 IL 60/83 IL 176 IL 176 IL 176 IL 176

AM AM Peak Hour

S C H A N K A V E S C H A N K A V E

I L 60/ 83 T ra ffic Prima ry Ro ute

I L 8 3 I L 8 3 IL 60/83 IL 60/83 IL 176 IL 176 IL 176 IL 176

PM PM Peak Hour

S C H A N K A V E S C H A N K A V E

IL 60 IL 60

I L 60/ 83/ 176 T ra ffic Ope ra tio ns

I L 8 3 I L 8 3 IL 60 IL 60 IL 60/83 IL 60/83 IL 176 IL 176 IL 176 IL 176

S C H A N K A V E S C H A N K A V E

AM AM Peak Hour Existing Configuration With Projected 2030 Traffic B B

Signalized Intersection

D D D D B B F F Int: Int: E E D D B B F F E E Int: Int: E E

I L 60/ 83/ 176 T ra ffic Ope ra tio ns

I L 8 3 I L 8 3 IL 60 IL 60 IL 60/83 IL 60/83 IL 176 IL 176 IL 176 IL 176

S C H A N K A V E S C H A N K A V E

PM PM Peak Hour Existing Configuration With Projected 2030 Traffic F F

Signalized Intersection

B B F F E E F F Int: Int: E E C C C C D D E E Int: Int: D D

I L 60/ 83 & Ha wle y St T ra ffic Ope ra tio ns

IL 60/83 IL 60/83 Hawley St Hawley St AM AM Peak Hour Existing Configuration With Projected 2030 Traffic IL 60/83 IL 60/83 Hawley St Hawley St IL 60/83 IL 60/83 Hawley St Hawley St PM PM Peak Hour Existing Configuration With Projected 2030 Traffic IL 60/83 IL 60/83 Hawley St Hawley St

F F C C C C E E Int: Int: F F C C F F F F F F Int: Int: F F

I L 60/ 83 & Midlo thia n Rd T ra ffic Ope ra tio ns

IL 60/83 IL 60/83

Midlothian Rd Midlothian Rd

AM AM Peak Hour Existing Configuration With Projected 2030 Traffic IL 60/83 IL 60/83 PM PM Peak Hour Existing Configuration With Projected 2030 Traffic

F F D D C C F F Int: Int: F F E E E E F F F F Int: Int: E E

Midlothian Rd Midlothian Rd

T ra ffic Simula tio n

• Existing Configuration with 2030

Projected Volumes

• North Portion of Study Area
• IL 60/83/176 Triangle
• IL 60/83 and Hawley Street
• IL 60/83 and Midlothian Road
• Future traffic exceeds roadway capacity

Ne xt Me e ting T

• pic s
• Summary of Meeting No. 2 Findings
• Focus on Segment No. 2 – South of

Midlothian Road to the Intersection of IL Route 60 (Town Line Road) and IL Route 83

• Identification of Sensitive Features
