Home Energy Storage Workshop

Is Is Battery ry Backup Rig ight For You?

Event Partners

Event Partners

Companies Represented

Agenda

• 1. Energy Storage for Resiliency (David Fukutomi )
• 2. PSPS Events (Southern California Edison)
• 3. Options during shutoff (Community Environmental Council)
• 4. Technical Stuff (Daniel Glaser)
• 5. Incentives (Community Environmental Council)
• 6. Virtual Power Plant (Swell Energy)
• 7. Community Choice and Storage (Clean Power Alliance)
• 8. Announcements
• 9. Mixer

Energy Storage for Resiliency

David id Fukutomi

Public Safety Power Shutoffs

Rondi Guthrie Southern California Edison

Wildfire Mitigation Plan December 2, 2019

California’s Wildfire Risk

1

Year-Round Fire Season: Changes to California’s climate means that the traditional notion

• f a fire “season” no longer exists

Hazardous fuel is building up: 10M acres of land contain ready-to-burn kindling from nearly 147M trees that have been killed or weakened by drought and bark beetle infestation

Source: http://www.fire.ca.gov/communications/downloads/fact_sheets/Top20_Destruction.pdf

Local Community High Fire Risk Area Map

2

What makes up SCE’s HFRA? A combination of historical map boundaries (based on past fire management and response experiences), CAL FIRE’s Fire Hazard Severity Zone (FHSZ) maps, and most recently the CPUC High Fire Threat District map are used to inform SCE’s High Fire Risk Areas.

CPUC Tier 3 = ~18% CPUC Tier 2 = ~9% Other HFRA = ~8%

Approximately 1/3 of SCE’s 50,000 square mile service area is located in HFRA.

* Areas within SCE’s service area that continue to be designated as HFRA and are in the process of being evaluated to determine whether they remain as HFRA

Scope of SCE’s 2019 SB 901 Wildfire Mitigation Plan

3 OPERATIONAL Inspections

• Enhanced overhead inspections (EOI) on transmission and distribution structures in

HFRA

• Various existing inspections (poles, switches, circuits, relays, etc.)
• Infrared, Corona scanning and high definition (HD) imagery

Public Safety Power Shutoff (PSPS)

• Effective communications and engagement with emergency services, customers and

communities

Situational Awareness

• Weather stations and HD cameras

Vegetation Management

• Hazard tree removal (trees beyond traditional trim zone)
• Vegetation removal at poles
• LiDAR surveying for transmission, supplemental inspections in HFRA
• SCE plans to implement a 12-ft tree clearances from distribution power lines

in high fire areas to ensure annual growth will not encroach on compliance distances.

INFRASTRUCTURE Covered Conductor

• Circuit miles of covered conductor in HFRA

Undergrounding

• Evaluation of certain distribution lines in HFRA for potential undergrounding.

Other Infrastructure Mitigations

• Various system hardening activities (e.g., composite poles, current limiting fuses (CLFs),

remote automatic reclosers (RARs), Fast Curve settings)

• Studies, evaluations and pilots of alternative technologies

Infrastructure - System Hardening Elements

4

Hardened System

Covered Conductor Reclosers Fast-Acting, Current Limiting Fuses (CLF)

Enhanced Overhead Inspections (EOI)

Enhanced Overhead Inspections Identify Potential Risks

• In less than 5 months, our crews

completed detailed ground- based inspections of 400,000+ distribution and transmission structures in HFRA

• Deploying helicopters and drones

equipped with Infrared, Ultraviolet, LiDAR and HD image scanning to perform aerial inspections of our facilities in HFRA

5

SCE’s helicopters are equipped with software and high-tech cameras, like the one shown above, to find potential risk undetectable to the human eye

Situational Awareness Capabilities

6

Situational Awareness Center

• SCE meteorologists
• 24/7 monitoring

Fire Monitoring Cameras

• High-Definition
• Remote-controlled

Advanced Weather Modeling

• Better Forecasting
• Advanced Warning

Weather Stations

• Hi-Res Data
• Local Weather

Public Safety Power Shutoff (PSPS)

7

▪ De-energization to prevent ignitions from powerlines ▪ Used during extreme fire conditions ▪ Primarily impacts circuits in high fire risk areas ▪ Other circuits in non-high fire risk areas may be impacted if

transmission lines are de-energized

▪ Red Flag Warning does not mean a PSPS will be called ▪ Actual frequency of PSPS events will depend on various weather and

environmental factors​

▪ Decision will be made with most accurate assessment of real-

time information and situational awareness data

PSPS Decision Points

8

Decision points include but are not limited to:

• SCE Meteorologists

forecast strong wind conditions in service territory

• SCE Fire Scientist

assessment of fire potential to include consideration of weather and fuels

• Impact of

de-energizing circuits on first responders and essential services

• Real-time
• bservations

from qualified personnel monitoring for hazardous conditions in the field

* Erratic or sudden onset of conditions may prevent the input from real-time observations or consultation with first responders

PSPS Ideal Timeline

9 4-7 DAYS AHEAD 3 DAYS AHEAD 2 DAYS AHEAD 1 DAY AHEAD POWER SHUTOFF POWER RESTORATION PLANNING AND MONITORING OUTAGE *Erratic or sudden onset of conditions may impact our ability to provide advanced notice to customers. Forecast Weather & Fire Conditions SCE Incident Management Team activated County Operational Areas informed

• f potential

activation 1st Notification PSPS Possible sent to agencies and customers 2nd Notification PSPS Possible 3rd Notification Power Shutoff 4th Notification Power Restored After Inspection

Useful Information

10

• Update Customer Contact Information https://www.sce.com/outagealerts
• Information on SCE Wildfire Mitigation Plan www.sce.com/wildfire
• Twitter - @sce
• Facebook – www.facebook.com/sce
• Fire Cameras- www.alertwildfire.org
• Weather Stations – mesowest.utah.edu
• CPUC Wildfire Maps Information - www.cpuc.ca.gov/wildfiresinfo/
• Fire Preparedness - calfire.ca.gov/fire_protection/fire_protection_be_prepared
• Red Cross Emergency Preparedness

www.redcross.org/get-help/how-to-prepare-for-emergencies.html

• FEMA Emergency Preparedness – www.ready.gov

Thank you

11

Options during a power shutoff

Apri ril Pri rice Community Environmental Council

Options During a Power Outage

• 1. Low Tech

Options During a Power Outage

• 1. Low Tech
• 2. Generator

“Have you considered the toxic impacts of diesel exhaust? Diesel soot, or diesel particulate, is the number one airborne carcinogen in California, and represents our state’s most significant toxic air pollution problem.”

• Santa Barbara Air Pollution Control District

Options During a Power Outage

• 1. Low Tech
• 2. Generator

Options During a Power Outage

Options During a Power Outage

• 1. Low Tech
• 2. Generator

Battery/Solar Generators: EXAMPLES Large Fridge 10+ hours

Options During a Power Outage

• 1. Low Tech
• 2. Generator
• 3. Special Inverter with Outlet

Options During a Power Outage

• 1. Low Tech
• 2. Generator
• 3. Special Inverter with Outlet
• 4. Solar+ Battery JUST FOR BACKUP

Easy to recycle and more affordable than other batteries that we will discuss

Options During a Power Outage

• 1. Low Tech
• 2. Generator
• 3. Special Inverter with Outlet
• 4. Solar+ Battery JUST FOR BACKUP
• 5. Solar+ Load Shifting Battery

Options During a Power Outage

• 1. Low Tech
• 2. Generator
• 3. Special Inverter with Outlet
• 4. Solar+ Battery JUST FOR BACKUP
• 5. Solar+ Load Shifting Battery

Options During a Power Outage

Sonnen eco Pika Energy LG Chem

Enphase

Simpliphi Tesla Powerwall EXAMPLES: Batteries that can be used for load shifting applications

Typical Solar Situation: (Net Energy Metering) You export solar to the grid when you don’t need it and get a monetary credit for each kWh that is sent to the grid.

What is Load Shifting?

Graphic from Energy Storage News You will charge your battery with your solar system during the day and then use some of that energy in the evening instead of buying the most expensive energy from the grid WITHOUT LOAD SHIFTING WITH LOAD SHIFTING

Typical Solar Situation: (Net Energy Metering) You export solar to the grid when you don’t need it and get a monetary credit for each kWh that is sent to the grid.

What is Load Shifting?

Graphic from Energy Storage News You will charge your battery with your solar system during the day and then use some of that energy in the evening instead of buying the most expensive energy from the grid WITHOUT LOAD SHIFTING WITH LOAD SHIFTING

EXAMPLE: Electricity cost impacts of load shifting

CPA Rates before storage (TOU-D-4 )- Summer CPA rates after storage (TOU-D-PRIME)- Summer

You pay (or get NEM credits) of: ~24 cents/kWh 4PM-9PM weekdays ~6 cents/kWh All other times

EXAMPLE: Electricity cost impacts of load shifting

CPA Rates before storage (TOU-D-4 )- Summer CPA rates after storage (TOU-D-PRIME)- Summer

You pay (or get NEM credits) of: ~24 cents/kWh 4PM-9PM weekdays ~6 cents/kWh All other times You pay (or get NEM credits) of: ~25 cents/kWh 4PM-9PM weekdays ~3.5 cents/kWh All other times ~11 cents/kWh 4PM-9PM weekends

EXAMPLE: Electricity cost impacts of load shifting

CPA Rates before storage (TOU-D-4 )- Summer CPA rates after storage (TOU-D-PRIME)- Summer

You pay (or get NEM credits) of: ~25 cents/kWh 4PM-9PM weekdays ~3.5 cents/kWh All other times ~11 cents/kWh 4PM-9PM weekends

GHG Im Impact of Load Shifting

Load Shifting allows you to use your own solar energy when the grid is most dependent on natural gas.

Battery ry Basics

Daniel Glaser

RESIDENTIAL SOLAR + STORAGE FUNDAMENTALS

DECEMBER 2ND, 2019

AGENDA

• Solar fundamentals
• Why energy storage?
• How does it work?
• AC vs DC coupled systems

Basic operation of PV systems

Grid Outage

X

X

WHY ENERGY STORAGE?

By going solar, you are taking the first step towards energy

• independence. However, with

a traditional system, the grid must be present to have power. By utilizing battery storage technology, you can bank the energy you produce for times when you need it most.

How does it work?

Energy Storage Fundamentals

• kW = Power
• kWh = Energy

kWh = how long will my battery last? kW = how many household loads can I run at a time?

• Solar PV systems typically sold by kW
• Energy storage systems typically sold by kWh
• kWh is what we are charged for on our monthly electric bill

AC vs. DC Coupled

AC Coupled

• Flexibility
• Great for existing PV systems
• Slightly lower efficiency than DC coupled

systems DC Coupled

• Simplicity => 1 inverter
• Great for new PV systems
• Slightly higher efficiency than AC coupled

system

DC power DC power AC power

DC Coupled

MLPE

AC Coupled

PV INVERTER(S)

Can I backup my whole home?

MAYBE

• Budget
• Home size
• Home location
• What do I really need

during an outage?

20% DoD

90% DoD

• Many factors influence the degradation rate including
• Charge/Discharge rate
• Temperature
• DoD
• Cycles per day (Throughput)

Key Points:

• DoD affects

degradation rate

• Lithium ion

batteries can handle full discharge much better than lead acid

• Refer to

manufacturer warranty for best design practices

Depth of Discharge

RESOURCES

• Introduction to Home Energy Storage with

EverVolt:

• https://www.voiceamerica.com/episode/118206/pa

nasonics-new-residential-energy-storage-system- evervolt

• Panasonic’s Battery Storage Homepage:
• https://na.panasonic.com/us/energy-

solutions/battery-storage/

THANK YOU

DAN GLASER Dan.glaser@us.Panasonic.com 805.220.0777

THANK YOU

DAN GLASER Dan.glaser@us.Panasonic.com 805.220.0777

In Incentives

Apri ril Pri rice Community Environmental Council

Federal Tax Credits

Investment Tax Credit (ITC) Your solar-tied battery system will be eligible for the ITC as long as it is charged by solar. Tax Credit: System installed in 2019= 30% System installed in 2020= 26% System installed in 2021= 22% System installed in 2022= 10%

Self Generation In Incentive Program

FOR LOAD SHIFTING BATTERIES TIED TO SOLAR: Incentive has been available at a price/watt hour. Most recent incentive was a one-time payment of 25 cents/watt hour So, for a 13.5 kWh battery, a $2,900 Incentive was recently available. Incentive levels decrease as more people subscribe. So, if the level is decreased- incentive COULD be: 20 cents/watt hour ($2,320 for same battery)

Self Generation In Incentive Program

Available~ April, 2020 Enhanced Incentives Enhanced Incentives

~April, 2020 Eligible customers are those in high fire threat districts, and are also:

• Low-income or living in a

disadvantaged community

• “Medical baseline” consumers or

consumers who have notified utilities that they have a serious illness or condition that could be life-threatening without electricity

• A critical services facility, such as

police and fire stations, emergency responders, health care facilities, cooling centers, and others providing critical functions

Virtual Power Plant

Shawn Ja Jacobson Swell Energy

805 Energy Security Initiative

Utility Grid Services

Connected energy resources Capacity/resource adequacy Demand response Non wires alternatives Resiliency and reliability

Consumer Energy Solutions

Innovative financing and energy services Utility incentive program enrollment TOU energy arbitrage and optimization Energy security with backup power Bring Your Own Device DER exchange

About Swell Energy

SCE’s Need for Local and Reliable Energy

3

• 2015 - Aliso Canyon Natural Gas Leak Reduces Local Gas Supplies
• 2017 - Rejection of the 262 MW Puente Natural Gas Plant
• Mandalay Generating Station Decommissioning
• Public Safety Power Shutoff Programs

Connected Energy Storage Solution

4

• Swell secured 14 MW to enroll behind-the-meter energy storage systems
• Additional resiliency incentives available from the CPUC
• Goal of over 5000 home and commercial systems by 2021
• Flexible participation options home and building owners
• Local electrician and solar company collaboration

Swell’s Connected Energy Network

5

EnergyShield

6

Energy Security Service

• Energy Savings through Time of Use Control
• Backup Power for Essential Circuits
• Connected Energy Network Participation
• Low Monthly Energy Security Agreements
• Residential and Commercial
• Battery Only or Solar + Storage

www.swellenergy.com/energy-shield

Energy Exchange Program Enrollment

7

Enroll your existing or new storage system in the program to receive annual benefits for participation and support the resiliency of the local grid.

Local Community Benefits

8

• Reliability in Local Electricity Supply
• Neighborhood Disaster Preparedness and Resiliency
• Improved Regional Air Quality
• Local Workforce Opportunities
• Climate Change Mitigation

9

(888) 465-1784

www.swellenergy.com/energy-shield www.sce.com/residential/demand-response

Community Choice and Storage

Karen Schmidt Clean Power Alliance

CLEAN POWER ALLIANCE

Locally powered energy innovation.

Ventura Home Energy Workshop, October 30, 2019

What is Clean Power Alliance?

The Clean Power Alliance is your Community Choice electricity provider,

• ffering clean, renewable energy at competitive rates to our community.

2

Ventura Home Energy Workshop, October 30, 2019

Investing in Local Priorities

• Presenting Local Programs 5-year

strategic plan the CPA Board in December

• Launching Distributed Energy Resources

(DER) demand response pilot January 2020

○

Solar + Storage

○

Smart Thermostats

○

Commercial EV Charging

• Pursuing State funding for community

solar projects and for EV infrastructure incentives in Ventura County starting 2020-2021

3

Ventura Home Energy Workshop, October 30, 2019

Solar + Storage DER Demand Response Pilot

• Customers with new or existing paired solar and battery storage system (or

standalone storage) will participate in events that allow CPA to call on their battery as a distributed resource

• On event days customers charge battery with solar during low price periods

in the middle of the day, and battery is discharged during evening peak (4pm-9pm)

• Enrollment incentive of $100 for residential and $250 for commercial ($125

and $300 for DAC)

• Annual incentive of $100/kW for participation in load shifting events based
• n committed capacity ($125/kW for DAC)

How it works

4

Ventura Home Energy Workshop, October 30, 2019

Solar + Storage DER Demand Response Pilot

• CPA residential or commercial customers

○

Accounts may not be enrolled in conflicting programs (e.g., Capacity Bidding Program, Summer Discount Program, other Demand Response programs)

• Existing or new paired solar + storage or storage-only systems

○

Automated response capability depending on equipment

• Sign up at our table or contact us to receive eligibility and enrollment

details.

Eligibility & Enrollment

5

Ventura Home Energy Workshop, October 30, 2019

Customer Service: 888-585-3788 customerservice@cleanpoweralliance.org cleanpoweralliance.org

Contact us

6

My contact information: Karen Schmidt, Regional Affairs Manager kschmidt@cleanpoweralliance.org

December 2, 2019 Ventura Home Energy Workshop

Clean Power Alliance

Locally powered energy innovation.

Announcements

One Min inute or Shorter

Mixer
