SUSE Enterprise Storage 6 Darren Soothill EMEA Storage Technical Strategist Agenda Enterprise Storage Business Challenges SUSE Enterprise Storage Architecture SUSE Enterprise Storage 6 SUSE Enterprise Storage Use Cases

slide-1
SLIDE 1

SUSE Enterprise Storage 6

Darren Soothill – EMEA Storage Technical Strategist

slide-2
SLIDE 2

199

Agenda

  • Enterprise Storage Business Challenges
  • SUSE Enterprise Storage Architecture
  • SUSE Enterprise Storage 6
  • SUSE Enterprise Storage

Use Cases

  • Questions
slide-3
SLIDE 3

200 200

Enterprise Storage Business Challenges

slide-4
SLIDE 4

201

The Data Explosion Continues

Mobile Data Emails Transactional Data Videos Medical Data IoT Data

175 ZB

by 2025

slide-5
SLIDE 5

202

SUSE Enterprise Storage

Bridge to the Future

Today’s Data Center

  • Traditional data center with storage silos
  • Disparate network, compute and storage setup
  • Data center disruptions because of regularly

changing technologies

Tomorrow’s Data Center

  • Software-defined data center
  • Agile infrastructure with support for DevOps model

through automation

  • Simplified data center management
  • Increased speed of delivery

SUSE Enterprise Storage is the first step in a software- defined future.

slide-6
SLIDE 6

203

SUSE Enterprise Storage

Unlimited Scalability with Self Managing Technology

Monitor Nodes Management Node

Object Storage Block Storage File System

Storage Nodes

Increase capacity and performance by simply adding new storage or storage nodes to the cluster

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 Object Object Object Object Object Object Object Object
slide-7
SLIDE 7

204

Limiting Factors of Traditional Enterprise Storage

Difficult to Scale and Manage Data Growth Expensive Won’t Extend to the Software-defined Data Center

$

slide-8
SLIDE 8

205 205

SUSE Enterprise Storage Architecture

slide-9
SLIDE 9

206

Powered by Ceph Technology

SUSE Enterprise Storage Architecture

slide-10
SLIDE 10

207 207

SUSE Enterprise Storage 6

slide-11
SLIDE 11

208

SUSE Enterprise Storage

Last 12-month Accomplishments

Monitor Nodes Management Node Storage Nodes

Unified

Open Source Software on x86 and Arm Resilient & Self-healing

High Performance

Massively Scalable

Public Cloud Like Pricing

Object Storage Block Storage File System Unified Cluster Hardware Flexibility Reduced IT Costs

  • Launched SUSE Enterprise Storage 5.5
  • 8th release
  • Latest upstream release Ceph Nautilus
  • 8 out of top 20 Ceph contributors

are from SUSE

  • SUSE team driving Ceph Dashboard

upstream project

  • SUSE more than doubled Ceph

customers in FY18 relative to FY17

slide-12
SLIDE 12

209

SUSE Enterprise Storage

Development Focus Areas

  • Unified Block, File

& Object

  • Fabric

Interconnects

  • Cache Tiering
  • Containerization
  • Hierarchical

Storage Management

  • Backup/Archive
  • Continuous Data

Protection

  • Remote

Replication

  • Ease of

Installation

  • GUI based

Monitoring & Management

Manageability Interoperability Efficiency Availability

slide-13
SLIDE 13

210

SUSE Enterprise Storage 6

** Items are tech preview

  • Ceph Dashboard (oA replacement)
  • Phone home (metrics and error

analysis)

  • Enhanced PG balancing
  • Autonomous PG scaling**
  • CephFS directory quotas
  • Graceful system shutdown
  • Storage enclosure disk integration

Manageability

slide-14
SLIDE 14

211

  • IPv6
  • RGW Elasticsearch sync module
  • Node to node encryption**
  • Multiple CephFS instances in one

cluster**

  • NFS-Ganesha active/active

architecture**

Interoperability

** Items are tech preview

SUSE Enterprise Storage 6

slide-15
SLIDE 15

212

  • QoS for RBD
  • QoS for background operations
  • S3 object policy driven tiering**

Efficiency

** Items are tech preview

SUSE Enterprise Storage 6

slide-16
SLIDE 16

213

  • Unidirectional sync

external cloud via S3

  • CephFS snapshots
  • Asynchronous file replication**

Availability

** Items are tech preview

SUSE Enterprise Storage 6

slide-17
SLIDE 17

214

SUSE Enterprise Storage Roadmap

*: These dates are indicative only, not guaranteed

Unified File, Object & Block

  • CephFS
  • Multisite object

replication

  • Acquired openATTIC

Performance and Ease of Use

  • BlueStore
  • Compression
  • Block/File

Erasure code

  • NFS/S3 interface
  • NFS/CephFS interface
  • OpenATTIC integrated

with DeepSea

  • Enhanced monitoring

and management

Interoperability and Security

  • Integration with SUSE

OpenStack Cloud

  • CIFS/Samba interface
  • Non SUSE

Ceph clients

  • Event notification
  • AppArmor integration
  • Security audit testing

Enhanced Management and Hybrid Cloud

  • Ceph Dashboard
  • Enhanced monitoring
  • Public cloud product
  • Sync to external cloud
  • Phone home
  • RBD QoS
  • CephFS snapshot
  • Async file replication

Containerization and Autonomous Self-Healing

  • Containerization
  • Enhanced intelligent

data placement

  • Guided

troubleshooting

  • Guided HW upgrade
  • Guided OSD repair
  • Data deduplication
  • RDMA interconnect
  • Windows drivers

SES 4: Nov 2016 SES 5: Oct 2017 SES 5.5: Oct 2018 SES 6: June 2019* SES 7: Q2/Q3 2020*

slide-18
SLIDE 18

215

Demo

slide-19
SLIDE 19

216 2018 2019 2021 2022

SUSE Enterprise Storage

5.5 6 7

Built On

  • Ceph Luminus release
  • SUSE Linux Enterprise Server 12

SP3

Manageability

  • Internationalization
  • Usability enhancements
  • Predefined profiles
  • Autonomous data balancer**
  • DeepSea (Salt) phase 3

Interoperability

  • Non SUSE RBD and CephFS clients
  • CIFS/Samba
  • AppArmor security module

Availability

  • Multisite RADOSGW N+1 with N/N-1

Efficiency

  • BlueStore/RocksDB optimizations

5.5 Built On

  • Ceph Nautilus release
  • SUSE Linux Enterprise Server 15 SP1

Manageability

  • Ceph Dashboard (oA evolution)
  • Phone home (metrics and error analysis)
  • Enhanced PG balancing
  • Autonomous PG scaling**
  • CephFS directory quotas
  • Graceful system shutdown
  • Storage enclosure disk integration

Interoperability

  • IPv6
  • RGW Elasticsearch sync module
  • Node to node encryption**
  • Multiple CephFS instances in one cluster**
  • NFS-Ganesha active/active architecture**

Availability

  • Unidirectional sync external cloud via S3
  • CephFS snapshots
  • Asynchronous CephFS replication**

Efficiency

  • SW cache layer**
  • QoS for RBD and background operations
  • S3 object policy driven tiering**

Built On

  • Ceph Pharaoh release
  • SUSE CaaS Platform
  • SUSE Linux Enterprise Server 15 SP2

Manageability

  • AIOPS driven self management
  • Phone home with consulting services
  • Self-healing PG

Interoperability

  • Hyper-converged SDI infrastructure
  • RDMA back-end**
  • NVMe over fabrics

Efficiency

  • Data deduplication
  • Crimson performance optimization

Built On

  • Ceph Octopus release
  • SUSE CaaS Platform
  • SUSE Linux Enterprise Server 15 SP1

Manageability

  • Kubernetes orchestration by Rook
  • Phone home analysis tools
  • Autonomous PG scaling
  • Self-healing PG**

Interoperability

  • Hyper-converged SDI infrastructure**
  • Containerized deployment
  • Native Windows client drivers
  • Node to node encryption
  • Multiple CephFS instances in one cluster
  • NFS-Ganesha active/active architecture

Availability

  • Bidirectional sync external cloud via S3
  • Asynchronous CephFS replication

Efficiency

  • SW cache layer
  • Crimson performance optimization**
  • S3 object policy driven tiering
  • QoS for RADOS

6 7 8

* Information is forward looking and subject to change at any time. 2020 8 ** Items are tech preview

slide-20
SLIDE 20

217 2018 2019 2021 2022

SUSE Enterprise Storage Management

5.5 6 7

Configure

  • Convert EC to replication (visa

versa)

Manage

  • RBD snapshot
  • OpenStack integration
  • Cluster rebuild progress
  • Admin node redundancy phase 1

Monitor

  • Event notification alerts**

5.5 Configure

  • iSCSI
  • NFS-Ganesha
  • Phone home
  • RBD QoS parameters
  • Background operation parameter (QoS)
  • RBD remote replication

Manage

  • Role-based Ceph dashboard
  • Localized Ceph dashboard
  • Ceph dashboard SSO (SAMLv2)
  • Crush map viewer
  • RBD snapshot

Monitor

  • Real-time performance metrics
  • Scale-out Prometheus monitoring
  • Event notification alerts
  • SNMP traps
  • Command audit log

Configure

  • Deploy new node to existing cluster

Manage

  • Automated upgrade process

Monitor

  • Ceph client performance

Diagnose

  • Guided troubleshooting
  • Guided OSD repair process

Configure

  • Deploy new OSD to existing node
  • CIFS/Samba
  • RGW and CephFS remote replication
  • Sync to external cloud
  • S3 object policy driven tiering

Manage

  • CephFS snapshot
  • Cluster topology map

Monitor

  • OSD and MDS statistics

Diagnose

  • Predictive disk failure analysis

6 7 8

* Information is forward looking and subject to change at any time. 2020 8 ** Items are tech preview

slide-21
SLIDE 21

218 218

SUSE Enterprise Storage Use Cases

slide-22
SLIDE 22

219

Backup to Disk Solution Custom Build

DIY with COTS Servers

Appliance HPC Storage Certified Reference Architectures Cloud & App Delivery

SUSE OpenStack Cloud Container as a Service

Analytics Custom Apps

SUSE Enterprise Storage

Classic Workloads Cloud Native Workloads

Data Protector

Use Case Focused Solutions

Partnership Ecosystem

Flexible Configs

File Sync and Share
