SUSE Enterprise Storage

143

SUSE Enterprise Storage

An intelligent software-defined storage solution, powered by Ceph technology, that enables IT to transform their enterprise storage infrastructure to deliver highly scalable and resilient storage that is cost-efficient and able to seamlessly adapt to changing business and data demands.

144

SUSE Enterprise Storage

Bridge to the Future

Today’s Data Center

• Traditional data center with storage silos
• Disparate network, compute and storage setup
• Data center disruptions because of regularly

changing technologies

Tomorrow’s Data Center

• Software-defined data center
• Agile infrastructure with support for DevOps model

through automation

• Simplified data center management
• Increased speed of delivery

SUSE Enterprise Storage is the first step in a software- defined future.

145

Code Developers

928

Core Regular Casual

28 64 833

Total downloads

305,973,127

Unique downloads

37,422,434

Client Servers (Windows, Linux, Unix)

RADOS (Common Object Store)

Block Devices

Server

Object Storage File Interface Storage Server Storage Server Storage Server Storage Server

Server Server

Storage Server Storage Server Applications File Share

OSD OSD OSD OSD OSD OSD

Network Cluster

MON

RBD iSCSI S3 SWIFT CephFS*

Monitors

MON MON

SUSE Enterprise Storage

Open Source Ceph as the Base

146 146

Why is SUSE Enterprise Storage Different?

147

What Makes SUSE Enterprise Storage Unique?

OpenATTIC

• GUI based configuration and management
• Graphical performance and capacity metrics
• Ability to drill down to per node performance

DeepSea Deployment Tool

• Collection of SALT files for deploying

SUSE Enterprise Storage

• 10 node or 10000 node fixed number
• f steps to deploy
• Deployment of Prometheus, Grafana

and openATTIC

148 148

How to Deploy SUSE Enterprise Storage

149

Steps to Deploy with DeepSea

salt-run state.orch ceph.stage.0 (prep) salt-run state.orch ceph.stage.1 (discovery) Edit proposal(s) and policy.cfg file salt-run state.orch ceph.stage.2 (configure) salt-run state.orch ceph.stage.3 (deploy core) salt-run state.orch ceph.stage.4 (deploy iscsi, rgw, mds, etc)

150

SUSE Enterprise Storage

Block Devices Object Storage File Interface

RBD SWIFT CephFS*

After Deployment We Have :-

iSCSI S3 CephFS*

NFS HTTP

151

SUSE Enterprise Storage

Block Devices Object Storage File Interface

RBD SWIFT CephFS*

Layering on the Environments

iSCSI S3 CephFS*

NFS LINUX LINUX

VMWARE Windows KVM Hyper-V

Containers Containers Containers

HTTP

152 152

Demo!

153 153

Roadmap

154 2017 2018 2020 2021 v4 v5 v6

Built On

• Ceph Luminous release
• SUSE Linux Enterprise Server 12 SP3

Manageability

• penATTIC phase 2

‐ Grafana monitoring dashboard ‐ Prometheus event alert - email

• DeepSea (Salt) phase 2

‐ Online Filestore to BlueStore Interoperability

• NFS Ganesha
• NFS access to S3 buckets
• CIFS Samba**
• CephFS Multi MDS support

Availability

• Erasure coded block and file

Efficiency

• BlueStore back-end
• Data compression

5 Built On

• Ceph Luminus release
• SUSE Linux Enterprise Server 12 SP3

Manageability

• Internationalization
• Usability enhancements
• Predefined profiles
• Autonomous data balancer**
• DeepSea (Salt) phase 3

Interoperability

• Non SUSE RBD and CephFS clients
• CIFS/Samba
• AppArmor security module

Availability

• Multisite RADOSGW N+1 with N/N-1

Efficiency

• BlueStore/RocksDB optimizations

Built On

• Ceph Octopus release
• SUSE Linux Enterprise Server 15 SP2
• SUSE CaaS Platform**

Manageability

• Integration with Rook + Kubernetes**
• Automatic metric reporting phase 2
• Self-healing PG
• Autonomous PG determination

Interoperability

• Containerized deployment**
• RDMA back-end
• Native Windows client drivers

Availability

• Asynchronous file replication

Efficiency

• Data deduplication
• SW cache layer
• OSD Daemon optimizations

Built On

• Ceph Nautilus release
• SUSE Linux Enterprise Server 15 SP1

Manageability

• Ceph-Mgr dashboard (oA replacement)
• Ceph-Mgr dashboard localized
• Ceph-Mgr dashboard SSO (SAMLv2)
• Automatic metric reporting phase 1
• CephFS directory quotas

Interoperability

• IPv6
• RDMA back-end**

Availability

• Sync to external cloud via S3
• CephFS snapshots
• Asynchronous file replication**

Efficiency

• QoS for RBD
• Background operation QoS

5.5 6 7

2019 v7

SUSE Enterprise Storage

** Items are tech preview * Information is forward looking and subject to change at any time.

155

Install

• Import unmanaged SUSE Enterprise

Storage cluster

Configure

• Online Filestore to BlueStore

Manage

• Deploy, configure, assign nodes
• iSCSI target management
• RGW users, buckets, keys
• View, create, delete CephFS
• NFS Ganesha gateway

Monitor

• Grafana dashboards
• CephFS status

Diagnose

• OSD health status
• Configure
• Convert EC to replication (visa versa)
• Manage
• RBD snapshot
• OpenStack integration
• Cluster rebuild progress
• Admin node redundancy phase 1
• Monitor
• Event notification alerts**

Configure

• Deploy new OSD to existing node
• CIFS/Samba setup
• Remote replication setup
• Sync to external cloud setup
• Automatic metric reporting setup

Manage

• CephFS snapshot
• Cluster topology map
• Guided upgrade process

Monitor

• OSD and MDS statistics
• Ceph client performance

Diagnose

• Predictive disk failure analysis
• Guided troubleshooting
• Guided OSD repair process

Manage

• OSD management
• Cluster configuration management
• Graceful system shutdown
• Role-based Ceph-Mgr dashboard
• Storage enclosure integration
• RBD QoS parameters
• Background operation parameters

Monitor

• Real-time performance metrics
• Scale-out Prometheus monitoring
• Event notification alerts
• SNMP traps
• Command audit log

2017 2018 2020 2021 v4 v5 v6

5 5.5 6 7

2019 v7

SUSE Enterprise Storage—Management

** Items are tech preview * Information is forward looking and subject to change at any time.
