ADIT Enterprise is a wholesale distribution business providing complete range of Electronic Security Systems

Kamlesh 093232 51184

Fire Alarm & Detection Systems

Adit Enterprise Adit Enterprise Adit Enterprise Adit Enterprise

3

Fire Alarm

Addressable Fire Alarm System Conventional Fire Alarm System

4

Beam Detector Heat Detector Multi Sensor Detector Smoke Detector Manual Call Point Siren

5

Conventional Fire Alarm System

6

Features: Different types of panels are available Single Zone, 2/4/8/12 Zone Conventional Fire Alarm Panel Both End of Line Resister and Active End of Line Can be used Day / Night Mode Selected Zone Isolate Control One Man Test, Key – Control evacuate Over- Ride Repeater Output Available Fire Alarm Output for Remote Alarm Active EOL enables multiple alarm reporting from same zone Active EOL max 15 fire detectors and infinite manual buttons each zone Resistor EOL up to 25 detectors and infinite manual buttons each zone

Conventional Two Zone Fire Alarm Panel.

7

Technical S echnical Specif pecificat cations ions

Power Supply: 230 V AC 50 / 60 Hz Operating Environment: Temperature: 0 ~ + 40°C Relative humidity: 95% Dimensions: 210 mm × 297 mm × 90 mm

8

Conventional 4 Zone Fire Alarm Panel Feat Featur ures es :

Resistor EOL up to 25 detectors and infinite manual buttons each zone * Active EOL max 15 fire detectors and infinite manual buttons each zone * Active EOL enables multiple alarm reporting from same zone * Fire Alarm Output for Remote Alarm * Repeater Output Available * Key – Control evacuate Over- Ride * One Man Test * Zone Isolate Control * Day / Night Mode Selected * Both End of Line Resister and Active End of Line Can be used * 4 Zone Conventional Fire Alarm Panel *

9

Technical S echnical Specif pecificat cations ions

Dimensions: 210 mm × 297 mm × 90 mm * Operating Environment:

• Temperature: 0 ~ + 40°C
• Relative humidity: 95%

* Power Supply: 230 V AC 50 / 60 Hz *

10

Conventional Optical Smoke Detector (C-9102R)

EN54 Compliance * Removable Optical Chamber Foe Easy Cleaning and maintenance * Twin LED for 360° Vision * Aesthetically pleasing low profile design with Remote Indicator Output * Dimensions: Diameter: 100 mm; Height: 50 mm * Operating environment:

• Temperature:- 10 ~ + 50°C
• Relative humidity: 95%

* Operating current:

• Standby current: 0.06 mA
• Alarm current: 30 mA

* Operating voltage: 24 V Loop * Standard : EN54 – Part 7 *

Feat Featur ures es : Technical S echnical Specif pecificat cations ions

11

Conventional Dual Heat Detector (C-9103R) Feat Featur ures es : Technical S echnical Specif pecificat cations ions

8 Bit Intelligent Processor * Twin LED for 360° Vision * Aesthetically pleasing low profile design * Fixed Temperature and Rate of rise Heat Detection with Remote Indicator Output * Dimensions: Diameter: 100 mm; Height: 50 mm * Operating environment: Temperature:- 10 ~ + 50°C Relative humidity: 95% * Operating current: Standby current: 0.06 mA Alarm current: 30 mA * Operating voltage: 24 V Loop * Standard : EN54 – Part 5 *

12

Feat Featur ures es : Conventional Multi Sensor (C-9101)

8 Bit Intelligent Processor * Ideal alternative to lonization detector * Heat Detector provide to the ultimate cover for life safety systems * Fixed Temperature and Rate of rise Heat Detection * EN54 Compliance * Removable Optical Chamber Foe Easy Cleaning and maintenance * Twin LED for 360° Vision * Aesthetically pleasing low profile design *

13

Technical S echnical Specif pecificat cations ions

Dimensions: Diameter: 100 mm; Height: 50 mm * Operating environment:

• Temperature:- 10 ~ + 50°C
• Relative humidity: 95%

* Operating current:

• Standby current: 0.06 mA
• Alarm current: 30 mA

* Operating voltage: 24 V Loop * Standard : EN54 – Part 5 ; Part 6; Part 7 *

14

Feat Featur ures es:

Compatible with latest EN standards. Non-breaking re-settable glass (via special key). Two parts plug-in construction with base mounted termination allows easy installation and connection.

Technical S echnical Speci pecificat cations ions:

Operating voltage: Loop 24V Stand by Current – 0 mA Alarm Current : 30 mA N/O Output Contact: Rating Value 60VDC, 0.1A Contact Resistance 100m Ohms Operating environment: Temperature:- 10 ~ + 50°C Relative humidity: 95% Dimension: 95 mm × 98 mm × 40 mm

Conventional Manual Call Point (C-9202)

15

Conventional Sounder Beacon (C-9401) Feat Featur ures es:

Two part plug-in construction with base mounted termination allowing easy installation and connection * Conventional combined flashing high intensity LED beacon and sounder *

Technical S echnical Specif pecificat cations ions

Dimensions: 144 mm × 90 mm × 57 mm * Operating environment:

• Temperature:- 10 ~ + 50°C
• Relative humidity: 95%

* Wiring: two-core polarized * Alarm volume (SPL): 95dB @1 Meter. * Operating current:

• Stand By current: 0
• Alarm current 160 mA

* Operating voltage: Loop 24V Polarized *

16

Addressable Fire Alarm System

17

Feat Featur ures es:

Single loop addressable fire detection panel packed with features not usually associated with smaller systems, providing a high quality solution at exceptionally good value. Loop capacity 235 intelligent devices Graphical LCD Display 30 Zone indication and manual intervention panel Net-workable with all GST fire panels, Programmable from PC Built-in Gas Extinguishing Control Integrated Security Alarm Facilities Optional Colour Graphics, Optional Panel Printer Optional Fireman’s Control Panel Advanced user friendly programming software including ‘Fuzzy Logic’

Intelligent Single Loop Fire Alarm Panel

18

Technical S echnical Specif pecificat cations ions

Operating Voltage: 230 V AC 50/60 Hz Temperature: 0 ~ + 40°C Relative Humidity: 95% Dimensions: 400 mm × 560 mm × 178 mm

19

Feat Featur ures es : Intelligent Optical Smoke Detector (I 9102R)

Removable optical chamber for easy cleaning and maintenance * Sensitivity adjustable via hand held programming tool * Twin LED’s for 360 degree vision * Electronically addressed * Built in algorithm maps for false alarm rejection * 8 Bit intelligent processor with A/D converter * Aesthetically pleasing low profile design *

20

Technical S echnical Specif pecificat cations ions

Dimensions: Diameter: 10cm Height: 5cm * Operating environment: Temperature:- 10 ~+ 50°C Relative humidity: 95% * Operating current: Standby current: 0.8 mA Alarm current 2mA * Operating voltage: Loop 24V *

21

Intelligent Dual Heat Detector (I 9103R) Feat Featur ures es :

Twin LED’s for 360 degree vision * between 54°C and 80°C * Fixed Temperature response is adjustable via hand held programming tool * Electronically addressed * 8 Bit intelligent processor with A/D converter * Aesthetically pleasing low profile design * Fixed Temperature and Rate of Rise Detection * Dual Heat detector as above with remote indicator output *

22

Technical S echnical Specif pecificat cations ions

Dimensions: Diameter: 10cm Height: 5cm * Detector Class: A1R * Operating environment:

• Temperature:- 10 ~ + 50°C
• Relative humidity: 95%

* Operating current:

• Standby current: 0.8 mA
• Alarm current 2 mA

* Operating voltage: Loop 24V *

23

Feat Featur ures es : Intelligent Multi Sensor(I-9101)

Adjustable Smoke Detection Sensitivity by Handhold Programmer * Ideal alternative to Ionisation detectors. * Combining all the features of the I-9102 Optical and the I-9103 Dual Heat Detector to provide the ultimate cover for life safety systems. *

Technical S echnical Specif pecificat cations ions:

Dimensions: Diameter: 10cm Height: 5cm * Field Programmable Sensitivity: 0.1 dB / m ~ 0.56dB / m-3 levels * Operating environment:

• Temperature:- 10 ~ + 50°C
• Relative humidity: 95%

* Operating current:

• Standby current: 0.8 mA
• Alarm current 2 mA

* Operating voltage: Loop 24V *

24

GST Duct Probe (DP-9100) Feat Featur ures es :

Compatible with GST addressable and conventional detectors. * Sampling pipes 250mm to 800mm in length (can be cut to size). * Lid removal raises fault indication at panel. * Pre-wired detector base * Easy maintenance as detector is mounted externally to the duct. * Duct probe housing for detection of smoke by sampling moving air inside the duct. *

25

Addressable Sounder Beacon (I-9401) Feat Featur ures es :

Two part plug-in construction with base mounted termination allowing easy installation and connection * Conventional combined flashing high intensity LED beacon and sounder *

Technical S echnical Specif pecificat cations ions

Dimensions: 144 mm × 90 mm × 57 mm * Operating environment:

• Temperature:- 10 ~ + 50°C
• Relative humidity: 95%

* Wiring: two-core polarized * Alarm volume (SPL): 95dB @1 Meter. * Operating current:

• Stand By current: 0
• Alarm current 160 mA

* Operating voltage: Loop 24V Polarized *

26

Addressable Sounder and Strobe (I-9403) Feat Featur ures es :

Electronically addressed. * Strobe provided by high intensity LED cluster * Remote start input can be used to co-operation with other systems. * Evacuate only or Alert/Evacuate mode can be set through handheld programmer. * Two parts construction with base mounted termination allows easy installation *

27

Technical S echnical Specif pecificat cations ions

Dimensions: 110 mm (D) × 97.5 mm (H) * Operating environment:

• Temperature:- 10 ~ + 50°C
• Relative humidity: 95%

* Wiring:

• Non-polarized two-core for loop
• Non-polarized two-core for 24VDC power supply

* Sounder Output 94dB @ 1 Meter * Operating current:

• Loop: Standby current – 1 mA; Alarm Current – 5 mA
• Power Supply: Standby Current – 3 mA , Alarm current 65

mA * Operating Voltage: Loop 24V, 24 V DC Power Supply *

28

Our company, ADIT Enterprise, is a professional, distinguished Distribution Company in the Electronic surveillance industry, a leading company in the Indian Industry for full range of CCTV solutions, Public Announcement System Fire Alarm Systems, Time Attendance & Access Control System, Hotel Automation System and others also. Continuously for 24 hours & 365 days our Technical team is developing and looking for new products with latest technology and latest fashion design to meet changing market requirements.

29

Contact Us : Web : www.aditgroup.com E Mail: info@aditgroup.com
