Common Maintenance Problems what to look for and how to avoid them www.underoneroof.scot Climate wind, rain temperature and Climate Change. Our winters are getting much wetter ITS IMPORTANT TO KEEP YOUR BUILDING DRY. This is not just a

slide-1
SLIDE 1

Common Maintenance Problems what to look for and how to avoid them

www.underoneroof.scot

slide-2
SLIDE 2

Climate – wind, rain temperature and Climate

  • Change. Our winters are getting much wetter
slide-3
SLIDE 3

This is not just a case of fixing holes in the roof but keeping walls dry. Why?

IT’S IMPORTANT TO KEEP YOUR BUILDING DRY.

slide-4
SLIDE 4

How tenements were built..

How tenements were built..

slide-5
SLIDE 5

No scaffolding – joists inserted directly into stone walls and used as working platform

How tenements were built..

slide-6
SLIDE 6

“H” Frames

slide-7
SLIDE 7

Timber frames used to support joists at mid point during build. These are load bearing – moving doors is tricky! http://www.underoneroof.s cot/articles/1016

slide-8
SLIDE 8

Look out for timber stiffeners used particularly in upper walls http://www.underoneroof.scot/articles/1016

slide-9
SLIDE 9

Wet walls lead to damp and rot in structural joist ends

slide-10
SLIDE 10

Rot in joists can lead to major structural problems

slide-11
SLIDE 11

Large one piece joists span front to back and tie in the walls

slide-12
SLIDE 12
slide-13
SLIDE 13

Removal of roof ties to create dormers can lead to additional pressure on joist ends

slide-14
SLIDE 14

Walls at first floor carrying weight of walls above are very vulnerable if joist ends rot.

http://www.underoneroof. scot/articles/997/

slide-15
SLIDE 15

Case study – note bulge

slide-16
SLIDE 16

Case study - then a high wind came along

slide-17
SLIDE 17

Case Study – the building today

slide-18
SLIDE 18

Was the cause of collaps the high winds

  • r rotten joist ends – insurance

implications

slide-19
SLIDE 19

Dampness in walls can lead to rot in inner timber safe lintol leading to cracked external stone lintol

slide-20
SLIDE 20

Steel angle lintol repair

slide-21
SLIDE 21

Better looking solution – indenting new stone lintel

slide-22
SLIDE 22

Dampness can also affect bay and oriel windows badly

slide-23
SLIDE 23
slide-24
SLIDE 24
slide-25
SLIDE 25

Oriels are pinned with metal cramps that can rust

http://www.underoneroof.scot/articles/1155/

slide-26
SLIDE 26
slide-27
SLIDE 27

Stone falls and expensive repairs result

slide-28
SLIDE 28
slide-29
SLIDE 29

Oriels are often supported by iron pieces

slide-30
SLIDE 30
slide-31
SLIDE 31
slide-32
SLIDE 32

Joists behind oriel windows are supported by a large timber “Bressumer” beams http://www.underoneroof.scot/articles/1348/

slide-33
SLIDE 33
slide-34
SLIDE 34
slide-35
SLIDE 35

Rot in Bressumer beam ends

slide-36
SLIDE 36

Replacing timber Bressumer beam with steel

slide-37
SLIDE 37

Rot in joist ends under leaking gutter

slide-38
SLIDE 38

Replacement of rotten roof timbers caused by gutter problems

slide-39
SLIDE 39

Keeping walls dry starts at gutter level

slide-40
SLIDE 40

Cute, but birdlife can be a problem…

slide-41
SLIDE 41

Bird guano drains into gutters…

slide-42
SLIDE 42
slide-43
SLIDE 43
  • Roofs: guano provides nutrients for plant growth

Guano provides nutrients for plant growth

slide-44
SLIDE 44
slide-45
SLIDE 45

TO KEEP WALLS DRY YOU NEED TO: ensure gutters and downpipes flow free

slide-46
SLIDE 46

Different gutter types http://www.underoneroof.scot/articles/1293/

slide-47
SLIDE 47

Cast iron gutters – need painting front and back

slide-48
SLIDE 48

Cast iron gutters – replacement mouldings are available

slide-49
SLIDE 49

Cast iron gutters have strength to cope with snow etc http://www.underoneroof.scot/articles/1290/

slide-50
SLIDE 50

50

slide-51
SLIDE 51

Parapet gutters: problems may be hidden http://www.underoneroof.scot/articles/985/

slide-52
SLIDE 52

Outlets and overflows need to be large enough for heavy downpours and kept clear

slide-53
SLIDE 53

Collapse partially caused by weight of water in gutter during heavy rain storm

slide-54
SLIDE 54
slide-55
SLIDE 55
slide-56
SLIDE 56

Lead lined stone gutter: note how it should be taken up well under slates and underfelt http://www.underoneroof.scot/articles/1295/

slide-57
SLIDE 57

Stone Gutter with raised lip to cope better with rainstorms

slide-58
SLIDE 58

Stone Gutter with raised lip - as built

slide-59
SLIDE 59

Central valley gutter – more hidden problems http://www.underoneroof.scot/articles/1318/

slide-60
SLIDE 60

Central valley gutters have internal downpipes

slide-61
SLIDE 61

Central valley gutter with overflow – again ensure

  • utlets and overflows are kept clear
slide-62
SLIDE 62
slide-63
SLIDE 63

Maintenance Regime

clean annually (bird shit, leaves) paint iron every 5 years replace gutters when rusty or when loose increase capacity of shallow gutters

slide-64
SLIDE 64

Open joints allow plants to grow, roots dislodge stone

slide-65
SLIDE 65

Downpipes also need to be maintained http://www.underoneroof.scot/articles/983

slide-66
SLIDE 66
slide-67
SLIDE 67

Other ways to keep walls dry

External walls generally: http://www.underoneroof.scot/articles/1020/ Stone defects: http://www.underoneroof.scot/articles/986 Pointing: http://www.underoneroof.scot/articles/1349/

slide-68
SLIDE 68

seeds land in open joints, roots dislodge stones:

slide-69
SLIDE 69

Allow walls to breathe so they can dry out.

slide-70
SLIDE 70
slide-71
SLIDE 71

cement pointing also leads to stone decay as moisture cannot escape though cement and escapes instead through face of stone

slide-72
SLIDE 72
slide-73
SLIDE 73

External stone wall construction – sandwich with dressed stone exterior, rubble middle

slide-74
SLIDE 74

When the stone is constantly soaked, frost attacks

slide-75
SLIDE 75

For the same reason, old cement base linostone repairs cause more decay

slide-76
SLIDE 76
slide-77
SLIDE 77

External wall repairs - indenting stone

slide-78
SLIDE 78

External wall repairs - indenting stone

slide-79
SLIDE 79

79

External wall repairs - new stone cill

slide-80
SLIDE 80

–

slide-81
SLIDE 81

External wall repairs – lime based Lithomex ‘plastic’ repair

slide-82
SLIDE 82

Protecting walls at ground level – don’t allow slate DPCs to be bridged by soil build up http://www.underoneroof.scot/articles/1163

slide-83
SLIDE 83

Ground floor joists vulnerable to rising damp

slide-84
SLIDE 84

Prevention – keep the solum ventilated

slide-85
SLIDE 85

Roof level repairs

Slate roofs: http://www.underoneroof.scot/articles/1245 Tiled Roofs: http://www.underoneroof.scot/articles/1164 Flat roofs: http://www.underoneroof.scot/articles/1165 Ridges: http://www.underoneroof.scot/articles/1007 Flashings: http://www.underoneroof.scot/articles/1286 Chimneys and chimneyheads: http://www.underoneroof.scot/articles/1350

slide-86
SLIDE 86
slide-87
SLIDE 87
slide-88
SLIDE 88

Slates can be moved to allow replacement of breakages

slide-89
SLIDE 89

Using a slate ripper to move slates

slide-90
SLIDE 90

Ensure breathable felt is used when roof replaced

slide-91
SLIDE 91

New slate roof – larger slates at bottom, smaller slates at top

slide-92
SLIDE 92

Lead is long lasting but needs proper

  • installation. This roof has inadequate overlaps

http://www.underoneroof.scot/articles/1242

slide-93
SLIDE 93

Flat roofs: lead needs to expand or cracks develop

slide-94
SLIDE 94

Flat roofs need ventilation to prevent condensation damp

slide-95
SLIDE 95
slide-96
SLIDE 96

Ridges - help secure the top rows of slates

slide-97
SLIDE 97
slide-98
SLIDE 98

Ridges – also protect the ridge pole from rot

slide-99
SLIDE 99
slide-100
SLIDE 100

Flashings – lead is recommended because of its long life

slide-101
SLIDE 101

Flashing: a skew covered in lead

slide-102
SLIDE 102

Flashing: skew partially covered in lead

slide-103
SLIDE 103

Flashings - Lead may be too thin or badly formed

slide-104
SLIDE 104

Chimneyheads: highly exposed and at risk from flue gases

slide-105
SLIDE 105

Chimneyheads: old repairs often cause high risk

slide-106
SLIDE 106

Chimneyheads – testing for loose render by tapping

slide-107
SLIDE 107
slide-108
SLIDE 108

Chimneyheads – flue and fuel gases cause decay

slide-109
SLIDE 109

Chimneys: Individual flues

slide-110
SLIDE 110

Chimneys - Individual flues are kept separate by bridges

slide-111
SLIDE 111

Close and stairs

http://www.underoneroof.scot/articles/993

slide-112
SLIDE 112

Separation cracks in closes – heavy outer walls sink more than lighter inner walls

slide-113
SLIDE 113

More signs of movement in close

slide-114
SLIDE 114

Solution – installing ties between inner close walls and exterior walls

slide-115
SLIDE 115

cast iron railings provide strength to stairs

slide-116
SLIDE 116

Individual stair treads can move

slide-117
SLIDE 117

Open treads may need strengthened

slide-118
SLIDE 118

Open treads danger of sudden collapse

slide-119
SLIDE 119

Ironwork

Not just decorative Important safety protection http://www.underoneroof.scot/articles/1563/

slide-120
SLIDE 120

Ironwork – rusting can split stone

slide-121
SLIDE 121

Ironwork – railings in this condition gave way when someone leant against them and fell into basement and was injured – upcoming court case?

slide-122
SLIDE 122

Noise

http://www.underoneroof.scot/articles/1211/

slide-123
SLIDE 123

Noise through floors can be due to a lack of deafening where it has not been replaced following repairs or where there are gaps at the wall edge http://www.underoneroof.scot/articles/1167/

slide-124
SLIDE 124

“Flanking” sound can also be a problem where noise travels through inner spine walls

slide-125
SLIDE 125

Noise can also travel through the thin walls of presses. These were often left

  • pen during the

build to allow workers access. People have been known to break in through them!
