Biogas Asia Pacific Forum Kuala Lumpur, April 2015 Gas Purification, Separation & Filtration Global presence, with headquarters in Montreal, Canada Toronto Stock Exchange (TSXV: XBC) Markets Who we are Strategy Focus Leverage key

slide-1
SLIDE 1

Biogas Asia Pacific Forum

Kuala Lumpur, April 2015

slide-2
SLIDE 2

www.xebecinc.com

Gas Purification, Separation & Filtration

Leading designer, manufacturer and

  • perator of gas purification,

separation and filtration systems for crude-derived fuels displacement

  • Biogas
  • Natural Gas
  • Associated Gas
  • Hydrogen
  • Helium

Global presence, with headquarters in Montreal, Canada Toronto Stock Exchange (TSXV: XBC)

2

Who we are Markets Focus Strategy

2 Leverage key technological advantages into long term customer relationships to grow sales and profitability

slide-3
SLIDE 3

www.xebecinc.com

Blainville (QC) Vancouver (BC) Shanghai Singapore

3 Headquarters in Blainville (QC) Manufacturing and Sales R&D in Blainville (QC) Customer support Office in Vancouver (BC) Manufacturing and Sales in Shanghai Bireme Ltd. in Singapore Sales & Engineering Office in Houston, Texas

Ability to gain business and service customers worldwide

International Presence

Houston (TX)

slide-4
SLIDE 4

www.xebecinc.com 4

Biogas Upgrading Technology TSA Technology for NGV refueling stations

  • Rapidly growing market
  • High recovery, high purity,

low energy plants

  • Key Customers: Sempra,

Montauk Energy, Halla, FortisBC, Golden Green, Sirim, SKS,

  • Growing market
  • Cost leadership through

Chinese manufacturing

  • Key Customers: Clean

Energy, Petrochina, Sinopec, Shell, Angi Energy, Greenfield,

PSA Technology for H2, He, CH4, CO

Business Segments

  • Growing market segment
  • Market-leading performance

for small & medium capacity purifiers

  • Syngas purification
  • Key Customers:

HydroChem, Haldor Topsoe Air Liquide, Linde, Iwatani

Membrane Technology – CH4, CO2 H2, He, N2

  • High recovery, high purity,

high selectivity & flux

  • CH4, H2, He, N2, CO

Biogas

  • Key Customers: Weil

Group, Apache Rapidly evolving market

slide-5
SLIDE 5

Technology and Products

slide-6
SLIDE 6

www.xebecinc.com 6

Pressure Swing Adsorption and Membranes

Pure Innovation™

  • 50 years of dedicated development in adsorption based gas

purification, separation and filtration

  • Complete proprietary product line with respect to rotary valves, and

fast cycle adsorption processes

  • Integration of membranes into overall system designs
  • Strong process capabilities in gas purification, separation & filtration
  • Ongoing development of next generation purification products,

especially membrane and hybrid systems

  • Current adsorption technology is applicable to all products segments

and is being augmented with membrane technology

  • Continued R&D activity with multiple Universities and Research

Institutes, focused on improved recovery and purity, while reducing costs

Xebec H2X unit installed at ExxonMobil refinery in 2007

Xebec Technology

Xebec’s membrane module for BGX biogas upgrading

slide-7
SLIDE 7

www.xebecinc.com 7

Solutions for Landfill and Digester Gas

 Complexity reduction ► One-step fast cycle multi-bed kPSA technology separates H2O/CO2/N2/O2 from landfill gas to produce biomethane product ► Superior compared against conventional two-step membrane + PSA  Greatly enhanced product recovery: ► 92% (1-step) vs. 81% (2-step) = 13% more product to sell  Xebec utilizes hollow fiber membranes which are made of high-performance polymers which display excellent durability and longevity.  Designed specifically for carbon dioxide and methane separation and ideally suited for biogas upgrading, where no N2 and O2 is present in the feed gas.  This results in a methane recovery of over 99,5% and a methane slip of less than 0.5%.

Landfill Gas – PSA Solutions Digester gas – Membrane Solutions

slide-8
SLIDE 8

www.xebecinc.com

Products

Biogas Upgrading (BGX) Natural Gas Drying (NGX) Hydrogen (H2X) Associated Gas (AGX)

8

Rumpke Landfill in Ohio, US MTA, Orange County HydroEdge ,liquid H2 plant, Japan Venoco Off-Shore Oil Platform Hilarides Dairy, California Trillium, California MKK, Japan PXP Oil Well, California

slide-9
SLIDE 9

Biogas Upgrading

slide-10
SLIDE 10

www.xebecinc.com

Biogas Value Chain

10

slide-11
SLIDE 11

www.xebecinc.com 11

Process Flow Diagram

Xebec’s core M-3200 Purification unit Xebec’s Containerized Small Scale BGX-30 with CNG option Xebec’s BGX-30 with CNG compression and storage

slide-12
SLIDE 12

www.xebecinc.com

BGX – Small Scale Biogas Upgrading

 Standard containerized sizes for 30, 60 125, and 250 SCFM Biogas Flows  Zero emissions with micro-turbine  Plug and Play - Fast Installation  Integrated Control Room  Dry Purification Process, i.e.:

  • No process water /no water treatment
  • No waste water treatment
  • No chemicals

 No bacterial contamination  Integrated drying/dew point < - 40ºC (compliant with CNG specifications SAEJ1616 specification)  No heat requirement  No corrosive gas atmosphere  24/7 Hotline Product Support

BGX-30 integrated control room High pressure CNG storage

slide-13
SLIDE 13

www.xebecinc.com

BGX – A Wide Range Of Options

 Optional H2S and / or Siloxane Removal  Optional Zero-Emission system with integrated Mircoturbine – no flare required  Optional integrated CNG compression, storage and dispensing station  Optional Product Flow meter  Optional Flare/Burner  Optional Xebec Leasing and Financing (EDC)

Optional H2S removal Containerized CNG fuel option Microturbine option for electricity generation Mobile flare for start-up and maintenance with microturbine option

13

slide-14
SLIDE 14

www.xebecinc.com

BGX Production Capacity

System size NCMH

BGX 50 BGX 100 BGX 200 BGX 400

Power usage

HP

25 40 75 145

Optional turndown 40 – 60% Methane recovery* 85 – 99% Fleet served

Pick-ups Heavy trucks

CNG Production

GLE/yr

257,000 510,000 1,077,000 2,150,000 20 40 82 164 2 4 8 16

Power cost

$/yr

10,000 17,000 33,000 66,000

*Methane recovery dependent on recovery option

Displacing diesel fuel with cleaner renewable natural gas is the most viable economic solution.

slide-15
SLIDE 15

www.xebecinc.com 15

U.S. DOE estimates 25% of all diesel fuel could be replaced by renewable gas

Impact on GHG Emissions

Source: German Energy Agency

slide-16
SLIDE 16

Selection Considerations

slide-17
SLIDE 17

www.xebecinc.com 17

End-Use Considerations Heat Electricity Upgrading

CNG Injection into Pipeline

Combination of Power & Upgrading

Choose the Right End-Use Option

slide-18
SLIDE 18

www.xebecinc.com 18

Operational Considerations Technology Recovery Availability Operational Costs Local Support & Service

Five important considerations that will impact your bottom line

slide-19
SLIDE 19

www.xebecinc.com 19

What about Capex? Less than you think Do your financial model Consider the right end- use (highest earnings) Get the right financing Include a 10% to 20% contingency. Be conservative

How important is Capex?

slide-20
SLIDE 20

Case Studies and References

slide-21
SLIDE 21

www.xebecinc.com 21

Location: Trifyl, France Developer: Verdemobil Biogas Feed: Landfill Gas Raw Biogas: 52% CH4 ~250 Nm3/h End-use: CNG for Refuse Trucks H2 for municipal vehicles Start-up date: 2011 to CNG 2013 to Hydrogen

Case Study – LFG to CNG and Hydrogen

First Landfill Gas to Renewable Hydrogen Worldwide

slide-22
SLIDE 22

www.xebecinc.com 22

Location: Southern California, US Developer: Sempra Utilities Biogas Feed: Waste Water Plant Raw Biogas: 58% CH4 ~360 Nm3/h End-use: Test/Pipeline Pipeline Operator: Southern California Gas Start-up date: 2011

Case Study – Waste Water Treatment

slide-23
SLIDE 23

www.xebecinc.com 23

Location: Seoul, South Korea Developer: Halla Environmental Biogas Feed: Food Waste Digester Raw Biogas: 60% CH4 ~650 Nm3/h End-use: CNG for Refuse Trucks Start-up date: 2011

Case Study – Mixed Waste to CNG

slide-24
SLIDE 24

www.xebecinc.com 24

Location: Inwil, Switzerland Operator: Swiss Farm Collective Biogas Feed: Farm Waste Digester / Food Waste Raw Biogas: 52% - 56 CH4 ~140 scfm / 225 Nm3/h End-use: Injection into local pipeline,

  • nsite heat and electricity

Owner: Swiss Farm Collective Start-up date: 2008

Case Study – Swiss Farm Collective

slide-25
SLIDE 25

www.xebecinc.com

1,400 NCMH PSA System, 2013 Daegu, South Korea, Municipal Digester

Other Xebec References

25

slide-26
SLIDE 26

www.xebecinc.com 26

10,000-15,000 NCMH PSA System, 2007 Rumpke Landfill, Cincinnati

Other Xebec References

slide-27
SLIDE 27

www.xebecinc.com

Project Location Biogas Source End-Use

2006 - 2009 Scenic View Dairy MI, US Digester Pipeline Rumpke Landfill OH, US Landfill Pipeline Widnau Switzerland Digester Pipeline Lavigny Farm Switzerland Digester Pipeline UNH NH, US Landfill Turbine SKS Austria Digester CNG Swiss Farmer Switzerland Digester Pipeline STEP Switzerland Digester Pipeline Hilarides Dairy CA, US Digester CNG Daesung Seoul, Korea Landfill CNG/LNG SKS Austria Digester CNG 2010 - YTD Sempra Energy CA, US Waste Water Pipeline Halla Engineering Seoul, Korea Digester CNG SKS Austria MSW Pipeline SKS Austria MSW Pipeline SKS Austria Waste Water CNG Verdemobil France MSW CNG Potlach Korea Digester CNG Loongas China Digester CNG FortisBC Canada Landfill Pipeline Golden Green China Landfill CNG

Biogas Upgrading Installations

27

Escondido, California - Waste Water Treatment Plant gas to pipeline 2011 Salmon Arm, British Columbia - landfill gas to pipeline - 2012

slide-28
SLIDE 28

www.xebecinc.com

Reliable and Simple Technologies (PSA and Membrane systems, robust and proven rotary equipment and valves)

Excellent Process Capabilities (CO2, N2, O2, H2S, H2O, VOCs, Siloxanes etc., ability to deal with varying feed gas qualities, while maintaining product gas specifications)

Flexible Designs (Plants designed for your needs, recovery and gas purity rates tailored to your needs, variable CH4 percentages in the exhaust gas for use in engines, boilers, turbines, etc.)

Complete Reference List (for all types of biogas - landfill gas, food digesters gas, organic farm waste gas, POME gas, mixed waste gas, waste waster treatment plant gas)

Full Aftermarket Support (Service and Parts support in the markets we

  • perate in) Experienced Local Support in South East Asia.

Remote monitoring (via internet/satellite)

Financing through EDC (for qualified buyers)

28

Why Chose Xebec for your upgrading Project Xebec your Technology Provider

slide-29
SLIDE 29

www.xebecinc.com

Natural Gas, CNG and Biogas Filtration

29

Low Pressure XL Series

20 BarG / 290 PSIG Volume Flow Rate: 70 to 3500 Nm3/h 40 to 2060 scfm Operating Temp: 0-80 C0 / 32-176 F0 (120 C0 elements are available) Port size : ¼” to 3” / 6mm to 75mm

Medium Pressure XM Series

50 BarG / 725 PSIG Volume Flow Rate: 450 to 22,300 Nm3/h 260 to 13,000 scfm Operating Temp: 0-80 C0 / 32-176 F0 (120 C0 elements are available) Port size: ½ ” to 3” / 13mm to 75mm

High Pressure XH Series

420 BarG / 6000 PSIG Volume Flow Rate: 800 to 11,200 m3/h 480 to 6560 scfm Operating Temp: 0-80 C0 / 32-176 F0 (120 C0 elements are available) Pipe size: ¼” to 2” / 6mm to 53mm www.xebecinc.com/products-natural-gas-filtration.php

slide-30
SLIDE 30

www.xebecinc.com

Thank you

Kurt Sorschak

President & CEO

+1.450.979.8701

ksorschak@xebecinc.com

Victor Han

Business Development Manager Biogas Upgrading Systems

+65.983.44865

victor.han@biremegroup.com
