Beyond-CMOS Technology Roadmap

An Chen Emerging Research Devices (ERD), ITRS

2

For slides, questions, and comments, please contact me at:

an.chen@globalfoundries.com

Outline

• Introduction
• Emerging logic devices

– CMOS extension vs. beyond-CMOS devices – Beyond-CMOS device assessment

• Emerging memory devices

– Emerging memory taxonomy and assessment – Promising emerging memories: STTRAM, RRAM, FeFET

• Emerging architectures

– Beyond von-Neumann architectures – Non-volatility information processing

• From scaling driver to function/application driver

– More-than-Moore: functional diversification

• Summary

3

Technology Innovations Driven by Scaling

4

• J. Y.C. Sun, VLSI Tech., T2 (2013)

Beyond-CMOS technologies

A Roadmap from ITRS PIDS

5

Courtesy of: Yuzo Fukuzaki, cited from M. Badaroglu, “More Moore scaling: opportunities and inflection points,” ERD Meeting: Bridging Research Gap between Emerging Architectures and Devices, Feb 27, 2015

?

“Energy Crisis” on Chip

• Scaling  increasing power density
• Low-power design and multi-core introduced
• Beyond-CMOS devices for low-power solution?

20 40 60 1970 1980 1990 2000 2010 2020

Power density (W/cm2) Year Suppliers: AMD, Intel, SPARC Symbol size = # of cores Courtesy of Jonas Wei-ting Chan, Andrew Kahng (UCSD)

Processor peak power density

Beyond-CMOS? Source: Bernard S. Meyerson (IBM)

6

ITRS Emerging Research Devices (ERD)

7

Emerging Research Devices

Emerging devices Memory Logic Emerging architectures More-than- Moore Emerging devices for RF Devices with learning capabilities New directions Sensor applications Security applications …..

• Low power
• Embedded NVMs
• Storage class memory
• A. Chen, J. Hutchby, V. Zhirnov, G. Bourianoff (Ed’s) “Emerging

Nanoelectronic Devices” (Wiley, Jan. 2015) http://www.wiley.com/WileyCDA/WileyTitle/productCd- 1118447743,subjectCd-EE13.html

ERD Methodology

• Selection

– Criteria to select technology entries to be added or removed in the

ERD chapter

– Transition of technology entries in and out of the chapter

• Categorization

– Categorize technology entries based on the types and mechanisms – Important considerations for materials, e.g., Si, III-V, carbon-based, 2D

materials, etc.

• Evaluation

– Conduct survey-based critical review among ERD experts – Reference to quantitative benchmark from research community

8

Outline

• Introduction
• Emerging logic devices

– CMOS extension vs. beyond-CMOS devices – Beyond-CMOS device assessment

• Emerging memory devices

– Emerging memory taxonomy and assessment – Promising emerging memories: STTRAM, RRAM, FeFET

• Emerging architectures

– Beyond von-Neumann architecturess – Non-volatility information processing

• From scaling driver to function/application driver

– More-than-Moore: functional diversification

• Summary

9

Emerging Logic Devices

Mechanism State variable Charge Non-charge Conventional Novel

Si FET SpinFET Spin wave NEMS TFET Atomic sw. Mott FET Neg-Cg Nanomagnet BiSFET All spin logic Ge & III-V CNT FET Graphene FET NW FET Spin-torque DW logic FinFET RTD SET QCA IMOS ExFET CMOS extension Charge, beyond-CMOS Non-charge, beyond-CMOS

• ITRS ERD categorizes emerging logic devices into three groups

based on state variables and mechanisms

10

CMOS Extension and Beyond-CMOS

Eb a

• New transport mechanisms
• New gating mechanisms
• New state variables

CMOS extension:

• New materials

 Strain, SiGe, Ge, III-V, CNT, …

• New structures

 FinFET, gate-all-around, … E.g., tunneling E.g., mechanical ferroelectric

Gate Source Drain

E.g., spin

Beyond-CMOS devices: new mechanism

• K. Kuhn, IEDM,

171 (2012)

A basic electronic switch model

11

Emerging Logic Device Survey

10% 15% 20%

Percentage of vote

Only showing devices with more than 10% vote  Most promising  Most need of resources

12

Carbon Nanotube (CNT) FET

13

Size-exclusion chromatography

Advantages:

• Scalability
• Ultra-thin body
• Ballistic transport
• Gate-all-around

Challenges:

• Purity, placement, density
• Variability
• Contact resistance
• NFET for CMOS

Rc

S.J. Han, ERD Emerging logic device assessment workshop. 2014

9nm Lch FET

Tunnel Field-Effect-Transistor (TFET)

14

Challenges:

• Improve Ion while keeping SS and Ioff low
• More stringent material, device, and fabrication

requirements

• Reduce interface state density
• Body thickness scaling at advanced nodes
• Device variation (body thickness, G-S overlap)

QM band-to-band tunneling enables steep sub-threshold slope for low-power operation

TFET surpasses MOSFET in energy at low Vdd

• S. Datta, ERD Emerging logic device assessment workshop. 2014

Outline

• Introduction
• Emerging logic devices

– CMOS extension vs. beyond-CMOS devices – Beyond-CMOS device assessment

• Emerging memory devices

– Emerging memory taxonomy and assessment – Promising emerging memories: STTRAM, RRAM, FeFET

• Emerging architectures

– Beyond von-Neumann architectures – Non-volatility information processing

• From scaling driver to function/application driver

– More-than-Moore: functional diversification

• Summary

15

Emerging Memory Devices

Memory Volatile SRAM DRAM Stand-alone Embedded Nonvolatile Baseline Flash NOR NAND Prototypical FeRAM PCM MRAM STT-RAM Emerging Ferroelectric Memory FeFET FTJ ReRAM Electrochemical Metallization Bridge Metal Oxide - Bipolar Filamentary Metal Oxide - Unipolar Filamentary Metal Oxide - Bipolar Nonfilamentary Mott Memory Carbon Memory Macromolecular Memory Molecular Memory

PIDS ERD

Two terminal structures

4F2 footprint

16

Emerging Memory Device Survey

10% 20% 30% 40%

Percentage of vote

Only showing devices with more than 10% vote  Most promising  Most need of resources

1st 2nd 2nd 1st

17

STTRAM: Spin-Transfer-Torque RAM

18

Challenges:

• Perpendicular-MTJ with sufficient parameters
• Integration and manufacturability
• Variability control
• Cost and commercial factors

Nonvolatile memory with endurance and speed comparable to those of DRAM and SRAM

• C. Yoshida, VLSI

Tech., 59 (2012)

• J. M. Slaughter, IEDM,

29.3 (2012)

RRAM: Resistive RAM (Including CBRAM)

19

Advantages:

• Potentially low-cost
• Potentially high-density
• Reasonable speed and endurance
• Versatile devices, materials and structures

(difficulties in down-selection and focus?) Challenges:

• Stochastic mechanisms
• Intrinsic variability
• Controllability and repeatability
• Failure mechanisms
• Forming requirements
• G. Jurczak, ERD Emerging logic device

assessment workshop. 2014 Rich Fackenthal, ISSCC (2014)

16Gb CBRAM (Micron/Sony)

Emerging NVMs toward Commercialization

Active industry R&D Testchip reports Early production

RRAM STTRAM

64kB RRAM in 8-bit microcontroller (2013) 64Mb DDR3 STTRAM (2013)

8Mb RRAM, 2012 32Gb RRAM, 2013 16Gb CBRAM, 2014 32Mb, in-plane, 2009 64Mb, in-plane, 2010 64Mb, p-MTJ, 2010

20

Ferroelectric-FET (FeFET) RAM

21

A key breakthrough: Ferroelectric HfOx

• J. Muller, ERD Emerging logic device

assessment workshop. 2014

ON: ID > 0 OFF: ID ~ 0 1995 2000 2005 2010 2015 10

• 2

10

• 1

10 10

1

10

2

physical gate length (m) publication year

perovskite

• rganic

FE-HfO2

Fe-HfOx closes FeFET gate length scaling gap

Outline

• Introduction
• Emerging logic devices

– CMOS extension vs. beyond-CMOS devices – Beyond-CMOS device assessment

• Emerging memory devices

– Emerging memory taxonomy and assessment – Promising emerging memories: STTRAM, RRAM, FeFET

• Emerging architectures

– Beyond von-Neumann architectures – Non-volatility information processing

• From scaling driver to function/application driver

– More-than-Moore: functional diversification

• Summary

22

Emerging Architectures

• Conventional von Neumann architecture: dominant in

today’s computing systems

• Novel architectures beyond von Neumann

– Cellular automata – Co-located memory-logic (e.g., processor-in-memory,

Memory-in-logic, computational memory, nonvolatile logic)

– Reconfigurable computing – Cognitive computing (e.g., neuromorphics, machine learning) – Statistical and stochastic computing (e.g., statistical

inference, approximate computing)

– Collective-effect computing (e.g., coupled oscillator network) – …

23

Brain-Inspired Architectures

24

P.A. Merolla, et al, Science 345, 668 (2014)

Emerging Logic Device Benchmark

25

• Benchmark emerging devices at logic gate levels (e.g., 32bit adder)
• Energy-delay tradeoffs extend to beyond-CMOS devices

D.E. Nikonov, IEDM, p. 576 (2012) Spin-wave device Spin-torque majority gate Nano-Magnet Logic Spin-transfer-torque domain-wall Spin-torque

• scillator logic

Alll-spin-logic device Graphene P-N junction Hetero-junction tunnel FET Graphene nano- ribbon tunnel FET

Unique Properties of Beyond-CMOS Devices

• Nonvolatility

– Built-in memory in logic devices

• Efficient logic implementation

– E.g., majority gate

• Structural / layout regularity

– E.g., Quantum Cellular Automata (QCA), crossbar arrays

• Self-adaptive property
• Coherent or collective behaviors

– Low-power switching, robustness

26

Novel architectures and designs enabled by these unique device characteristics?

Non-Volatile Information Processing (NVIP)

27

MTJ, ReRAM, FRAM, FeFET, PCM, Flash … SRAM, FF, adder, CAM, LUT, FPGA, …

NV gates and logic

Nonvolatile switches

NVM CMOS logic

FF: flip-flop LUT: look-up table CAM: content-addressable memory

• Leverage fast-growing emerging NVM technologies

 E.g., STTRAM, RRAM, FeFET, …

• Reduce/eliminate standby power

 Run-time power-gating

• Increase throughput and lower power

 Reduced data movement; immediate data availability

• Enable novel architectures

 Non-von-Neumann architectures (e.g., cellular automata), computation-in-memory, latch-less pipeline design, ...

NVIP: Examples

28

Magnetic LUT

W.S. Zhao, et al, ICVSC, 37 (2011)

Ferroelectric flip-flop

• M. Koga, et al,

TENCON, 317 (2010)

ReRAM-based programmable interconnect

• J. Cong, et al, IEEE TVLSIS 22, 864 (2014)

MTJ-based NV adder

• S. Matsunaga,

et al, APE 1, 091301 (2008)

ReRAM-based NV SRAM

P.F. Chiu, et al, JSSC 47, 1483 (2012)

Emerging Architecture Roadmap

• Challenges

– Numerous applications and architecture concepts – Different performance assessment methods and criteria – General-purpose vs. application-specific computing – Research gap between emerging architectures and devices

• A proposed approach

– Identify common tasks/applications – Develop a uniform set of figure-of-merits (FOMs) – Assess performance – Map with underlying technologies

29

Outline

• Introduction
• Emerging logic devices

– CMOS extension vs. beyond-CMOS devices – Beyond-CMOS device assessment

• Emerging memory devices

– Emerging memory taxonomy and assessment – Promising emerging memories: STTRAM, RRAM, FeFET

• Emerging architectures

– Beyond von-Neumann architectures – Non-volatility information processing

• From scaling driver to function/application driver

– More-than-Moore: functional diversification

• Summary

30

Booming Mobile and IoT Applications

31

More-than-Moore: Functional Diversification

32

ITRS More-than-Moore whitepaper (2011)

Emerging Devices for Sensor Node/Network

• Sensor materials

– Graphene, 2D materials, functional oxides, …

• Ultra-low power devices and design

– Sub-threshold and near-threshold design – Steep sub-threshold slope devices (e.g., TFET)

• Nonvolatile memories

– Low-power, low-cost, high-density – RRAM vs. STTRAM

• Communication components
• Power management

33

• D. Sylvester, “Cubic millimeter sensor nodes,” Workshop
• n Rebooting the IT Revolution, March, 2015

Extremely tight power budget in highly scaled sensor nodes

Emerging Devices for Hardware Security

34

• Y. Bi, et al, "Emerging Technology

based Design Primitives for Hardware Security", submitted.

Utilize ambipolarity of Si nanowire FET for:

• Logic camouflaging: layout-level obfuscation with

similar layouts for different gates

• Polymorphic gates: multiple functionalities in the

same cell Random number generator based on random telegraph noise in RRAM

C.Y. Huang, et al, IEEE EDL 33, 1108 (2012)

                     Address(a) Address(b)

a b

n n

Bit-wise comparison

Challenge Response

1T1R RRAM cells

Eg: Ri = 1 if ai > bi Ri = 0 if ai < bi (1  i  n)

RRAM-based physical unclonable functions (PUF)

• A. Chen,

IEEE EDL 36, 138 (2015)

Connectivity = vulnerability

Align Beyond-CMOS Technologies with New Application Drivers

Computing/ Communication

• 1. Memory
• 2. Logic
• 3. Architectures
• 4. More-than-

Moore (RF) Internet-of- Things

• 1. Low-power

devices, e.g., TFET, NEMS

• 2. Embedded

NVM

• 3. Security, e.g.,

TRNG, PUFs

• 4. RF and wireless
• 5. Sensors

integrated with CMOS

• 6. Energy-

harvesting devices Cloud/Big Data

• 1. Optical

interconnects

• 2. Storage

Class Memory

• 3. Efficient DC-

DC converters

• 4. Data driven

computing (accelerators for Hadoop, etc)

• 5. Security

Focus of beyond- CMOS technology: Today

• Emerging Logic
• Emerging Memory

Future

• Novel architectures
• Sensor integration
• Hardware security
• Energy-harvesting
• Circuit blocks and

architectures for IoT and cloud

• …

35

Summary

• Beyond-CMOS logic devices focus on low-power and may

utilize novel switching mechanisms and/or state variables.

• Emerging nonvolatile memories have made significant

progress and some promising candidates may enable new applications and overcome memory performance bottleneck.

• Opportunities exist in the research gap between emerging

architectures and device technologies.

• Technology drivers are transitioning from “scaling” to

“functions and applications”.

• Technology roadmap needs to be aligned with new market
• pportunities and technology drivers.

36
