ASIC Physical Design CMOS Processes Smith Text: Chapters 2 & 3 Weste CMOS VLSI Design Global Foundries: BiCMOS_8HP8XP_Training.pdf BiCMOS_8HP_Design_Manual.pdf Physical design process overview CMOS transistor

SLIDE 1

ASIC Physical Design CMOS Processes

Smith Text: Chapters 2 & 3 Weste – “CMOS VLSI Design” Global Foundries: “BiCMOS_8HP8XP_Training.pdf” “BiCMOS_8HP_Design_Manual.pdf”

SLIDE 2

Physical design process overview

 CMOS transistor structure and fabrication steps  Standard cell layouts  Creation, verification & characterization of a standard-cell

based logic circuit block

 Creation of a chip from circuit blocks

ELEC 5250/ 6250/ 6256 2

SLIDE 3

ASIC layout

ELEC 5250/ 6250/ 6256 3

SLIDE 4

ASIC Design Flow

Behavioral Design Gate-Level Netlist Transistor-Level Netlist Physical Layout DFT/BIST & ATPG Verify Function Verify Function Verify Function & Timing Verify Timing DRC & LVS Verification

Mask Data

ELEC 5250/ 6250/ 6256 4

SLIDE 5

ASIC Design Flow

ELEC 5250/ 6250/ 6256 5

SLIDE 6

IC “Floorplan”

ELEC 5250/ 6250/ 6256 6

SLIDE 7

Source: Weste “CMOS VLSI Design”

CMOS standard cell layout (generic)

ELEC 5250/ 6250/ 6256 7

SLIDE 8

BiCMOS8HP NAND2_A Cell (LEF file)

Yellow – “Pins” Orange = Poly Blue = Metal1 Cadence Encounter “Cell Viewer” Tool

ELEC 5250/ 6250/ 6256 8

SLIDE 9

BiCMOS8HP DFFS_B Cell (LEF file)

Yellow – “Pins” Orange = Poly Blue = Metal1 Cadence Encounter “Cell Viewer” Tool

ELEC 5250/ 6250/ 6256 9

SLIDE 10

Standard Cell-Based Block

ELEC 5250/ 6250/ 6256 10

SLIDE 11

Global Foundries BiCMOS8HP process cross-section

“Passivation”

ELEC 5250/ 6250/ 6256 11

SLIDE 12

BiCMOS8HP process cross-section

Aluminum Copper PC = Polysilicon

Via Via Via Via

CA = Contact to diffusion/poly External Connections

ELEC 5250/ 6250/ 6256 12

SLIDE 13

BiCMOS8HP metallization options: AM

(RF wiring) Analog Metal

ELEC 5250/ 6250/ 6256 13

SLIDE 14

GND or VSS + VDS L W VGS bulk source drain Tox Ex electrons + + VDS bulk drain gate source VGS + mobile channel charge depletion region p-type n-type n-type gate fixed depletion charge

Basic N-channel MOS transistor

ELEC 5250/ 6250/ 6256 14

SLIDE 15

CMOS Inverter Cross-Section

Source: Weste “CMOS VLSI Design”

ELEC 5250/ 6250/ 6256 15

SLIDE 16

Inverter cross-section with well and substrate contacts

Source: Weste “CMOS VLSI Design”

ELEC 5250/ 6250/ 6256 16

SLIDE 17

1 2 4 3 6 As+ 5 7 8 9 10 11 12 1 hour grow crystal saw resist spin furnace mask etch resist

xide

wafer grow oxide

IC fabrication process

4. Grow oxide SiO2
5. Apply photoresist
6. UV light exposes resist
7. Remove exposed resist
8. Etch exposed oxide

9-10. Implant ions in exposed substrate

11. Strip resist
12. Etch oxide

ELEC 5250/ 6250/ 6256 17

SLIDE 18

CMOS Process steps

P-substrate SiO2 layer Photoresist Expose and etch Etch SiO2 Remove photoresist Implant n-well Remove SiO2 Source: Weste “CMOS VLSI Design”

ELEC 5250/ 6250/ 6256 18

SLIDE 19

Deposit poly Etch Deposit SiO2 Etch Diffusion Remove SiO2 Source: Weste “CMOS VLSI Design”

CMOS Process steps

ELEC 5250/ 6250/ 6256 19

SLIDE 20

Inverter mask set

N-well Poly N+ diffusion P+ diffusion Contacts Metal Source: Weste “CMOS VLSI Design”

Generated by IC layout tools “Layout” is a set

f patterns for

each layer.

ELEC 5250/ 6250/ 6256 20

SLIDE 21

Inverter mask set

ELEC 5250/ 6250/ 6256 21

SLIDE 22

Source: Smith, Figure 2.7

Standard Cell Mask Set (Submitted to foundry)

ELEC 5250/ 6250/ 6256 22

SLIDE 23

MOSIS fabrication processes (www.mosis.org)

 TSMC Fabrication Processes 28, 40, 65, 90, 130, 180 and 350 nanometer processes. Tiny2 program is also available on 65 and 180nm processes.  GlobalFoundries Fabrication Processes

14 nm, 28 nm, 40 nm, 55 nm, 0.13 µm,0.18 µm, 9HP (90 nm), 8HP (0. 13 µm), 8XP (0.13 µm), 7WL (0.18 µm), 7RF SOI (0.18 µm) 7SW (0. 18 µm) 9WG (90 nm), 9WG (90 nm), andTinyChip processes.

 ON Semiconductor Fabrication Processes

0.7 µm high voltage CMOS, 0.5 µm CMOS, and 0.35 µm high voltage CMOS.

 ams AG Fabrication Processes

180 and 350 nanometer processes - CMOS and high voltage CMOS and SiGe-BiCMOS.

 AIM Fabrication Processes AIM Photonics Fabrication

ELEC 5250/ 6250/ 6256 23

SLIDE 24

Source: Weste “CMOS VLSI Design”

(Older) MOSIS fab processes

(http://www.mosis.org)

Mentor Graphics ASIC Design Kit

Scalable CMOS AMI bought by ON Semiconductor: http://www.onsemi.com/ TSMC (Taiwan Semiconductor): http://www.tsmc.com =ON =ON

ELEC 5250/ 6250/ 6256 24

SLIDE 25

nwell pwell nwell pwell ndiff pdiff pdiff ndiff ndiff pdiff pdiff nwell poly nwell pwell p-select n-select ndiff poly poly nwell poly metal2 m1 poly contact pdiff poly active contact m3 via2 m3 glass m2 m1 n-select pdiff p-select ndiff pdiff

1. well
2. active
3. poly
4. select
5. poly

contact

6. active

contact

7. metal1
9. metal2
15. metal3
10. overglass (micr
ns)

pwell nwell hot poly ndiff m1 m2 via1

8. via1

m2 m3 via2 via1 m2

14. via2

m2 via1 m1 2 1 4 3 5 6 7 8 15 10 14 9 m3 0 (1.4) 9 (1.2) 10 (1.1) 0 or 6 (1.3) 3 (2.1) 3 (2.2) 5 (2.3) 0 or 4 (2.5) 0 or 4 (2.5) 3 (2.4) 3 (2.2) 3 (2.1) 5 (2.3) 3 (2.4) 2 (3.2) 2 (3.1) 2 (3.3) 1 (3.5) 3 (3.4) 1.5 (5.2a) 2 2 (5.1a) 2 (5.3a) 1.5 (6.2a) 2 2 (6.1a) 2 (6.4a) 1.5 (6.2a) 3 (8.2) 2 2 (8.1) 2 (8.5) 2 (8.5) 2 (8.4) 1 (8.3) 2 (6.3a) 1 (4.3) 2 (4.2) 3 (7.1) 1 (7.3) 3 (7.2a) 1 (7.4) 3 (4.1) 2 (7.2b) 3 (14.2) 2 (14.4) 1 (14.3) 2 2 (14.1) 3 (9.1) 4 (9.2a) 1 (9.3) 3 (9.2b) 6 (15.1) 4 (15.2) 2 (15.3) 6 (10.3) 30 (10.4) 15 (10.5) 100 100 (10.1)

Scalable CMOS process design rules

Source: Smith, Figure 2.11

ELEC 5250/ 6250/ 6256 25

SLIDE 26

MOSIS Design Rules

Smith text: Tables 2.7-2.9

ELEC 5250/ 6250/ 6256 26

SLIDE 27

MOSIS Design Rules

Smith text: Tables 2.7-2.9

ELEC 5250/ 6250/ 6256 27

SLIDE 28

MOSIS Design Rules

ELEC 5250/ 6250/ 6256 28

Smith text: Tables 2.7-2.9

SLIDE 29

MOSIS Design Rules

ELEC 5250/ 6250/ 6256 29

Smith text: Tables 2.7-2.9

SLIDE 30

MOSIS Design Rules

ELEC 5250/ 6250/ 6256 30
