40TH AVENUE NE BRIDGE REPLACEMENT 40TH AVENUE NE BRIDGE REPLACEMENT Where to get updates? Please visit the Project website at: http://www.40thavenuebridge.com/ 40TH AVENUE NE BRIDGE REPLACEMENT Is this Project funded? The City plans to use
SLIDE 2
SLIDE 3
40TH AVENUE NE BRIDGE REPLACEMENT
Is this Project funded?
The City plans to use approximately $22 million of Penny for Pinellas funds to rebuild this and other bridges in the near future. The Federal Department of Transportation (FDOT) has identified this Project for funding
SLIDE 4
40TH AVENUE NE BRIDGE REPLACEMENT Overview
- August 2017 – City found extensive corrosion in main span when performing concrete repairs, bridge
closed, emergency diversion installed to safely divert two lanes of traffic from damaged areas
- November 2017 – City issued Request for Qualifications (RFQ) for Architectural/Engineering (A/E) firm
(RFQ issued via CCNA Process per Florida Statutes)
- January 2018 – City selected Cardno as A/E firm
- March 2018 – City Council approval of A/E firm and start of website, interim improvements phase
- May 2018 – 40thavenuebridge.com website launched
- June 2018 – Bridge closed for interim improvements to traffic flow, City Council approves start of
bridge design report and permitting process
- October 2018 – City Authorizes Final Design Services
SLIDE 5
40TH AVENUE NE BRIDGE REPLACEMENT
- Extensive Corrosion found in main span when performing concrete repairs in August 2017
- City issued RFP for A/E firm immediately following discovery of deficiency
- Legal Process for A/E procurement “CCNA” followed
- Cardno selected in January
- Moving forward with interim repairs to bridge, final design
Schedule
SLIDE 6
40TH AVENUE NE BRIDGE REPLACEMENT Average Bridge Project Schedule vs. 40th Ave Project Schedule
SLIDE 7
40TH AVENUE NE BRIDGE REPLACEMENT
Public Meeting No. 1 Objective
- Introduction of Project Team
- Information Gathering
- Navigational Clearances
- Functional Use/Typical Section
- Sustainability/Resiliency
Public Meeting No. 2 Objective
- Recommendations based on
Information Gathering and Survey
- Navigational Clearances
- Functional Use/Typical Section
- Sustainability/Resiliency
SLIDE 8
40TH AVENUE NE BRIDGE REPLACEMENT
Key Project Objectives
- Navigational Clearance
- Safety
- Accessibility
- Aesthetics
- Sustainability/Resilience
*Based on Survey and Public Feedback
SLIDE 9
40TH AVENUE NE BRIDGE REPLACEMENT
Navigational Clearance
(Arch is Illustrative)
SLIDE 10
40TH AVENUE NE BRIDGE REPLACEMENT
Navigational Clearances - Existing
SLIDE 11
40TH AVENUE NE BRIDGE REPLACEMENT
Clearzones/Sight Distances
SLIDE 12
40TH AVENUE NE BRIDGE REPLACEMENT
Navigational Clearances - Recommended
- Shifting Crest and Channel
- Not Impacting Adjoining Residents
- Channel Depth Verified by Hydrographic
Survey
SLIDE 13
40TH AVENUE NE BRIDGE REPLACEMENT
Navigational Clearances – Not Recommended
- No Shift in Crest
- No Impacts to Channel
SLIDE 14
40TH AVENUE NE BRIDGE REPLACEMENT
Community Input Opportunity
SLIDE 15
40TH AVENUE NE BRIDGE REPLACEMENT
Typical Sections
(Widths are Conceptual)
- Accessibility
- Safety
- Aesthetics
North South
- Bicycle Buffers
- Maximizes Vertical Clearance
SLIDE 16
40TH AVENUE NE BRIDGE REPLACEMENT
Typical Sections
(Widths are Conceptual)
- Accessibility
- Safety
- Aesthetics
North South
- Median Separator
- Maximizes Vertical Clearance
SLIDE 17
40TH AVENUE NE BRIDGE REPLACEMENT
Typical Sections
(Widths are Conceptual)
- Accessibility
- Safety
- Aesthetics
North South
- Barrier-Seperated Sidewalk
- Impacts Sight Distance
- Constrains Vertical Curve
SLIDE 18
40TH AVENUE NE BRIDGE REPLACEMENT
Barrier Options
NEW Crash Rated Barrier
- Safety
- Aesthetics
SLIDE 19
40TH AVENUE NE BRIDGE REPLACEMENT
Lighting Options
- Safety
- Aesthetics
- Meet AASHTO and FDOT Pedestrian Lighting Requirments
- LED
SLIDE 20
40TH AVENUE NE BRIDGE REPLACEMENT
Next Steps
Implement Pedestrian and Bicycle Access
- Impact – Bridge Closure of 4 – 6 weeks
- Construction initiation in Spring 2019 for Pedestrian and Bicycle Access
- Would serve as the first phase of Maintenance of Traffic during Construction Phase of the Bridge Replacement
SLIDE 21
40TH AVENUE NE BRIDGE REPLACEMENT
Next Steps
SLIDE 22
40TH AVENUE NE BRIDGE REPLACEMENT
Proposed Construction Sequence
SLIDE 23
40TH AVENUE NE BRIDGE REPLACEMENT
Key Points
- Navigational access of approximately 13 feet
- Constructing new support elements in line with existing will provide for minimizing impacts for boaters during construction
- Typical sections which provide for safety of all users
- Developed features which enhance aesthetics
- Develop Design which can be constructed while maintaining access during construction
- A resilient design to maintain access during its’ service life
- Survey Results will be posted after the meeting
