1 6/28/2018 2018 TRANSPORTATION TECHNOLOGY TOURNAMENT Presentation Overview Description of Problem & Solution Scenarios C O Data N Preliminary Results O ITS Architecture P Budget & Timeline S Potential

slide-1
SLIDE 1

6/28/2018 2018 TRANSPORTATION TECHNOLOGY TOURNAMENT

1

slide-2
SLIDE 2

2018 Transportation Technology Tournament

Presentation Overview

  • Description of Problem & Solution
  • Scenarios
  • Data
  • Preliminary Results
  • ITS Architecture
  • Budget & Timeline
  • Potential Benefits

8/21/2018 2

C O N O P S

slide-3
SLIDE 3

2018 Transportation Technology Tournament

Description of Problem & Solution

Problem

  • Over 17% of all traffic fatalities involve pedestrians
  • Bicyclists constitute 1% of all trips but 2% of all traffic fatalities

Solution

  • Address both safety and mobility issues pertaining to vulnerable road users
  • Use connected vehicle and autonomous vehicle technology & smart phone

applications

Feasibility for Adoption

  • Aligns with the Florida’s existing Pedestrian and Bicyclist Strategic Safety Plan
  • Generic enough to be adopted by agencies within and outside Florida

8/21/2018 3

slide-4
SLIDE 4

Scenario A: Vehicle automatically stops in front of a pedestrian

slide-5
SLIDE 5

Scenario B: Vehicles are aware

  • f the presence of bicyclists,

and are yielding to bicyclists

slide-6
SLIDE 6

Scenario C: Bicyclists are Given the Right-of-way When There are No Vehicles in the Conflicting Approaches

Green is extended for approaching bicyclists

slide-7
SLIDE 7

Data from City of Gainesville

8/21/2018 2018 Transportation Technology Tournament 7

  • Ped, Bike, & Vehicle Volume Data from Vantage Live
  • Vehicle Speed Data from Waze
  • Signal Timing Plans from the City of Gainesville
slide-8
SLIDE 8

8/21/2018 8 2018 Transportation Technology Tournament

Preliminary Results for Scenario A Involving a Distracted Ped.

Case 2 (87 Conflicts) Case 1 (241 Conflicts)

Conflict Analysis Results

Case 1: Conventional Vehicles Case 2: AV with APCAS 64%

slide-9
SLIDE 9

Proposed Deployment Location

8/21/2018 2018 Transportation Technology Tournament 9

6 Signalized Intersections along US Hwy 1 in the City of Miami Beach

slide-10
SLIDE 10

ITS Roadway Equipment

  • CCTV Cameras
  • Detection

(Video, LiDAR)

  • RSUs
  • Communication

(DSRC, Cell)

Vehicles

  • OBUs
  • APCAS

Personal Information Device

  • Smartphone

with Apps for ped/bike safety

Proposed: Roadway S&PM

  • High contrast

and wider, closely spaced markings

  • Technology

enabled signs

Centers

  • RTMC
  • TMC
  • Central

signal control systems

ITS Architecture: Physical View

8/21/2018 2018 Transportation Technology Tournament 10

slide-11
SLIDE 11

Two RSUs per Intersection Controller Upgrades Cellular Communications Infrastructure Collision Avoidance System $12,000/unit $8,000/unit $4,000/unit $5,000/unit $246,000

2018 Transportation Technology Tournament

Intersection-level Deployment Costs

8/21/2018 11

Total for 6 intersections

slide-12
SLIDE 12

Smartphone Application Sun Guide Interface Upgrade 10 OBUs for testing 10 Smartphone OBUs for Ped/Bike Applications for Testing $300,000 $50,000 $5,000/unit $4,000/unit SE, CEI, Configuration & Integration $590,000 $150,000

2018 Transportation Technology Tournament

System-level Deployment Costs

8/21/2018 12

+ + + +

slide-13
SLIDE 13

$246,000

Intersection-level Deployment Cost System-level Deployment Cost

$590,000

Contingency @12%

$100,000 TOTAL COST $936,000

8/21/2018 2018 Transportation Technology Tournament 13

Total Cost

+ + =

slide-14
SLIDE 14

3 Months • Stakeholder Consultation and Needs Assessment 6 Months

  • ConOps Document, System Engineering Management

Plan, RFP Preparation, and Preliminary Engineering

4 Months • Procurement Process 8 Months • Design-Build for Implementation

2018 Transportation Technology Tournament

Timeline

  • The deployment of

the proposed system is anticipated to take 21 months.

  • The Design-build

phase includes FIITT:

8/21/2018

  • Furnish
  • Install
  • Integrate
  • Test
  • Train

14

slide-15
SLIDE 15

Safety

  • Improved pedestrian/bicyclist detection, verification, validation, and response.
  • Fewer pedestrian and bicycle crashes at signalized intersections.
  • Reduce red-light violations.
  • Help proactively prioritize locations for safety improvements based on conflict analysis.

Mobility

  • Maximizing the available green time and signal phases to accommodate all modes.
  • Reduced delay and number of stops for bicyclists.
  • Increasing the throughput of bicycles and vehicles due to advanced detection.
  • Accommodating higher pedestrian volume particularly in downtown.

Enforcement

  • Future enhancement: An additional detection system that will determine the at-fault road

user and issue a ticket.

2018 Transportation Technology Tournament

Potential Benefits

8/21/2018 15

slide-16
SLIDE 16

Thank You!

Team Members: Angela Kitali (FIU) Fabio Soto (FIU) Jaqueline Masaki (FSU) Wei Guo (FIU) Faculty Advisor: Priyanka Alluri (FIU) Industry Advisor: Raj Ponnaluri (FDOT) Emmanuel Posadas (City of Gainesville)

2018 Transportation Technology Tournament 8/21/2018 16
