1 FITOK Overview FITOK was founded in 1998 One of the worlds leading suppliers of Valves and Fittings 900+ employees globally FITOK German factory and China factory have been certificated with ISO 9001, ISO 14001 and

slide-1
SLIDE 1

1

slide-2
SLIDE 2
  • FITOK was founded in 1998
  • One of the world’s leading suppliers of Valves and Fittings
  • 900+ employees globally

FITOK Overview

2

  • FITOK German factory and China factory have been certificated with ISO 9001, ISO 14001

and OHSAS 18001

  • FITOK has obtained a variety of certificates, including ABS, TA-Luft, TPED, CRN, ASTM

F1387, DVGW, PED, EAC, API 607, ATEX, DOT, ISO15848, ECE R110 and the Manufacture License of Civil Nuclear Safety Equipment (China)

  • Test reports of FITOK products issued by third party authorities includes:

 Interchangeability Test Report with Swagelok by TUV  MSS SP-99-2010 Test Report for Instrumentation Valve & Manifolds by SGS  ECE R110 Test Report for Tube Fittings by TUV

slide-3
SLIDE 3

FITOK Headquarter and Factory

– In Offenbach, Germany

FITOK Global Sales and Service

– In Texas, USA

FITOK Regional Sales and Service

– In Dubai, UAE

  • Inventory and sales service centers in Germany, the USA, China and the UAE

FITOK Factory and Shared Service

– In Shenzhen, China

FITOK Overview

3

  • Manufacturing centers in Germany and China
slide-4
SLIDE 4
  • General Instrumentation Valves and Fittings
  • Product sizes: 1/16″ ~ 2″ (2mm ~ 50mm)
  • Working pressures: up to 10,000 psi (690bar)
  • Optional materials: SS304/316/316L/904L, Alloy20/400/600/625/C-276, Duplex and Super Duplex
  • Medium & High Pressure Valves and Fittings
  • Product sizes: 1/8″ ~ 1″
  • Working pressures: 10,000 ~ 60,000 psi (690 bar ~ 4,137 bar)
  • Product sizes: 1/8″ ~ 1″
  • Working pressures: vacuum ~ 6,000 psi (414bar)
  • Optional materials: 316, 316L, 316L VAR, 316L VIM/VAR and Exotic Alloys
  • High Purity & Ultra High Purity Products
  • Sampling Systems
  • Utilizing all valves and fittings manufactured by the FITOK facilities from the shelf to ensure
  • verall performance and short lead time
  • Tailor-made cost-effective solutions to satisfy customers’ special technical and safety

requirements

Products

4

  • Tubing
  • Instrumentation Tubing, High-purity Tubing, Medium and High Pressure Tubing, Jacketed Tubing,

Insulated Tubing, and Heat Trace Tubing

slide-5
SLIDE 5

General Instrumentation Fittings

Tube Fittings Pipe Fittings Weld Fittings 37°Flared Tube Fittings VA Series Vacuum Adapter Fittings

Products

5

slide-6
SLIDE 6

General Instrumentation Valves

Ball Valves Needle Valves Other Valves

Products

6

slide-7
SLIDE 7

General Instrumentation Manifolds

Gauge Valves and Instrumentation Manifolds Block and Bleed Valves

Products

7

slide-8
SLIDE 8

Products

8

Vessels and Sample Cylinders Air Headers and Distribution Manifolds

slide-9
SLIDE 9

Products

9

Quick-connects Hoses and Connectors

slide-10
SLIDE 10

Medium & High Pressure Fittings

Tube Fittings Medium and High Pressure Fittings Pipe Fittings Adapter Fittings Quick Couplings

Products

10

slide-11
SLIDE 11

Medium & High Pressure Valves

Products

11

slide-12
SLIDE 12

Subsea Valves

Products

12

slide-13
SLIDE 13

Tubing and Tools

Products

13

slide-14
SLIDE 14

High Purity & Ultra High Purity Products

Weld Fittings Face Seal Fittings Cylinder Connections

Products

14

slide-15
SLIDE 15

High Purity & Ultra High Purity Products

Products

15

slide-16
SLIDE 16

Pressure Control Panels Gas Control Equipment Point-of-use Panels

Products

16

slide-17
SLIDE 17

Changeover Systems Gas Control Equipment

Products

17

slide-18
SLIDE 18

Sampling Systems

Bottle Configuration Cylinder Configuration

Products

18

slide-19
SLIDE 19

Products

19

  • Instrumentation Tubing
  • High-purity Tubing
  • Medium and High Pressure Tubing
  • Jacketed Tubing and Insulated Tubing
  • Heat Trace Tubing

Tubing

slide-20
SLIDE 20

600 tons raw materials 500k+ pieces forging blanks 4,000k+ valves and fittings 200k+ meters tubing

3E – Efficient, Effective and Economic

 Benefiting from our global facilities paired with flexible manufacturing system, we

  • ptimize the most cost-effective resources within short lead time.

 With over 600 tons of raw materials, we are prompt to satisfy our customers’ special requirements.  FITOK keeps sufficient stock of finished goods in our global warehouses to save the purchasing and stocking cost for our customers.  With our wide range of best quality products, we provide our customers with one- stop solutions and most professional services.

Superiority

20

slide-21
SLIDE 21

FITOK applies 316 SS material with critical compositions of narrowed tolerance compared with the 316 SS material applied by most other brands that are just according to ASTM A479: Chemical Composition Nickel Chrome Carbon ASTM A479 10-14% 16-18% ≤0.08% FITOK 12-14% 17-18% 0.04-0.065%

Purpose For better corrosion resistance, high-temperature resistance and higher metal strength.

Strictly controlled raw materials ensures the consistency and reliability of the FITOK products.

Superiority

21

Tailor-made 316 SS Material

slide-22
SLIDE 22

ASME B1.20.1 FITOK Single thread engagement length tolerance ±1 threads threads Engagement length for 1/2 NPT couple thread

  • Min. length : 2.48 threads
  • Min. length : 4.48 threads
  • Tolerance for thread engagement length of FITOK NPT thread is half of that of

ASME B1.20.1 requirements with only plus tolerance.

Precision Threads

1 

Superiority

22

slide-23
SLIDE 23

Precision Threads

  • The ASME B1.20.1 standard only requires to check L1 value.

Qualified Male NPT

L1 Hand-tight engagement length L2 Wrench take-up engagement length a Thread taper angle a a

L3 L1 L3

a'

L2' L1 L2

Defective Male NPT

Superiority

23

  • FITOK NPT thread complies with ANPT of SAE AS71051 standard, where need

test more parameters (L1, L2 and a) of thread.

  • If a manufacturer only check NPT thread with compliance ASME B1.20.1 standard,

and only doing tests for L1, some geometrical imperfections on the thread may be unnoticed.

slide-24
SLIDE 24

By choosing tailor-made material, optimized design, high accuracy machining and high level hardening process, FITOK tube fittings deliver supreme level performance in the industry.

  • FITOK rear ferrule is treated with low temperature carbonization for the whole ferrule.

Hardness and corrosion resistance are improved significantly with better sealing performance against harsh environment. Rear Ferrule Hardening Process Comparison among Major Brands:

FITOK Low temperature carbonization for the whole ferrule Hardness: HV0.2 800~1,000 Salt spray test: 600h no rust Magnetism: No S-Brand Low temperature carbonization for the whole ferrule Hardness: HV0.2 800~1,000 Salt spray test: 222h, pitting appeared; 600h, pitting didn’t deteriorate Magnetism: No

Substrate Hardened layer 25~30μm Substrate Hardened layer 25~30μm

Safe and Reliable Tube Fittings

Superiority

24

slide-25
SLIDE 25

P-Brand Suparcase Hardness: HV0.2 700~1,000 Salt spray test: 400h, pitting appeared; 600h, pitting didn’t deteriorate Magnetism: No K-Brand High temperature carbonization for edge area Hardness: HV0.2 500~600 Salt spray test: 6h, rust Magnetism: No G-Brand Stamping Hardness: HV0.2 285 Salt spray test: 600h no rust Magnetism: Yes

Substrat e Substrat e Stamping flow texture, no hardened layer Hardened layer 35~40μm Hardened layer About 100μm

Superiority

25

slide-26
SLIDE 26
  • Enables Smooth flow path to reduce flow resistance;
  • Eliminates entrapment zones for easy system internal cleaning;
  • Burrs on the angular junction would block the system with high speed flow.

FITOK Radius junction Other Brands Angular junction

Radius Junction of FITOK Fittings within Elbows

Superiority

26

slide-27
SLIDE 27
  • FITOK installation torque is at the same level as S-brand, which is smaller than

those of other brands. Smaller installation torque avoids threads and sealing surface damage caused by excessive torque, and reduce safety risks caused by incorrect installation.

Safe and Reliable Tube Fittings

Comparison of Installation Effect between FITOK and P-Brand:

Superiority

27

Please click to play the “Tube-stick” video

slide-28
SLIDE 28
  • A. ΔF<ΔP and LF>LP, tighter grip by FITOK, resulting more force put into the ferrule tightening.

FITOK LP LF ΔP ΔF

Swelling O.D.: 10.17mm Swelling O.D.: 10.09mm Eliminated flanging Visible flanging

P-Brand

  • B. Eliminated flanging by FITOK, provides better sealing if there any tube surface roughness.
  • C. Wider swelling of FITOK tube-end, resulting excellent sealing performance.

Comparison of Installation Effect between FITOK and P-Brand :

Safe and Reliable Tube Fittings

Superiority

28

slide-29
SLIDE 29

Stringent Testing Standard

  • Each FITOK valve is tested with nitrogen at pressure rating (max. of 6,000 psig/41.4

Mpa) before delivery. No visible leakage is allowed in any case. Needle Valve Testing Standard Comparison among FITOK, ASME B16.34 and Other Major Brands:

ASME B16.34 S-Brand H-Brand FITOK Test condition 80 psig gas 1,000 psig nitrogen 1,000 psig nitrogen 6,000 psig nitrogen Acceptability leakage rate Without visible leakage 0.1 std cm3/min 0.1 std cm3/min Without visible leakage

  • Min. time for leakage of 1

ml nitrogen gas at normal atmospheric pressure —— 10 minutes 10 minutes >100 minutes

To sum up, FITOK always applies the industry's most stringent standards while designing, manufacturing and testing every single piece of product, so as to enable the best performance to exceed user expectation.

Superiority

29

slide-30
SLIDE 30

Machining Facility Offenbach, Germany Machining Facility Shenzhen, China

Manufacturing Strength

30

slide-31
SLIDE 31

250+ advanced, high precision and high productivity processing equipments LGMazak SPINNER Hardinge

Manufacturing Strength

31

slide-32
SLIDE 32

Thread Rolling FITOK threads are produced by rolling instead of cutting to strengthen thread surface hardness and smoothness to ensure substantial performance improvement. Automatic Orbital Welding Equipment

By : ORBIMATIC

Automatic orbital welding resulting advanced and flawless welding seams in addition to superior sealing performance. Helium leak rate under 2×10-10 mbar L/S, meet and exceed the requirements of clean industry products. Private Forging Plant Ensures consistency and traceability for all of our materials. Quality of the blanks are thoroughly controlled.

Manufacturing Strength

32

slide-33
SLIDE 33

Class 100 Cleanroom Ultra High Purity Cleaning Equipment Ultrasonic Cleaning Line Up to the requirements of ISO 14644-1. The FITOK Class 100 cleanroom has been certified by the National Environmental Balancing Bureau of the United States of America. Full automation during the whole process, applicable to different products of a variety of materials, without manual operation. Adopting DI Water of Pure Class ≥17.5MΩ for cleaning parts of UHP products for specialty gas and semiconductor applications.

Manufacturing Strength

33

slide-34
SLIDE 34

Profile and Roughness Measuring Instrument

By: Mahr

The industry’s state of the art testing equipment. Contours and roughness measurements are analyzed with exceptional accuracy in

  • ne

measuring run, eliminates measuring error. Measurement accuracy: Accuracy of axle X: 1.70μm (1.4+L/100 =1.70); Accuracy of axle Z: 2.52μm (2.5+L/100＝2.52). Quality is what drives us. Quality is at the heart of everything we do. Customer satisfaction is our guiding principle.

Quality Assurance

34

slide-35
SLIDE 35

Coordinate Measuring Machine

By: Hexagon

With powerful measurement capabilities, provides enough flexibility, accuracy and convenience for dimension, shape and position measurement. Measurement Accuracy: 2.6 μm(2.3+3.3L/1000=2.6) Measurement Range: X 500mm / Y 700mm / Z 500mm

Quality Assurance

35

slide-36
SLIDE 36

Helium Leak Detector

By: INFICON

Mainly used for detecting leak tightness performance of products with low molecular

  • gas. High stability and sensitivity.

Smallest detectable leak rate is less than 5 x 10ˉ12 mbar L/S

Quality Assurance

36

slide-37
SLIDE 37

Portable Spectrometer Direct-reading Spectrometer

By: Innov-X

Suitable for rapid on-site metal material identification, making the supervision of on-site material designation more effective.

By: Spectro

Utilized for quantitative analysis of chemical compositions

  • f all types of materials. Confirms whether materials are

qualified and provides significantly more details compared to our Portable Spectrometer.

Quality Assurance

37

slide-38
SLIDE 38

Universal Pull-test Machine X-ray Apparatus Measures physical performance of raw and processed materials, such as elongation test, squeezing test, flaring test , and bending test, etc. Measurement range: 1.2~300 KN Applies non-destructive X-ray testing for all kinds of materials, welding parts, and nuclear grade products. Maximum penetration of A3 steel plate: 39mm

Quality Assurance

38

slide-39
SLIDE 39

Germany Factory ISO 9001:2015 Certificate Germany Factory ISO14001&OHSAS18001 Certificate

Appendix 1

39

slide-40
SLIDE 40

China Factory ISO14001:2015 Certificate China Factory ISO 9001:2015 Certificate China Factory OHSAS18001:2007 Certificate

Appendix 1

40

slide-41
SLIDE 41

ABS Certificate by ABS

Appendix 1

41

slide-42
SLIDE 42

TA - Luft Certificate by TUV

Appendix 1

42

slide-43
SLIDE 43

TPED Certificate by Lloyd's Register

Appendix 1

43

slide-44
SLIDE 44

Canadian Registration Number (CRN)

Appendix 1

44

slide-45
SLIDE 45

ASTM F1387 American Society for Testing and Materials

Appendix 1

45

slide-46
SLIDE 46

ASTM F1387 American Society for Testing and Materials

Appendix 1

46

slide-47
SLIDE 47

ISO 15848 Certificate (NB&ND)

Appendix 1

47

slide-48
SLIDE 48

ISO 15848 Certificate (NB&ND)

Appendix 1

48

slide-49
SLIDE 49

DVGW Certificate (Stainless steel)

Appendix 1

49

slide-50
SLIDE 50

DVGW Certificate (Brass)

Appendix 1

50

slide-51
SLIDE 51

PED Certificate (Fittings)

Appendix 1

51

slide-52
SLIDE 52

PED Certificate (Valves)

Appendix 1

52

slide-53
SLIDE 53

EAC Certificate (Valves)

Appendix 1

53

slide-54
SLIDE 54

EAC Certificate (Valves)

Appendix 1

54

slide-55
SLIDE 55

API 607 Fire Test Certificate

Appendix 1

55

slide-56
SLIDE 56

ATEX Certificate

Appendix 1

56

slide-57
SLIDE 57

DOT Approval

Appendix 1

57

slide-58
SLIDE 58

DOT Approval

Appendix 1

58

slide-59
SLIDE 59

Test Report of FITOK and Other Brand Tube Fittings Interchangeability by TUV

Appendix 2

59

slide-60
SLIDE 60

Test Report of FITOK and Other Brand Tube Fittings Interchangeability by TUV

Appendix 2

60

slide-61
SLIDE 61

Test Report of MSS SP-99-2010 For Instrumentation Valve & Manifolds by SGS

Appendix 2

61

slide-62
SLIDE 62

Test Report of MSS SP-99-2010 For Instrumentation Valve & Manifolds by SGS

Appendix 2

62

slide-63
SLIDE 63

Test Report of ECE R110 Tube fittings by TUV

Appendix 2

63

slide-64
SLIDE 64

64

Test Report of FITOK and Other Brand Face Seal Fittings Interchangeability by TUV

Appendix 2

64

slide-65
SLIDE 65

Thank you!

slide-66
SLIDE 66

FITOK E-Catalog
