TWO-GANTRY, FIVE-BRUSH MACHINES Objective NET.5 is a 2-gantry, 5-brush machine remarkable because of its high technological content; it was conceived and constructed to develop a brush washing concept unique in its class. New look The

SLIDE 1

TWO-GANTRY, FIVE-BRUSH MACHINES

SLIDE 2

Objective

NET.5 is a 2-gantry, 5-brush machine remarkable because of its high technological content; it was conceived and constructed to develop a brush washing concept unique in its class.

SLIDE 3

New look

The 5-brush technology sports the exclusive Giugiaro Design look.

SLIDE 4

Ongoing technological evolution

The 2-gantry, 5-brush car wash machine has undergone continuous technological development from its inception until now, reaching the peak of hardware and software evolution with NET.5.

SLIDE 5

Utilising this fieldbus allows very fast transmission of data between the two gantries; as a result, all NET.5 manoeuvres during wash cycles are fluid and smooth.

Interpolated control

SLIDE 6

Configuration

The machine is characterised by two individually driven gantries.

Gantry 1 functions

Two side brushes
DISCOVER wash system for

rims and lower sides

Fixed side high pressure.
Contour drying

(profile-following)

Side drying

Gantry 2 functions

Two side brushes
One top brush
Disk-type rim wash
Oscillating/rotating high

pressure for wheel arches and lower sides

Cross oscillating top high

pressure

Oscillating side high pressure
Top drying with two oscillating

fans

Side drying

SLIDE 7

Function Groups

Top brush Fixed side high pressure Discover rim wash system Disk-type rim wash Side drying Profile-following contour drying Oscillating wheel arch high pressure Side brushes Oscillating top drying Cross oscillating top high pressure Side brushes Oscillating side high pressure

First gantry Second gantry

SLIDE 8

Chemical product distribution

Gantry 1

Rim product
Chemical prewash
Detergent
Insect removal product

(high and low)

Magic Foamer 1 and 2

(foaming detergents)

Autolux

Gantry 2

Detergent
Magic Foamer 3

(foaming detergent)

r Rain-x

(rain-proofing treatment)

SLIDE 9

PRODUCT DISTRIBUTION

Magic foamer Extra

r Rain-x

Lower insect removal product Rim product Fixed chemical prewash Magic foamer Magic foamer Duplo and Autolux Upper insect removal product Wax Wax Detergent Detergent

SLIDE 10

NET.5 MAKES IT POSSIBLE

 To carry out multiple functions during the wash cycle,

thanks to the simultaneous action of two gantries

For example, the two pairs of side brushes on both gantries simultaneously brush the vehicle’s front and rear.

SLIDE 11

For example, while the first gantry applies side high pressure, the second applies side and cross-oscillating top high pressure.

 High pressure at maximum levels.

Thanks to a system including high side pressure on both gantries, combined with the wheel arch system with rotating and oscillating

nozzles. The action is completed by cross-oscillating top high

pressure.

SLIDE 12

 Drying: an unbeatable feature.

A broad range of features allows NET.5, to obtain highly effective results on all types of vehicle profiles.

Gantry 1

Top drying with tilting dryer

that follows the vehicle’s profile with two motors.

Fixed side drying with two

motors. Gantry 2

Top drying with two
scillating fans.
Fixed side drying with two

motors.

SLIDE 13

SIDE CHEMICAL PREWASH
TOTAL HIGH PRESSURE
WASH WITH DISCOVER SYSTEM
BRUSH WASH WITH DETERGENT
RIM WASH WITH DISK
RAIN-PROOFING TREATMENT WITH RAIN-X
RINSE
WAX
COMPLETE DRYING

A single forward pass and a return pass of the two gantries can perform the following functions:

 Complete wash within a reasonable time.

SLIDE 14

CHEMICAL PREWASH TOP BRUSHES WITH DETERGENT SIDE BRUSHES WITH DETERGENT CROSS-OSCILLATING TOP HIGH PRESSURE

FORWARD PASS

RAIN-X OSCILLATING SIDE HIGH PRESSURE DISK-TYPE WHEEL WASH SIDE BRUSHES WITH DETERGENT SIDE HIGH PRESSURE DISCOVER

SLIDE 15

A single gantry wash machine would have to perform 8 passes (4 forward and 4 return) to complete a wash cycle with the same functions. Therefore, same wash results, but with significant time savings. RETURN PASS

TOP BRUSH RINSE SIDE BRUSHES WAX TOP CONTOUR DRYING WITH TWO REAR PASSES SIDE DRYING

SLIDE 16

 Maximum customer satisfaction.

It is possible to wash all the difficult to reach areas, such as the vehicle’s wheel arches, from within which all traces

f soil and mud are removed.

This is achieved through the high pressure provided by its rotating and oscillating nozzles, located on the second gantry, that oscillate from top to bottom and rotate on the horizontal plane.

SLIDE 17

From NET.5 to FLY.5

For those who have no special aesthetic requirements, but focus on technology only, NET.5 becomes FLY.5 by shedding the decorative features while keeping the same technological content.

SLIDE 18
