WASH BAY MACHINES

Objective

To develop technological self-service wash bay machines capable of addressing all needs and requirements, with machines ranging from a single wash bay to large installations with eight wash bays.

Two different Looks

The wash bay structures (made of hot dip galvanised steel, with the possibility of being painted) are clad with pressure-formed aluminium elements. ALU-LOOK

Exclusive claddings that have always characterised AUTOEQUIP LAVAGGI wash bay machines with a simple and essential style.

VISUAL-LOOK

This look enhances the aesthetics of the machines by conferring

• riginality

and personality through graphics and LED RGB lighting.

A complete range

AUTOEQUIP LAVAGGI offers the technology of its wash bay machines in four distinct models:

Pinguino Verde

Developed for those who have large spaces and demand the best technology applicable on the wash bays without compromise. Pinguino Verde makes it possible to manage machines with 2 – 8 wash bays.

Pinguino Wash

The technical solutions adopted allow the Pinguino Wash technology to be placed into utilities cabinets to be located between the wash bays. This model makes it possible to manage 2 – 4 wash bays.

Jet Wash

Technological solution to set up one wash bay, especially suited to operators who have only limited space, but want to provide a complete self-service car wash.

Jet-one

Super compact technological solution to set up one wash bay; two versions are available:

The Pre-Wash version is especially suited to a wash bay leading to gantries not equipped with total high pressure.

 Wash

(5 programmes)

 Pre-Wash

(3 programmes)



Rim wash



Prewash



Brush



Wax



HP rinse



Rim wash



Chemical prewash



HP rinse

Wash programmes

Nine different wash programmes have been developed for wash bay machines; they make it possible to configure the machines to obtain complete wash cycles, up to seven cycles with various solutions.



Prewash with liquid chemical product



Prewash with powder chemical product



Chemical prewash



Rim wash



Brush wash



Wax



Rain-X rain-proofing treatment



Rinse



Anti-mark

High pressure groups

All high pressure groups of the wash bay machines are equipped with pumps specific to the car wash, having a flow rate of 12 l/min at 110 bar and capable of operating at high and low temperature. High temperature

• peration HP groups

Low temperature

• peration HP groups

Payment systems

Various payment and service activation options are used on the self-service wash bay machines:

 Cash: with tokens or coins  Cashless: through loyalty

payment systems, with cards

• r rechargeable keys.

The AE wash bay machines allow

 High reliability thanks to the use of high quality parts and of

stainless steel components such as:

 Chemical product

distribution manifolds

 Solenoid valves

 Limited machine stoppages even during maintenance,

thanks to separate supply circuits that allow one wash bay to be excluded at a time.

 With dedicated technical solutions, accessories and

programmes that make it possible to wash almost all two and four wheeled vehicles.

 With versatile technologies, that can be assembled on

stainless steel skid structures, to renovate any existing installation.
