SINGLE-GANTRY MACHINES Objective To develop a new generation of car wash machines having a technological core and an exclusive design, capable of revolutionising car washing with an eye on the future. GIUGIARO DESIGN Look Giugiaro Design

SLIDE 1

SINGLE-GANTRY MACHINES

SLIDE 2

Objective

To develop a new generation of car wash machines having a technological core and an exclusive design, capable of revolutionising car washing with an eye on the future.

SLIDE 3

GIUGIARO DESIGN Look

Giugiaro Design brings a distinctive Italian style to the new AUTOEQUIP LAVAGGI car wash machines line. Nothing was overlooked; all technical details are enhanced by a look capable of blending into the bold and refined lines of the machine.

SLIDE 4

New traffic lights

The machine is equipped with new stylish multi-colour LED traffic lights, with an automatic adjustment system controlled by ambient light; this ensures:

 Energy savings  Maximum visibility  Elimination of dazzle

effects

SLIDE 5

New display

The large luminous display, perfectly integrated into the machine, plays a vital role in its look, but can also be used to display:

 Information on the wash phases under way  Advertising

SLIDE 6

These accessories, whose aesthetics were carefully thought out, assume a key role in the machine’s design.

New splash guards

SLIDE 7

Dynamic configuration

NET allows a broad range of configuration options, from a base configuration that includes: The broad range of functions available allows great flexibility in setting up the machine to suit specific needs.

 Water presoak arch  Brush assembly  Rinsing arch  Side drying  Top contour drying

SLIDE 8

Rim wash

The machine can be equipped with:

 The

DISCOVER system

 The Telescopic disk system

SLIDE 9

Side high pressure

The system can be configured by combining:

 Fixed low side high pressure  Low rotating side high pressure

integrated into the rim washer

 Fixed side high pressure  Oscillating side high pressure

SLIDE 10

Top high pressure

The system can be set up with:

 Profile-following Top

Contour

 Profile-following tilting Top

Contour

 Profile-following tilting Top

Contour, with “POWER HP” system with hammer nozzles.

SLIDE 11

Product distribution arches

 Chemical prewash

arch

 Insect removal

chemical prewash arch

 Foaming detergent

arch 1 The choice of products to be dispensed is also flexible, to the base configuration that includes: The following can be added, depending on the requirements:

 Autolux arch  Super wax or Rain-X

arch

 Shampoo arch  Wax arch

SLIDE 12

PRODUCT DISTRIBUTION

Rain-X Top chemical prewash Detergent Magic foamer Autolux Detergent Rim product Side chemical prewash Wax

SLIDE 13

NET MAKES IT POSSIBLE

20°

 To closely follow the profile of all vehicles thanks to the

side brush tilting system

SLIDE 14

 Manage alarms  Manage maintenance  Personalise wash cycles

and operation by setting a few parameters

 Maximum level of interaction with the machine through

touch-screen operator terminal; besides starting the cycles it is possible to:

SLIDE 15

 Maximum durability thanks to the use of stainless steel

components, such as:

 Brush beam

 Frame columns and base  Dryer

SLIDE 16

 The opening system for the front and side doors makes

maintenance operations easier. 1 2

SLIDE 17

From NET to FLY

For those who have no special aesthetic requirements, but focus on technology only, NET becomes FLY by shedding the decorative features while keeping the same technological content.
