The Drycleaning Machines BÖWE P 12 / P15 Presentation

The Drycleaning Machines BÖWE P 12 / P15

Our Our perc shop perc shop machines machines with a with a loading capacity of loading capacity of

12 12 and and 15 kg 15 kg

Highlights

Compact Compact and and

• f high performance
• f high performance

Proven Proven technique technique based on the based on the P 240 / 300, of which P 240 / 300, of which more than 3000 more than 3000 machines were sold machines were sold

The Drycleaning Machines BÖWE P 12 / P15

Advantage: Advantage: Short cycle times Short cycle times

Highlights

• Garments are quickly

dried Cage perforation typical for HC

• Consistent penetration

Dynamic cage perforation Power Drying System (PDS)

High air flow rate

The Drycleaning Machines BÖWE P 12 / P15 Highlights

Advantage: Advantage: Short cycle times Short cycle times

Special „speed programs“ When loaded with 9 resp. 12 kg cycle times of less than 30 minutes are possible

P1 / P2

Optimized processing times for cleaning High drying capacity, due to great heating capacity

Course of Drying Böwe P15

10 20 30 40 50 60 70 80

drying time (min) temperature (°C)

temperature cage outlet temperature cage entry

Test at Customer's Load: normal garments Program P1; 1-bath-program Loaded quantity: 15kg

The Drycleaning Machines BÖWE P 12 / P15

Advantage: Advantage: complying with complying with regulations regulations

Highlights

Advantage: Advantage: Differentiation Differentiation

Solvent security

Meets highest international standards

Germany: 2nd BlmSchV

France: A.T. 2345

Excellent cleaning quality

Proven process technology Customers commend excellent cleaning results Delimitation against competitors

The Drycleaning Machines BÖWE P 12 / P15

Advantage: Advantage: User friendly User friendly

Highlights Control panel

Comprehensible program menues Numerous diagnostic functions Clear operator's guidance Numerous proven cleaning and maintenance programs Tank bottoms are even more smooth, due to a new processing technique Cage flange with cataphoresis coating Inspection openings in the cage back plate are part of the standard equipment integrated cycle meter

Lint filter

1 maintenance point easy to clean:

• pen up
• brush
• close

The Drycleaning Machines BÖWE P 12 / P15

Advantage: Advantage: Smooth, small, Smooth, small, aesthetic aesthetic

Highlights - Integration in the Drycleaning Shop

low space requirement

Slimline or crossline design

Variable speed drive (option) Imbalances during extraction are electronically leveled out

• also with partial loads.

BÖWE EBS -

Electronic Balancing System Top modern. Emphasizes the modernity

• f your shop.

New design

Entry measurement: height less than 2m

The Drycleaning Machines BÖWE P 12 / P15 Highlights

Easy retrofit of the

activated carbon adsorption unit

SLIMSORBA possible

Foresighted conception

• Keeps strictest limitations
• Reduction of solvent consumption
• Integrated loading door venting
• Desorption is possible during the

cleaning cycle

• Stainless steel

components Top quality

Durability through high-quality material

• Recovery section
• Still unit
• Water separator
• Button trap
• Solvent containing pipes

Advantage: Advantage: investment with a investment with a guaranteed future guaranteed future Advantage: Advantage: stability of value stability of value + + reliability reliability

The Drycleaning Machines BÖWE P 12 / P15

Advantage: Advantage: Standard machine Standard machine best equipped best equipped

Substantial Standard Equipment

• Drystat for optimum drying results
• Refrigeration unit with heat recovery
• Robust safety trough

Serial components

• Eco filter with proven multiple disc extraction technique with pressure control

The Drycleaning Machines BÖWE P 12 / P15 Options

Advantage: Advantage: reduces labor cost reduces labor cost Advantage: Advantage: reduces service cost reduces service cost

• Serial interface prepared
• Low-priced program
• Offers statistical and diagnostic possibilities from the shop,

from the head office or from the service technician's office

BÖWE Direct Connect

Benefit:

• Automized still rake out
• Meets requirements of 2nd BImSchV
• Lowest possible quantities of solvent in still residues

Emission free still rake

• ut system

The Drycleaning Machines BÖWE P 12 / P15 Options

Advantage: Advantage: Flexibility Flexibility

2nd extraction filter with 3rd tank

• thus especially flexible

Adsorption filter Variable speed drive Cool down

The Drycleaning Machines BÖWE P 12 / P15 Difference between P12/P15 and P240/P300 New design

• better appearance

2nd extraction filter with 3rd tank

• thus especially flexible

New cage perforation

• shorter drying time

Dirt deposit in the tank reduced

• reduced maintenance efforts

Large inspection openings and lint drying

• 2nd BlmSchV

New and adjusted programs

• shorter cycle times

Lower height

• easier entry

Improved methods of production

• more attractive prices

The Drycleaning Machines BÖWE P 12 / P15 Thank You very Much for Your Interest!
