GANTRY TRUCK AND CAR WASH MACHINE

CAMBUS NET 2 ONE

Cambus

Cambus

Stainless steel electrical board box New electrical board

Standard configuration Inverter on gantry movement FULL configuration Inverter on: Gantry movement Right vertical brush movement Left vertical brush movement Up/down horizontal brush

Updated programs setting

• Selection of the water to be used during the wash cycle
• Selection of the vehicle type to be washed
• Selection of the functions to activate or deactivate during the wash cycle

Exemple

• Deactivation detection of the pedestrian mirror wash program
• Deactivation brushing on the rear part of the vehicle
• Deactivate horizontal brush on the front of the vehicle
• Wash cycle management

Update of the personalization of the different functions settings Update of management of the winter discharge and set-up

• Activation of the washing speed increase on the sides of the vehicle

When a threshold valuechanges, the control resets automatically in standard configuration.

Manual controls to simplify the setting/ regulation operations and maintenance.

• Password personalized by the user
• Registration of the alarms.

To interact with the gantry in a DYNAMIC and INTUITIVE way. Operator board Touch screen

Cambus

Cambus

Wi-Fi connection

Connection, on the car wash machine site, by the use a Wi- Fi router It is possible to visualise with proper license,

• n

smartphone or tablet with operating system (android/ios2), the operator panel of the machine .All the controls and functions on the XBT operator panel are active on smartphone and tablets.

Cambus

Configuration

• f

water collector with CHEMICAL PREWASH option Configuration STANDARD water collector STANDARD

Products pneumatic dosing pumps OPTION Products electrical dosing pumps

Cambus

Direct towing

TANKER

On this equipment we have applied the same features as the equipment model CAMBUS

NET 2

“ NET 2 ” “ FLY 2 “ With new SW and HW configuration

NET 2

Stinless steel AISI 304 outfitting for the version : “ NET 2 ” “ FLY 2 “

• Components of the machine in stainless steel for a maximum durability along the time
• ut

Internal parts of the construction Equipment basis Vertical brushes Movement beam Trolley plates and components Top drying Top blower Plates of support

Inverter

Towing Up/down CONTOUR drying

PLC M340

CAN – Open technology

1 st Gantry Drying / High pressure 2 nd Gantry Washing

Inverter

Towing Up/down Horizontal brush Right vertical brush movement Left veritical brish movement

PLC M340

CAN – Open technology

NEW CONFIGURATION ELECTRICAL BOARD

NET 2

1 st Gantry

Left upper part

NET 2

2 nd Gantry

Left upper part

Water system High Pressure

A E3 E4 S-D M2 MF AL 2B 2R 2R 2Sa 2Sb

NET 2

Ethernet Connection

Remote connection by secomea modem The data modem sends the following information:

• Equipment during discharge
• Equipment in block
• Equipment restarted
• Temperature

By email sending, possibility to configure up to 5 email addresses through the XBT). It is possible to visualise, with the proper license, the equipment operator panel on smartphone or tablet with

• perating system (android/ios2).

It is NOT possible to make from remotely the following controls:

• Restart
• Reset
• Start of washing cycle

When this connection is active those controls are disabled both on the operator panel and on the connected device.

MODEM

Operator panel Tablet

Wi-Fi connection

Connection, on the car wash machine site, by the use a Wi- Fi router It is possible to visualise with proper license,

• n

smartphone or tablet with operating system (android/ios2), the operator panel of the machine .All the controls and functions on the XBT operator panel are active on smartphone and tablets.

NET 2

NET 2

CONTOUR top high pressure MOTORIZED TILTING DISCOVER Proper piston pump

• f 7,5 kW

MOTORIZED OSCILLATING SIDE high pressure

• DOUBLE piston oump (7.5 kW + 7.5 kW 60 liter/min 60 bar)

A pump feeds in one passage:

• CONTOUR top high pressure, positioned on the top dryer blower

front/back tilting system in a second passage

• SIDE high pressure
• The second pump feeds the DISCOVER system

HIGH PRESSURE

Management with:

• single piston pump

15 kW 100 liter/mint80 bar Supply of side and top high pressure in TWO gantry separated passages

“ POWER HP ”

CONTOUR top high pressure With percussion nozzels CONTOUR top chemical prewash arch

NET 2

ONE

ONE

ONE

Componenents in stainless steel

Front door Side cladding towing Support in stainless steel NEW FIXING Beam and trolley plates vertical brushes CONTOUR Blower dryer SIDE dryer blower Wheel washer support

ONE

SIDE DRYER UPDATE

The side dryer blowers are no longer anchored directly on the side upper part of the gantry in a fix position but by the use of spacers, in order to allow the passage of the air during the aspiration and to position its to a variable height according to the washing height.

Direct fixing on equipment side upper part Fixing through spacers

ONE

Solenoid valve group Regulators of Dosing pumps

Right side part

PLC M340 Ethernet connection

Left side part

PLC EXPANSION In external board Ethernet connection

ONE

Contour dryer

ONE

SIDE HIGH PRESSURE

Piston pump for high pressure

50 let/min - 50 bar - 5.5kW

Inside the gantry

(Right side of the gantry)

Side high pressure Integrated in the wheelwasher Side High pressure

ONE

Loading dimensions H. 28

For the loading, if the machine will be loaded with a space required of 3080 mm, the machine will be shipped all assembled with the upper part included For the loading, if the machine will be loaded with a space required of 2580 mm, you must dismantle, beside the horizontal brush guides and the top dryer, also the side dryer blowers Horizontal brush guide Top dryer guide Side dryer blowers

Loading dimensions H. 25

For the loading, if the machine will be loaded with a space required of 2850 mm, the machine will be shipped all assembled with the upper part included For the loading, if the machine will be loaded with a space required of 2580 mm, you must dismantle, beside the horizontal brush guides and the top dryer, also the side dryer blowers Horizontal brush guide Top dryer guide Side dryer blowers

ONE

ONE

Loading dimensions H. 23

For the loading, if the machine will be loaded with a space required of 3100 mm, the machine will be shipped all assembled with the upper part included For the loading, if the machine will be loaded with a space required of 2580 mm, the machine will be shipped all assembled with the upper part included
