SMART SOLUTIONS TO TODAYS TOUGH APPLICATION DESIGN TECHNOLOGIES INTERNATIONAL Sp. z o.o. HEAVY DUTY PLANER MILL TYPE FB 240 CNC The machine is designed for machining of workpiece in the range of milling, drilling operations according to
SLIDE 2
SLIDE 3
The machine is designed for machining of workpiece in the range of milling, drilling operations according to the technical characteristic
- f
the machine.
SLIDE 4
TECHNICAL SPECIFICATION
SLIDE 5
1. Table size 2400mmx8000mm 2. Longitudinal travel of table „X” axis 10000mm 3. Distance between columns 2800mm 4. Vertical stroke of milling head „Z” axis 750 mm 5. Feed range 10÷5000mm/min. 6. Rapid travel i „X” axis 15m/min
SLIDE 6
7. Rapid travel „Z” ad „Y” axes 7,5m/min 8.
- Max. power of milling spindle drive
68kW ( S1) 9.
- Max. torque of milling spindle
5400Nm 10. Range of rotary speed of vertical milling spindle 5÷2000rpm 11. Tool taper of milling spindle ISO60 12.
- Max. torque of 90°anqular milling head
5100Nm
SLIDE 7
13.
- Max. speed of 90°anqular milling head
spindle 1400rpm 14. Tool taper of 90° angular milling head spindle ISO60 15. Automatic positioning of 90° milling head 360° every 1° 16. Tool changer 10 positions for vertical tools 5 positions for horizontal tools 17.
- Max. diameter of cutting tools
- dia. 315mm
18.
- Max. weight of cutting tools
50kg
SLIDE 8
MAIN FEATURES
SLIDE 9
1. All main components:
- bed
- table
- crossrail
- columns
Gray iron castings x Standard 2. Vertical milling head 2 Standard 3. 15 positions toolchanger
- 10 - vertical tools
- 5 - horizontal tools
2 Standard 4. 90 deg. angular milling head with automatic pick up system by the ram 2 Standard 5. Vertical ram – size 540mm x 570mm 2 Standard
SLIDE 10
6. Hardened (60HRc) and ground slide ways X Standard 7. The feed drive for vertical travel of each ram includes 2 ball screws, 2 planetary gear boxes and 2 AC Siemens servomotors X Standard 8. 3 ways support the vertical head for horizontal movement X Standard 9. Up to feed drive for the table ”X” axis - ball screw (dia. 100mm) X Standard 10. Siemens CNC control Sinumeric 840D sl X Standard 11. Heidenhain linear scale for all CNC axes X Standard
SLIDE 11
12. Rittal electrical cabinet and pendant X Standard 13. Chips removal system includes 3 chips conveyors X Standard 14. Coolant system X Optional 15. Renishaw probe for workpiece X Optional 16. Special hydraulic clamping device for tongues X Optional
SLIDE 12
17. Power drive movement system for rails X Optional 18. CE standard X Standard
SLIDE 13
How we do it
SLIDE 14
SLIDE 15
Bed - grey iron casting Hardened (60HRc) and ground slide ways
SLIDE 16
up to 10m feed drive for the table (”X” axis) - ball screw (dia. 100mm)
SLIDE 17
Table - grey iron casting
SLIDE 18
SLIDE 19
Chips removal system includes 3 chips conveyors
SLIDE 20
Columns - grey iron castings
SLIDE 21
Crossrail - grey iron casting
SLIDE 22
The feed drive for vertical travel of each ram includes 2 ball screws, 2 planetary gear boxes and 2 AC Siemens servomotors
SLIDE 23
SLIDE 24
SLIDE 25
Vertical milling heads
SLIDE 26
SLIDE 27
15 positions toolchangers
- 10 - vertical tools
- 5 - horizontal tools
SLIDE 28
90 deg. angular milling heads with automatic pick up system by the ram
SLIDE 29
SLIDE 30
Special hydraulic clamping device for tongues Power drive movement system for rails
