GreenFlux Smart Charging 1

Leading Smart Charging

Lennart Verheijen

GreenFlux Smart Charging 2

Vision

GreenFlux Smart Charging 3

Proud to be GreenFlux

Leader in EV smart charging solutions

20+ countries 20.000

Access to connected charge points International customers in

100.000+ charge stations in Europe 61.000 drivers

Supporting 1.000.000+ drivers to use our customers’ stations

GreenFlux Smart Charging 4

White label CPO & eMSP platform

Smart Charging Remote management and support Billing and transaction management Global Roaming via open standards Interfaces / API App

GreenFlux Smart Charging 5

increase/decrease maximum charge rate

What is smart charging?

GreenFlux Smart Charging 6

Why do you do smart charging?

LOCAL RENEWABLE ENERGY USER REQUIREMENTS DYNAMIC ENERGY PRICES GRID CONSTRAINTS

GreenFlux Smart Charging 7

How do we do it

GreenFlux platform

GreenFlux Smart Charging 8

Cloud-based solution

Works with any charging station Interoperable Communicates through

• pen standards

Infinitely scalable Unlimited number

• f chargers

Blazingly fast response Cloud-based intelligence Intelligent Ongoing updates and optimizations Independent User input possible, not required Any location, any charger, any EV

GreenFlux Smart Charging 9

How do we do it

STEP 1 We set the available capacity over time

Power Max kW Time

GreenFlux Smart Charging 10

How do we do it

Power

STEP 2 We distribute energy over time

Max kW Time

GreenFlux Smart Charging 11

How do we do it

Power Max kW Time

GreenFlux Smart Charging 12

How do we do it

Power Max kW Time

GreenFlux Smart Charging 13

How do we do it

GreenFlux Smart Charging 14

2013: 16 chargers at 250A 2018: 100 chargers at 400A Smart charging saved ~€250.000

• n infrastructural costs

Smart charging is active ~10%

• f the time, resulting in a 90%

higher charge rate for an EV

Use case

Head office of the largest Dutch grid operator

GreenFlux Smart Charging 15

Use case

Electric Nation Project

GreenFlux Smart Charging 16

Use case

Electric Nation Project

• 673 participants
• 2 year trial
• Over 130,000 charging events

GreenFlux Smart Charging 17

Households come first

Consumption by

• ffice building

Electric Nation

GreenFlux Smart Charging 18

Electric Nation

Households come first

Consumption by households

GreenFlux Smart Charging 19

Electric Nation

Households come first

GreenFlux Smart Charging 20

Electric Nation

Households come first

GreenFlux Smart Charging 21

GreenFlux Smart Charging 22

GreenFlux Smart Charging 23

First iteration

GreenFlux Smart Charging 24

Second iteration

High Priority Medium Priority Low Priority

GreenFlux Smart Charging 25

Third Iteration

Introducing price incentives

GreenFlux Smart Charging 26

Third Iteration

GreenFlux Smart Charging 27

Third Iteration

GreenFlux Smart Charging 28

Third Iteration

Optimise time Default setting

GreenFlux Smart Charging 29

Third Iteration

Minimize cost

GreenFlux Smart Charging 30

Third Iteration

Optimise time and cost

GreenFlux Smart Charging 31

Third Iteration

At the end of the project: Reward paid as an Amazon voucher

GreenFlux Smart Charging 32

Electric Nation project

Learnings

• 1. Data is crucial and not

always available

• 2. Some cars do not respond

to smart charging signals Smart charging can be a challenge

• 4. Possible network failure

requires fallback scenario’s

• 3. Some cars

are on timers

• 5. Data costs can ruin

your business case

• 6. Limited bandwidth

with 2G

GreenFlux Smart Charging 33

Electric Nation project

Learnings

GreenFlux Smart Charging 34

Electric Nation project

Learnings - 1

Demand management is technically feasible, and acceptable to the majority of participants

GreenFlux Smart Charging 35

Electric Nation project

GreenFlux Smart Charging 36

Electric Nation project

Learnings - 2

Data from smart chargers can provide a strong data source for building an evidence base for future developments Data shows there is a lot of flexibility in EV charging

GreenFlux Smart Charging 37

Electric Nation project

Learnings - 3

Informing and empowering EV- drivers is crucial in smart charging It needs to be easy

GreenFlux Smart Charging 38

• Finding chargers
• Smart charging
• Roaming and Paying

The best apps never leave the pocket

GreenFlux Smart Charging 39

Electric Nation project

Learnings - 4

Trial data shows that Time of Use incentives appear to be highly effective at moving demand away from the evening peak. The right incentive is crucial though

GreenFlux Smart Charging 40

Start of charging time – Dynamic Tariffs

GreenFlux Smart Charging 41

Start of charging time – Dynamic Tariffs

GreenFlux Smart Charging 42

Start of charging time – Dynamic Tariffs

This is great for the grid, For the energy supplier: not so much

GreenFlux Smart Charging 43

What we now offer

GreenFlux Smart Charging 44

Electric Nation project

Learnings - 5

Waiting 15 minutes for a recalculation can be annoying

GreenFlux Smart Charging 45

Switching to event-based algorithms

GreenFlux Smart Charging 46

Switching to event-based algorithms

Our developers call this “smart charging art”

GreenFlux Smart Charging 47

Switching to event-based algorithms

Responding directly to events:

• Start of charge session
• Stop of charge session
• EV nearly full
• EV full
• High priority request from driver
• High priority request from charger
• DC charger starting a session
• Sudden change in available capacity
• New setpoint from energy supplier
• New setpoint from TSO
• …

GreenFlux Smart Charging 48

Electric Nation project

Learnings - 6

We can apply this TODAY

GreenFlux Smart Charging 49

Why do you do smart charging?

LOCAL RENEWABLE ENERGY USER REQUIREMENTS DYNAMIC ENERGY PRICES GRID CONSTRAINTS

GreenFlux Smart Charging 50

GreenFlux Smart Charging 51

Beyond Electric Nation

Continuously updating the algorithms Further integration with apps, metering platforms, charging stations, etc. Rolling this out commercially

GreenFlux Smart Charging 52

Contact

lennart.verheijen@greenflux.com +31 6 21 29 10 68 www.greenflux.com info@greenflux.com

Project report: https://www.westernpower.co.uk/downloads/64369 Project summary: https://www.westernpower.co.uk/downloads/64369
