Writing Smart Contracts Dionysis Zindros Smart Contracts Day Athens, March 2017 We talked all about what smart contracts are... ...but what does a real smart contract look like? Lets talk about writing actual Smart Contracts with code

slide-1
SLIDE 1

Writing Smart Contracts

Dionysis Zindros

Smart Contracts Day Athens, March 2017

slide-2
SLIDE 2

We talked all about what smart contracts are...

...but what does a real smart contract look like?

  • Let’s talk about writing actual Smart Contracts with code
  • Using the first ever blockchain: Bitcoin

In this talk, we’ll get slightly more technical :)

slide-3
SLIDE 3

Outline

  • The bitcoin blockchain
  • The transaction graph
  • Inputs and outputs
  • Unspent transaction outputs
  • Digital signatures
  • Creating and resolving encumbrances
  • The stack-based bitcoin computer
  • A first contract: Paying someone some money
slide-4
SLIDE 4

Enter bitcoin

  • Very simple “smart contract” capabilities
  • Expressibility very limited

○ Can express ideas such as a “payment contract” ○ We’ll go through that in this talk

  • Good introductory example to practical smart contracts
  • Significantly extended by blockchains created after Bitcoin

○ e.g. Ethereum, Cardano ○ Darryl will talk more about this in a bit

slide-5
SLIDE 5

Transactions

  • Bitcoin’s basic structure: A transaction (tx)
  • A transaction transfers money from an old owner to a new
  • ne

tx from to

slide-6
SLIDE 6

tx Alice Bob

slide-7
SLIDE 7

Transaction edges

  • I’ll illustrate a transaction as a node (circle)
  • It has incoming and outgoing edges (lines)
  • The incoming edge shows who pays
  • The outgoing edge shows who is paid
  • The nodes do not illustrate owners, but transactions
  • The edges have owners
  • Each edge has a weight (number associated with it)

which is its nominal monetary value

slide-8
SLIDE 8

tx Alice Bob 15€ 15€

slide-9
SLIDE 9

tx Alice Bob 15mBTC 15mBTC

slide-10
SLIDE 10

tx input

  • utput
slide-11
SLIDE 11

The transaction graph

tx

  • A graph is a group of edges connecting various nodes

together

  • Payments are made by connecting transaction nodes
  • Money is a chain of transactions

Alice Bob 1 BTC 1 BTC

tx

Charlie 1 BTC

tx tx

Dionysis 1 BTC

slide-12
SLIDE 12

1 BTC

Unspent money

  • Money that can be spent is unspent money
  • It is the dangling outgoing edges of transactions (utxo)

tx Alice Bob 1 BTC tx Charlie 1 BTC tx Unspent transaction output

slide-13
SLIDE 13

1 BTC Alice tx

slide-14
SLIDE 14

1 BTC Alice tx utxo

slide-15
SLIDE 15

1 BTC Alice tx tx

slide-16
SLIDE 16

1 BTC Alice 1 BTC Bob tx tx

slide-17
SLIDE 17

1 BTC Alice 1 BTC Bob not utxo any more new utxo tx tx

slide-18
SLIDE 18

Proof of ownership

  • Digitally sign the UTXO that I want to spend with the new tx details
  • This ensures I’m the true owner of the UTXO
  • The new transaction must include the tx
  • This way I ensure I give permission to the new owner and my signature

cannot be forged towards a wrong owner with just copying it

slide-19
SLIDE 19

1 BTC Alice tx 1 BTC Bob Alice signs tx

slide-20
SLIDE 20
slide-21
SLIDE 21

Bitcoin script: The original smart contracts

  • People talk about Smart Contracts in Ethereum
  • The original Smart Contract language is bitcoin!
  • Bitcoin provides a language for expressing simple smart

contracts

  • What can it express?

○ Alice owns some money ○ Alice and Bob own money together ○ Micropayments - continuous transfer of value

slide-22
SLIDE 22

Bitcoin script: Encumbrances

  • The owner of an edge on the bitcoin tx graph is not just

bitcoin address!

  • It is a computer program which decides whether the

edge can be spent

  • It is written bitcoin script
  • A dangling edge is an encumbrence
  • This program is called a scriptPubKey
  • This is the program the verifier runs
  • This allows us to express more complicated ownerships
slide-23
SLIDE 23

tx Alice Bob 36 mBTC 36 mBTC

slide-24
SLIDE 24

1FdtUtvK5vZxwo8jzjzid5EwGAB7paqX4n 128MZKqUsvg2kYJQ5LCVDx8Mdn8xrijzQY

tx 36 mBTC 36 mBTC

slide-25
SLIDE 25

tx

OP_DUP OP_HASH160 128MZKqUsvg2kYJQ5LCVDx8Mdn8xrijzQY OP_EQUALVERIFY OP_CHECKSIG

36 mBTC

OP_DUP OP_HASH160 1FdtUtvK5vZxwo8jzjzid5EwGAB7paqX4n OP_EQUALVERIFY OP_CHECKSIG

36 mBTC

slide-26
SLIDE 26

Bitcoin script

  • The script runs on a stack machine
  • It contains simple serial commands without loops
  • It runs on every network computer when a utxo is spent
  • The output of the execution is 0 or 1
  • This is part of transaction validation
  • If the output is 1, the input is valid and can be spent
  • Otherwise the input is not valid
  • And the tx is not valid
slide-27
SLIDE 27

Bitcoin script

  • When a tx spends a UTXO, the creator of the tx has to prove that the script
  • utputs 1 successfully

○ i.e. that the output edge is spent fairly

  • For this purpose, it supplies some parameters for the scriptPubKey program

(the program = the encumbrance) so that when the scriptPubKey program runs with these parameters, it outputs 1

  • The execution parameters of scriptPubKey are called scriptSig
  • These parameters are given as part of the new tx which the old UTXO is

connected to

slide-28
SLIDE 28

Bitcoin script execution

  • 1. We put the scriptSig parameters on the stack
  • 2. We run the commands of scriptPubKey one by one
  • 3. Each of these commands can change the stack
  • 4. We check if the stack ends up with just a 0 or 1 in the end

for failure or success

slide-29
SLIDE 29

Pay-to-pubkey (p2pk)

  • The simplest smart contract
  • And the first ever written
  • Expresses the notion that some money rightfully belongs

to an owner

  • Similar to a physical bank check
  • Except it doesn’t need a central trusted third party like

bank or government

  • Security is provable
  • Unlike “security by call-the-cops” of traditional checks
  • So it can work pseudonymously
slide-30
SLIDE 30

Pay-to-pubkey

scriptPubKey: 045a5f526dfe5d5995bf95f12 OP_CHECKSIG scriptSig: signature σ

slide-31
SLIDE 31

Pay-to-pubkey

scriptPubKey: 045a5f526dfe5d5995bf95f12 OP_CHECKSIG scriptSig: signature σ σ

slide-32
SLIDE 32

Pay-to-pubkey

scriptPubKey: 045a5f526dfe5d5995bf95f12 OP_CHECKSIG scriptSig: signature σ σ

slide-33
SLIDE 33

Pay-to-pubkey

scriptPubKey: 045a5f526dfe5d5995bf95f12 OP_CHECKSIG scriptSig: signature σ 045a5f526dfe5d5995bf95f12 σ

slide-34
SLIDE 34

Pay-to-pubkey

scriptPubKey: 045a5f526dfe5d5995bf95f12 OP_CHECKSIG scriptSig: signature σ 045a5f526dfe5d5995bf95f12 σ

slide-35
SLIDE 35

Pay-to-pubkey

scriptPubKey: 045a5f526dfe5d5995bf95f12 OP_CHECKSIG scriptSig: signature σ 1

transaction completed successfully

slide-36
SLIDE 36

Pay-to-pubkey-hash (p2pkh)

  • The way payments are done in bitcoin today
  • Again a contract that ensures someone owns money
slide-37
SLIDE 37

Pay-to-pubkey-hash

scriptPubKey: OP_DUP OP_HASH160 1FdtUtvK5vZxwo8jzjzid5Ew OP_EQUALVERIFY OP_CHECKSIG scriptSig: pubKey signature σ

slide-38
SLIDE 38

Pay-to-pubkey-hash

scriptPubKey: OP_DUP OP_HASH160 1FdtUtvK5vZxwo8jzjzid5Ew OP_EQUALVERIFY OP_CHECKSIG scriptSig: pubKey signature σ pubKey signature σ

slide-39
SLIDE 39

Pay-to-pubkey-hash

scriptPubKey: OP_DUP OP_HASH160 1FdtUtvK5vZxwo8jzjzid5Ew OP_EQUALVERIFY OP_CHECKSIG scriptSig: pubKey signature σ pubKey signature σ

slide-40
SLIDE 40

Pay-to-pubkey-hash

scriptPubKey: OP_DUP OP_HASH160 1FdtUtvK5vZxwo8jzjzid5Ew OP_EQUALVERIFY OP_CHECKSIG scriptSig: pubKey signature σ pubKey pubKey signature σ

slide-41
SLIDE 41

Pay-to-pubkey-hash

scriptPubKey: OP_DUP OP_HASH160 1FdtUtvK5vZxwo8jzjzid5Ew OP_EQUALVERIFY OP_CHECKSIG scriptSig: pubKey signature σ pubKey pubKey signature σ

slide-42
SLIDE 42

Pay-to-pubkey-hash

scriptPubKey: OP_DUP OP_HASH160 1FdtUtvK5vZxwo8jzjzid5Ew OP_EQUALVERIFY OP_CHECKSIG scriptSig: pubKey signature σ H(pubKey) pubKey signature σ

slide-43
SLIDE 43

Pay-to-pubkey-hash

scriptPubKey: OP_DUP OP_HASH160 1FdtUtvK5vZxwo8jzjzid5Ew OP_EQUALVERIFY OP_CHECKSIG scriptSig: pubKey signature σ H(pubKey) pubKey signature σ

slide-44
SLIDE 44

Pay-to-pubkey-hash

scriptPubKey: OP_DUP OP_HASH160 1FdtUtvK5vZxwo8jzjzid5Ew OP_EQUALVERIFY OP_CHECKSIG scriptSig: pubKey signature σ 1FdtUtvK5vZxwo8jzjzid5Ew H(pubKey) pubKey signature σ

slide-45
SLIDE 45

Pay-to-pubkey-hash

scriptPubKey: OP_DUP OP_HASH160 1FdtUtvK5vZxwo8jzjzid5Ew OP_EQUALVERIFY OP_CHECKSIG scriptSig: pubKey signature σ 1FdtUtvK5vZxwo8jzjzid5Ew H(pubKey) pubKey signature σ

slide-46
SLIDE 46

Pay-to-pubkey-hash

scriptPubKey: OP_DUP OP_HASH160 1FdtUtvK5vZxwo8jzjzid5Ew OP_EQUALVERIFY OP_CHECKSIG scriptSig: pubKey signature σ pubKey signature σ

slide-47
SLIDE 47

Pay-to-pubkey-hash

scriptPubKey: OP_DUP OP_HASH160 1FdtUtvK5vZxwo8jzjzid5Ew OP_EQUALVERIFY OP_CHECKSIG scriptSig: pubKey signature σ 1

transaction completed successfully

slide-48
SLIDE 48

Pay-to-pubkey-hash

  • Most payments in bitcoin today are Pay-to-pubkey-hash
  • Pay-to-pubkey was used at the beginning of bitcoin
slide-49
SLIDE 49

A more complicated contract

OP_SIZE OP_NIP 16 OP_NUMEQUAL OP_NUMEQUAL OP_IF ALICE_PUB_KEY OP_ELSE BOB_PUB_KEY OP_END_IF OP_CHECKSIG OP_2DUP OP_HASH160 BOB_HASH_CONST OP_EQUALVERIFY OP_HASH160 ALICE_HASH_CONST OP_EQUALVERIFY OP_SIZE OP_NIP 16 OP_NUMEQUAL OP_SWAP

slide-50
SLIDE 50

How can one argue about the security of these?

  • These scripts are complicated and unreadable
  • How can we know they do what we want?
