Smart home and building solutions. Smart home and building solutions. Global. Secure. Connected. Global. Secure. Connected. Smart Switching Solutions with KNX-RF Batteryfree and wireless pushbutton module for KNX-RF Features


slide-1
SLIDE 1

Smart home and building solutions.

  • Global. Secure. Connected.

Smart home and building solutions.

  • Global. Secure. Connected.

Smart Switching Solutions with KNX-RF

slide-2
SLIDE 2

Join us

www.knx.org

Smart home and building solutions.

  • Global. Secure. Connected.
  • Self-powered, wireless pushbutton module for building automation
  • Maintenance-free – no batteries to replace
  • Easy to install – even in virtually inaccessible places
  • Configurable via ETS5 software using a

programming adapter

  • Direct communication with KNX RF devices

Batteryfree and wireless pushbutton module for KNX-RF – Features

slide-3
SLIDE 3

Join us

www.knx.org

Smart home and building solutions.

  • Global. Secure. Connected.
  • Compatible with standard frames and panels

for energy harvesting switch modules or combined with customer-specific designs

  • KNX RF1.R S-Mode
  • RF distance in buildings: up to 30 m
  • 20°C to 45°C
  • Min. 100,000 switching cycles

Pushbutton Module – Technical Details

P/N AFIM-1010

slide-4
SLIDE 4

Join us

www.knx.org

Smart home and building solutions.

  • Global. Secure. Connected.
  • Powers the module with energy during programming

phase via configuration software ETS

  • Adaptable to ZF KNX-RF pushbutton module
  • Min. 1,000 matching cycles
  • 5°C to 45°C

Programming Adapter – Technical Details

P/N AFZM-0001

slide-5
SLIDE 5

Join us

www.knx.org

Smart home and building solutions.

  • Global. Secure. Connected.

Integration of pushbutton module into ETS

  • Catalogue selection
  • Four push points, two push points are assigned to one

rocker for a custom programming by room and room use

  • Can be used as a two-, four- or six-fold device
  • General function: 4-fold push button (light on/off and

shutter up/down)

  • Two more functions are available by pushing a

combination of buttons (e.g. for dimming)

slide-6
SLIDE 6

Join us

www.knx.org

Smart home and building solutions.

  • Global. Secure. Connected.

Integration of pushbutton module into ETS – 2-Channel Switch Dimming

slide-7
SLIDE 7

Join us

www.knx.org

Smart home and building solutions.

  • Global. Secure. Connected.

Integration of pushbutton module into ETS – 4/6-Channel Switch

slide-8
SLIDE 8

Smart home and building solutions.

  • Global. Secure. Connected.

Smart home and building solutions.

  • Global. Secure. Connected.

Thank you for your attention! For more information, please visit https://switches-sensors.zf.com/knx-systems/

ZF Friedrichshafen AG Cherrystraße 91275 Auerbach Germany Markus.Bachmeyer@zf.com Jana.Pilhofer@zf.com
