SLIDE 1

Run your Research

On the Effectiveness of Lightweight Mechanization

C Klein, J Clements, C Dimoulas, C Eastlund, M Felleisen, M Flatt, J A McCarthy, J Rafkind, S Tobin-Hochstadt, R B Findler

1

SLIDE 2

and the Walrus the Orangutan, The Koala,

ftp> user anonymous 331 Guest login ok Password: 230-Welcome to λ.com int main () {

One day, Koala decided to build an ftp server 2

SLIDE 3

and the Walrus the Orangutan, The Koala,

230-Welcome to λ.com int main () { if (!(q = 0)) *((int*)p)=12; } \[\Gamma\ \vdash\

and made the unfortunate choice to use the programming language C. 3

SLIDE 4

and the Walrus the Orangutan, The Koala,

230-Welcome to λ.com int main () { if (!(q = 0)) *((int*)p)=12; } \[\Gamma\ \vdash\

We must not be surprised by this choice, however, as C is well-known to be a programming language that is effective for building systems software. 4

SLIDE 5

and the Walrus the Orangutan, The Koala,

230-Welcome to λ.com int main () { if (!(q = 0)) *((int*)p)=12; } \[\Gamma\ \vdash\

After a few months of effort, Koala produced a functioning server that was rapidly adopted across the internet and widely used. 5

SLIDE 6

and the Walrus the Orangutan, The Koala,

230-Welcome to λ.com int main () { if (!(q = 0)) *((int*)p)=12; } \[\Gamma\ \vdash\

One day, Orangutan decided to apply a new, automated testing technique to Koala’s ftp server and, sure enough, found multiple bugs — 6

SLIDE 7

and the Walrus the Orangutan, The Koala,

230-Welcome to λ.com int main () { if (!(q = 0)) *((int*)p)=12; }p == 0 ∨ *p == *q \[\Gamma\ \vdash\

unsurprising for software of that complexity implemented in a programming language like C. After all, C is designed for performance and provides no help to maintain invariants of data structures or to detect errors early, when they are easy to fix. 7

SLIDE 8

and the Walrus the Orangutan, The Koala,

}p == 0 *p == *q \[\Gamma\ \vdash\ (\lambda x:\tau_2.e) : \tau_1\rightarrow \tau_2 \]

So, Orangutan decided to write a paper that explained the mathematical techniques it used to uncover the bugs and made the unfortunate choice to use the programming language LaTeX. 8

SLIDE 9

and the Walrus the Orangutan, The Koala,

}p == 0 *p == *q \[\Gamma\ \vdash\ (\lambda x:\tau_2.e) : \tau_1\rightarrow \tau_2 \]

We must not be surprised by this choice, however, as LaTeX is well-known to be a programming language that is effective for typesetting mathematical formulas. 9

SLIDE 10

and the Walrus the Orangutan, The Koala,

}p == 0 *p == *q \[\Gamma\ \vdash\ (\lambda x:\tau_2.e) : \tau_1\rightarrow \tau_2 \]

After a few months of effort, Orangutan produced a paper extolling the virtues of its new techniques, and the ideas were adopted across the software engineering community and the paper was widely cited. 10

SLIDE 11

and the Walrus the Orangutan, The Koala,

}p == 0 *p == *q \[\Gamma\ \vdash\ (\lambda x:\tau_2.e) : \tau_1\rightarrow \tau_2 \]

One day, Walrus decided to apply a new, lightweight mechanized metatheory technique to Orangutan’s paper and, sure enough, found multiple bugs — 11

SLIDE 12

and the Walrus the Orangutan, The Koala,

}p == 0 *p == *q \[\Gamma\ \vdash\ (\lambda x:\tau_2.e) : \tau_1\rightarrow \tau_2 \]

unsurprising for a piece of mathematics of that complexity implemented in a programming language like LaTeX. After all, LaTeX is designed for beautiful output and provides no help to check invariants of mathematical formulas or to run examples to ensure they illustrate the intended points. 12

SLIDE 13

Moral: bugs are

everywhere

13

SLIDE 14

A niche for mechanized metatheory:

lightweight: high level of expressiveness (think scripting

language)

supports the entire semantics lifecycle:

Write-up Robust model Prototype model 14

SLIDE 15

The Semantics Lifecycle

Write-up Robust model Prototype model

15

SLIDE 16

misrenamed non-terminal

Write-up Robust model Prototype model

The Semantics Lifecycle

16

SLIDE 17

misrenamed non-terminal forgot typing rule

Write-up Robust model Prototype model

The Semantics Lifecycle

17

SLIDE 18

misrenamed non-terminal forgot typing rule lost a case in a helper function

Write-up Robust model Prototype model

The Semantics Lifecycle

18

SLIDE 19

misrenamed non-terminal forgot typing rule lost a case in a helper function added a case to wrong fn

Write-up Robust model Prototype model

The Semantics Lifecycle

19

SLIDE 20

misrenamed non-terminal forgot typing rule lost a case in a helper function added a case to wrong fn

Write-up Robust model Prototype model

swappped args

The Semantics Lifecycle

20

SLIDE 21

misrenamed non-terminal forgot typing rule lost a case in a helper function added a case to wrong fn

Write-up Robust model Prototype model

swappped args misused the inductive hyp.

The Semantics Lifecycle

21

SLIDE 22

misrenamed non-terminal forgot typing rule lost a case in a helper function added a case to wrong fn

Write-up Robust model Prototype model

swappped args misused the inductive hyp. didn’t recheck a lemma

The Semantics Lifecycle

22

SLIDE 23

misrenamed non-terminal forgot typing rule lost a case in a helper function added a case to wrong fn

Write-up Robust model Prototype model

swappped args misused the inductive hyp. didn’t recheck a lemma transcribed math wrong

The Semantics Lifecycle

23

SLIDE 24

misrenamed non-terminal forgot typing rule lost a case in a helper function added a case to wrong fn

Write-up Robust model Prototype model

swappped args misused the inductive hyp. didn’t recheck a lemma transcribed math wrong forgot to recheck example

The Semantics Lifecycle

24

SLIDE 25

Redex

ur tool designed to fill this niche

25

SLIDE 26

Our study:

Can random testing find bugs in an existing,

well-tested Redex model?

Can Redex find bugs in published papers?

26

SLIDE 27

Our study:

Can random testing find bugs in an existing,

well-tested Redex model? Yes

Can Redex find bugs in published papers?

Yes

27

SLIDE 28

10

10 papers in Redex 9 ICFP ’09 papers 8 written by others 2 mechanically verified

28

SLIDE 29

10

papers with errors

10

10 papers in Redex 9 ICFP ’09 papers 8 written by others 2 mechanically verified

29

SLIDE 30

10

Your

papers have errors too

10

30

SLIDE 31

Copy & Paste Typesetting Error:

31

SLIDE 32

Copy & Paste Typesetting Error:

32

SLIDE 33

Copy & Paste Typesetting Error: Typesetting should be automatic

33

SLIDE 34

Erroneous Example:

34

SLIDE 35

Erroneous Example:

35

SLIDE 36

Erroneous Example:

36

SLIDE 37

Erroneous Example: Examples can be tested

37

SLIDE 38

Unexpected Behavior: select(c, c)

38

SLIDE 39

Unexpected Behavior: compile select(c, c) ⊙c | ~ select(c, c)

39

SLIDE 40

Unexpected Behavior: compile select(c, c) – stuck ⊙c | ~ select(c, c) – loops forever Deadlock in source but busy waiting in target

40

SLIDE 41

Unexpected Behavior: compile select(c, c) – stuck ⊙c | ~ select(c, c) – loops forever Deadlock in source but busy waiting in target Found this by playing with examples

41

SLIDE 42

False Theorem: If a term reduces with a memo store, then the program without the memo store reduces the same way

42

SLIDE 43

False Theorem: If a term reduces with a memo store, then the program without the memo store reduces the same way Counterexample: If σ = {(δ,1) → 2} then (λδ x. x) 1, σ ⇒* 2, σ, but (λδ x. x) 1 ↦ 1 Not a fly-by-night proof; 12 typeset pages in a dissertation chapter

43

SLIDE 44

False Theorem: If a term reduces with a memo store, then the program without the memo store reduces the same way Counterexample: If σ = {(δ,1) → 2} then (λδ x. x) 1, σ ⇒* 2, σ, but (λδ x. x) 1 ↦ 1 Not a fly-by-night proof; 12 typeset pages in a dissertation chapter Random testing easily finds this

44

SLIDE 45

Recap:

Automatic typesetting
Unit Testing
Exploring Examples
Random testing

45

SLIDE 46

p ::= (e ...) e ::= (e e ...) | (λ (x:t ...) e) | x | (+ e ...) | number | (amb e ...) t ::= (→ t ... t) | num P ::= (e ... E e ...) E ::= (v ... E e ...) | (+ v ... E e ...) | [] v ::= (λ (x:t ...) e) | number Γ ::= · | (x : t Γ) P[((λ (x:t ...1) e) v ...1)] [βv] P[e{x:=v ...}] P[(+ number1 ...)] [+] P[Σ[[number1, ... ] ] ] (e1 ... E[(amb e2 ...)] e3 ...) [amb] (e1 ... E[e2] ... e3 ...) Γ ⊢ e1 : (→ t2 ... t3) Γ ⊢ e2 : t2 ... Γ ⊢ (e1 e2 ...) : t3 (x1 : t1 Γ) ⊢ (λ (x2:t2 ...) e) : (→ t2 ... t) Γ ⊢ (λ (x1:t1 x2:t2 ...) e) : (→ t1 t2 ... t) Γ ⊢ e : t Γ ⊢ (λ () e) : (→ t) (x : t Γ) ⊢ x : t Γ ⊢ x1 : t1 x1 ≠ x2 (x2 : t2 Γ) ⊢ x1 : t1 Γ ⊢ e : num ... Γ ⊢ (+ e ...) : num Γ ⊢ number : num Γ ⊢ e : num ... Γ ⊢ (amb e ...) : num Γ ⊢ e : num ... Γ ⊢ (amb e ...) : num (e1 ... E[(amb e2 ...)] e3 ...) [amb] (e1 ... E[e2] ... e3 ...) | number | (amb e ...) t ::= (→ t ... t) | num p ::= (e ...) e ::= (e e ...)

46

SLIDE 47

p ::= (e ...) e ::= (e e ...) | (λ (x:t ...) e) | x | (+ e ...) | number | (amb e ...) t ::= (→ t ... t) | num P ::= (e ... E e ...) E ::= (v ... E e ...) | (+ v ... E e ...) | [] v ::= (λ (x:t ...) e) | number Γ ::= · | (x : t Γ) P[((λ (x:t ...1) e) v ...1)] [βv] P[e{x:=v ...}] P[(+ number1 ...)] [+] P[Σ[[number1, ... ] ] ] (e1 ... E[(amb e2 ...)] e3 ...) [amb] (e1 ... E[e2] ... e3 ...) Γ ⊢ e1 : (→ t2 ... t3) Γ ⊢ e2 : t2 ... Γ ⊢ (e1 e2 ...) : t3 (x1 : t1 Γ) ⊢ (λ (x2:t2 ...) e) : (→ t2 ... t) Γ ⊢ (λ (x1:t1 x2:t2 ...) e) : (→ t1 t2 ... t) Γ ⊢ e : t Γ ⊢ (λ () e) : (→ t) (x : t Γ) ⊢ x : t Γ ⊢ x1 : t1 x1 ≠ x2 (x2 : t2 Γ) ⊢ x1 : t1 Γ ⊢ e : num ... Γ ⊢ (+ e ...) : num Γ ⊢ number : num Γ ⊢ e : num ... Γ ⊢ (amb e ...) : num

Γ ⊢ e : num ... Γ ⊢ (amb e ...) : num (e1 ... E[(amb e2 ...)] e3 ...) [amb] (e1 ... E[e2] ... e3 ...) | number | (amb e ...) t ::= (→ t ... t) | num p ::= (e ...) e ::= (e e ...)

47

SLIDE 48

Recap: ✓ Automatic typesetting ✓ Unit Testing ✓ Exploring Examples ✓ Random testing

48

SLIDE 49

Takeaways:

Nobody will produce error-free papers
Errors introduce friction into our communication
Redex can help reduce the errors — with about as

much effort as LaTeX requires

49

SLIDE 50

Thank you.

50
