RADITEK SATCOM www.raditek.com/telecom 2014 A California USA corporation RADITEK 2014 SATCOM OVERVIEW PRESENTATION 1 Component and System Products Founded in 1 9 9 3 By Malcolm Lee & Peter Corbett RF/ Microw ave Com ponents m

slide-1
SLIDE 1

RADITEK SATCOM

www.raditek.com/telecom

2014

1 RADITEK 2014 SATCOM OVERVIEW PRESENTATION

A California USA corporation

slide-2
SLIDE 2

Component and System Products

2

Founded in 1 9 9 3 By Malcolm Lee & Peter Corbett

RF/ Microw ave Com ponents m anufacturer… Stripline, Coax, Microstrip, w aveguide isolators and circulators Phase locked DRO, Synthesizer Filters, couplers, Splitters, com biners Telecom m unications SYSTEMS:-

RADITEK 2014 SATCOM OVERVIEW PRESENTATION

slide-3
SLIDE 3

Satellite Products BUCs

3 RADITEK 2014 SATCOM OVERVIEW PRESENTATION

slide-4
SLIDE 4

Satellite Products Power BUCS Ku/Ka

4 RADITEK 2014 SATCOM OVERVIEW PRESENTATION

slide-5
SLIDE 5

Satellite Products Beacon receivers

5 RADITEK 2014 SATCOM OVERVIEW PRESENTATION

slide-6
SLIDE 6

Satellite Products

Dream and Super Dream (DamaREAdy Modem) DAMA (Demand Assigned Multiple Acess) ABOD (Adaptive Bandwidth on Demand)

ALL IP based ROUTER SCPC modem, which is always SINGLE HOP. Can be used as either: 1.A Stand alone SCPC, Point to Point modem or 2.A remote “TDM” based modem function used in a DREAM Super Hub modem network or 3.A super (satellite) efficient DAMA (Demand Assigned Multiple Access) based SCPC modem ABOD)

  • Multiple STAR or MESH networks
  • Central network status display, spectrum analyzer display etc

6

TPC or LDPC To 22MBPS To 16QAM

RADITEK 2014 SATCOM OVERVIEW PRESENTATION

slide-7
SLIDE 7

LNB BUC SPLITTER Broadcasts the TDM control Channel to the w hole netw ork Tx From STSR Card To 8RO cards To 4 per Dream Super Zero loss active splitter IF UNIT CAT 5 IP cables DAMA HUB I ncom ing RX channels for all the netw ork Are m onitored here NMS Server

7 RADITEK 2014 SATCOM OVERVIEW PRESENTATION

slide-8
SLIDE 8

Satellite Products DVB-S2/S2x Modulator

Features:

  • L-Band and I F ( 7 0 / 1 4 0 M) Band support
  • Sym bol rate from 0 .1 to 6 8 Msps ( w ith 1 sps step)
  • Low channel roll-off ( 5 % to 3 5 % , 1 % step)
  • 1 6 APSK & 3 2 APSK m odulations included
  • Carrier I D com pliant ( ETSI 1 0 3 1 2 9 ) DVB-CI D
  • ASI and I P inputs
  • BI SS 0 / 1 / E encryption
  • Multi-stream according to EN 3 0 2 3 0 7 standard
  • Block Up Converter ( BUC) Driver options
  • Up to 6 4 em bedded profiles
  • Physical Layer Scram bling according to EN 3 0 2 3 0 7
  • 1 + 1 redundancy m anagem ent
  • Low pow er consum ption

8 RADITEK 2014 SATCOM OVERVIEW PRESENTATION

slide-9
SLIDE 9

Satellite Products DVB-S2/S2x DeModulator

Features:

  • Dual L-Band ( 9 5 0 -2 1 5 0 M) ports
  • Sym bol rate from 0 .2 to 6 5 Msps to 2 4 0 MBPS
  • Low channel roll-off: 5 % to 3 5 % , ( 5 % step) support
  • 1 6 APSK & 3 2 APSK dem odulation included
  • Very low im plem entation loss ( w ith dem od. option)
  • Quick boot tim e
  • Low pow er consum ption ( 9 W fan-less)
  • RS2 3 2 and 1 2 C control and m onitor
  • Physical layer scram bling to EN 3 0 2 3 0 7 standard
  • Multi-stream support
  • CCM, VCM, ACM support
  • Seam less sw itching of MODCOD w ith ACM

9 RADITEK 2014 SATCOM OVERVIEW PRESENTATION

slide-10
SLIDE 10

Satellite Products

DVB-S2/S2x MODEM

10 RADITEK 2014 SATCOM OVERVIEW PRESENTATION

slide-11
SLIDE 11

Satellite Products DVB-S2/S2x Modulator

11 RADITEK 2014 SATCOM OVERVIEW PRESENTATION

slide-12
SLIDE 12

Satellite Products DVB-S2/S2x Modulator

12 RADITEK 2014 SATCOM OVERVIEW PRESENTATION

slide-13
SLIDE 13

Satellite Products EXTREME MODEM

Multi I F band support: ( 7 0 M/ 1 4 0 MHz and L-band) Data rates 1 8 Kbps to 1 5 5 Mbps DVB-S2 -/ ACM, to 1 6 APSK. LDPC/ BCH, TPC FEC options Terrestrial interface options including Ethernet: EI A-5 3 0 , G.7 0 3 ( balanced & unbalanced) , OC-3 , STM-1 , Serial LVDS, ASI , HSSI , Quad E1 , Modulation up to 6 4 QAM Sim u-Carrier™ option ( reusing uplink frequencies) Uplink Pow er control ( AUPC) Signal-under-carrier™ real tim e interferer detection tool Built-in spectrum and constellation m onitors tool I Pv6 com pliant Drop and insert: T1 -D4 , T1 -ESF, E1 -G.7 3 2 I nteroperable w ith other Raditek SCPC m odem s

13 RADITEK 2014 SATCOM OVERVIEW PRESENTATION

slide-14
SLIDE 14

Satellite Products Antenna

14 RADITEK 2014 SATCOM OVERVIEW PRESENTATION

slide-15
SLIDE 15

Satellite Products

Man Pack Antenna system

15 RADITEK 2014 SATCOM OVERVIEW PRESENTATION

slide-16
SLIDE 16

Satellite Products IOTM antenna Ku, Ka

  • Linear or circular polarization available
  • Com patible w ith RADI TEK DREAM m odem s, BUCs and LNBs
  • Cold start acquisition < 3 m in,
  • < 1 0 0 m s re-acquisition after signal loss/ block
  • Rescan < 2 0 s
  • High Pow er, low profile BUC ( eg 4 0 W ) available

16 RADITEK 2014 SATCOM OVERVIEW PRESENTATION

slide-17
SLIDE 17

Satcom Special Projects.

RADI TEK can provide turnkey solutions Exam ple1 : Rapid response system ( using m anpacks and vehicles) using Satellite backhaul, w ith TETRA/ LTE m icro-base stations, handsets etc. Also connects to VHF, UHF radio system s and video over I nternet. Using video servers and m ulti large screen displays of 1 0 0 0 s of video feeds. Exam ple2 : Design single and m ulti-hop satellite links around the w orld, connecting to m ulti-redundant, ship borne and ground locations to track a Mars Orbiter launch. Contact us for m ore inform ation, W e w ant to be your turn-key solutions partner ( 4 0 8 ) 2 6 6 - 7 4 0 4 , sales@raditek.com

17 RADITEK 2014 SATCOM OVERVIEW PRESENTATION
