Satellite Uplink Amplifier Specialists

EUROPE’S DEDICATED SATELLITE AMPLIFIER MANUFACTURER

E2v Satcom product range acquired in April 14

Located in Hook (45mins LHR Airport) Private, British Company, run by Satellite Professionals.. An organisation focused on our Customers! Over 8,000 fielded amplifiers

All legacy designs have undergone thorough engineering review Products in production and available on short delivery lead- times C, Ku, DBS (typically 30-45 days)

Shipped over 280 units over 12 months

A strategic partnership formed with IRT Canada (established over 5 years) Spacepath assemble, market & support across EMEA a full range of SSPA/SSPBs & Redundant systems

SSPA/SSPBs

A complete product portfolio

Band C X Ku DBS KA Q 800 500 400 300 200 100 90 80 70 60 50 40 30 20 10 750 750 750 750 500 500 400 400 400 400 300 200 100 / 150 80 40 20 100 / 150 180 200 250 / 300 / 350 80 60 40 50 16 / 20 / 25 20 8 / 10 150 / 175 200 TWTA SSPA

High Power Uplink Amplifiers (TWTAs)

Power levels: 200- 1200W Frequencies: C, X, Ku, DBS & Ka Bands

Solid State Uplink Amplifiers (SSPAs)

Power levels: 8-600W Frequencies: C, X, Ku & Ka Bands

Redundant & Power Combined Systems & Controllers

Our Products

High Power Uplink Amplifiers (TWTAs) Outdoor Amplifiers

Ultra linear, high efficiency, small, lightweight & low prime power consumption

For DSNG &

• n-the-move

applications For fixed earth station applications

OPTIONS

• Gain control
• L-band block upconverter
• Break-out link for upconverter
• Lineariser (allowing 4dB Back-off)

FEATURES

• Lightweight and compact
• High operating temperature
• Circulator, receive band filter and

harmonic filter included as standard

• Weatherproof antenna mount
• RoHS compliant
• CE compliant

 Small, Lightweight & Efficient

350mm L, 185mm W, 132mm H, 9kg weight

 Optional BUC & 10Mhz Autosense Ref  Redundant & Phased Combined options

180W Stellar Mini Amplifier Series

OPTIONS

• Lineariser
• L-Band Block upconverter
• Break-out link for upconverter

FEATURES

• Lightweight and compact
• High operating temperature
• Circulator, receive band filter and

harmonic filter included

• Weatherproof antenna mount
• RoHS compliant &• CE compliant

 Optional BUC & 10Mhz Autosense Ref  Offered in 1:1, 1:2 Phased combined systems  Same RF Performance – Thales or NEC TWTs  Same Size, Weight & Efficiency as others  400W C-Band, X-Band, Ku-Band

400W CW Stellar Amplifier Series

 Optional BUC & 10Mhz Autosense Ref  Redundant & Phased Combined Systems FEATURES

• Lightweight and compact
• High operating temperature +55c
• Circulator, receive band filter &

harmonic filter included

• V/Gain Control
• Lineariser included

 Linear Power 175W  Small, Lightweight & Efficient

400W Ku High Efficiency Amplifier

OPTIONS

• Lineariser
• L-band block upconverter
• Break-out link for upconverter

FEATURES

• Lightweight and compact
• High operating temperature
• Circulator, receive band filter and

harmonic filter included

• Weatherproof antenna mount
• RoHS compliant &• CE compliant

 Optional BUC & 10Mhz Autosense Ref  Offered in 1:1, 1:2 Phased combined systems  Same RF Performance – Thales or NEC TWTs  Same Size, Weight & Efficiency as others  750W C-Band, X-Band, Ku-Band, DBS- Band

750W CW Stellar Amplifier Series

Small, Lightweight & Efficient

Proven, Ruggedized, Highly Efficient Power Supply Designs

Advanced Thermal Mechanical Design

Ka Band Amplifiers

Ka Band Amplifiers

STA3252 Thermal Design

Ka Band Amplifiers

STA3252 Thermal Testing

 Optional BUC & 10Mhz Autosense Ref  Redundant & Phased Combined Systems FEATURES

• Ethernet SNMP
• High operating temperature +55c
• Commercial & Military Bands
• V/Gain Control
• Lineariser included

 Linear Power 135W (250W Peak)  Small, Lightweight & Efficient

120-175W Ka High Power Amplifier Series

 Optional BUC & 10Mhz Autosense Ref  Redundant & Phased Combined Systems FEATURES

• Ethernet /SNMP
• High operating temperature +55c
• Commercial & Military Bands
• V/Gain Control
• Lineariser included

 Lightweight 14.5Kg  Smallest 500W Ka amplifier available

45.7cm(18”)x22.8cm(9”)x21.5cm(8.5”)

500W Ka High Power Compact Amplifier Series

 Optional BUC & 10Mhz Autosense Ref  Redundant & Phased Combined Systems FEATURES

• Quick Release Liquid connectors
• Ethernet /SNMP
• High operating temperature +55c
• Commercial & Military Bands
• V/Gain Control
• Lineariser included

 Lightweight 15.4Kg  Compact Form factor

45.7cm(18”)x22.8cm(9”)x19.5cm(7.7”)

500W Ka High Power Liquid Cooled Amplifier

High Power Uplink Amplifiers (TWTAs) Indoor Rack Amplifiers

 400W,750W, 1250W C-, X-, Ku- & DBS-band  Touch-screen TFT front panel provides an easy-to-use visual interface:  HPA’s operational status,  Graphical displays of parameter trend analysis and event logs  Built-in Ethernet network interface for local and remote diagnostics

For fixed earth station applications

 Optional BUC & 10Mhz Autosense Ref  Redundant & Phased Combined Systems FEATURES

• Easy to use, colour touch

screen control

• Event Logging Feature
• TWTA Performance Data
• Front Panel Redundancy Control
• Lineariser option

 400W/750W C, X, Ku & DBS Bands  Easy to use touch screen control

Indoor Rack Amplifier SPR Series

Indoor Rack Amplifier Layout

Easily accessible fan assembly Complete Power Supply Assembly can be removed/replaced Easy access to RF Assembly Air flow directed

• ver power supply

heat sink & TWT assembly

Indoor Rack Amplifier SPR Series

Indoor Rack Amplifier SPR 750 Series

FEATURES

• Easy to use, colour touch

screen control

• Event Logging Feature
• TWTA Performance Data
• Front Panel Redundancy Control
• Linearisption

Indoor Rack Amplifier SPR Series

FEATURES

• Easy to use, colour touch

screen control

• Event Logging Feature
• TWTA Performance Data
• Front Panel Redundancy Control
• Linearistion

Indoor Rack Amplifier SPR Series

Indoor Rack Amplifier SPR Series

GaAs & GaN Solid State Amplifiers (SSPAs) Outdoor Amplifiers

 C- to Ka-bands and power outputs from 8 to 600W  For Lightweight, High Efficiency SSPA design  Featuring GaAs & GaN Technology  Low prime power consumption

For flyway and

• n-the-move

uplink applications

C-Band SSPBs

Ku-Band SSPBs

Redundant and Phase Combined Subsystems

1:1 Redundant Systems Ampiers

 Two amplifiers, indoor

controller, cable harness

 External waveguide

network, load and waveguide switch



Three amplifiers, touch Screen indoor controller, cable harness



External waveguide network, loads and waveguide switches



Standard two amplifier power combined system



Two amplifiers, indoor controller, cable harness



External waveguide network, combiner, phase adjuster, load and waveguide switch

1:2 Redundant Systems Power Combined Systems



Unique three amplifier power combined system



Three amplifiers, indoor controller, cable harness



External waveguide network, combiner, phase adjuster, load and waveguide switch

1:2 Power Combined Systems

Customer Support

First class, support & service

Repair turn-around is less than 2 weeks ,

• ne week for urgent

situations Amplifiers & controllers available to support any temporary situation Telephone technical support Remote diagnostics

Built on the reputation of the founders of the Company

Reliability, Choice and Innovation

USA

Support Centres

With Support Centres in EMEA, Asia & USA

UAE UK Singapore SA India

An Industry Standard

We also offer Events Rental Purchase Lease Schemes

Visit our New Web Site

www.space-path.com
