AT Industry Day- ARTES presentation ESA-TIA-T-HO-0082 ESA UNCLASSI FI ED - For Official Use Overview of Satcom Market Evolution ESA View, May 2019 Dietmar Schmitt, TIA-TT Vienna, 18/ 06/ 2019 ESA-TIA-T-HO-0082 ESA UNCLASSI FI ED - For

slide-1
SLIDE 1

ESA UNCLASSI FI ED - For Official Use

AT Industry Day- ARTES presentation

ESA-TIA-T-HO-0082

slide-2
SLIDE 2

ESA UNCLASSI FI ED - For Official Use

Overview of Satcom Market Evolution

ESA View, May 2019

Dietmar Schmitt, TIA-TT Vienna, 18/ 06/ 2019

ESA-TIA-T-HO-0082

slide-3
SLIDE 3

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 3

Operational Satellites by Domain end 2018

Proportion of communications satellites falling and now well below 50% , Earth observation increasing

slide-4
SLIDE 4

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 4

Global Satellite Industry Revenue

slide-5
SLIDE 5

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 5

Space heavy industry underpins a sector 10.8 times its own size

  • Satellite TV
  • Satellite radio
  • Satellite broadband

receivers and chip sets

Key growth areas:

  • satellite radio
  • satellite broadband
  • managed services
  • mobile services
  • EO services

Key growth areas:

  • network equipment
  • GNSS chip sets

Global Satellite Industry Revenue 2018 Breakdown

slide-6
SLIDE 6

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 6

Satellite TV Revenue since 2000 ($ billions)

Product Life Cycle

slide-7
SLIDE 7

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 7

Ground Equipment 2018 Revenue Breakdown

slide-8
SLIDE 8

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 8

Satellite Operators

slide-9
SLIDE 9

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 9

Conventional Satellite Operators’ Revenue

Operator 2 0 1 8 w rt 2 0 1 7

Q1 2 0 1 9 w rt Q1 2 0 1 8

Amos Spacecom 17.0%

6.0&

AsiaSat 6.5% APT Satellite 2.5% SES

  • 1.2%
  • 3.1%

Eutelsat

  • 2.4%
  • 2.8%

Telesat

  • 2.6%
  • 4.3%

Revenue w eighted average for sector

  • 2 .8 %

Intelsat

  • 4.2%
  • 2.8%

EchoStar Satellite Services

  • 8.7%
  • 16.0%

Thaicom

  • 10.2%

+ 10.6%

Avanti

  • 28.0%
slide-10
SLIDE 10

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 10

Long-Term Trend in GEO Satellite Orders

slide-11
SLIDE 11

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 11

Smallsats and Constellations

slide-12
SLIDE 12

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 12

SmallSats and CubeSat Launches

slide-13
SLIDE 13

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 13

Some of Today’s Constellations Projects

Operator Orbit Num ber of Satellites SpaceX Q/ V-band LEO 7,518 1 SpaceX Ku-band LEO 4,425 2 Amazon Ku-band LEO 3,236 Boeing Q/ V-band LEO 2,956 OneWeb Q/ V-band MEO 1,280 OneWeb Q/ V-band LEO 720 OneWeb Ku-band LEO 648 Kepler LEO 140 Telesat Ka-band LEO 117 Theia LEO 112 LEOSat LEO 108 O3b MEO 60 Boeing Ka-band LEO 60 ViaSat Ka-band MEO 24

Note 1: SpaceX Q/ V-band 7,518 satellites x 227kg = 1,706 tonnes = 27 x Falcon Heavy or 85 x Ariane 5 launches Note 2: SpaceX Ku-band 4,425 satellites x 227kg = 1,004 tonnes = 16 x Falcon Heavy or 50 x Ariane 5 launches

slide-14
SLIDE 14

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 14

Most Credible Constellations

1. O3b – 20 first generation MEO satellites launched, 7 second-generation O3b mPOWER satellites on order 2. OneWeb – 6 test & demo satellites launched, 648 to be built and launched starting December 2019 3. SpaceX Starlink – downsized from 11,943 satellites to 1,548 satellites, 2 test & demo satellites launched, 60 satellites launched May 2019 and possibly 360 more this year 4. Telesat LEO – 1 test & demo satellite launched, contract to be placed this summer for 117 / 292 / 512 satellite constellation 5. Amazon – latest credible entrant with plans for 3,236 satellite constellation

slide-15
SLIDE 15

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 15

O3b 17-20 Launched Successfully on 4th April 2019

slide-16
SLIDE 16

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 16

OneWeb Satellites Factory, Florida

Late 2017 Early 2019

slide-17
SLIDE 17

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 17

SpaceX Starlink Satellites in Falcon 9 Nosecone

slide-18
SLIDE 18

ESA UNCLASSI FI ED - For Official Use

ARTES Future Preparation and Core Competitiveness: An Overview for Austria

Dietmar Schmitt, TIA-TT Vienna, 18/ 06/ 2019

slide-19
SLIDE 19

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 19

ARTES Objectives

ARTES: Advanced Research in Telecommunications Systems

  • Support the competitiveness
  • f the European and

Canadian industry on the world market

  • Develop the use of space for

the benefit of the European citizens and of the economy

slide-20
SLIDE 20

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 20

space science hum an spaceflight exploration earth observation launchers navigation

  • perations

technology

TIA: Telecommunications and Integrated Applications Directorate ARTES: Advanced Research in Telecommunications Systems

  • Future Preparations (FP)
  • Business Applications

Integrated Applications Promotion (IAP)

  • Core Com petitiveness ( CC)
  • ScyLight
  • Large Platform Mission (LPM)
  • Next Generation Platform (Neosat)
  • European Data Relay Satellite System (EDRS)
  • Iris - SatCom for Air Traffic Management
  • Automatic Identification System (SAT-AIS)
  • Partner (e.g. Electra, Quantum, Indigo, ECO,

Pioneer, Govsatcom, AIDAN)

telecom m unications ( TI A) ARTES = Advanced Research in Telecom m unications System s

slide-21
SLIDE 21

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 21

The ARTES Programme: Based on Partnership

  • National Delegates contribute

funding

  • I ndustry & institutions(1) develop

technology and products(2) for the world Satcom market

  • ESA shares the risks and manages

the contracts and activities

  • I ndustry brings the end result to

market & retains IPR

(1) within ESA Member States participating in ARTES (2) Any hardware, software, system or sub-system, service or application item

slide-22
SLIDE 22

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 22

ARTES 4 .0 A Matrix with Strategic and Generic Programme Lines

Space for 5 G Strategic Program m e Lines Responding to societal/ economic objectives Flexibility for MS/ Subscriptions

Partnership Projects Business Applications Space Solutions Core Com petitiveness

Generic Program m e Lines Maximum efficiency/ Execution Secure System s for Safety and Security ( 4 S) Optical Com m unication

  • ScyLight

€

slide-23
SLIDE 23

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 23

  • Space for 5 G ( S4 5 G)

 The new generation of communications is key to support the Digital Transformation with integration of satellite with terrestrial telecom networks

  • Secure System s for Safety and Security ( 4 S)

 Innovative solutions to societal challenges and the security of European citizens; Aiming at coherence wrt EU GOVSATCOM as anchor customer

  • ScyLight - Optical Com m unication

 Cutting edge technology at the frontiers of knowledge and with technological challenges yet to be mastered. Foster Industry capabilities to answer to the upcoming markets and to provide solutions to European strategic needs.

Covering highly visible societal/ econom ic high im pact objectives

Strategic Program Lines in ARTES 4.0

slide-24
SLIDE 24

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 24

Space for 5 G Secure Satcom for Safety and Security 4 S SAGA

Security and Cryptographic Mission

ARTES Space19+ OPPORTUNITIES

NOVACOM Next Gen Satcom System s

I RI S Satcom

Global Solution

SUNRI SE Phase 2

Optical Com m unication

Strategic Lines Generic Lines

EDRS Global

slide-25
SLIDE 25

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 25

ARTES Future Preparation ( FP)

  • The strategy elem ent of ARTES

based on continuously open “Call for Ideas” and Rolling Work Plan (100% funded) No specific support required from National Delegations Results are freely available to all actors within the ARTES States

slide-26
SLIDE 26

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 26

Future Preparation Scope - 4 Activity Streams

  • Monitor and assess market developments and performance:

 Creating insight and understanding of future needs

  • Out-reach and engagement with actors from across the Satcom

sector:

 New Entrants, Start-ups, Adjacent Industries, Established Players, Academia, Institutions

  • Identify and explore new applications, technologies, and

systems:

 Characterize opportunities for growth across the value chain

  • Build new ARTES programme activity:

 Technology Validations, Product Developments, Demonstration and Validation Opportunities

slide-27
SLIDE 27

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 27

Future Preparation: Current Study Areas

Study Topics Addressed by the Current Work Plans

  • Chinese Satcom Development
  • HAPS
  • VLEO Systems
  • M2M/ IoT
  • Small Satellites
  • Machine Learning and AI
  • Open Source Development
  • Constellations
  • 5G
  • Big Data
  • Communication Techniques
  • WRC-19 Preparation
  • Spectrum Access
  • Next Gen Trunking Systems
  • VHTS/ UHTS Development
  • Standardisation
  • Cyber Security
  • In-Orbit Servicing
slide-28
SLIDE 28

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 28

Via the ESA ARTES web-site (https: / / artes.esa.int/ future-preparations/ projects):

 Summaries of over 150 running and completed ARTES Future Preparation activities  Copies of Final reports and Executive Summaries can be requested (normally provided within a week)  Available to anyone working within the ARTES participating states (web site registration required)

By attending the ARTES Final Presentation days:

 Presentation of all Future preparation studies completed in the previous year by contractors  Outcomes of internal studies and investigations  Typical every January at ESTEC

How Can I Access the Results of Future Preparation?

slide-29
SLIDE 29

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 29

ARTES CC – over 25 Years of Success

Paves the future of Satcom technology and products, aw arding > 1 4 0 M€ in 2 0 1 8 Attracts Industry, Academy, SMEs, Institutions Attracts large private investments: 300 M€ since 2014 Provides business and technical knowledge to all stakeholders and fosters cooperation Delivers high Socio-Economic Impact to ESA Member States Catalyst of Satcom Innovation in Europe

4 .7 / 5

Support Rating by I ndustry

4 .8 / 5

Overall experience Rating by I ndustry

> 50 ARTES AT ITTs issued per year

> 330M€ Total price of running contracts > 535M€ Total cost of running contracts (* )

582 M€ ARTES CC funding subscribed at 2016 ESA Ministerial Council (2017-2019)

(* ) including Industrial funding – status end 2017

> 3 5 0 running contracts

  • Ca. 100 new contracts per year
slide-30
SLIDE 30

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 30

  • 1. Makes funding available
  • 2. Facilitates synergies and cooperation among Industry
  • 3. Enables think tank for ideas and opportunities
  • 4. Offers independent assessment and

technical expertise

  • 5. Ensures full transparency of the process
  • 6. Guarantees confidentiality and fairness

ARTES Core Competitiveness (‘ARTES CC’):

ADDED VALUE

slide-31
SLIDE 31

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 31

Definition Technology Product Dem onstration Advanced Technology ( AT)

Up to 50% * 100%

ARTES Com petitiveness & Grow th ( C&G) ARTES AT

Initiated By Industry Call for Ideas (CfI)

Direct Negotiation ARTES Core Competitiveness Element

Required for all phases

Open Competition

Up to 50% * Up to 75% Up to 50% *

& Industry

* 75% for SMEs

slide-32
SLIDE 32

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 32

ARTES Advanced Technology on the ARTES website

https:/ / artes.esa.int/ advanced-technology

slide-33
SLIDE 33

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 33

ARTES Competitiveness & Growth Development Phases

Breadboard, prototype or EM

Products ready for the market

50% Technical Studies Requirements System Analysis

Activities Objectives

Technical Risk Mitigation

  • Development
  • Qualification
  • Verification
  • Industrialisation

Validated Products

  • Space flight “Atlas”
  • Ground operational valid.
  • Application: pilot phase

Definition Technology Product

FP

ARTES Com petitiveness & Grow th

Up to 50% *

CCN CCN CCN

CNN: Contract Change Notice EM : Engineering Model FP : Full Proposal

FP FP FP Dem onstration

Products validated in the

  • perational environment

I nitiated by I ndustry

Up to 75% Up to 50% * Up to 50% *

* 75% for SMEs

slide-34
SLIDE 34

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 34

ARTES Competitiveness & Growth Process

Outline Proposal (OP) Full Proposal (FP) Submission Clarification & Negotiation Contract Consult Delegation

Industry National Delegation

OP Feedback Authorisation of Funding Evaluation and feedback

ESA

Announcement of FP Submission

Gate x-1

~ 4 weeks

Gate x

> 2 weeks > 5 weeks

slide-35
SLIDE 35

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 35

Funding Levels in ARTES C&G

Development Phase

Funding level up to

Non-SME SME

Definition Phase

  • up to 250 k€

50% 75%

Technology Phase

75% 75%

Product Phase

50% 75%

Demonstration Phase

50% 75%

slide-36
SLIDE 36

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 36

Maxim um Funding Level for Universities or Research I nstitutes ARTES C&G Developm ent Phase W ith commercial Interest in the product (SME status) No commercial interest in the product Definition Phase 7 5 % * 5 0 % * Technology Phase 7 5 % * 1 0 0 % * Product Phase 7 5 % * 5 0 % * Dem onstration Phase 7 5 % * not allow ed

* up to 3 0 % of total contract cost

Funding Levels in ARTES C&G: Universities and Research Institutions

slide-37
SLIDE 37

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 37

Summary of Main Changes in ARTES C&G CfP rev.2

 SMEs: support increased to 75% for all development phases (no ARTES Entry)  Atlas also allows ‘pilot’ case flight configuration (up to 25 Mio Euro)  Sim plified Full Proposal Tem plate:

  • Reduced from 12 to 7 parts
  • Optional Parts for smaller Proposals from SMEs (up to 500k Euro)
  • 5 w eeks ESA response to industry after Full Proposal submission thanks to

introduction of “Gates” (approximately every 4 weeks) … and com ing soon: ARTES 4 .0

slide-38
SLIDE 38

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 38

Satcom Technology Pillars – Where to invest

Q/ V, W band devices, systems, techniques and equipment for ground and space Scalable and efficient digital signal processing for ground and space Optical devices, systems, techniques and equipment for ground and space Multi-beam antennas Large reflectors Flat Self-Scanning user terminals Digital transformation of the value chain (Industry 4.0)

m m w avelength Com m unication Digital Processing Optical Com m unication Sm art Antenna Sm art Manufacturing

slide-39
SLIDE 39

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 39

Some Recent Achievements in Austria in ARTES CC

  • Generic Telecommunication Payload EGSE/ SCOE – ATOS

  • perational EGSE for OneWeb
  • Advanced Mobility management Protocols – Frequentis

 testbed built & validated

  • SatComWeather – Space Analyses et al

 VSAT installation quality metric map was successfully implemented

  • Magneto Rheological Fluid Speed Regulator for Deployment of Large Appendages – RUAG

 EM built & tested – TRL 4 achieved

  • IFM Nano Thruster Module – FOTEC

 built & extensively tested – including IOD

  • Design and Verification of Antenna Tracking System for Q/ V Band Hubs – Joanneum Research

 test bed built & validated

slide-40
SLIDE 40

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 40

Participation in ARTES AT per Technology Domain

slide-41
SLIDE 41

ESA UNCLASSI FI ED - For Official Use

Strategic Program m e Lines: Optical Com m unication - ScyLight & Space System s for Safety and Security ( 4 S)

  • Dr. Harald Hauschildt, ScyLight Programme Manager

ESA, ESTEC

slide-42
SLIDE 42

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 42

Optical Com m unication – ScyLight Satellites of the future need optical com m unication technology

  • Optical Communication Technology is a

disruptive technology which requires strategic long term investm ents

  • Commercial market is missing ESA and

its Mem ber States to take the lead

  • Create right programmatic framework to

address the associated high technical and com m ercial risks

slide-43
SLIDE 43

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 43

  • Com ponent A: Com m on System and Critical Technologies Activities

ESA-initiated implementation roadmap and to characterize the environmental drivers for the disruptive technologies.

  • Com ponent B: Optical Com m unication and Quantum Technologies/ Applications

I ndustry-initiated developments & in-orbit validation

  • Com ponent C: Optical Com m unication Projects/ Cornerstone Missions

ESA proposed & ESA led dem onstration m issions to foster the build-up of industrial capabilities

ScyLight ARTES Strategic Program m e Line I ndustrial Excellence and Market Lead in Optical Com m unication Technology by 2 0 2 5

slide-44
SLIDE 44

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 44

Optical Com m unication – ScyLight Cornerstone Mission: HydRON

High thRoughput Optical Netw ork

slide-45
SLIDE 45

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 45

HydRON:

High thRoughput Optical Network = > “Fibre in the Sky”. Vision: Develop the world first (all) optical Network at Terabit Capacity. Extend terrestrial Fiber Netw orks seam lessly by “Fibre in the Sky”.

HydRON - Vision

slide-46
SLIDE 46

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 46

HydRON Vision– Fibre in the Sky

  • Terabit Optical

Transport Network in Space

  • Terabit Space-

Ground Links

  • High speed optical

routing

  • Collection and

distribution of end user data on- ground

  • Seamless

integration in terrestrial networks

slide-47
SLIDE 47

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 47

HydRON–Impacting the future of SatCom

Mission and Vision Statem ent:

  • “Fibre in the Sky” at Terabit capacity dem onstrated by

European and Canadian I ndustries by 2 0 2 5 . Strengthen the role of the satellite by Optical Com s

  • Seam less integration of Space and Terrestrial Netw orks is essential for

m any applications (e.g. 5G).

  • HydRON – due to its netw ork concept- w ill provide the m eans to

  • vercom e the atm ospheric dependencies of optical feeder up/ downlinks

 re-route traffic by sw itching capabilities on board  share optical infrastructure on ground and therefore ease the use of optical for space

slide-48
SLIDE 48

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 48

HydRON Objectives

  • Foster the im plem entation of the Optical Roadm ap to ensure

European and Canadian industrial capabilities in the areas of:

 I ntra-Satellite Photonics  Optical terminals (Space and Ground)  Optical Network Concepts  Platform-Enhancements

  • Provide Fram ew ork for Developments up to PFM/ FMs to ensure the

strengthening of industrial capabilities

  • Provide End2 End Flight Opportunities to dem onstrate m aturity
  • f technology AND the I ndustry
  • I ntegrate end users (primes, operators) at an early stage
slide-49
SLIDE 49

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 49

ESA Implementation approach

  • HydRON to be implemented by m ultiple but self-standing “HydRON

Dem onstrator Missions” (HydRON DM# 1 [ GEO] , DM# 2 [ LEO] ).

  • Multiple im plem entations by m ultiple vendors/ com panies by

means of parallel place contracts

  • Advisory/ user group shall be established to support ESA in the

definition and use cases

  • I ntegration into the hosting platform of the com m ercial m ission
  • HydRON is beyond single Operators planning

horizon and the m aturity of the technology is low = > ESA as System Architect

slide-50
SLIDE 50

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 50

HydRON DM# 1 @GEO HydRON DM# 2 @LEO with connection to Mega-Constellation HydRON DM# 1 & DM&2

  • GEO (HydRON DM # 1)

serving Mega-Constellation via HydRON DM# 2 (LEO) to reduce Ground Segment Benefits:

  • I ndustry supported for LEO

and GEO case

  • Reduced cost for Demo
slide-51
SLIDE 51

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 51

HydRON Concept

HydRON sat(s) in GEO or LEO

WDM LCT

  • Optical head
  • Terminal control

electronics

  • Optical HPA
  • Optical LNA

D E M U X M U X

OSM

WDM LCT

  • Optical head
  • Terminal control

electronics

  • Optical HPA
  • Optical LNA

M U X D E M U X

Bidirectional 100 Gbps

  • 10 WDM Ch
  • 10 Gbps /Ch

100 Gbps

  • 10 WDM Ch
  • 10 Gbps /Ch

100 Gbps

  • 10 WDM Ch
  • 10 Gbps /Ch

100 Gbps

  • 10 WDM Ch
  • 10 Gbps /Ch

100 Gbps

  • 10 WDM Ch
  • 10 Gbps /Ch

Bidirectional 100 Gbps

  • 10 WDM Ch
  • 10 Gbps /Ch

Main Payload by Operator

Optical

Ground

Station (fix or mobile)

Mobile Optical Ground Station

Terrestrial Network

= HydRON# 1 Elements HydRON Network Control Center

slide-52
SLIDE 52

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 52

HydRON proposed Schedule

slide-53
SLIDE 53

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 53

Project of Space System s for Safety and Security ( 4 S) SAGA - Security And cryptoGrAic Mission

slide-54
SLIDE 54

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 54

  • The principles of Quantum Physics

allow s to detect presents of a 3 rd party.

  • Therefore Quantum Com m unication

( Photons) used for Secure Key transm ission.

  • Photons that had been “listened in”

be identified and the Key can be discarded.

Role of Satellite in the future Quantum Key Distribution

slide-55
SLIDE 55

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 55

  • Terrestrial Fibre QKD netw orks

are lim ited in distance – every 1 5 0 km the signal is lost

  • Satellites can bridge this gap
  • Quantum Key Distribution from

Space Dem onstrated by China’s Micius LEO Satellite

Quantum Key Distribution – and the Role of Satellites

CHI NA’S ‘MI CI US’ PASSI NG OVER ESA OPTI CAL GROUND STATI ON I N TENERI FE

slide-56
SLIDE 56

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 56

Rationale – why is ESA active in Space-QKD

  • QKD is a novel technology
  • strategic long-term investm ents
  • stim ulate a m arket where industrial players can become leaders in the field
  • expand Europe’s leadership/ excellence in quantum technologies, and

increase Europe’s strategic autonom y

  • support industry and academ ia to build up its capabilities and to mature the

technology.

  • Enable extensive test and validation cam paigns with the newly developed

technology in an end-to-end system - to I ndustry, Academia and the EC QCI

  • Due to the activities at ESA and at the EC, SAGA could become a space

segm ent for the EC Quantum Com m unication I nfrastructure ( QCI ) .

slide-57
SLIDE 57

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 57

Satellites @Digital Europe/ Cybersecurity

The Digital Europe Program m e proposed by the Commission in June 2018 aims to ensure the best use of advanced technologies in the area of cybersecurity. I n this context a pan-European quantum com m unication infrastructure ( QCI ) is under discussion. On June 13th 7 EU countries signed a joint Declaration to explore how to build a Quantum Communication I nfrastructure (QCI ) across EU within the next 10 Years, BE, DE, I T, LUX, NL, ES and Malta signed. AT expected to join.

slide-58
SLIDE 58

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 58

  • QKD Service based on Entangled Photon

sources.

  • No storage of keys on-board (non

trusted node concept)

  • Keys are produced on Ground only.
  • Potential pre-cursor for EC Pan-

European Quantum Com m unication I nfrastructure QCI

Note: Depending on the security demands combination of trusted and non-trusted node concepts might exists in an

  • verall architecture.

ESA QKD Dem onstration in GEO: SAGA - Security And cryptoGrAic Mission

slide-59
SLIDE 59

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 59

SAGA - Security And cryptoGrAphic mission

  • I mplementation as GEO System

would ensure:

 More than European coverage  Allows for long link time to ensure required key data rates (very weak signals)  pre-selection of clear sky conditions per end user (pairs)  no tracking requirements for user ground stations (reduced cost)

GEO-Satellite Non-tracking ground stations > Continental coverage Weather pre-selected service

slide-60
SLIDE 60

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 60

SAGA – Preperatory Work at ESA

  • Concurrent Design Facility (CDF) Study nearly

finalized

 A star type communication network between Brussels and 50 other locations (mostly Europe, but some further away). This could be a network between capital cities, EC agencies, international

  • rganizations, major embassies, etc…

).  Technical challenges identified:

  • Large Space Telescopes
  • High efficient Entangled Photon Source
  • Ground Stations featuring 2-3m class optical telescopes
  • CDF Results are reflected

 in the Project Proposal for Space19+  DG Connect/ DG Grow QKD Expert-Group to define Architecture

slide-61
SLIDE 61

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 61

Mission Layout and Concept of Operations

  • E91 QKD Protocol - entangle

photon

  • Laser source signal transmitted

into non-linear crystal

  • resulting in entangled infrared

photon pairs.

  • coupled into optical fibres which

are linked to the optical terminals.

  • Keys are generated and stored
  • n ground within the end user

premises

SAGA satellite in GEO w ith tw o optical ground stations for testing end-to-end security

slide-62
SLIDE 62

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 62

Service coverage area

slide-63
SLIDE 63

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 63

Large QKD GEO Terminals and Ground Stations to cope with weak signals

Two 1m diameter Telescopes in GEO > 2m Optical Antennas

  • n ground

System trade-offs to be performed !

slide-64
SLIDE 64

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 64

Technical Challenges

  • Entangled Photon Source

 Entangled photon sources with the required performances have been demonstration in laboratories.

  • 1 m Optical Term inal for GEO and Course Pointing Mechanism

 Telescope fulfilling GEO specific tracking requirements needs to be designed and demonstrated

  • Optical Ground Station Developm ent – cost optim ised.

 Challenge to develop a cost efficient solution, which potentially can be deployed to the users.

  • Background Light Suppression Technologies

 Driver is usage in Urban environment

slide-65
SLIDE 65

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 65

Indicative Schedule

slide-66
SLIDE 66

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 66

SAGA Security And CryptoGrAphic Mission

slide-67
SLIDE 67

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 67

saga

slide-68
SLIDE 68

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 68

Main Satcom Technology/ Product Areas in Austria

Austrian Entities participating in ARTES CC activities are covering:

  • Advanced materials and manufacturing, composites
  • Antenna measurement systems
  • Motion controller and positioner systems
  • Electronics
  • Energy conversion, heat and hydrogen storage
  • I nterference mitigation
  • Mechanisms
  • Multi Layer I nsulation (MLI )
  • Mechanical Ground Support Equipment (MGSE)
  • Navigation receivers
  • Photonics, quantum information
  • Propulsion
  • Safety-critical communication and information solutions
slide-69
SLIDE 69

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 69

ARTES CC Socioeconomic Impact since 2014

8 5 % 1 4 % 1 %

Phase

6 0 % 2 4 % 1 6 %

Dom ain

<

→ Austria Overview

8

→ NEW TECHNOLOGIES

2

→ NEW PATENTS FILED

1 2 3 4 5 6

2017 2018 2019

Million €

→ ARTES CC Commitments per year - Austria

33

→ ON-GOING & COMPLETED ACTIVITIES

Based on 9 completed activities

slide-70
SLIDE 70

ESA UNCLASSI FI ED - For Official Use ESA | Vienna | 18/ 06/ 2019| Slide 70

For more information, please consult:

https:/ / artes.esa.int

Note To enable hyperlinks included in this handout please register and log-in to: ARTES web site: EMITS:

ARTES Core Competitiveness Overview Presentation: ARTES Core Competitiveness Documents: ARTES Advanced Technology Call for Ideas:
