Orion Star T900 Series Titrators Product Introduction MK Malhotra The world leader in serving science Titration Basics Titration: Technique that is based upon the addition of a reagent (titrant) that reacts with the sample species

slide-1
SLIDE 1

The world leader in serving science

MK Malhotra

Orion Star T900 Series Titrators Product Introduction

slide-2
SLIDE 2

2

  • Titration:
  • Technique that is based upon the

addition of a reagent (titrant) that reacts with the sample species

  • As reagent is added, the changes

in electrode potential are recorded

  • The sample concentration is

calculated from the volume of reagent that is chemically equivalent to the sample species

  • Automated Titrator:
  • The device used to perform the

titration, titrant standardization or direct measurement

Titration Basics

slide-3
SLIDE 3

3

  • Equivalence Point / Inflection

Point Titration:

  • Technique of adding small aliquots
  • f a titrant to the sample, recording

the potential changes, and applying a first derivative analysis to the data, from which the endpoint is calculated

  • The technique assumes that the

change in mV reading per volume

  • f titrant added will be greatest at

the endpoint

  • This technique is a very precise

technique for performing routine titrations

Titration Basics

2 3 4 5 6 7 8 9 10 11 12 0.0 0.5 1.0 1.5 2.0 2.5

pH Value mL of NaOH Added

Acidity Titration (Equivalence Point)

slide-4
SLIDE 4

4

  • Preset Endpoint Titration
  • Type of titration where aliquots of

the titrant are added until a predetermined mV or pH value is reached

  • This is a fast way to do a titration,

but requires that the sample and its reaction with the titrant be well known

  • The preset endpoint technique is

useful for analyses without a clearly defined endpoint and is

  • ften a technique required by

industry standards

Titration Basics

2 3 4 5 6 7 8 9 0.0 0.5 1.0 1.5

pH Value mL of NaOH Added

Acidity Titration (Preset Endpoint)

slide-5
SLIDE 5

5

  • Our core electrochemistry

technology integrated with state-

  • f-the-art reagent dispensing

system to create a modern, simplified automated titrator

  • Designed to make performing

titrations easier, more reliable and more reproducible than manual titrations

  • Expands the number of

chemicals that can be measured beyond direct electrode analysis

  • Offers dynamic process controls

that adjust the titration to

  • ptimize analysis results

Titration Basics

slide-6
SLIDE 6

6

Orion Star T900 Series Titrators Product Introduction

Product Overview

slide-7
SLIDE 7

7

  • Titrator functions are focused on:
  • Intuitive operation
  • Easy usability
  • Enjoyable daily operation
  • Overall layout of components
  • Compact design to reduce

required bench space

  • All components within one unit

for easy access and operation

  • Large touchscreen display
  • Easy-to-view
  • Lab glove compatible

Highlights of the Orion Star T900 Series Titrator User Interface

slide-8
SLIDE 8

8

  • Home Screen – All key titrator functions are accessible in one location for

easy navigation

Highlights of the Orion Star T900 Series Titrator User Interface

slide-9
SLIDE 9

9

Titration Setup Wizard

  • Walks user through setup steps

for performing a sample titration

  • Step 1: Select electrode settings
  • Step 2: Select titrant settings
  • Step 3: Select titration settings
  • Option to save as a method
  • Titrations can be recalled and

repeated without additional setup

Highlights of the Orion Star T900 Series Titrator User Interface

slide-10
SLIDE 10

10

Methods Screen

  • Save ten methods per titrator
  • Optional password protection
  • Prevents unintentional modification
  • f methods
  • Save methods to a USB flash

drive for backup

  • Transfer methods on USB flash

drive to multiple titrators

Highlights of the Orion Star T900 Series Titrator User Interface

slide-11
SLIDE 11

11

Titration Screen

  • Large graphic representation of

live titration data

  • Real-time measurement results
  • Run up to five cycles per sample
  • Includes average concentration

and RSD calculations

  • Automatic results calculation

(compared with manual calculations)

  • Simplifies analysis
  • Reduces computational errors

Highlights of the Orion Star T900 Series Titrator User Interface

slide-12
SLIDE 12

12

Data Log Screens

  • Save 100 data sets for each log
  • Sample titration log
  • Titrant standardization log
  • Electrode calibration log
  • Direct measurement log
  • Easily view saved data
  • Export data to a printer, computer
  • r USB flash drive

Highlights of the Orion Star T900 Series Titrator User Interface

slide-13
SLIDE 13

13

  • Burette installation and removal –

reduces downtime and allows for flexibility of burette sizes

  • Burette sizes available:
  • 10 mL
  • 20 mL (included)
  • 50 mL
  • Automated titrant delivery system
  • High-accuracy burette and

dispenser

  • Provides consistent results

Highlights of the Orion Star T900 Series Titrator Industrial Design

slide-14
SLIDE 14

14

  • Valve location and design
  • Designed for long lifespan
  • Allows easy maintenance to be

performed in the rare event valve needs to be replaced

  • Tubing installation
  • Tubing connections are color-

coded for easy installation and replacement

  • Able to see liquid passing through

the tubing to ensure no bubbles

  • Light blocking tubing option for

light sensitive titrants

Highlights of the Orion Star T900 Series Titrator Industrial Design

slide-15
SLIDE 15

15

  • Electrode holder
  • Helps position electrodes properly
  • Smooth, easy to use operation
  • Flexible positioning
  • Includes stoppers (not shown)
  • Dedicated, labelled positions:
  • Stirrer
  • Dispenser
  • ATC
  • Two electrodes
  • Use either electrode position or

both for half-cell electrodes

Highlights of the Orion Star T900 Series Titrator Industrial Design

slide-16
SLIDE 16

16

  • Titrator Connectors
  • Electrode inputs
  • USB outputs
  • Easily connect electrodes and

external devices

  • Simple data transfer options
  • Printer
  • USB flash drive
  • Computer software
  • Critical data can be easily exported

to meet GLP or SOP requirements

Highlights of the Orion Star T900 Series Titrator Industrial Design

slide-17
SLIDE 17

17

Orion Star T900 Series Potentiometric Titrators

slide-18
SLIDE 18

18

  • Orion Star T900 Series Automated Laboratory Titrators
  • Four models are being launched
  • Three dedicated models for frequent, routine titrations
  • f similar samples:
  • Orion Star T910 pH Titrator
  • Orion Star T920 Redox Titrator
  • Orion Star T930 Ion Titrator
  • One dedicated model with all-in-one functionality

for occasional titrations of various samples:

  • Orion Star T940 All-in-One Titrator

Orion Star T900 Series Potentiometric Titrators

slide-19
SLIDE 19

19

Orion Star T910 pH Titrator

  • For acid-base titrations including:
  • Titratable acidity of juices and wines
  • Acidity of food products
  • Alkalinity of waters
  • Acidity and alkalinity of consumer

products

  • Total acid number (TAN)
  • Total base number (TBN)
  • Equivalence point titrations
  • 1 or 2 point EQP
  • Preset pH or mV endpoint titrations
  • 1, 2 or 3 point EP

Orion Star T910 pH Titrator

slide-20
SLIDE 20

20

  • Food and Beverage Applications
  • Titratable acidity of juice and wine by preset endpoint titration using pH electrode
  • Acidity of milk and yogurt by direct titration using pH electrode
  • Acidity of ketchup by direct titration using pH electrode
  • Formol number of fruit and vegetable juices by direct titration using pH electrode
  • Drinking Water Applications
  • Alkalinity of drinking water by preset endpoint titration using pH electrode (EPA approved)
  • Wastewater Applications
  • Alkalinity of wastewater by preset endpoint titration using pH electrode (EPA approved)
  • Consumer Product Applications
  • Acids in various products by direct titration using pH electrode
  • Acidity of various products by preset endpoint titration using pH electrode
  • Alkalinity of various products by preset endpoint titration using pH electrode
  • Caustic/alkali of various products by direct titration using pH electrode

Orion Star T910 pH Titrator Applications

slide-21
SLIDE 21

21

  • Industrial (Chemical and Petrochemical) Applications
  • Acids in various products by direct titration using pH electrode
  • TAN (total acid number) in various products by direct titration using pH electrode
  • TBN (total base number) in various products by direct titration (non-aqueous) using pH

electrode

  • Caustic/alkali of various products by direct titration using pH electrode
  • Amine (weak base) in various products by direct titration (non-aqueous) using pH

electrode

  • Agriculture Applications
  • Total Kjeldahl Nitrogen (TKN) of soil and plants by direct titration using pH electrode
  • Total calcium carbonate of soil by preset endpoint titration using pH electrode
  • Academic Applications
  • Chemistry experiments using acid/base titrations (pH endpoint and pH equivalence point)
  • Basic R&D work for grad-student level applications

Orion Star T910 pH Titrator Applications

slide-22
SLIDE 22

22

Orion Star T920 Redox Titrator

  • For redox titrations including:
  • Sulfite/SO2 and reducing sugar in

juice and wine

  • Ascorbic acid (vitamin C) and

peroxide value in food products

  • Dissolved oxygen in wastewater by

Winkler titration

  • Organic matter in soil
  • Equivalence point titrations
  • 1 or 2 point EQP
  • Preset mV endpoint titrations
  • 1, 2 or 3 point EP

Orion Star T920 Redox Titrator

slide-23
SLIDE 23

23

  • Food and Beverage Applications
  • Sulfur dioxide and sulfite in juice and wine by direct titration using redox electrode
  • Reducing sugar in juice and wine by direct titration using redox electrode
  • Ascorbic acid (vitamin C) in juice by direct titration using redox electrode
  • Peroxide value of edible oils by direct titration using redox electrode
  • Nitrite (AOAC) of salt cure and pickling by direct titration with CO2 flush using redox

electrode

  • Sulfite in dry mix foods and ingredients by direct titration using redox electrode
  • Wastewater Applications
  • Dissolved oxygen (Winkler) in wastewater by direct titration using redox electrode
  • Agriculture Applications
  • Organic matter (Walkley-Black) of soil by direct titration using redox electrode
  • Academic Applications
  • Chemistry experiments using redox titrations
  • Basic R&D work for grad-student level applications

Orion Star T920 Redox Titrator Applications

slide-24
SLIDE 24

24

Orion Star T930 Ion Titrator

  • For ion titrations including:
  • Salt in food products
  • Calcium in juice and milk
  • Hardness of drinking and wastewater
  • Chloride in drinking and wastewater
  • Ammonia and Total Kjeldahl Nitrogen

(TKN) of wastewater

  • Surfactants in consumer products
  • Equivalence point titrations
  • 1 or 2 point EQP
  • Preset mV endpoint titrations
  • 1, 2 or 3 point EP
  • Multiple known additions (MKA)

Orion Star T930 Ion Titrator

This image cannot currently be displayed.
slide-25
SLIDE 25

25

  • Food and Beverage Applications
  • Sodium in juice, soda, milk, cheese and canned food by MKA using sodium ISE
  • Sodium in dry mix foods and ingredients by MKA using sodium ISE
  • Salt in juice by direct titration using silver/sulfide ISE
  • Salt (chloride) in milk, cheese, sauce and ketchup by direct titration using silver/sulfide ISE
  • Salt (chloride) in dry mix foods and ingredients by direct titration using silver/sulfide ISE
  • Salt (sodium chloride) in milk and cheese by MKA using chloride ISE
  • Salt (sodium chloride) in sauces and ketchup by MKA using chloride ISE
  • Salt (sodium chloride) in dry mix foods and ingredients by MKA using chloride ISE
  • Calcium in juice and waters by MKA using calcium ISE
  • Calcium in milk and cheese by MKA using calcium ISE
  • Calcium in canned food by MKA using calcium ISE
  • Calcium in dry mix foods and ingredients by MKA using calcium ISE
  • Potassium in juice by MKA using potassium ISE
  • Total Kjeldahl Nitrogen (TKN, protein content) of milk, cheese by MKA using ammonia ISE

Orion Star T930 Ion Titrator Applications

slide-26
SLIDE 26

26

  • Drinking Water Applications
  • Free ammonia in drinking water by MKA using ammonia ISE (EPA approved method)
  • Total hardness of drinking water by direct titration using calcium ISE
  • Calcium hardness of drinking water by direct titration using calcium ISE
  • Chloride in drinking water by direct titration using silver/sulfide ISE (EPA approved)
  • Nitrate in drinking water by MKA using nitrate ISE
  • Total residual chlorine in drinking water by direct titration using chlorine ISE
  • Wastewater Applications
  • Ammonia in wastewater by MKA using ammonia ISE (EPA approved method)
  • Total Kjeldahl Nitrogen (TKN) of wastewater by MKA using ammonia ISE (EPA approved)
  • Total hardness of wastewater by direct titration using calcium ISE
  • Calcium hardness of wastewater by direct titration using calcium ISE
  • Chloride in wastewater by direct titration using silver/sulfide ISE (EPA approved method)
  • Cyanide in wastewater by direct titration using silver/sulfide ISE
  • Total chlorine in wastewater by direct titration using silver/sulfide ISE

Orion Star T930 Ion Titrator Applications

slide-27
SLIDE 27

27

  • Consumer Product Applications
  • Surfactant in various products by direct titration using surfactant ISE
  • Chloride in various products by direct titration using chloride ISE
  • Chloride of various products by MKA using chloride ISE
  • Industrial (Chemical and Petrochemical) Applications
  • Surfactant in various products by direct titration using surfactant ISE
  • Chloride in various products by direct titration using chloride ISE
  • Chloride of various products by MKA using chloride ISE
  • Mercaptan sulfide in various products direct titration with N2 flush using silver/sulfide ISE

Orion Star T930 Ion Titrator Applications

slide-28
SLIDE 28

28

  • Agriculture Applications
  • Calcium in animal feed and rocks by MKA using calcium ISE
  • Potassium in animal feed, soil and fertilizer by MKA using potassium ISE
  • Sodium in animal feed and pet food by MKA using sodium ISE
  • Chloride in pet food and soil by direct titration using chloride ISE
  • Nitrate in soil by MKA using nitrate ISE
  • Phosphate in animal feed and fertilizer by direct titration using fluoride ISE
  • Academic Applications
  • Chemistry experiments using ion titrations and multiple known addition techniques
  • Basic R&D work for grad-student level applications

Orion Star T930 Ion Titrator Applications

slide-29
SLIDE 29

29

Orion Star T940 All-in-One Titrator

  • For pH, redox and ion titrations
  • Designed for occasional titrations in

labs with diverse applications

  • Equivalence point titrations
  • 1 or 2 point EQP
  • Preset pH or mV endpoint titrations
  • 1, 2 or 3 point EP
  • Multiple known additions (MKA)

Orion Star T940 All-in-One Titrator

slide-30
SLIDE 30

30

  • Target customers looking to

upgrade from manual to automated titrations

  • They need titrations to be:
  • Easier to setup and run
  • More accurate and reproducible
  • More reliable and reportable
  • Faster and self-determining
  • Removes visual inspection and

manual dosing of samples

  • Are willing to invest $3000-5000

in automating their titrations

Key Messaging – Upgrade from Manual to Automated Titrations
