Product Launch: ELIO Series

New Tangent product and design series

3

Elio Design Series

Design

The new Tangent ELIO design series takes inspiration from the early days of radio design. The retro look combines a aluminum front with sharp edges and round buttons in the minimalistic Danish design.

Materials

The Elio series uses a high quality thick brushed aluminum for the front and a real loudspeaker cabined made from MDF.

Sound

High quality sound has been the focus of the cabinet design with room for one or two bass reflex ports and powerful full range speaker unit(s). The combination have given our acoustical engineers the possibility to create a best in class sound and an incredible value for money.

Tangent ELIO Stereo

Tangent ELIO Stereo

Tangent ELIO Stereo

Tangent ELIO Stereo Functionalities

FM Radio DAB/DAB+ Radio Internet Radio CD Player Bluetooth Aux in UPnP USB Media Spotify Connect

8

Tangent ELIO Stereo

Di Display Options:

• 3.2” TFT Color Display
• Local Weather
• Own start up photo
• Analogue or Digital Time
• Dimmer options
• Monochrome or color option
• Alarm
• Timer

Tangent ELIO Stereo

Co Controls

• All functions can be controlled either via the buttons
• n the Tangent Elio Stereo, via the remote control or

via an APP

• Easy Control via menu and navigation buttons on the

product

• Remote Control
• App for Android or iOS

10

Remote

Ke Key Commands:

• Separated On/off and MUTE buttons
• Quick button for home and mode change
• Easy navigation and volume control
• Radio presets and easy entry of wifi and password

via number buttons

11

APP Control

Ai AirMusic App App – iO iOS & Android id

Automatically finds products on the network Control Multiple Products

• n the network

Choose sources and make your own presets See and control everything

12

APP Control

Ai AirMusic App App – iO iOS & Android id

Access music on the network and USB Make announcements Change start up screen picture Access music on your phone

13

Front & Back

Sp Specifi fications:

• 1 – 6: Navigation in menus / Next-Previous / Play-

Pause / Favourites

• 7: 3.2” TFT colour display
• 8: Menu
• 9: Alarm
• 10: Scan
• 11: Volume (turn) & Standby on/off (push)
• 12: Navigate (turn) & Select (push)
• 13: CD Slot-in
• 14: Telescopic Antenna for DAB+/FM
• 15: On/Off Power Switch
• 16: DC input
• 17: Line out 3.5 mm
• 18: Aux in 3.5 mm
• 19: USB input for playback and update

7

Unit Front View – Elio Stereo

: Previous track & Turn left/back : Press to stop CD playing in CD mode : CD Eject : Play/Pause : Next track & Turn right/forward FAV: To select & save favorite radio stations Display: TFT Display 3.2” Menu: Enter the menu Alarm: For access Alarm Scan: Scanning radio stations in DAB & FM mode. Volume/Standby: Rotate rotary knob to adjust the volume when in working mode Press knob to switch between standby and working mode Navigate/Select: Rotate rotary knob to navigate Press rotary knob to confirm when in menu mode Switch program menu when in working mode CD tray: Slot-in CD tray 12 11 13 7 8 9 10 1-6 8

Unit Back View – Elio Stereo

DAB/FM Telescopic antenna ON/OFF Power switch DC INPUT Power inlet LINE OUTPUT Line out 3.5mm AUX INPUT Aux in 3.5mm USB INPUT Playback and update (Update service center only) 1 4 5 6 2 3 14 - 19

Setup Data

SKU/Item Product EAN Gross Kg Net Kg CBM Product Dim. MM Carton Dim. MM Qty Master Master Dim. MM / KG TANELIOSTBK Elio Stereo Alu/Black 5703959230904 6.5 5.0 0.042 430 x 280 x 140 495 x 345 x 245 2 500 x 355 x 495 / 14.2 TANELIOSTWN Elio Stereo Alu/Walnut 5703959230911 6.5 5.0 0.042 430 x 280 x 140 495 x 345 x 245 2 500 x 355 x 495 / 14.2

15

Assets

App? Pictures?

Pictures are available in high res on the Tangent website after launch

Other Assets?

Tech sheet and full manual is available to download from the Tangent website after launch The AirMusic Control (MediaU) app is available for download in Apple’s app store for iOS and Google play store for Android
