standard series Overview DP series DX series H series M series - - PowerPoint PPT Presentation

Maier rotary joints standard series

• DP series
• DX series
• H series
• M series

Overview

11.02.2019 bitte hier Kurzzeichen einfügen Seite 2

DP SERIES

• 1. DP for water applications
• 2. DP for hot oil applications
• 3. DP 06 for hydraulic oil and air
• 4. DPN for chemical | pharma | food industry
• 5. DP sizes 65 – 100 (2 ½“ – 4“)

Overview

11.02.2019 bitte hier Kurzzeichen einfügen Seite 4

• 1. DP for water applications
• 2. DP for hot oil applications
• 3. DP 06 for hydraulic oil and air
• 4. DPN for chemical | pharma | food industry
• 5. DP sizes 65 – 100 (2 ½“ – 4“)

Overview

11.02.2019 bitte hier Kurzzeichen einfügen Seite 5

Application data | DP Series

11.02.2019 bitte hier Kurzzeichen einfügen Seite 6

Water Thermal oil Size:

DN 10 - 100 3/8" - 4" DN 10 - 100 3/8" - 4"

Temeprature:

• max. 160°C
• max. +320°F
• max. 160°C
• max. 320°F

Pressure:

• max. 10 bar
• max. 145 PSI
• max. 10 bar
• max. 145 PSI

Speed:

55000/DN 55000/DN

Medium

• Multi purpose rotary joint
• Self-supported ball bearing type
• with balanced mechanical seal
• brass housing
• and rotor of chrome steel
• Used for various applications
• Cooling water
• Hot water
• Thermal oil
• Hydrailic oil
• (compressed) Air

DP characteristics

11.02.2019 bitte hier Kurzzeichen einfügen Seite 7

High speed, low torque type

DP series buildup

11.02.2019 bitte hier Kurzzeichen einfügen Seite 8

Balanced mechanical seals

(various sealing combinations available)

Rotor = chrome steel (with CU-seal) ZC3 Bearings

(life time lubricated up to 80°C/176°F)

NBR O-ring

(bearing protection)

Compression spring

(spring steel)

Housing = brass EPDM O-rings

(seal protection)

Sealing combinations | DP series

11.02.2019 bitte hier Kurzzeichen einfügen Seite 9

Mechanical seal

(static seal part)

Counter face

(dynamci seal part)

Combination

• Mech. Seal

against

Counter face

Application 1 Chrome steel ↔ Artificial carbon Water max. 80°C/175°F for standard cooling water applications 3 SIC ↔ metal impregnated carbon Water max. 160°C/320°F for hot water and tough applications 4 SIC ↔ SIC Water max. 160°C/320°F Dirty/abrasive medium 5 SIC ↔ Artificial carbon Water max. 160°C/320°F for air and tough applications

Rotor connections

Thread

• European G / BSP
• European metric M

→ with copper seal

• American NPT
• American UN

→ sealed via thread

Other threads available upon request

DP K-flange connection | size 40 and 50

Rotor K-flange Roller shaft Inner ring Flat packing (gasket)

alternatively vailable with O-ring

Fixed flane connection | size 40 and 50

Rotor with flange O-ring Roller shaft Gasket inside groove

Typology rotary joints

Elbows for duo-flow application

11.02.2019 Seite 14

DP Elbows for duo-flow application

P2 Designed for stationary innerpipe PR2 Designed for rotating inner pipe PO2 Designed for stationary inner pipe

• Siphon secured by srew and supported via O-ring

PO2 - Principle

DU-bush O-Ring Inner pipe Roller Screw

Housing connections

• G / BSP
• or NPT threads

Typology Elbows

11.02.2019 bitte hier Kurzzeichen einfügen Seite 18

Spare Parts

Spare- and wearing parts | E / V

Wearing parts:

• Seals no. 180 + 190
• 2 x O-Rings 210
• 1 x O-Ring 220
• 1 x Copper seal 280

Option: Axial shaft seal as bearing protection Instead of pos. 220 for hot oil

Parts to change during every repair

11.02.2019 bitte hier Kurzzeichen einfügen Seite 21

DP catalogue (standard metric)

DP catalogue (US - NPT)

11.02.2019 bitte hier Kurzzeichen einfügen Seite 23

• 1. DP for water applications
• 2. DP for hot oil applications
• 3. DP 06 for hydraulic oil and air
• 4. DPN for chemical | pharma | food industry
• 5. DP sizes 65 – 100 (2 ½“ – 4“)

Overview

11.02.2019 bitte hier Kurzzeichen einfügen Seite 24

• Standard metric version: -800
• Standard NPT version: -750

DP series for hot oil

11.02.2019 bitte hier Kurzzeichen einfügen Seite 25

Build-up similar to water DP, but:

Balanced mechanical seal

Sealing combination 3: SIC against artificial carbon

Axial shaft seal made of VITON

(bearing protection)

VITON O-rings

(seal protection)

Production of:

• BOPP/BOPET Films
• Chemical fibers
• Coating, Laminating
• Packaging
• Tyre Cord

Application

11.02.2019 bitte hier Kurzzeichen einfügen Seite 27

O.E.M.s

• Lindauer Dornier
• Brückner
• Saueressig
• (Oerlikon) Barmag
• MB; It.
• I.S.T. It.
• Valmet Rotomec, It.

DP - 800

BOPP-Film Stretching Line

MDO

Hot oil DP special versions

11.02.2019 bitte hier Kurzzeichen einfügen Seite 30

For e.g. thermal oil applications upto max. 180°C

• Additional vent/bore holes (to divert heat off the seals)
• Special high temp bearing grease
• Special O-rings (FFKM)
• Heat stabilized bearings up to 200°C
• Elbows additionally secured in housing via set screw

Hot oil DP special versions

11.02.2019 bitte hier Kurzzeichen einfügen Seite 31

DP - 800 versus HW

Pro DP:

• Lower torque
• Higher speeds
• simple installation

(no torque support) Pro HW(R, A, B, X)

• Higher temperatures
• Standard housing flanges

(-400/-500)

• Maintenance-free / no

greasing

• Simple repair

Comparison of speeds with oil at 6 bar

11.02.2019 bitte hier Kurzzeichen einfügen Seite 33

1000 2000 3000 4000 5000 6000 10 15 20 25 32 40 50

Speed Size - DN DP H

Comparison with Deublin

DP – 800 Deublin Series 55 Mechanical seal SIC – metal impregnated carbon Ceramic – Carbon graphite O-Rings Viton Viton Shaft seal Viton none Ball bearings heat-stabilized up to 160°C Standard

• 1. DP for water applications
• 2. DP for hot oil applications
• 3. DP 06 for hydraulic oil and air
• 4. DPN for chemical | pharma | food industry
• 5. DP sizes 65 – 100 (2 ½“ – 4“)

Overview

11.02.2019 bitte hier Kurzzeichen einfügen Seite 35

DP 06

11.02.2019 bitte hier Kurzzeichen einfügen Seite 36

• ¼“ type for high speed and high pressure

DP 03 / DP 06 Application data

11.02.2019 bitte hier Kurzzeichen einfügen Seite 37

Diameter DN 1/8" + 1/4" Air Cold water Hot water Hydraulic oil Temperature

• max. +120°C | 248°F

Pressure

• max. 10 bar | 145 PSI

Speed / rpm

• max. 6.000 min.-1

DP 03 / 06 Medium

DP 06 buildup

11.02.2019 Seite 38

Aluminium housing Sealing combination 5 = synthetic carbon / SIC Lubricated for life

Application – where to use DP 06

Air

• Pneumatic winding shafts
• Pneumatically actuated

couplings

• Machine tools

Water

• Cooling Cylinders

Hydraulic oil

• Machine tools
• Automation

11.02.2019 bitte hier Kurzzeichen einfügen Seite 39

• Endusers applying airshafts in the
• plastic film industry
• packaging industry
• paper converting industry
• Manufacturers of winding shafts
• Machine Tool manufacturer

Target Groups Air

Target Groups Water

• Plastic film industry
• Packaging Industry
• Laminators / Coaters

Possible Design Features

• Special threads on rotor and housing:
• NPT
• UN fine thread; metric
• Housing connection also axial
• Axial shaft seal for bearing protection
• Special dimensions
• Installation into cylinders

Installation into cylinders DP 06

Installation into cylinders DP 03

Competition

• Deublin
• Turian
• Fluiten
• Filton
• ...

Summary

• DP 03 and DP 06 round off our DP-Series
• Positive results at test runs

• 1. DP for water applications
• 2. DP for hot oil applications
• 3. DP 06 for hydraulic oil and air
• 4. DPN for chemical | pharma | food industry
• 5. DP sizes 65 – 100 (2 ½“ – 4“)

Overview

11.02.2019 bitte hier Kurzzeichen einfügen Seite 47

• Stainless steel joint for food industry applications

and for aggressive media

DPN series

11.02.2019 bitte hier Kurzzeichen einfügen Seite 48

• Design of DPN corresponds to series DP
• Suitable for use water
• Designed for food industry applications, in an aggressive

environment or using aggressive media

• Standard design is made of 430 F (1.4104)
• Opional available DPN”-100” made of 316 Ti (1.4571)
• Or in 304 (1.4301)

Series DPN

Application data

Avoid combination of maximum values. Higher values and other media on request.

Diameter DN 3/8" - 2" Cold water Hot water Temperature

• max. +90°C

Pressure

• max. 10 bar

Speed / rpm 55000 / DN DPN Medium

DPN Typology

• Version 1 (one way flow: 1B, 1C) -

DPN1 10-50

• Version 1 (one way flow: 1B, 1C) -

DPN1 10-50

• Version 2 (two way flow: 2, R2) -

DPN2 10-50

• Version 2 (two way flow: 2, R2) -

DPN2 10-50

Spare parts | for Version DPN1, DPN 2, DPNR 2 - DN 10-50

• 1. DP for water applications
• 2. DP for hot oil applications
• 3. DP 06 for hydraulic oil and air
• 4. DPN for chemical | pharma | food industry
• 5. DP sizes 65 – 100 (2 ½“ – 4“)

Overview

11.02.2019 bitte hier Kurzzeichen einfügen Seite 57

„big“ DP‘s | DN 65 - 100

11.02.2019 bitte hier Kurzzeichen einfügen Seite 58

Diameter DN 2 1/2" - 4" Cold water Hot water Thermal oil Temperature

• max. +160°C

Pressure

• max. 10 bar

Speed / rpm 55000 / DN DPN Medium

Technical features

Stainless steel rotor Slide bushing rotor seal O-Ring Mechanical seal Ball bearings Steel housing Alternatively in cast iron

The Seal

Rotor Compression springs Thrust collar

Seite 60

Mechanical Seal Housing Fixing ring Counter face

Development Targets

• Alternative to Deublin series 755, 857 and 6000 and
• ther competitors
• 3“ version for water
• low-price segment below DX-series
• balanced seal (reliable solution for pressures > 5 bar)
• springs outside of media

61

Deublin 755 and 6000

62

Market Target

• Rubber and tyre industry
• Calenders
• Mixers, kneaders
• Plastics and Packaging
• Flexo-Printing

63

Available Versions

Housings

• one-way flow
• two-way flow
• for stationary inner pipe
• for rotating inner pipe
• housing connections in G(BSP) or NPT

64

Available Versions

Rotors

• with thread in G(BSP) and NPT
• K-Flange
• Fixed flange
• Special versions

65

Flange rotor versions

fix flange DN 65 and 75 screwed flange DN 80 and 100 K-flange Standard Dim. DN 65, 75, 80, 100

66

Fix-flange-Versions

67

• DN 65 (2 ½“)

DN 73 (3“) identical to Deublin series 755 and 857

• welded flange

Fix-flange-Versions

68

• DN 80 (3 1/2“)

and 100 (4“) identical to Deublin series 6300 and 6400 with male centering

• screwed flange

• Inner pipe dimensions …

(centering dia. and length)

• Housing connections arre not identical
• must be adapted !

Caution !

69

• Balanced mechanical seal
• Easy repair
• Low spare parts- / repair costs
• 3 different sealing combinations
• Option: nickle plated housing
• 20 % cheaper than DX / DXS

Advantages

70

Disadvantages

• No B2-version for rotating inner pipe available (limited

speed)

• Heavy weight

Steel housing heavier as DX / Deublin in brass

71

Experience

• Good
• No claims
• Higher application data possible as shown in the

catalogue :

72

• Appendix -800
• Heat stabilized ball bearings C3 S1
• Sealing combination 3

SIC – metalimpregnated carbon

• Viton O-Rings
• High-temperature grease

Klüber Temp 83-402 (identical to Barrierta L55/2)

DP 65 – 100 Hot Oil

73

• Nonwoven calenders
• Trouble shooter for HW (torque, installation)
• smaller and less expensive than DQL

Markets

74

• Problems competitor‘s joints
• Spare parts cheaper than DX / DXS
• Cheaper than DX / DXS (to keep competition out)
• no standard with NPT-threads for DX / DXS available

Customers ordered because…

75

• Drink & Schlössers, D, Rollers
• Breyer, D, Sheet extruder (usually H/HW)
• Torninova, I, Calender + Extruder
• Ramina, I, Nonwoven-calender
• Siltex, I, Coating machines
• Proform, F, Calender sweets / chew.gum
• Sahut-Conreur, F, Briquetting machines
• Glesi, China, BOPP-lines
• ESOPP, F, BOPP-lines

OEMs

76

• Paper
• Plastic / Film
• Chemistry
• Adhesive Tapes
• Rubber

Endusers Industries

77

• OEMs
• Deublin
• Kadant-Johnson
• Duff-Norton
• …

Attack !!

78

DP series MARKETS

11.02.2019 bitte hier Kurzzeichen einfügen Seite 79

• Plastic film
• Packaging
• Furniture
• Printing
• Food
• Pharma

Markets

11.02.2019 bitte hier Kurzzeichen einfügen Seite 80

Plastic Film

OEM‘s

• Brückner
• Battenfeld
• Lindauer Doriner
• Omipa
• Arnuit
• Saueressig
• Illig

Endusers

• Film for plastic bags
• Coated film
• Thermoforning sheet
• Cups plates, etc
• Office supplies

11.02.2019 bitte hier Kurzzeichen einfügen Seite 81

Cast Film

Film Coating Line

Packaging Industry

• Valmet Rotomec (I)
• Uteco (I)
• Nordmeccanica (I)
• Starlinger
• Breyer
• Manufacturers of
• Chemicals
• Pharmaceuticals
• Food
• Etc..

11.02.2019 bitte hier Kurzzeichen einfügen Seite 84

Packings

Packings

Labelling

Furnitue Industry

OEM‘s

• VITS
• Bürkle
• BMB Bachofen + Maier
• Kroenert Drytech
• Olbrich

End users

• Furniture Manufacturers
• Coaters/Laminators
• Flooring manufacturers

11.02.2019 bitte hier Kurzzeichen einfügen Seite 88

Coating

Coating

Coating

Coating

11.02.2019 bitte hier Kurzzeichen einfügen Seite 92

Food Industry

OEM‘S

• Bosch Regamey (F)
• Higel Eistechnik
• Sandvik
• Netsch
• Linden
• Ekato

End users

• Manufacturers of
• Sweets
• Food
• Fine Ice

11.02.2019 bitte hier Kurzzeichen einfügen Seite 93

Food

Kneaders, Mixers & Extruders

Kneaders, Mixers & Extruders

• OEM‘s
• Harburg-Freudenberger

(Farrel)

• Kneader Machinery (USA)

11.02.2019 bitte hier Kurzzeichen einfügen Seite 96

KNEADER MACHINERY USA, Ltd. 4270 Hudson Dr. Stow, Ohio 44224 Phone: 1-877-KNEADER Fax: 330-923-6070

Printing Industry

OEMS‘s

• MAN
• IST Metz
• Zirkon
• KBA
• Valmet Rotomec

End users

• Printers for packaging
• Newspaper print

11.02.2019 bitte hier Kurzzeichen einfügen Seite 97

Edale, GB | On-line Web-printing machine designed for BSH (to be installed directly after the the corrugator)

Flexo- | Web-printing

Zirkon

Printing Industry - Accessories

• Mixers for printing ink
• Mills

e.g. from

• Netzsch
• Draiswerke
• Linden

Competition: Deublin Series 55 + 57

Competition: Ompi Serie U

Competition: Turian

• S
• Type R, RH, RX

Type R, RB (obsolete)

Competition: Kadant Johnson(-Fluiten)

Other Competitors

• Airmat
• Barco (Aeroquip) – bought by Deublin, US
• Duff-Norton, US
• Filton, GB
• Pearl / Showa Giken,J
• Vrska Press, HU
• Rotomac, TR

DX SERIES

Application Data

DX DXS Size:

DN 10 - 100 3/8" - 4" DN 10 - 200 3/8" - 6"

Temeprature:

• max. 80°C
• max. +176°F
• max. 150°C
• max. 302°F

Pressure:

• max. 8 bar
• max. 116 PSI
• max. 8 bar
• max. 116 PSI

Speed:

55000/DN 55000/DN

Type

Sealing + alignment with 60° cone Ball bearings 5 leakage bores Rotor of chrome steel Housing

• f brass

Product Description DX

Mechanical seal Anti-rotation pin

Design Mechanical Seal DX

Stainless steel case with carbon sealing ring Stationary O-ring O-ring in casing Rotor sealing face

• chrome steel DX
• metal ceramic DXS

Unbalanced mechanical seal

Difference DXS compared to DX

• Equipped with grease nipple

to relubricate bearings

 DX types are life-time lubricated → housing plugged

• DXS = coated rotor shoulder

with chrome oxyde

 = metal ceramic thickness ca. 10-20 µ

11.02.2019 bitte hier Kurzzeichen einfügen Seite 110

• On older machines
• Used for higher speeds (A2-principle)
• Used for higher pressure
• 100 % sealing between inlet and outlet
• ATTENTION:

Do not mistake it for special multi-channel DXSA types designed for rotating stretch blow-mouling machines

DXSA (old standard design)

• Replaces obsolete standard design DXSA
• B2 principle (siphon pipe rotates along with rotor)
• No wear at inner pipe
• For higher speeds
• For higher pressure
• Rotor not with shoulder but exchangeable rotor seal

(counter face)

• More expensive than DXSR

DXSB

DXSB

DU-bush Inner pipe Mechanical seal Counter face

DX series typology

11.02.2019 bitte hier Kurzzeichen einfügen Seite 114

• No spring in the flow area
• Allows higher velocities
• Solid ss rotor
• Drain ports
• Special versions
• On demand

Advantages DX / DXS

Film extrusion calender

Bandera, Italy with 2x DX 265 K and 1x DXSB 2100 K-200

“big” Series DXS | DN 100 - 150

versions K-200 and K-300

• Plastic industry
• Stretching lines / chill rolls
• Paper industry
• Hot water calenders
• Replacement for old standard series DXSA

Applications

Medium cold / hot water Temperature

• 15°C / 5°F up to +150°C / 302°F

Pressure 0,2 up to 8 bar Speed

• max. 300 min-1

Application data K-200

DXS -200

Medium cold / hot water Temperature

• 15°C / 5°F up to +160°C / 320°F

Pressure 0,2 up to 16 bar Speed

• max. 600 min-1

Application data K-300

DXS - 300

• Balanced mechanical seal
• Tapered roller bearings

Results in:

• higher speed: max. 600 -1min (instead of 300 -1min)
• higher pressure: max. 16 bar (instead of 8 bar)

Advantages of -300 compared to -200

11.02.2019 bitte hier Kurzzeichen einfügen Seite 124

H SERIES

• Most important rotary joint of Maier
• Biggest varieties by means of:

 Housing variants  Media  Applications

H Series

11.02.2019 bitte hier Kurzzeichen einfügen Seite 126

• Universal joint
• Maintenance free
• Easy to repair
• Rotor with wear indicator
• Two carbon bearings

Characteristics

11.02.2019 bitte hier Kurzzeichen einfügen Seite 127

• One-way (Mono)
• Two-way (Duo)
• Fixed inner pipe
• Rotating inner pipe
• Rotating inner pipe for 100% separation (inlet/outlet)
• Three-way with vacuum valve

Big standard housing variety

11.02.2019 bitte hier Kurzzeichen einfügen Seite 128

• Cold Water
• Hot Water
• Steam
• Thermal oil (HW)

Media

11.02.2019 bitte hier Kurzzeichen einfügen Seite 129

H series Application data

11.02.2019 bitte hier Kurzzeichen einfügen Seite 130

Water/Steam Thermal oil Size:

DN 10 - 300 3/8" - 12" DN 10 - 300 3/8" - 12"

Temeprature:

• max. 250°C
• max. +482°F
• max. 300°C
• max. 572°F

Pressure:

• max. 28 bar
• max. 406 PSI
• max. 10 bar
• max. 145 PSI

Speed:

100000/(DNxP) 150000/(DNxP)

Medium

• Textile dryers
• Nonwovens
• Plastics
• Paper
• Rubber
• Chemical
• ...

Applications

11.02.2019 bitte hier Kurzzeichen einfügen Seite 131

H classic

11.02.2019 bitte hier Kurzzeichen einfügen Seite 132

H classic build up

Housing Compression spring Locking pin Flat packing (gasket) Cover Rotor Cover bearing Anti-rotation pins Sealing ring Carbon bearing

H types: H(W) 1, H(W)2, H(W)R2

bitte hier Kurzzeichen einfügen Seite 134

Sealing concept H series

Flat packing (gasket) Cover Rotor Cover bearing Sealing ring

• Sealing surface 1 on rotor
• Sealing surface 2 on cover
• Pressure on sealing surface as well as torque increase

when medium pressure rises

• seal is pretensioned by spring pressure
• metal impregnated sealing ring (HW)

Sealing concept H series

11.02.2019 bitte hier Kurzzeichen einfügen Seite 136

H 3 | the „3“ stands for vacuum valve

H3 vacuum valve

Why H 3?

• Used on steam heated textile dryers
• Which are rather thin-walled
• Optional to H duo-flow versions
• Vacuum valve prevents damage of cylinders
• e.g. implosion
• H3 joints are used when dryers do not have their own

vacuum valve

• Standard sealing ring (synthetic carbon):

For steam and water , max. 250°C, 20 bar

• (optionally also for hot oil: < 10 r.p.m and pressure < 2 bar)
• „W“ sealing ring (metal impregnated carbon):

For hot oil (generally) higher pressure, speed and temperature

Sealing concept H series

11.02.2019 bitte hier Kurzzeichen einfügen Seite 139

HW - 400

Flanges soldered into housing Rotor in stainless steel 316Ti (1.4571)

H - 400

H - 400

• Standard version with housing flanges

according to DIN 2635; PN 40

• Inlet and outlet have the same size
• Mainly for hot oil applications
• Rotor in stainless steel

(before nitrated, earlier: standard steel)

Series HWA, HWB, HWX

11.02.2019 bitte hier Kurzzeichen einfügen Seite 143

HWB HWA HWX B2 principle A2 principle X principle

11.02.2019 bitte hier Kurzzeichen einfügen Seite 144

Advantages of new HWA, B, X

• See „Classic H-Series“
• Two wide-spaced carbon

bearings

better lifetime, higher speed

• Anti-rotation fork between

bearings

better distribution of the loads

• Standard steam version

HWA for rotating inner pipe and 100% separation of steam and condensate

• Modular design with two-piece housing
• Standard air-vent-screws
• Freeflow cross-section
• Spring integrated in elbow
• ATEX Versions with temperature sensor
• Water, steam and hot oil

Advantages of new HWA, B, X

• Series -500 with housing flanges
• lose flanges with neck screwed into housing
• no soldering as at -400 series
• Rotors made of stainless steel
• DN 32 – 65:

1.4571 / AISI 316 ti

• DN 80 – 100:

1.4301 / AISI 304 plus coating

Advantages of new HWA, B, X

• Rotor design reduces temperature

at the sealing gap

Advantages of new HWA, B, X

148

149

 Inner pipe is secured by means of a clamping nut  (DN 65-100)

Advantage HWX

150

HW - 500

151

HW (X,B,A) - ATEX

152

HWA

inner pipe rotor springs butting ring

HWA

• on older machines
• for higher speeds (A2-principle)
• for higher pressure
• 100 % sealing between inlet and outlet

HWB

• replaces HWA
• for higher application data than HW
• future standard

Stiffer bearing Separation of inlet and outlet standard W-seal Inner pipe support in the rotor Stiffer bearing

Product Features Series HWB

Application Data

• Medium:

cooling water, hot water, steam and hot oil

• Temperature:

260 °C up to 320 °C on request

• Pressure:

40 bar

M Series

Application data

Medium Water Steam Pressure bar 20 5 Speed rpm 16000 DN 8000 DN Temperature°C

• 15

+160 +160

Product Description M

packing set compression spring rotor

• ne ball bearing

support bearing sealing with cone cast housing

thrust collar

Series M

• For dirty water
• Low speeds only, due to sealing principle
• High torque
• Rotor hardened in range of seal
• Easy to repair

• Change of sealing material about 10 years ago
• Now: asbestos-free
• Before: M capable for hot oil
• Used on very old machines | partially still running

Series M

Rotary joint series

11.02.2019 bitte hier Kurzzeichen einfügen Seite 163

• DX
• DC
• H
• M
• DP
