International Product Marketing Department

Monitor Introduction

Pro Series/ Value Series

Monitor Introduction

Contents

Pro Series

02

Value Series

03

Overview

01

Applications

04

01.

Overview

Naming Rule Product Family Product Evolution

Overview

Naming Rule

Monitor 50： Hikvision Display

DS-D：

Screen Size 19” 32” 65” 19: 32: 65: 4K HD Economic U: F: Q:

DS-D 50 32 Q E

Metal casing Plastic casing Economic Narrow Bezel L: C: E: N:

Products Family

Overview

Monitor DS-D50XXUC DS-D50XXFL(-B) DS-D50XXQE(-B/E/C) QE Series 4K Series FL Series Pro Series Value Series DS-D50XXFC(-A) FC Series DS-D50XXFN FN Series

• Plastic Casing
• 4K Ultra HD Display
• Various Sizes
• ERP Level A
• Plastic Casing
• Base Bracket Included
• Plastic Casing
• 2 mm Narrow Bezel
• Wide View Angle
• Plastic Casing
• Various Sizes
• Wide View Angle
• Metal Casing
• Industrial Panel
• USB Media Play

New New New

QE Series FC Series FL Series 4K Series 19’’ 22’’ 24’’ 28’’ 27’’ 32’’ 43’’ 50’’ 55’’ 49’’

DS-D5019QE DS-D5022QE-B DS-D5022FC DS-D5024FC DS-D5032FC-A DS-D5032FL DS-D5043FL-B DS-D5028UC DS-D5050UC DS-D5022QE-E

65’’ FN Series

DS-D5024QE DS-D5049UC-B DS-D5043UC DS-D5027UC DS-D5055UC DS-D5043UC-B DS-D5055UC-B DS-D5065UC DS-D5024FN DS-D5022FN DS-D5027FN DS-D5032QE DS-D5032QE-B DS-D5019QE-B DS-D5022QE-C DS-D5043QE

Overview

24/7 Operations

Ultimate Clarity

Designed for 24/7 365-Day Use with 50000~60000 hours ultra long life. Wide view delivers life-like visuals and abundant details of monitoring images.

Professional and Reliable

Professional Design with Powerful Functions and Better Quality

Features – Rich Colors

Millions Color Shades

Supporting millions shades of color, the Hikvision monitors deliver incredibly colorful images. Colors appear more natural and vivid.

Wide Viewing Angle High Contrast Ratio

Wide viewing angle panel provides wide viewing angle horizontally and vertically, so that customers can experience the optimal screen from any position. Contrast ratio is the difference between the brightest and darkest portions of an image. Higher contrast ratio means monitor can display deeper blacks, which makes a big difference in overall picture quality.

20000-25000 hours 50000-60000 hours

HikvisionMonitor Ordinary PC Monitor Features – Longer Life Span

No Image Persistence Obvious Image Persistence

HikvisionMonitor Ordinary PC Monitor Features – No Image Persistentce

VESA Mounting Standard

VESA Mounting Standard is a family of standards defined by the Video Electronics Standards Association for mounting flat panel monitors, TVs, and other displays to stands

• r wall mounts.

All Hikvision monitors are VESA compliant and compatible with third-party brackets. Size Model VESA

22 inch DS-D5022QE-C 75 mm × 75 mm 22 inch – 32 inch QE Series: DS-D5022QE-E DS-D5024QE DS-D5032QE DS-D5032QE-B FN Series: DS-D5022FN DS-D5024FN DS-D5027FN FC Series: DS-D5022FC DS-D5024FC DS-D5032FC-A 4K Series： DS-D5028UC 100 mm × 100 mm 32 inch – 43 inch DS-D5043QE DS-D5032FL DS-D5043UC 200 mm × 200 mm 50 inch – 55 inch DS-D5050UC DS-D5055UC 400 mm × 200 mm 43 inch DS-D5043FL-B 400 mm × 300 mm 43 inch – 65 inch DS-D5043UC DS-D5055UC DS-D5065UC 400 mm × 400 mm

100 mm 100 mm

Need Special Bracket?

02.

Pro Series

4K Series FL Series FC Series

4K Series Overview - UC Series

DS-D5028UC 28’’, 3840 × 2160 H: 170°, V: 160° HDMI + VGA + DP DS-D5043UC 42.5’’, 3840 × 2160 H: 178°, V: 178° 2 × HDMI + VGA DS-D5050UC 50’’, 3840 × 2160 H: 178°, V: 178° 2 × HDMI + VGA DS-D5055UC 55’’, 3840 × 2160 H: 178°, V: 178° 2 × HDMI + VGA DS-D5065UC 65’’, 3840 × 2160 H: 178°, V: 178° 2 × HDMI + VGA DS-D5027UC 27’’, 3840 × 2160 H: 178°, V: 178° HDMI + DP DS-D5043UC-B 42.5’’, 3840 × 2160 H: 178°, V: 178° 3 × HDMI + VGA + YPbPr DS-D5049UC-B 49’’, 3840 × 2160 H: 178°, V: 178° 3 × HDMI + VGA + YPbPr DS-D5055UC-B 55’’, 3840 × 2160 H: 178°, V: 178° 3 × HDMI + VGA + YPbPr

New New New

4K Series

4K Ultra HD display

Standard HDMI interface and 4K signals can effectively resist the material and surroundings disturbance, perfectly show the image of camera and allow users to experience the real scene.

UHD FHD

4K Series

EasyIP 3.0 & 2.0+ 4K Camera EasyIP 3.0 & 2.0+ 4K Camera I Series NVR Network Cable HDMI Cable Having great compatibility with EasyIP 3.0 & 2.0+ 4K cameras and I Series NVR, 4K monitors can empower your surveillance system with much more details。

FL Series Overview

DS-D5032FL 31.5’’, 1920 × 1080 H: 178°, V: 178° HDMI + VGA + DVI + BNC DS-D5043FL-B 42.5’’, 1920 × 1080 H: 178°, V: 178° HDMI + VGA + DVI + BNC in + BNC out

FL Series Features

Wide View Angle

Horizontal: 178° Vertical: 178°

Industrial Design

Metal casing and industrial panel

Different Sizes

Meet different scenario requirement

24/7 Operation

FL Series Features

Multiple Interfaces

Support HDMI, DVI, VGA, BNC, USB, Audio input

USB Media Play

Support play videos by USB drive

Built in Speaker

Support audio playing

VESA Standard Bracket

Support third party bracket manufacturers

FC Series Overview

DS-D5022FC

21.5’’, 1920 × 1080 H: 170°, V: 160° HDMI + VGA + BNC in + BNC out

DS-D5024FC

23.6’’, 1920 × 1080 H: 170°, V: 160° HDMI + VGA + BNC in + BNC out

DS-D5032FC-A

31.5’’, 1920 × 1080 H: 178°, V: 178° HDMI + VGA + DVI + BNC in + BNC out

FC Series Characteristic

Plastic Casing

Light and thin structure Support audio playing

VESA Standard Bracket Wide View Angle 24/7 Operation USB Media Play Multiple Interfaces

DS-D50XXFC

Different Sizes

Horizontal: 170°/ 178° Vertical: 160° / 178° Support HDMI, DVI, VGA, BNC, Audio input Different sizes meet different scenario requirement

Built in Speaker

Support third party bracket manufacturers Support play videos by USB drive

03.

Value Series

QE Series

FN Series Overview

DS-D5022QE-E 21.5’’, 1920 × 1080 H: 90°, V: 65° HDMI + VGA DS-D5024QE 23.8’’, 1920 × 1080 H: 178°, V: 178° HDMI + VGA DS-D5032QE 31.5’’, 1920 × 1080 H: 178°, V: 178° HDMI + VGA

FN Series Characteristic Super Narrow Bezel

FHD 1920 × 1080

FHD

178° Wide View Angle

178°

24/7 Operation

24/7

HDMI, VGA Interfaces

QE Series Overview

DS-D5019QE 18.5’’, 1366 × 768 H: 90°, V: 65° VGA DS-D5019QE-B 18.5’’, 1366 × 768 H: 90°, V: 65° HDMI + VGA DS-D5022QE-E 21.5’’, 1920 × 1080 H: 90°, V: 65° HDMI + VGA DS-D5022QE-B 21.5’’, 1920 × 1080 H: 170°, V: 160° HDMI + VGA DS-D5024QE 23.8’’, 1920 × 1080 H: 178°, V: 178° HDMI + VGA DS-D5032QE 31.5’’, 1920 × 1080 H: 178°, V: 178° HDMI + VGA DS-D5032QE-B 31.5’’, 1920 × 1080 H: 178°, V: 178° HDMI + VGA DS-D5043QE 42.5’’, 1920 × 1080 H: 178°, V: 178° HDMI + VGA DS-D5022QE-C 21.5’’, 1920 × 1080 H: 178°, V: 178° HDMI + VGA

New

QE Series Characteristic

A

Lightweight Design

• Plastic casing
• Small sizes
• Light and thin structure
• Base Bracket Included

QE Series

High Reliability

• VGA and HDMI interfaces
• 24/7 Operation
• VESA standard bracket

B

04.

Applications

Applications

Scenario:

• Control Room

Product Model:

• DS-D5024QE

Specification:

• Cost-effective
• Desktop Design
• 24/7 operation

Applications

Scenario:

• Monitoring Center

Product Model:

• DS-D5032FC-A
• DS-D5055UC

Specification:

• Multiple interfaces
• Wall-mounted
• 24/7 operation
