Horizontal Water Source Heat Pump Horizontal Water Source Heat Pump Product Training Product Training Product Training New Product New Product New Product Horizontal Water Source Heat Pump Product Introduction Product Introduction

slide-1
SLIDE 1

Product Training Product Training Product Training New Product New Product New Product

Horizontal Water Source Heat Pump Horizontal Water Source Heat Pump

slide-2
SLIDE 2

Product Training Product Training Product Training New Product New Product New Product

Product Introduction Product Introduction

  • Water Cooled Product
  • Packaged types
  • Capacity: 3.4kW – 23.0kW
  • 11,600 Btu/hr to ~78,480 Btu/hr

Horizontal Water Source Heat Pump

MODEL WH011BR WH012BR WH015BR WH020BR WH025BR NOMINAL COOLING CAPACITY kW 3.4 3.5 4.2 5.7 7.6 Btu/h 11600 12000 14400 19500 26000 NOMINAL HEATING CAPACITY kW 3.8 3.7 4.3 5 8.4 Btu/h 13000 12700 14800 17000 28800 MODEL WH030BR WH040BR WH050BR WH060BR WH070BR NOMINAL COOLING CAPACITY kW 9.0 13.0 15.0 19.0 23.0 Btu/h 30710 44360 51510 64820 78480 NOMINAL HEATING CAPACITY kW 9.5 15.5 17.0 20.5 23.0 Btu/h 32410 52890 58000 69950 78480

slide-3
SLIDE 3

Product Training Product Training Product Training New Product New Product New Product

Product Name Product Name WH11/12/15/20/25/30/40/50/60/70 B/BR

10 20 30 40 50 60 70 80 Btu/hr x 103 2.93 5.86 8.79 14.65 17.59 20.52 11.72 23.45 kW

Horizontal Water Source Heat Pump

slide-4
SLIDE 4

Product Training Product Training Product Training New Product New Product New Product

Product Application Product Application Multi space commercial

Buildings

Piping connecting all of the

WSHP to a closed water loop.

The system includes, cooling

tower/ dry cooler, boiler, piping, pumps, expansion tank and related accessories.

Horizontal Water Source Heat Pump

slide-5
SLIDE 5

Product Training Product Training Product Training New Product New Product New Product

Product Features Product Features

  • 1. Low Height Profile
  • 1. Low Height Profile
  • WH-11 B/BR using Horizontal

Compressor

  • Flexibility in Installation

WH11 B/BR

250 mm!!

Horizontal Water Source Heat Pump

slide-6
SLIDE 6

Product Training Product Training Product Training New Product New Product New Product

Product Features Product Features Product Features

500 70 475 60 440 50 440 40 370 30 340 25 353 20 337 15 325 12 250 11 Height (mm) WH-B/BR

  • 2. Height of the WH-B/BR
  • 2. Height of the WH-B/BR

250 mm to 500 mm

Horizontal Water Source Heat Pump

slide-7
SLIDE 7

Product Training Product Training Product Training New Product New Product New Product

Product Features Product Features

  • 3. Developed on Less Vibration Design
  • 3. Developed on Less Vibration Design
  • Double Isolation Panel

Upper Panel Lower Panel Compressor Grommet

Horizontal Water Source Heat Pump

slide-8
SLIDE 8

Product Training Product Training Product Training New Product New Product New Product

Product Features Product Features

  • 4. No Outdoor Fan is Required
  • 4. No Outdoor Fan is Required
  • Extremely quiet design
  • No visible outdoor unit
  • Avoid the air well effect

Example

Horizontal Water Source Heat Pump

slide-9
SLIDE 9

Product Training Product Training Product Training New Product New Product New Product

Product Features Product Features

Hot Air

Improper arrangement of

  • utdoor unit (air cooled) in the

building will trap the hot air which will affect the performance of the air conditioner.

Horizontal Water Source Heat Pump

Building A Building B Building C Building D Building E Building F

slide-10
SLIDE 10

Product Training Product Training Product Training New Product New Product New Product

Product Features Product Features

  • 5. High Heat Exchange Efficiency
  • 5. High Heat Exchange Efficiency
  • Tube in Tube Heat Exchanger
  • High Energy Efficiency Rating (EER) with
  • WH11-WH30: Panasonic Rotary Compressor
  • WH30-WH70: Mitsubishi Rotary Compressor

Horizontal Water Source Heat Pump

slide-11
SLIDE 11

Product Training Product Training Product Training New Product New Product New Product

Product Features Product Features

High COP and EER High COP and EER

1 2 3 4 5 6 W H1 1 W H1 2 W H1 5 W H2 W H2 5 W H3 W H4 W H5 W H6 W H7 0.0 2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0 18.0 W H 1 1 W H 1 2 W H 1 5 W H 2 W H 2 5 W H 3 W H 4 W H 5 W H 6 W H 7

Heating COP vs Models Cooling EER vs Models Range: 3.3 – 5.4 Range: 12.6 – 16.3

Horizontal Water Source Heat Pump

slide-12
SLIDE 12

Product Training Product Training Product Training New Product New Product New Product

Product Features Product Features

  • 6. Application Flexibility
  • 6. Application Flexibility
  • Wide Operating Range of Temperature

13°C = EWT = 45°C 10°C = EWT = 32°C Cooling Cycle EWT Range Heating Cycle EWT Range

Horizontal Water Source Heat Pump

slide-13
SLIDE 13

Product Training Product Training Product Training New Product New Product New Product

Product Features Product Features

  • 7. Protection Features
  • 7. Protection Features

HP & LP Switches

  • Compressor Overload Protection

Water Outlet Sensor

  • Monitoring the Leaving Water Temperature

Suction Sensor

  • Compressor will cut out if the suction Temperature is less

than -6°C

Horizontal Water Source Heat Pump

slide-14
SLIDE 14

Product Training Product Training Product Training New Product New Product New Product

Product Features Product Features

  • 8. Part Loading Capability (WH25-WH70)
  • 8. Part Loading Capability (WH25-WH70)
  • 2 stage loading capacity at 50%-100%
  • Less Noise during low load condition
  • Energy Saving

Horizontal Water Source Heat Pump

100 50

  • Comp. Loading %

Step Capacity

slide-15
SLIDE 15

Product Training Product Training Product Training New Product New Product New Product

Product Features

  • 8. Sequencing Control of the Compressor

(WH25-WH70)

  • 8. Sequencing Control of the Compressor

(WH25-WH70)

  • Accumulative compressor operating time

can be monitored

  • Even loading of the compressor
  • Improve compressor reliability

Horizontal Water Source Heat Pump

COMP1 COMP2

slide-16
SLIDE 16

Product Training Product Training Product Training New Product New Product New Product

Double Skin Double Skin Ducted Split Blower, DSB Ducted Split Blower, DSB

slide-17
SLIDE 17

Product Training Product Training Product Training New Product New Product New Product

Product Features

DX - DX - Available Now Available Now Chilled Water Fan Coil – To be Chilled Water Fan Coil – To be launched at Feb2005 launched at Feb2005 200, 000 Btu/hr – 500, 000 Btu/hr 200, 000 Btu/hr – 500, 000 Btu/hr 58.61 kW to 146.54 kW 58.61 kW to 146.54 kW

Double Skin Ducted Split Blower

slide-18
SLIDE 18

Product Training Product Training Product Training New Product New Product New Product

Product Features

Dimension:

Double Skin Ducted Split Blower

DX INDOOR UNIT

DESCRIPTIONS Height Width Depth DSB200 BW 932 1972 904 DSB250/300 BW 1318 1243.5 1770 DSB400/500 BW 1550 2212 1438

CHILLED WATER FC

DESCRIPTION HEIGHT WIDTH DEPTH DSB200B(BR) 932 1972 904 DSB250B(BR)/300(BR) 1318 1243.5 1770 DSB350B(BR) 1557 2050 1153 DSB400B(BR)/500B(BR) 1550 2212 1438

slide-19
SLIDE 19

Product Training Product Training Product Training New Product New Product New Product

Product Features

  • Double Wall Panel (1”) – No Screws
  • PU insulation
  • Low Noise
  • Belt Driven – Offer Flexibility
  • Access Door for Service
  • Taper Lock Pulley
  • Horizontal & vertical air discharge

Double Skin Ducted Split Blower

slide-20
SLIDE 20

Product Training Product Training Product Training New Product New Product New Product

R410A R410A Tandem Compressor Mini Chiller Tandem Compressor Mini Chiller

slide-21
SLIDE 21

Product Training Product Training Product Training New Product New Product New Product

HydroTech Chiller – Product Range HydroTech Chiller – Product Range

20 40 60 80 100 120 140 160 R22 5.9 11.7 17.6 29.3 35.2 41.0 R407C R410A 23.5 46.9 Btu/hr x 103 kW

R410A Tandem Compressor Mini Chiller

slide-22
SLIDE 22

Product Training Product Training Product Training New Product New Product New Product

Tandem Compressor Mini Chiller Tandem Compressor Mini Chiller 5AC 30/40/50/55 CR 5AC 30/40/50/55 CR

  • Approx. Capacity: 30,000-55,000 Btu/hr

Single circuit with Tandem Rotary Compressor

  • Capacity Step Control

100 60 40

  • Comp. Loading %

Step Capacity 100 50

  • Comp. Loading %

Step Capacity

5AC 40/50 CR 5AC 30/55 CR

R410A Tandem Compressor Mini Chiller

slide-23
SLIDE 23

Product Training Product Training Product Training New Product New Product New Product

Tandem Compressor Mini Chiller Tandem Compressor Mini Chiller 5AC 30/40/50/55 CR 5AC 30/40/50/55 CR

  • Low Equipment Cost
  • Easily attain to Single Phase or 3 phase

power supply.

  • No water tank is required

R410A Tandem Compressor Mini Chiller

slide-24
SLIDE 24

Product Training Product Training Product Training New Product New Product New Product

Tandem Compressor Mini Chiller Tandem Compressor Mini Chiller Chiller Panel As Standard Controller Chiller Panel As Standard Controller

R410A Tandem Compressor Mini Chiller

  • Allows user to have customized control of each connected unit
  • User Friendly, versatile control features

Operation Menu Operation Menu Setting Menu Setting Menu Timer Menu Timer Menu Alarm Menu Alarm Menu Display Menu Display Menu

  • Main Menu includes;
  • Whole system configuration
