Sustainable Shorelines Designs: Long I sland to Lake Erie Living Shorelines Project Long I sland Sound, W estport, CT Michael Ludwig Senior Biologist and Lead Regulatory Specialist 1 Presentation Outline Introduction Site Conditions

slide-1
SLIDE 1

1

Sustainable Shorelines Designs: Long I sland to Lake Erie

Living Shorelines Project

Long I sland Sound, W estport, CT

Michael Ludwig Senior Biologist and Lead Regulatory Specialist

slide-2
SLIDE 2

2

Presentation Outline

› Introduction › Site Conditions › Problem Definition › Constraints › Alternative Assessment and Evaluation › Design Solution › Installation › Performance / Evaluation › Lessons Learned / Conclusions

18 NOVEMBER 2016 LIVING SHORELINES PROJECTS

slide-3
SLIDE 3

2

Introduction

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

slide-4
SLIDE 4

4

OCC| COWI History

› Founded in 1983 › Local Firm – CT and NYC › 90+ Staff › ISO9001: 2008 Certified › Dedicated Solely to Waterfront Engineering Projects › Joined COWI in 2007

  • F. MICHAEL LUDWIG

SENIOR BIOLOGIST AND LEAD REGULATORY SPECIALIST

18 NOVEMBER LIVING SHOELINE PROJECTS

SPECIALIZATION: Biology, Regulatory Services, Project Management YRS EXPERIENCE: 40 EDUCATION: Doctoral Courses, Physical Oceanography, SUNY Stony Brook, NY M.S. Fisheries Management, Long Island University B.S., Major Biology, Minor Marine Geology, Southern CT State University Formerly, Regional Regulatory Affairs Coordinator for the National Oceanic and Atmospheric Administration’s (NOAA) National Marine Fisheries Service (NMFS 10+ Years Consulting Experience for Shoreline Erosion Mitigation and Coastal Resiliency

slide-5
SLIDE 5

5

Natural or "Green" Resiliency for sustainable shorelines

› W hat is a Sustainable Shoreline?

› Shoreline structures that seek to protect shoreline wildlife habitat ecological functions and values, outdoor recreation, community quality of life, and water-dependent business attributes for future generations. › These designs to not attain full protection but provide for natural recovery by incorporating resiliency characteristics.

18 NOVEMBER LIVING SHOELINE PROJECTS

slide-6
SLIDE 6

6

› Located in Westport, CT › community of sailors and their families who share a common interest in sailboat racing. › With a 115-year racing tradition › CPYC is a participatory club with racing, social, cruising, and other sailing-related activities

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

slide-7
SLIDE 7

7

Site Conditions

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

slide-8
SLIDE 8

Location / Conditions

8

› North Shore of Long Island Sound › Developed Shoreline (typical of western LI Sound) › Basin Protected from Long Island Sound Southern and Eastern Fetch › Open to the North › Erodible Soils – Sands, Silts & Gravel › Subject to Over-wash During Storm Conditions (Sandy)

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

slide-9
SLIDE 9

9

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

slide-10
SLIDE 10

10

Problem Definition

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

slide-11
SLIDE 11

Site Conditions

11

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

The m arina basin is m aintained by periodic dredging of glacial

  • utw ash sand and

gravel m aterial. The dredging and w ave activity cause erosion and basin infilling.

slide-12
SLIDE 12

Site Details

12

13 SEPTEMBER 2016 CITY OF MILFORD RESILIENCY & STABILIZATION PROJECTS

› The shoreline within the upper, intertidal zone on the southern and western sides is populated with an eroding Smooth/ Saltmarsh cordgrass (Spartina alterniflora) community.

slide-13
SLIDE 13

Site Details

13

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

Physical

* Erosion above and below salt marsh * Over-wash events

Biological

* High saltmarsh Vegetation - Minor * Intertidal saltmarsh Vegetation - Dominant * Common Reedgrass, Shrubs and Trees above * Fiddler Crabs and Oysters

slide-14
SLIDE 14

Site Details

14

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

› The southern shore showed signs of erosion even through is was at the inner most portion of the marina and well protected(?).

slide-15
SLIDE 15

Site Details

15

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

slide-16
SLIDE 16

Site Details

16

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

slide-17
SLIDE 17

Shoreline Change Analysis

17

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

slide-18
SLIDE 18

18

Constraints

18 NOVEMBERR 2016 LIVING SHORELINE PROJECTS

slide-19
SLIDE 19

Constraints

19

› Engineered Solution: › "Perm anent," Cost Effective, & having Regulatory Acceptability

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

slide-20
SLIDE 20

20

Alternative Assessment and Evaluation

18 NOVEMBERR 2016 LIVING SHORELINE PROJECTS

slide-21
SLIDE 21

Alternatives & I nsights

21

› Steel Sheet Pile Bulkhead › Permanent and robust › Well understood design › Expensive › Potential regulatory issues Riprap › Permanent and robust › Well understood design › Moderately priced › Moderate regulatory concerns

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

slide-22
SLIDE 22

Alternatives

22

› Vegetated Slope › Sustainability / survivability / maintenance › Design certification (level of protection?) › Relatively inexpensive (initial costs) › Regulatory friendly › Reinforced Vegetated Slope › Improved longevity › Better understood design › Moderately priced › Moderate regulatory concerns

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

slide-23
SLIDE 23

Alternatives

23

› Reinforced Vegetated Slope › (Gabion Mats / Riprap Sill)

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

slide-24
SLIDE 24

Alternatives

24

› Reinforced Vegetated Slope (Gabion Mats / Riprap Sill) › Improved longevity BUT has VANDALISM › Better understood design › Moderately priced › More regulatory concerns (fill) › Reinforced Vegetated Slope (Coir Mats) › Longevity relies more on vegetation development › Some design guidance › Moderately priced w/ fewer regulatory concerns (softer / non-permanent [ Bio-degradable] )

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

slide-25
SLIDE 25

Alternatives

25

› Reinforced Vegetated Slope (Coir Mats)

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

slide-26
SLIDE 26

26

DESIGN SOLUTION

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

slide-27
SLIDE 27

Design Solution

27

› Reinforced Vegetated Slope (Coir Mats) › Faster Implementation (Regulatory Acceptance) › Cost Effective › Monitor for Effectiveness (Revisit if or as needed) › Low wave energy / infrequent

  • vertopping – acceptable design

conditions › Acceptable level of protection / risk

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

slide-28
SLIDE 28

Design Solution

28

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

slide-29
SLIDE 29

29

INSTALLATION

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

slide-30
SLIDE 30

Coir Log Sill

30

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

April 2015

slide-31
SLIDE 31

Coir Mat

31

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

May 2015

slide-32
SLIDE 32

Comments on Installation

32

› Material availability / substitution › Installation duration › Contractor experience (marine construction vs. environmental & landscape experience)

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

slide-33
SLIDE 33

2

Performance / Evaluation

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

slide-34
SLIDE 34

Performance

34

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

Installation June 2015

slide-35
SLIDE 35

Performance

35

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

Early July 2015

slide-36
SLIDE 36

Performance

36

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

Late July 2015

slide-37
SLIDE 37

Performance

37

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

August 2015

slide-38
SLIDE 38

Performance / Evaluation

38

› Filled in nicely during first growing season › No issues during first summer / fall › Minimal damage during winter 2015/ 16 › Further growth during 2016 growing season

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

slide-39
SLIDE 39

2

Lessons Learned / Conclusions

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

slide-40
SLIDE 40

Lessons Learned / Conclusions

40

› Needs: › Additional regulatory guidance / acceptance › Additional design guidance for soft solutions › Client education / understanding of risks › Contractor experience › Lessons Learned › Involve client early / often in decision process › Monitoring is critical to help with future designs and installations

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

slide-41
SLIDE 41

41

Thank You

Questions?

18 NOVEMBER 2016 LIVING SHORELINE PROJECTS

FMLU@COW I .com
