SLIDE 1
JUSTIN WILSON US MUM 2017
J2SW.COM
TOPICS COVERED
- MPLS - WHAT YOU NEED TO KNOW
- NETWORK DESIGN PHILOSOPHIES
- LESSONS LEARNED ON THE OL INTERWEBS
- WHAT YOU NEED TO KNOW IN THE NEXT 18 MONTHS
- EXTRAS IF TIME
- GIVEAWAY
JUSTIN WILSON US MUM 2017 J2SW.COM TOPICS COVERED MPLS - WHAT YOU - - PowerPoint PPT Presentation
JUSTIN WILSON US MUM 2017 J2SW.COM TOPICS COVERED MPLS - WHAT YOU - - PowerPoint PPT Presentation
JUSTIN WILSON US MUM 2017 J2SW.COM TOPICS COVERED MPLS - WHAT YOU NEED TO KNOW NETWORK DESIGN PHILOSOPHIES LESSONS LEARNED ON THE OL INTERWEBS WHAT YOU NEED TO KNOW IN THE NEXT 18 MONTHS EXTRAS IF TIME GIVEAWAY JUSTIN
SLIDE 2
SLIDE 3
JUSTIN WILSON
- CCNA – CCNP – COMTRAIN - MTCNA
- ISP INDUSTRY SINCE 1993
- BLOGGER, THE BROTHERS WISP MEMBER, COMMUNITY REGULAR
- CEO MTIN.NET, COO MIDWEST-IX/FD-IX
- AVID GI JOE COLLECTOR
j2sw.com • mtin.net • connectivity.engineer • midwest-ix.com
SLIDE 4
MPLS / VPLS / ALPHABET SOUP
- MPLS
- VPLS
- WHY AND WHEN?
SLIDE 5
WHY SHOULD I EVEN CARE ABOUT MPLS?
- SCALABILITY
- TRAFFIC ENGINEERING
- QOS
- REDUNDANCY
- INDEPENDENT OF LAYER 2 AND LAYER 3 PROTOCOLS
- BUT I CAN DO THIS WITH OSPF AND BGP ALREADY?
SLIDE 6
SLIDE 7
MPLS…
- MPLS IS LAYER 2.5
- YOU STILL NEED THINGS LIKE OSPF, BGP
, EIGRP FOR IP
- IF YOU ARE RUNNING RIP COME SEE ME. YOU NEED HELP. I WILL HELP
YOU FOR FREE YOU POOR B@$%!RD.
- ARE STATIC ROUTES BAD?
- NO, JUST NOT SCALABLE
- IF YOU ARE RUNNING STATIC ROUTES COMFORTABLY YOU PROBABLY
DON’T HAVE A NEED FOR MPLS
SLIDE 8
DRAWBACKS TO MPLS
- MORE ADMINISTRATIVE OVERHEAD
- LARGER MTUS NEEDED
- INCREASED NETWORK COMPLEXITY
- CHANGE IS SCARY
- DO I REALLY NEED MPLS?
SLIDE 9
MPLS SECURITY
- EASY TO SPOOF IP ADDRESSES, ALMOST IMPOSSIBLE TO SPOOF
LABELS
- EVERY PE ROUTER MAINTAINS A SEPARATE BRF
- DOES NOT DO ENCRYPTION OR AUTHENTICATION
- MOST ATTACKS ARE AGAINST THE PE ROUTER OR THE ROUTING
ON TOP OF MPLS
SLIDE 10
VPLS
- VPLS CAN HELP YOU SAVE IP ADDRESSES
- TUNNEL BACK TO A CENTRAL CORE WHERE A SINGLE POOL
CAN ASSIGN IPS
- WILL EOIP DO THE SAME FOR ME?
SLIDE 11
NETWORK PHILOSOPHY
SLIDE 12
WHERE TO USE?
SLIDE 13
SWITCH CENTRIC
- Switch Fabric from 2013
- Transport and Transit circuits terminated
- n Cisco Chassis (pre mikrotik switching)
- Routers in VRRP
- BGP routers fed into VRRP Core
- Switches Switch Routers Route
SLIDE 14
SMALL SWITCH CENTRIC
- Small DC Deployment
- Same concept
- Switches switch
- Provider circuits are your
failure points most of the time
SLIDE 15
SLIDE 16
WHAT DOES IT COST TO PLAN
- PLAN FOR 100 CUSTOMERS, PLAN FOR 10000
- YOU CAN PLAN WHILE EATING GREEN EGGS AND HAM
- SUCCESSFUL ISPS AND NETWORKS HAVE CONTINGENCY PLANS FOR
EVERYTHING NOT JUST DISASTERS
- KNOW YOUR PAIN POINTS
- KNOW YOUR LIMITATIONS
SLIDE 17
WHAT SHOULD I KNOW IN THE NEXT 12 MONTHS?
SLIDE 18
WHAT DO I NEED TO LEARN ABOUT?
- WIRELESS
- LTE
- SHRINKING CELL SIZES
- MORE BANDWIDTH CLOSER TO THE CUSTOMER
- INTERFERENCE MITIGATION
SLIDE 19
IPV4 EXHAUSTION
- CGN
- IPV6
- OPEN MARKET PURCHASES
- NAT *
*WWJD (What would Janis do)
SLIDE 20
MIKROTIK STUFF TO KNOW
- FOR US PROVIDERS CALEA
- AUTOMATING YOUR NETWORKS
- EIRP LIMITS AND WIRELESS
- LEARN ABOUT 60 GHZ, EVEN IF YOU ARE RURAL
SLIDE 21
LLFF (LESSONS LEARNED FROM FACEBOOK)
- PROTECT YOUR NETWORK DEVICES. EVEN IF THEY ARE PROTECTED BY
FIREWALLS KEEP UP ON SOFTWARE UPDATES. *
- GROUND YOUR STUFF….PROPERLY
- THERE ARE MANY WAYS TO DO SOMETHING. MANY ARE RIGHT. SOME ARE
TOTALLY WRONG.
- MODULAR NETWORKS
SLIDE 22
MIKROTIK CASE STUDY
- SWITCHES AND ROUTERS IN A DATA CENTER 4 HOURS AWAY
FROM THE CLOSEST TECH
- NEEDED TO BE ABLE TO SEE WHAT IS GOING ON BEFORE
DISPATCHING SOMEONE
- MULTIPLE METRO SITES
- 2011S AT THE HEART OF THE MANAGEMENT NETWORK
SLIDE 23
SLIDE 24
RESOURCES
- FACEBOOK GROUPS (WISP TALK MOST ACTIVE)
- CONFERENCES
- MUM
- WISPA
- SERVICES AND PROGRAMS
- UNIMUS
- TOWERCOVERAGE
- PODCASTS
- THE BROTHERS WISP
- PACKET PUSHERS
SLIDE 25
