Ipdia Capacitor Introduction Capacitor Range 1. High Stability Silicon Capacitor ( HSSC ): -55 to +150 degree C 2. High Temperature Silicon Capacitor ( HTSC ): -55 to + 200 degree C 3. Xtreme Temperature Silicon Capacitor ( XTSC): -55 to

slide-1
SLIDE 1

Ipdia Capacitor Introduction

slide-2
SLIDE 2

Capacitor Range

  • 1. High Stability Silicon Capacitor ( HSSC ):
  • 55 to +150 degree C
  • 2. High Temperature Silicon Capacitor ( HTSC ):
  • 55 to + 200 degree C
  • 3. Xtreme Temperature Silicon Capacitor ( XTSC):
  • 55 to +250 degree C
  • 4. Low Profile Silicon Capacitor ( LPSC ):

Thickness down to 100um.

slide-3
SLIDE 3

High Stability Silicon Capacitor HSSC

slide-4
SLIDE 4

High Stability Silicon Capacitor (HSSC )

Key Benefits: Lowest Derating Rate (<1%)

  • Ageing rate: 0.001% per decade
  • Temperature: 70ppm / decade
  • Voltage: 0.1% / Volts
  • Longer battery lifetime
  • ESR down to 90mΩ
  • ESL down to 100pH
slide-5
SLIDE 5

High Stability Silicon Capacitor ( HSSC) Capacitor Range - 1nF to 0.1uF Aging Rate – 0.001% over 10 years Equivalent Series Resistor down to 90mOhm Equivalent Series Inductor <100pH Temperature Coefficient < 1% Operating Temperature -55 to +150 C Capacitor Height 400um

slide-6
SLIDE 6
slide-7
SLIDE 7
slide-8
SLIDE 8
slide-9
SLIDE 9
slide-10
SLIDE 10

High Temperature Silicon Capacitor HPSC

slide-11
SLIDE 11

High Temperature Silicon Capacitor ( HTSC ) Key Benefits

  • 100nF can pack in 0402 size, compare to

1206 size needed for alternative technology.

  • Optimal Stability from -55°

° ° °C to 200° ° ° °C

  • 1206 package: Ipdia can provide 1000nF

Kemet provide at 100nf

slide-12
SLIDE 12

High Temperature Stability Silicon Capacitor ( HTSC) Capacitor Range - 1nF to 0.1uF Aging Rate – 0.001% over 10 years Equivalent Series Resistor down to 90mOhm Equivalent Series Inductor < 100pH Temperature Coefficient < 1% Operating Temperature -55 to +200 C Capacitor Height 400um

slide-13
SLIDE 13
slide-14
SLIDE 14
slide-15
SLIDE 15
slide-16
SLIDE 16

Xtreme Temperature Silicon Capacitor XTSC

slide-17
SLIDE 17

Xtreme Temperature Silicon Capacitor (XTSC) Key Benefits

  • Unique capacitor of 1μ

μ μ μF available in 1206 size.

  • Optimal Stability from -55°

° ° °C to 250° ° ° °C

  • Same Out of Standard performances that

HTSC capacitor

slide-18
SLIDE 18

Xtreme Temperature Stability Silicon Capacitor ( XTSC) Capacitor Range - 1nF to 0.1uF Aging Rate – 0.001% over 10 years Equivalent Series Resistor down to 90mOhm Equivalent Series Inductor < 100pH Temperature Coefficient < 1% Operating Temperature -55 to +250 C Capacitor Height 400um

slide-19
SLIDE 19

Low Profile Silicon Capacitor LPSC

slide-20
SLIDE 20

Low Profile Silicon Capacitor (LPSC) Key Benefits

  • Unique capacitor of 1μ

μ μ μF available in 100μ μ μ μm Thickness

  • ESR down to 90mΩ
  • ESL down to 100pH
  • Same Out of Standard performances that

HSSC capacitor

slide-21
SLIDE 21

Lop Profile Silicon Capacitor ( LPSC) Capacitor Range - 1nF to 0.1uF Aging Rate – 0.001% over 10 years Equivalent Series Resistor down to 90mOhm Equivalent Series Inductor < 100pH Temperature Coefficient < 1% Operating Temperature -55 to +150 C Capacitor Height 100um

slide-22
SLIDE 22
slide-23
SLIDE 23

Package Type

  • Tape and Reel
  • Waffle Pack
  • Wafer delivery
  • Array type package ( 4 -10 capacitors in one

package ) – custom
