THE “VACUUM CAPACITOR”

THE ULTIMATE ENERGY STORAGE TECHNOLOGY

FREEL TECH DESIGNED THE «VACUUM CAPACITOR» A REVOLUTION IN ENERGY STORAGE

WE NEED A SAFE, CHEAP, HIGH-DENSITY, EASILY SCALABLE, INDEPENDANT FROM SENSITIVE RESOURCES AND ENVIRONMENTALLY-FRIENDLY TECHNOLOGY, THAT CAN BE IMPLEMENTED MASSIVELY THROUGHOUT EUROPE (AND GLOBALLY)

WE NEED A REAL PARADIGM SHIFT!

THEY DID NOT KNOW IT WAS IMPOSSIBLE, SO THEY DID IT!

MARK TWAIN

FREEL TECH HAS THE SOLUTION TO ADDRESS MASSIVE ENERGY STORAGE!

CHEAP AND SCALABLE SAFE LIGHT VERY HIGH-DENSITY SUITABLE AND AFFORDABLE FOR ALL ENERGY STORAGE APPLICATIONS NO CHEMISTRY INVOLVED, PURE ELECTRICAL STORAGE IN VACUUM SCALABLE NO RELIANCE ON EXPENSIVE MINERAL RESOURCES ONE SOLUTION TO COVER ALL CONTINENTS, EVEN SPACE APPLICATIONS ENVIRONMENTALLY- FRIENDLY TECHNOLOGY

CHARGES (e-)

STORED DIRECTLY AS CHARGE CLUSTERS INSIDE A SMALL BULB UNDER VACUUM

THE VACUUM CAPACITOR: TARGETED PARAMETERS

• ENERGY DENSITY : 0,5 - 1 kWh / cm3
• AFTER INTEGRATION : UP TO 20 kWh / kg
• LOW COST: << 100 USD / kWh
• HIGH NUMBER OF CYCLES
• HIGH ROUND-CYCLE EFFICIENCY
• SMALL QUANTITIES OF MATERIALS NEEDED
• NO RARE OR EXPENSIVE RAW MATERIALS
• LOW ENVIRONMENTAL IMPACT
• SIMPLE RECYCLING

TARGETED PARAMETERS

UNMATCHED ENERGY AND POWER DENSITY…

FREEL TECH’s VACUUM CAPACITOR (TARGET) OUR BEST EXPERIMENTAL RESULT TO DATE 𝟐𝟏 𝟐 𝟐𝟏𝟑 𝟐𝟏3 𝟐𝟏4 𝟐𝟏5 𝟐𝟏6 𝟐𝟏7 𝟐𝟏-1 𝟐𝟏-2 𝟐 𝟐𝟏 𝟐𝟏2 𝟐𝟏3 𝟐𝟏4 𝟐𝟏5

7 500 WH/KG 62 500 W/KG

CAPACITORS ELECTROCHEMICAL CAPACITORS BATTERIES FUEL CELLS ENERGY DENSITY(WH/KG) POWER DENSITY (W/KG) X 100 TIMES!

… AT SIGNIFICANTLY LOWER COST

PUMPED HYDRO LEAD-ACID FUEL CELLS LITHIUM-ION

EXPECTED POSITION & TREND FOR FREEL TECH’S TECHNOLOGY

OUR TECHNOLOGY IS – AND SHOULD REMAIN – SIGNIFICANTLY LESS EXPENSIVE THAN ANY OTHER TECHNOLOGY

COST WELL UNDER 100 USD / KWH OUR TARGET : TO BE ALWAYS AT LEAST 5 TIMES LESS EXPENSIVE THAN LI-ION

HOW IT ALL STARTED 15 YEARS AGO…

STATUS TODAY: OPTIMIZED PROTOTYPES

CURRENT WEIGHT ≈ 40 GRAMS

TARGET: 1 KWH PER DEVICE

TESTS OF THE VACUUM CAPACITOR IN FRANCE (DEC. 2019 – FEB 2020)

HIGH DENSITY CHARGE CLUSTERS (HDCC), OR CONDENSED PLASMOIDS (CP), ARE WELL IDENTIFIED STRUCTURES, WHICH HAVE BEEN STUDIED IN PARTICULAR BY KEN SHOULDERS (USA), AS WELL AS OTHER SCIENTISTS (USA, RUSSIA, BELARUS, GERMANY). HDCCs (« EV », « EVO ») are « … highly organized, micron-sized clusters of electrons, having soliton behavior, with electron populations on the order of Avogadro's number… » (K. Shoulders)

THE PHYSICS BEHIND IT: THE CHARGE CLUSTERS

• R. FEYNMAN FIRST DISMISSED THE IDEA PRESENTED

BY KEN SHOULDERS, BUT LATER (1986), HE SENT A LETTER TO K. SHOULDERS, TO RECOGNIZE THAT HE WAS WRONG, AND TO ACKNOWLEDGE THAT ELECTRON CLUSTERS WERE FEASIBLE …

PLEASE VISIT : www.freel.tech (section about charge clusters)

A UNIQUE, BREAKTHROUGH TECHNOLOGY

CHEAPEST EVER ENERGY STORAGE TECHNOLOGY PURE ELECTRICITY STORAGE

HIGH ROUND-CYCLE EFFICIENCY, LIMITED LOSSES ONCE CHARGED

UNMATCHED ENERGY DENSITY VERSATILE: SUITABLE FOR MAJOR STATIONARY AND MOBILE APPLICATIONS SAFE NO RELIANCE ON RARE, EXPENSIVE OR ‘ECO-DAMAGING’ RESOURCES LONG LIFE AND EASILY RECYCLABLE LARGE NUMBER OF CYCLES

THESE COMPETITIVE ADVANTAGES ARE SUSTAINABLE IN TIME OUR SOLUTION

TARGET MARKETS FOR FREEL TECH’S TECHNOLOGY

THANKS TO ITS COMPETITIVE ADVANTAGES, FREEL TECH CAN ACCESS ALL MAJOR MARKETS FOR ENERGY STORAGE IN FUTURE YEARS: GRID SCALE STORAGE SMART GRIDS ELECTRICALMOBILITY: ROAD, AIR, SEA BEHIND-THE-METER: RESIDENTIALM, I&C MAIN TARGET MARKETS AND APPLICATIONS FOR THE VACUUM CAPACITOR

1 2 3

STATUS OF THE PROJECT MILESTONES

2007 - 2011 2011 – 2012 2015 – 2017 2017 2017 – 2018 2019 (March) 2019 (Dec.) 2020 2021 – 2022

FIRST TESTS PROOF OF CONCEPT

TRL 3 REACHED

(300 Wh / cm3)

PATENTS FILED IN SEVERAL COUNTRIES NEW PROJECT MANAGEMENT SEARCH FOR INVESTORS PERSONAL INVESTMENTS PREPARATION OF NEW PROTOTYPES AND TEST BENCH WORK ON THEORY & SIMULATIONS INCEPTION OF FREEL TECH (APRIL) R&D : NEW TESTS, OPTIMISATION, IN COOPERATION WITH INDUSTRIAL PARTNERS

TARGET: TRL 4 EARLY IN 1H21

RELOCATION OF R&D (FRANCE)

TESTS OF NEW CHARGING CIRCUITS

FIRST MODULES INDUSTRIAL PILOTS TESTS IN REAL CONDITIONS :

TARGET: REACHING TRL 6 IN 2022

& PREPARATION TO INDUSTRIALIZATION START OF IN-HOUSE EXPERIMENTS WITH NEW PROTOTYPES

FREEL TECH: THE TEAM

THESE COMPETITIVE ADVANTAGES ARE SUSTAINABLE IN TIME

Günther IRGANG - President

Graduated from the Bremerhaven High School

• f

Electronics for military applications. Günther later joined the private sector and graduated from HEC management. Beside its management role with FREEL TECH, Günther is President

• f

two privately-owned entities, active in specific industrial sectors. One of these entities is an appreciated supplier of France’s major naval shipyards of St-Nazaire.

Michael IRGANG - CEO

Graduated from Mines Paristech, 20+ years of working experience in Russia, in particular in the energy sector. (Nuclear, Oil & Gas) Michael developed a taste for fundamental and applied

• physics. He created in 2016 a website dedicated to

theories & facts in theoretical physics, as well as new applications. In 2014 Michael discovered the Vacuum Capacitor technology, and fostered the creation of FREEL TECH.

Julien PLAN - Business Development Director

Mechanical- and Nuclear-engineer (INSA de Lyon & UGA, respectively), Julien also graduated as Executive-MBA at the EM-Lyon Business School. Julien has a strong industrial and technical background and believes the Vacuum Capacitor is the key technology for energy storage. Shareholder of FREEL TECH, Julien actively contributes to the project’s promotion.

Roman KOLOSHENKO, CTO

After a military career, Roman graduated as Engineer. He always showed great interest in electronics & magnetics fields. Head of a team of talented experimenters highly skilled in electronics, who developed the first Vacuum Capacitors prototypes. Roman patented the Vacuum Capacitor in 2010 - 2011, which were eventually transferred to FREEL TECH at the time of its inception, in 2017.

FREEL TECH WAS CREATED AND INCORPORATED IN LUXEMBOURG IN APRIL 2017 ITS SHAREHOLDERS' STRUCTURE IS MAJORITY OWNED BY ITS MANAGEMENT and by a several private investors (business angels, entered in 2017-2019) IP: FREEL TECH OWNS MULTIPLE PATENTS FOR THE TECHNOLOGY (Europe, North America, Eurasia, Brazil, India, and other countries).
