CLEANING IN A VACUUM

slide-2
SLIDE 2

Outline

  • Vacuum processing
  • Contamination and defects
  • Cleaning in a vacuum
  • Vacuum qualification test
  • Organic contamination
  • Summary

2

slide-3
SLIDE 3

3

slide-4
SLIDE 4

VACUUM PROCESSING

slide-5
SLIDE 5

What is a vacuum system

  • It is a large strong metal container called a

Vacuum Chamber

  • In use it is completely sealed to stop any

air getting in

  • The materials to be coated are put in the

chamber before it is sealed

  • All the air is pumped out
  • The coating is made

5

slide-6
SLIDE 6

What is a vacuum chamber

  • A sealed container from which all the air has

been pumped out

  • The pressure within a vacuum is less than

normal atmospheric pressure (10−7mbar)

  • Along with the air any water or other low boiling

point materials present within the materials of the vacuum chamber or materials placed in it for processing will also be sucked out

  • This is called outgassing
slide-7
SLIDE 7

Outgassing

  • Most plastics will outgas so special

plastics have to be used in vacuum.

  • There is more outgassing in flexible plastic

films

  • Many additives will outgas
  • Unreacted chemicals in rubbers will
  • utgas
  • Even metals can outgas under vacuum
slide-8
SLIDE 8

Vacuum Format

  • Sheet format

– Mainly used in the semi-conductor industry – Has to be cleaned before it enters vacuum

  • Roll to Roll format

– Currently used in wide format for food packaging – Increasingly used in narrow format for Hi Tech applications such as Plastic Electronics

8

slide-9
SLIDE 9

R2R vacuum line

9

slide-10
SLIDE 10

Benefits of vacuum

  • Metal melts at a lower temperature
  • Coatings can be deposited more quickly
  • No oxidation of coatings like aluminium or

silver as there is no oxygen

  • Very thin films can be deposited
  • The films are very dense as there are no

solvents or other carriers

  • No air molecules so no collisions

10

slide-11
SLIDE 11

Vacuum Processes

  • Thermal Evaporation
  • Chemical Vapour Deposition (CVD)
  • Physical Vapour Deposition (PVD)
  • Plasma Enhanced Deposition (PE)
  • Atomic Layer Deposition (ALD)

11

slide-12
SLIDE 12

Thermal Evaporation

  • Thermal Evaporation often called vacuum

metallizing.

  • Metal is melted and turns into vapour
  • Resistance heating or E beam melting
  • Long established relatively low technology
  • Used mainly in food packaging

applications to provide an oxygen barrier

  • Metal used is mainly aluminium

12

slide-13
SLIDE 13

Chemical Vapour Deposition(CVD)

  • Different chemicals are injected into the

vacuum chamber

  • They react to form a material which is

condensed onto the film surface

  • They can form conductive or insulative

materials

  • They can also form ceramic coatings
  • Used for barrier coatings and TFT

13

slide-14
SLIDE 14

Physical Vapour Deposition (PVD)

  • Sputtering
  • A solid metal target is hit with ions which

knock particles of metal off

  • The particles of metal are attracted to the

film surface by an electric field

  • The most common material is ITO
  • This gives a conductive surface which is

transparent

14

slide-15
SLIDE 15

Atomic Layer Deposition (ALD)

  • Conformal Thin Films on structured

substrate- self limiting

  • 2 precursors – 2 half reactions separated

by a purge cycle

  • Min Film Thickness ~0.1Å
  • Can be in vacuum or ambient

15

slide-16
SLIDE 16

Plasma Enhancing (PE)

  • Plasma is a cloud of ions
  • There are two used for plasma in a

vacuum

– As a pretreatment to remove organic contamination, change the surface energy of the film and improve adhesion – To supply energy to improve the coating process

16

slide-17
SLIDE 17

Substrates

  • Polyester Terepthalate (PET)
  • Polyester Napthalate (PEN)
  • Polyimide
  • Polypropylene (PP)
  • Metal foils eg steel or aluminium
  • Flexible glass

17

slide-18
SLIDE 18

Vacuum Applications

  • ITO Films
  • ITO Glass
  • Barrier Films
  • Plastic Electronics
  • Touch Panel
  • OLED/OPV
  • TFT

18

slide-19
SLIDE 19

CONTAMINATION AND DEFECTS

slide-20
SLIDE 20

Technology Drivers

  • Films are getting thinner – easier to

damage by particles in the wind of the roll

  • Coatings are getting thinner – even

nanoscale particles can cause pinholes

  • The functional requirements on coatings

are becoming more demanding

20

slide-21
SLIDE 21

Issues

  • Particles of contamination on substrates

cause defects in vacuum deposition processes used in Flat Panel display manufacturing

  • Defects cause significant yield loss
  • Removal of particles is essential for high

functionality and reliability

21

slide-22
SLIDE 22

Challenges

  • Yield

– Functional Failure

  • Shorts/opens

– Barrier failure

  • H20 ingress

– Brittle coating fracture – Adhesion Failure

  • Cost of substrate

22

slide-23
SLIDE 23

Key Yield Drivers

  • Contamination

– Base film contamination

  • Oligomer
  • Particles

– Protective Film contamination

  • Removal creates static which attracts particles

– Process Generated contamination

23

slide-24
SLIDE 24

Where contamination comes from

  • People
  • Atmosphere
  • Substrate
  • Deposition process
  • Vacuum Chamber cleaning
  • Vacuum Chamber pumpdown
  • Vacuum Chamber venting

24

slide-25
SLIDE 25

How particles cause defects 1

  • The particles prevent the coating reaching

the substrate

  • The particles get covered in coating
  • When the substrate is moved or rewound

the particles are knocked loose from the substrate leaving uncoated areas called pinholes in the coating

  • These pinholes affect the functionality of

the film

25

slide-26
SLIDE 26

How particles cause defects 2

  • Particles can fall from the walls and roof of

the vacuum chamber

  • If they land on the surface of the film and

the film is wound up the particles will cause a depression or dent in the film which will repeat for several layers

  • The particles can also fracture brittle

ceramic coatings during rewind

26

slide-27
SLIDE 27

How particles cause defects 3

27

slide-28
SLIDE 28

Starry Night 1

28

slide-29
SLIDE 29

Starry Night 2 - Korea

29

slide-30
SLIDE 30

Starry Night 2 – Korea Japanese Base Film

30

slide-31
SLIDE 31

CLEANING IN A VACUUM

slide-32
SLIDE 32

Cleaning Technology Options

32

slide-33
SLIDE 33

Cleaning Issues

  • No outgassing
  • No decline in cleaning performance
  • No impact on Surface Energy
  • Be able to clean full roll without intervention
  • No air, not liquids
  • Must not add static
  • Operate at normal drum temperatures -15°C

to 100°C

  • Remove particles 20nanometer to 200micron

33

slide-34
SLIDE 34

Typical types of particle

  • Particle size from 200 microns to 20 nm
  • Small particles of airborne dust and fibres
  • Slitting dust
  • Metal particles from deposition process
  • Ceramic particles from deposition process
  • Particles from roll cores
  • Particles from packaging and handling

34

slide-35
SLIDE 35

R2R vacuum line

35

slide-36
SLIDE 36

Cleaning Locations

  • Unwind
  • Post Deposition
  • Rewind
  • Rewind protective Film

36

slide-37
SLIDE 37

Which side to clean?

cooled deposition drum cooled deposition drum thermal expansion substrate thermal load thermal load

As the heat load is applied the substrate wants to expand but is constrained by the friction between the substrate and cooled deposition drum Now there is some debris preventing the web laying flat on the surface of the drum. There is then, locally, less cooling & the web wants to expand. As it is already off the surface this is easy to achieve & the wrinkle starts.

Debris

Keep the drum & substrate clean

37

slide-38
SLIDE 38

Rear Side Issues

  • Particle on rear of film becomes front side

contamination at rewind.

  • Ceramic coating are easily fractured by

rear side particle being pressed against deposition.

38

slide-39
SLIDE 39

Rear Side Issues

39

slide-40
SLIDE 40

Results – Metallised PET

40

slide-41
SLIDE 41

Additional cleaning opportunities

  • Hand Cleaning of Chamber/shields etc
  • Hand cleaning of roll ends prior to loading
  • Hand cleaning of outer wrap of roll

41

slide-42
SLIDE 42

Shield Cleaning

In the R2R vacuum tool cleaning is very important for removal of particles from the machine. This cleaning can be done with:

  • Industrial vacuum cleaner with HEPA filter

Very suited for removal of large SiN flakes around the microwave tubes and other locations

  • Tissues with IPA

Very suited for cleaning drums

  • Tacky roller (Teknek)

Very suited for cleaning walls/shieldings of all the chambers

42

slide-43
SLIDE 43

Cleaning results with Teknek roller

Shieldings PC1 Shieldings PC1 Backside foil LL1- PC1 1 PC1 walls LL1 bottom Bottom PC1 Bottom PC1

1 Backside foil dirty

because of removal slit

43

slide-44
SLIDE 44

VACUUM QUALIFICATION TEST

slide-45
SLIDE 45

Teknek Technology

  • Fully certified Vacuum compatible contact

cleaning system

– Nanocleen cleaning roller

  • 100% silicone free, no other free chemistry – no
  • utgassing
  • High cleaning efficiency – unaffected by vacuum
  • No change to Surface Energy

– AREF Adhesive

  • 100% silicone free, no release liner – no
  • utgassing

45

slide-46
SLIDE 46

Certified Vac Compatible

  • Approved by Holst Institute (Holland)

– Tested at 10-7mbar – Outgassing verified by RGA – Silicone free verified by

  • FTIR
  • Edx
  • RGA

– Cleaning efficiency checked before/after vacuum exposure

46

slide-47
SLIDE 47

Vacuum Test - Holst Institute

  • Scud Vacuum System 032
  • 2 small rollers
  • 2 sheets adhesive
  • Pumped down to 1E-7 mbar
  • Time in vacuum 66 hours
  • Each sample weighed before and after

– Nanocleen Rollers – Weight loss 0.4% * * Adsorbed moisture

47

slide-48
SLIDE 48

Cleaning performance before/after Vacuum - Holst Institute

Teknek Cleaning System Efficiency Test - Holst Institute

Vacuum Conditions

Particle Nanocleen Roller AREF Adhesive Capacity (g) ambient ambient 0.26 ambient 1 weekend in vac (0.1 mbar) 0.25 ambient 18 hours in high vac (1e-6 mbar) 0.25 1 weekend in vac (0.1 mbar) ambient 0.26 1 weekend in vac (1e-6 mbar) ambient 0.25

48

slide-49
SLIDE 49

RGA Test - Holst Institute

49

slide-50
SLIDE 50

ORGANIC CONTAMINATION

slide-51
SLIDE 51

Oligomers

  • Oligomers are unreacted monomers left in

the film during manufacture

  • Oligomers migrate to the surface over time
  • Temperature increases the rate of

migration

  • Oligomers are not dry unattached particles
  • Oligomers cause pinhole defects
slide-52
SLIDE 52

Additives

  • Antioxidants
  • Nucleation promoters
  • Radical scavengers
  • Surface activators
  • Anti misting
  • Slip agents
  • Colour
  • Optical brighteners
  • Viscosity modifiers
  • Gloss improvers
  • Anti static
  • Anti blocking
  • Voiding agents
  • Dispersion stabilisers
  • Flame retardants
  • Surfactants

52

slide-53
SLIDE 53

Questions to ask

  • How wide is the substrate
  • What pressure is the vacuum operating
  • Are the unwind and rewind operating at

the same pressure as the deposition

  • What are the maximum and minimum

temperatures within the chamber

  • What length is the roll of substrate

53

slide-54
SLIDE 54

Benefits Summary

  • Teknek technology can now

– Remove particles down to 100 nm – From all types of substrates – As thin as 15 microns – In both sheet and roll format – At speeds from 1m/min to 300m/min – In a high vacuum environment – Without silicone – Gives significant yield improvements
