Insights and Approaches for Mapping Soil Organic Carbon as a Dynamic - - PowerPoint PPT Presentation

Insights and Approaches for Mapping Soil Organic Carbon as a Dynamic Soil Property Mark H. Stolt, Patrick J. Drohan, and Matthew J. Richardson Soil Science Society of America Journal (2010) Site Locations 17 sites, ranging in age from 25 to 86


slide-1
SLIDE 1

Insights and Approaches for Mapping Soil Organic Carbon as a Dynamic Soil Property

Mark H. Stolt, Patrick J. Drohan, and Matthew J. Richardson

Soil Science Society of America Journal (2010)

slide-2
SLIDE 2

Site Locations

17 sites, ranging in age from 25 to 86 years.

slide-3
SLIDE 3

1954 1997

  • Field and forest having

same soil type comprise paired site

  • Sample multiple locations

within field and forest

  • Core trees to determine

age and measure SOC

  • Difference between field

and forest used to calculate rate of C sequestration

Paired Sites:

slide-4
SLIDE 4

Anderson Land Cover Level I O A B C Upper Meter Percent of Upper Meter Pool in O and A Horizons Numeric Phase Value ──────── Mg ha-1 ──────────── % (Mg ha-1) Agricultural 55 35 15 103 53 55 (Moderate) Forest 32 70 40 17 157 65 102 (High) Average SOC by horizon and for the upper meter by Anderson Land Cover Class Add a phase component to the Soil Survey for SOC pools Focus on the O and A horizon For example: MmB in the soil survey in agriculture would be changed to MmBM

slide-5
SLIDE 5

Assessing the Effects

  • f Land Use Change
  • n Riparian Zone

Soils in Southern New England

Matthew C. Ricker Mark H. Stolt

Ecological Applications 2012

slide-6
SLIDE 6

Matt Ricker

slide-7
SLIDE 7
  • Important links between upland

and aquatic systems

  • Provide multiple environmental

and ecosystem functions

  • Form as a result of episodic alluvial

deposition

  • Land use change may result in

impacts to riparian soil functions

Buried horizon (Ab)

RIPARIAN ZONES

slide-8
SLIDE 8
slide-9
SLIDE 9

Develop Multi-Proxy Indices of Land Use Change for Riparian Soils

Objectives

  • 1. Establish stratigraphic indices of

watershed land use change using a multi-proxy approach

  • 2. Utilize these indices to establish

time frames of alluvial deposition

  • 3. Relate riparian sedimentation and

carbon sequestration rates to land use

Diatomaceous Earth

SEM Image

500x Magnification

slide-10
SLIDE 10

Methods

  • 18 representative headwater

watershed riparian sites selected

– Hydric soils (Inceptisols, Entisols)

  • Formed in alluvium over outwash
  • Raypol, Rumney, Scarboro, and

Walpole series

  • Varied watershed land use

– Urban, agricultural, mixed use, forested

  • Soil pits dug to 1 m or greater

– Soils described in field – Bulk density – PSD – Heavy metals – Pollen samples by horizon – Soil organic carbon (SOC)

slide-11
SLIDE 11

Study Watersheds

4 urban, 4 agricultural, 4 forested, and 6 mixed LU watersheds

slide-12
SLIDE 12

General Land Use Periods and Associated Indices

  • Constrain riparian soil horizons into three

major distinct land use periods

  • Pre-colonial period (17,000 YBP–1650 AD)
  • Colonial (agrarian) period (1650-1900 AD)

– Rise and/or peak ragweed and other non- arboreal pollen types – Supported by twelve 14C dates

  • Rise in ragweed dated to 1780±40 AD
  • Peak ragweed dated to 1850±50 AD
  • Modern industrial/urbanization period

(1900 AD-present) – Increased coarse materials (sand, gravels) – Presence of human artifacts – Rise and peak pollutant metals (Pb)

  • Supported by 210Pb cores
slide-13
SLIDE 13

Many sand lenses (A/Cg)

  • Particle size distribution

– Coarser deposits as watersheds undergo extensive LU change

  • Buried horizons (i.e. Ab)
  • Combination horizons (i.e. A/C)

– Indicative of short term stability

  • Human artifacts (i.e. Cu horizon)

– Indicative of colonial-urban time periods

  • Pollutant metals

– Pb, Cu, Zn, Cd, As above background levels; on average 3 to 6 times higher in surface horizons

Indices of Land Use Change:

Soil Morphology and Pollutant Metals

slide-14
SLIDE 14

Examples of Riparian “Artifacts”

(One Person’s Garbage is Another’s Stratigraphic Marker…)

A: Glass B: Plastic C: Cloth D: Asphalt E: Brick F: Styrofoam G: Shingle 50 cm 15 cm 20 cm 30 cm 50 cm 15 cm 40 cm

slide-15
SLIDE 15

Pollutant Metals

Indices of Anthropogenic Activities

(1900-present)

Concentration of pollutant metals in riparian zone soil horizons a a b y y z 50 100 150 200 250 300 Upper Most Horizon (n=18) Upper Most Mineral Horizon (n=18) Glacial Parent Materials (n=31)

(mg kg

  • 1)

Pb Total Pb, Zn, Cu, Cd, As

Means with different letters are significantly different (α=0.05) Metals concentrated near soil surface, likely anthropogenic origins: 1900-present fossil fuel combustion, especially leaded gasoline

slide-16
SLIDE 16
  • Past land uses affected the

vegetation of the region

– Impacts evident in pollen record – Pollen stratigraphy can be used to reconstruct land use

  • Pollen indicators, specifically:

– ragweed (Ambrosia taxa, family Asteraceae) – grasses (Poaceae) – have been used to date peak land use disturbance in many depositional environments (lakes and ponds)

Grass pollen (monoporate) Ragweed pollen (tricolporate, spines)

Indices of Land Use Change:

Preserved Pollen (Colonial Period)

slide-17
SLIDE 17
  • Moderate to abundant pollen was preserved in subsurface horizons
  • Range 300 to >60,000 pollen grains per gram of soil
  • Pollen was preserved in horizons dated to >11,000 YBP
  • 88% riparian soils contained preserved pollen
  • 71% riparian soils contained enough pollen for land use stratigraphy

Example Pollen Diagrams

  • 110
  • 100
  • 90
  • 80
  • 70
  • 60
  • 50
  • 40
  • 30
  • 20
  • 10

10 20 30 40 50

% Pollen Depth (cm)

Non-arboreal Ragweed Alder

  • 60
  • 50
  • 40
  • 30
  • 20
  • 10

10 20 30 40 50

% Pollen Depth (cm)

Non-arboreal Ragweed Alder

AMA-RI URI-RI

1230 45 AD 1770 40 AD 1870 67 AD 1770 41 AD

slide-18
SLIDE 18

Mean Proportion (%) Riparian Sediment and SOC from Major Land Use Periods 16 (69) 30 (60) 51 (45) 45 (49) 33 (76) 25 (80) 0% 25% 50% 75% 100% % Sediment % SOC Pre-Colonial Colonial Modern

70% 84% a b ab a b a * ** * p-value < 0.01 ** p-value < 0.0001 n = (24)

Average net sediment and SOC distribution by land use period

slide-19
SLIDE 19

Evaluating Net Sedimentation and SOC Sequestration Rates Utilizing Stratigraphic Indices

2.8a 1.8a 0.02b 0.06b 0.81y 0.53y 0.004z 0.02z 1 2 3 4 5 6 Modern Colonial Pre-Colonial Total Net

Accretion Rate SOC Seqestration SOC Sequestration (Mg C ha-1 yr-1) Sedimentation Rate (mm yr-1)

(1900 AD – Present) (1650 – 1900 AD) (17,000 YBP – 1650 AD) (17,000 YBP – Present)

  • 115x overall increase net sedimentation rates since pre-colonial period
  • 225x overall increase net SOC sequestration since pre-colonial period
  • Riparian rates for SOC sequestration are 2 to 4 times that of upland forests
slide-20
SLIDE 20

Sedimentation and SOC Sequestration:

What is the relationship?

y = 0.2378x + 0.0834 R2 = 0.70

0.0 0.5 1.0 1.5 2.0 2.5 3.0 2 4 6 8 10

Sedimentation Rate (mm yr-1) SOC Sequestration (Mg C ha-1 yr-1)

Pre-Colonial Colonial Modern

  • Suggests sedimentation and SOC sequestration are related.
  • Exact driver of this relationship is unclear (burial, C influx, additional surface area?).
slide-21
SLIDE 21

Conclusions

  • Soil morphology, pollutant

metals, and pollen stratigraphy can be used to successfully date riparian soil deposition

  • Land use change has had

significant impacts on riparian zone sedimentation and C sequestration

– Riparian zones acting as large sinks for sediment and C – Riparian SOC sequestration and sedimentation may be linked processes

Ab horizon 1770 AD 40

slide-22
SLIDE 22

Are riparian zones “hot spots” for SOC at watershed-scale

Methods

  • -29 representative riparian soil pedons

were examined, (Blazejewski, 2003; Donohue, 2007; Ricker, 2010)

  • -Soils sampled by horizon to 1 m
  • Bulk density
  • SOC
  • Calculated SOC pools at landscape

scale (Mg C ha-1)

  • -Riparian SOC pools compared to

published data (Davis et al., 2004) Watershed-scale analysis done in GIS

slide-23
SLIDE 23

SOC Pools Across the Landscape

110a 136a 187b 246c 586d

100 200 300 400 500 600 700 ED WD PD Riparian VPD (Organic)

SOC Pool (Mg C ha-1)

* From (Davis et al., 2004)

* * * * Means with different letters are sig. dif. (α = 0.05) Error bars = 1 SD

Uplands Wetlands

  • Mean riparian SOC pool was 246 Mg C ha-1
  • SOC pools (to 1 m depth) in riparian zone more than all
  • ther mineral soils evaluated by Davis et al. (2004)
  • Only Histosols contained more SOC to 1 m
slide-24
SLIDE 24

Spatial Distribution of SOC in Riparian Soils

53 (64) 47 (43)

0% 25% 50% 75% 100%

Riparian Zone SOC Distribution (n=29) Proportion Total SOC

Lower 70 cm Upper 30 cm

  • 53% SOC below 30 cm depth
  • By comparison:
  • ED - 30%
  • WD - 30%
  • PD - 45%
  • VPD - 75%
  • In addition:
  • 52% of riparian soils

studied had buried SOC rich horizons below 1 m

  • Suggests deep burial of

SOC is important in riparian landscapes

CV (%) in parentheses

slide-25
SLIDE 25

Factors Affecting Riparian SOC Pools

Urban Riparian Soil Norwich, CT

  • Many factors tested, none significant
  • Differences in SOC with differences

in soil morphology

  • Soils with buried surface horizons

contained significantly more SOC

  • Suggests riparian soils with high

sedimentation contain more SOC

p = 0.01 188 b 277 a

50 100 150 200 250 300 With Buried Surface Horizons (n=19) Without Buried Surface Horizons (n=10)

SOC to 1 m (Mg C ha-1)

slide-26
SLIDE 26

Riparian SOC Pools at a Watershed-scale

  • On average, riparian zones

comprised 8% of the total watershed area

  • Contained as much as 20% of

the total watershed SOC

  • Riparian zones occupy small

portion of the landscape, but represent large sink for SOC at a watershed-scale

Example GIS Map

slide-27
SLIDE 27
  • M. H. Stolt and M. C. Rabenhorst

University of Rhode Island University of Maryland

Field Estimations of Soil Organic Carbon

slide-28
SLIDE 28

Field Estimations of Soil Properties

  • Redoximorphic Features
  • Soil Texture
  • Soil Organic Carbon

– Mineral soil materials – Mucky modified soil materials – Organic soil materials

slide-29
SLIDE 29

Field Indicators of Hydric Soils

  • Thirteen of the approved field indicators of

hydric soils (A1, A2, A3, A5, A6, A7, A8, A9, A10, S1, S2, S3, F1) require the recognition of

  • rganic or mucky modified materials as part of

their definition.

slide-30
SLIDE 30

We Asked:

  • How well can this be done?
slide-31
SLIDE 31

Methodology

  • Two parallel studies
  • One utilized members and participants in the

Mid-Atlantic Hydric Soils committee

  • The second utilized members of the New England

Hydric Soils Committee

  • These groups were selected because they mainly

included experienced soil and wetland scientists who had some experience in making distinctions among mineral, mucky mineral, and organic soil materials.

slide-32
SLIDE 32

5 10 15 20 25 20 40 60 80 100

Percent OC Percent Clay

Mucky Modified Mineral Organic

USDA-NRCS. 2010. Field Indicators of Hydric Soils in the United States, Version 7.0. USDA, NRCS, in cooperation with the National Technical Committee for Hydric Soils.

slide-33
SLIDE 33

Sample ID Location SOC content (%) Mineral Mucky Mineral Organic 1 NH 2 RI 3 MA 4 MA 5 RI 6 MA 7 NH 8 MA 9 RI 10 MA

Pre-Training and Post-Training the same 11 people participated in both pre and post

slide-34
SLIDE 34

y = 0.26x + 8.31 R² = 0.13 R² = 0.39 5 10 15 20 25 30 35 5 10 15 20 25 30 35

Estimated % OC % OC

New England Pre Training

Individuals means

slide-35
SLIDE 35

y = 0.46x + 4.70 R² = 0.50 R² = 0.89 5 10 15 20 25 30 35 5 10 15 20 25 30 35

Estimated % OC % OC

New England Post Training

Individuals means

p < 0.001

slide-36
SLIDE 36

Participant A B C D E F G H I J K

Average correct (%)

Pre-training Correct (%) 60 50 60 30 30 40 40 50 30 20 40 41% After training Correct (%) 70 80 50 50 60 100 50 70 70 70 80 68% Individual Improvement (%) 10 30 -10 20 30 60 10 20 40 50 40 27%

New England Class Assignment Results

slide-37
SLIDE 37

y = 0.58x + 2.06 R² = 0.23 R² = 0.81 5 10 15 20 25 30 5 10 15 20 25 30

Estimated % OC % OC

Mid-Atl Pre Training

Individuals Means

p < 0.001

slide-38
SLIDE 38

y = 0.57x + 3.80 R² = 0.48 R² = 0.70 5 10 15 20 25 30 5 10 15 20 25 30

Estimated % OC

% OC Mid-Atl Post Training

Individuals Means

p < 0.001

slide-39
SLIDE 39

Participant A B C D E F G H I average correct Pretraining Correct 45% 55% 36% 45% 73% 64% 64% 45% 73% 56% Aftertraining Correct 73% 55% 45% 55% 73% 91% 82% 64% 82% 69% Individual Improvement 27% 0% 9% 9% 0% 27% 18% 18% 9% 13%

Mid-Atlantic Class Assignment Results

slide-40
SLIDE 40

0% 10% 20% 30% 40% 50% 60% 70% 80% Mid-Atlantic New England Correct Placement

Set 1 Set 2

a b c c

Placement into classes: mineral, mucky modified, organic

slide-41
SLIDE 41

Summary

  • Not easy to estimate SOC and determine between mucky

modified and mineral or organic soil materials

  • Without training New England folks could only assign the

correct class on average 41% of the time.

  • Training improved our ability to assign the correct class

(68%). This was essentially the same amount as the Mid- Atlantic committee got correct after training (69%)

  • In general we over-estimate SOC in mineral soil materials

and under-estimate SOC in organic soil materials.

slide-42
SLIDE 42

Method Fibric Hemic Sapric Field 3 82 Lab

Determination of soil organic soil material (SOM) type. Field is based on visual rubbed fiber content. Lab is based in standard lab rubbed fiber approach and sodium- pyrophosphate color. n = 85.

slide-43
SLIDE 43

Method Fibric Hemic Sapric Field 3 82 Lab 8 49 28

Determination of soil organic soil material (SOM) type. Field is based on visual rubbed fiber content. Lab is based in standard lab rubbed fiber approach and sodium- pyrophosphate color. n = 85.

slide-44
SLIDE 44

Mesic-Spodic Hydric Soil Indicator: Development and Testing We investigated 33 pedons for which we had 2 to 4 years of surface hydrology data for six sites. Most of the wetter soils had spodic morphology. Based on the hydrology, 25 pedons were identified as hydric. Five of the pedons met both the NE regional and national indicators. Two of the hydric pedons met the NE regional indicators but failed to meet the national indicator. Eight hydric pedons met national indicators but did not meet New England regional indicators, and 10 hydric pedons did not meet either the national nor regional indicator. Thus, 40% of the hydric soils reviewed did not meet any indicator and suggested the need for the development of an effective indicator for hydric spodic soils. Thus, our goal was to develop and test such an indicator.

slide-45
SLIDE 45

Cooper Cedar Woods (CCW) Pit #1 NH Soil Judging Contest 2005. Likely an Alaquod or Duraquod.

slide-46
SLIDE 46

Plates from Bhsm. Note the mottled appearance that suggests Fe concentrations

slide-47
SLIDE 47
  • Bhsm. Plates and mottled appearance.
slide-48
SLIDE 48

Bhsm over bedrock on last stop during 2005 Maine

  • tour. Note Fe

concentrations. Bhsm in NH formed in outwash (CCW Pit #1). No concentrations observed. Bw and Bhsm for comparison. Samples photographed after heating to 550 degrees C in muffle furnace to remove organic matter.

slide-49
SLIDE 49

Fe concentrations visible after muffle furnace in the Bhsm

  • ver bedrock.
slide-50
SLIDE 50
slide-51
SLIDE 51

Roque Bluffs Maine 2005 NEHSTC Fall Tour E Horizon Bhs Horizon Bs Horizon Pit #4 Pit #2 Bw horizon and Bhsm horizon

slide-52
SLIDE 52
  • TA6. Mesic Spodic.

For testing in MLRAs 144A and 145 of LRR R and MLRA 149B

  • f LRR S.

A layer 5 cm (2 inches) or more thick, starting within 15 cm (6 inches) of the mineral soil surface, that has value of 3 or less and chroma of 2 or less and is underlain by either:

  • a. A layer(s) 8 cm (3 inches) or more thick occurring within 30

cm (12 inches) of the mineral soil surface, having value and chroma of 3 or less, and showing evidence of spodic development; or

  • b. A layer(s) 5 cm (2 inches) or more thick occurring within 30

cm (12 inches) of the mineral soil surface, having value of 4 or more and chroma of 2 or less, and directly underlain by a layer(s) 8 cm (3 inches) or more thick having value and chroma of 3 or less and showing evidence of spodic development.

slide-53
SLIDE 53

Dark surface at least 2” thick and; 1) Layer at least 3” thick starting within 12” of soil surface that is 3/3 or darker and shows evidence

  • f spodic morphology; or

2) A layer 2” or more thick occurring within 12” of the mineral soil surface, having value of 4 or more and chroma of 2 or less, and directly underlain by a layer 3” or more thick having value and chroma

  • f 3 or less and showing evidence of

spodic development.

slide-54
SLIDE 54
  • There are 4 monitoring sites:
  • Two in Rhode Island
  • Two in Massachusetts
  • Year 1 data
  • all met the indicator,
  • showed reduction on IRIS tubes, and
  • met wetland hydrology
slide-55
SLIDE 55
