Energy Storage System (ESS) + PV – North America

• Introduction
• Evaluation and Testing
• TÜV Rheinland‘ Services in this indurstry

2

Introduction – Compliance requirement of USA and Canada

TÜV Rheinland Italy of North America _ FZ

• 1. North America Market – ESS + PV, One of the biggest markets, globally
• 2. NRTL (National Recognized Testing Laboratory) & SCC (Standards Council of Canada)
• Appropriate standard list, Major NRTL’s
• NRTL link: www.osha.gov/dts/otpca/nrtl/tuv.html
• 3. ANSI/UL/CAN Safety Standards and NFPA 70 (NEC) / Canadian Electric Code (CEC)
• National Fire Protection Association (NFPA) 70 - National Electrical Code (NEC)

Covers the installation of electrical conductors, equipment, and raceways, etc.

• The Canadian Electrical Code, CE code, or CSA C22.1

A standard published by the Canadian Standards Association pertaining to the installation and maintenance of electrical equipment in Canada

• Product safety standards: construction, components, testing, and documentation –
• vs. general requirement, installation, and maintenance. Should be no-confliction.
• 4. TUV Rheinland of North America, Inc. (TRNA)
• Headquarter in Köln, Germany, a top NRTL, to serve US, Canada, and other global

manufacturers, one stop local testing and field services for global compliances

• CSI link: www.gosolarcalifornia.ca.gov/documents/CSI_HANDBOOK.PDF

3

Introduction – Compliance requirement of USA and Canada

TÜV Rheinland Italy of North America _ FZ

• 5. Standard Development
• TÜV Rheinland together

with Sandia, ASU and Bosch, etc., authorized by U.S. Department of Energy, is developing the micro-inverter standard to include Reliability (see right).

• Once finished, it could

be applied to other big inverters or inverter sub- assemblies, when there is no better one available.

4

Evaluation and Testing per ANSI/CAN/UL 9540

TÜV Rheinland Italy of North America _ FZ

6. ANSI/CAN/UL 9540: 2016, Energy Storage Systems and Equipment (only in NA)

• What Included in this standard?
• Construction, components, performance/testing, and documentation requirements, etc.
• UL 1741: Inverters, Converters, Controllers and Interconnection System Equipment for

Use With Distributed Energy Resources, include SA to meet Rule 21, H14, etc.

• CSA C22.2 No. 107/1: 2016, Power conversion equipment for Canada (Language)
• IEEE 1547 (& IEEE 1547.1): Interconnecting Distributed Resources with Electric Power

Systems – new 2018 version to be used and combined with Rule 21 and H14

• ANSI/CAN/UL 1973: 2018, Batteries for Use in Light Electric Rail (LER) Applications and

Stationary Applications (may need to apply UL 1998 + UL 991 for functional safety)

• Walk-in System (NFPA 70E)
• Safety analysis and control system (failure modes and effects analysis (FMEA)
• Heating and cooling system
• Communication system
• Fire detection and suppression system
• Special installation environment: outdoor use near marine, seismic area

5

TÜV Rheinland’ Services in ESS + PV

TÜV Rheinland Italy of North America _ FZ

Our global ESS + PV global testing network located in Germany, Italy, Hungary, Greater China, India, Japan, Korea, Australia, and USA, to provide product safety testing, global grid- connection compliance, performance (reliability) measurement, and field evaluation services

• Efficient global testing network and long time experience for this industry
• Global team of engineers and experts to provide local one stop services
• Active participation in the important standardization committees (US, Canada, and

international IEC/EN)

• Field Labelling on big ESS installation in USA and Canada
• Consulting services in early product development stage for

product safety and compliances

• New services as required by local utilities, such as:

NEM Interconnection Handbook: March 2018 v 7.0 | 33

• Clause 5.11, Energy Management System Performance

Requirements to Not Allow Energy Storage to Charge from Grid

• Testing services per client’s specification, such as:

USABC Electric Vehicle Battery Test Procedures Manual

• Others

TÜV Rheinland of North America, Inc. Thank you！

Fred Z. Zhu

Program Manager, TÜV Rheinland of North American, Inc. +1 925.918.5123 zzhu@us.tuv.com
