Energetics with ELVAC Energetics with ELVAC ELVAC development for energy sector Year 1998 MCS system for power distribution control in substations From 1998 until now more than 130 substations with MCS system installed Energetics with

SLIDE 1

Energetics with ELVAC

SLIDE 2

Energetics with ELVAC

ELVAC development for energy sector

Year 1998 – MCS system for power distribution control in substations From 1998 until now – more than 130 substations with MCS system installed

SLIDE 3

Energetics with ELVAC

ELVAC development for energy sector

Year 2000 – beginning of RTU series development as a logical next step after MCS system. The goal was to fulfil new demands in energy sector and enlange possibilities for other market segments.

SLIDE 4

Energetics with ELVAC wide range of configurations – from cheap small systems up to sophisticated powerful systems enhanced communication abilities – GPRS, serial, LAN, many standard communication protocols protective functions – for grid protection battery backup support – charging, testing

RTU features (comparing to MCS system)

MCS system 1998 ELVAC RTU nowadays

ELVAC development for energy sector

SLIDE 5

Energetics with ELVAC

ELVAC development for energy sector

From Y2000 until now – RTU series extended the application abilities for the following fields: remote control of distribution substations remote control and measurement of distributional transforming stations (DTS)

verhead power distribution – remote control and measurement of section circuit

breakers and reclosers underground power distribution – cable grid measurement and evaluation renewable energy control and measurement – solar and wind water, gas and thermal management energy efficiency management (energy consumption audits in industry)

SLIDE 6

Energetics with ELVAC

ELVAC product range for energy sector

RTU7.4 - control and communication unit, 4x IFC RTU7K (KL) - control and communication unit, 3U+3I RTU7M - modular system for larger or tailor made systems RTU7C - general communication module with DIO and protocols demanded in power industry

SLIDE 7

Energetics with ELVAC

ELVAC product range for energy sector

RPSII – redundant power supply for ctitical applications Boxes RY – tailor made boxes with RTU units and all necessary wiring and accessories for direct customer implementation Tailor made RTU units – for customers with specific demands

SLIDE 8

Energetics with ELVAC

ELVAC product range for energy sector

EPG7

3-channel current generator 3-channel voltage generator DIO for protection testing USB interface wide range of user FW Used as: current, voltage generator function generator record player – for errors records from protections tester of indicators for failure currents protection tester DI datalogger

SLIDE 9

ELVAC product range for energy sector

EPG7 HP

Generator and tester with high power

utputs for full range testing of protections

Energetics with ELVAC

SLIDE 10

Energetics with ELVAC

Related ELVAC products for energy sector

SCADA SW Mikrodispecink for dispatching control RTU user software LCD display for RTU units Communication converters for RTU units Other RTU accessories – power supplies, batteries, antennas, measuring transformers Operator LCD multipanels and big screens (rear projection) Time synchronization GPS card for PCs

SLIDE 11

Energetics with ELVAC

Wide product range Flexibility for different applications Many years experience References in energy sector

SLIDE 12

References

Energetics with ELVAC

Company: ČEZ, a.s., Czech Republic Name of project: 150x substations control Project description: Remote control of substations in 150 places Used device: MCS and RTU systems Number of devices: 2500 pcs Term: 1997 – 2008

SLIDE 13

References

Energetics with ELVAC

Company: Energetika Vítkovice, a.s., Czech Republic Name of project: Substations control Project description: Remote control of substations in factory energetics Used device: RTU7M/MS Number of devices: 500 pcs Term: 2006-2008

SLIDE 14

References

Energetics with ELVAC

Company: ČEZ, a.s., Czech Republic Name of project: Distribution switching elements control Project description: Remote control of disconnectors and reclosers in distribution grid for dispatching control and automatic grid control Used device: RTU7M/MS, RTU7K, RTU7KL Number of devices: 2000 pcs Term: 2002 – still going

SLIDE 15

References

Energetics with ELVAC

Company: Owners of wind power plants in Czech Republic Name of project: Wind power plant control Project description: Remote control and measurement

f wind power plant

Used device: RTU7M or RTU7K/KL Number of devices: 25 pcs Term: 2005 – still going

SLIDE 16

References

Energetics with ELVAC

Company: Owners of solar power plants in Czech Republic Name of project: Solar boom in Czech Republic Project description: Connection of solar power plants to the distribution grid of ČEZ Inc. for performance control in SCADA Used device: RTU7M or RTU7K/KL Number of devices: 1500 pcs Term: 2009 - still going

SLIDE 17

References

Energetics with ELVAC

Company: E.ON Česká republika, s.r.o., Czech Republic Name of project: Solar boom in Czech Republic Project description: Connection of solar power plants to the distribution grid of E.ON Used device: RTU7M or RTU7K/KL Number of devices: 200 pcs Term: 2011 – still going

SLIDE 18

References

Energetics with ELVAC

Company: Západoslovenská energetika, a.s, Slowakia (group E.ON) Name of project: Fault currents indicators in Bratislava Project description: Control of cable lines in distribution grid Used device: RTU7.4 Number of devices: 700 pcs Term: 2009 - 2012

SLIDE 19

References

Energetics with ELVAC

Company: Západoslovenská energetika, a.s., Slowakia (group E.ON) Name of project: Distribution switching elements control Project description: Remote control of sectionalizers in distribution network Used device: RTU7M, RTU7K/KL Number of devices: 480 pcs Term: 2010 – still going

SLIDE 20

References

Energetics with ELVAC

Company: Stredoslovenská energetika, a.s., Slowakia (group EP Energy) Name of project: Distribution switching elements control Project description: Remote control of reclosers in distribution network Used device: RTU7M, RTU7K, RTU7KL Number of devices: 110 pcs Term: 2010 – still going

SLIDE 21

References

Energetics with ELVAC

Company: Východoslovenská energetika, a.s., Slowakia (group RWE) Name of project: Distribution switching elements control Project description: Remote control of reclosers in distribution network Used device: RTU7M, RTU7K, RTU7KL Number of devices: 120 pcs Term: 2010 – still going

SLIDE 22

References

Energetics with ELVAC

Company: CEZ BULGARIA EAD Name of project: 43x substations control Project description: Remote control of substations in 43 places Used device: Large RTU7M systems Number of devices: 70 pcs Term: 2012 – still going

SLIDE 23

References

Energetics with ELVAC

Company: CEZ BULGARIA EAD Name of project: Overhead and underground lines control Project description: Pilot project for measuring and remote control

f distribution elements in overhead lines and

underground lines Used device: Whole systems of RTU7 installed in cabinets, with measuring transformers, capacitive deviders and transformers for power supplying Number of devices: 20 pcs Term: 2013

SLIDE 24

References

Energetics with ELVAC

Company: CEZ BULGARIA EAD Name of project: Overhead and underground lines control Project description: Measuring and remote control of distribution elements in overhead lines and underground lines Used device: Whole systems of compact RTUs installed in cabinets, with measuring transformers, capacitive dividers and transformers for power supplying Number of devices: 30 pcs Term: 2014 – still going

SLIDE 25

References

Energetics with ELVAC

Company: CEZ BULGARIA EAD Name of project: SCADA Mikrodispečink Project description: Instalation and maintenance of SCADA SW Used device: Software Number of devices: 1 pc Term: 2009 – still going

SLIDE 26

References

Energetics with ELVAC

Company: CEZ ROMANIA, S.A. Name of project: Distribution switching elements control Project description: Remote MV/LV substation and Recloser control Used device: RTU7M and RTU7.4 Number of devices: 330 pcs Term: 2013 – still going

SLIDE 27

References

Energetics with ELVAC

Company: CEZ ROMANIA, S.A. Name of project: SCADA Mikrodispečink Project description: Instalation and maintenance of SCADA SW Used device: Software Number of devices: 1 pc Term: 2009 – still going

SLIDE 28

References

Energetics with ELVAC

Company: EVN Macedonia Name of project: Distribution switching elements control Project description: Pilot project and following another installation

f ELVAC RTUs for remote control of reclosers

in distribution grid Used device: RTU7M Number of devices: 30 pcs Term: 2012 – still going

SLIDE 29

Contacts ELVAC a.s. Hasičská 53 700 30 Ostrava-Hrabůvka Czech Republic Tel.: +420 597 407 311 Fax: +420 597 407 102 E-mail: sales@elvac.eu Web: www.rtu.cz www.elvac.eu
