www.elvac.eu IEC 61850 in the ELVAC products Jan Slezk IEC 61850 in the ELVAC products IEC 61850 in the Mikrodispecink SCADA Used mainly as an HMI (e.g. CEZ substations Havov and Kojetn) Support through a separate driver (similar to

SLIDE 1

Jan Slezák

IEC 61850 in the ELVAC products

www.elvac.eu

SLIDE 2

IEC 61850 in the ELVAC products Used mainly as an HMI (e.g. CEZ substations Havířov and Kojetín) Support through a separate driver (similar to KomX module) Two variants: Classic application running on desktop – KomX_61850 System service running in the background – Kom61850 Configured by configuration file and by CSV files in the control folder Each CSV file defines: A connection to one IED All points transferred from / controlled on this IED

www.elvac.eu | www.rtu.cz

IEC 61850 in the Mikrodispecink SCADA

Products for energetics

SLIDE 3

IEC 61850 in the Mikrodispecink SCADA

www.elvac.eu | www.rtu.cz

Products for energetics

SLIDE 4

IEC 61850 in the Mikrodispecink SCADA To work with the driver: The Mikrodispecink must have a properly configured routes. The configuration table of the routes is newly expanded.

www.elvac.eu | www.rtu.cz

Products for energetics

SLIDE 5

IEC 61850 in the Mikrodispecink SCADA Configuration GUI = Mikrodispecink Editor

www.elvac.eu | www.rtu.cz

Products for energetics

To configure driver in the Mikrodispecink Editor: Create folder ZIVY\61850 in the system folder of Mikrodispecink (probably something like D:\MDisp\MD93) Set control folder of driver to the newly created ZIVY\61850 folder Create working folder EDITACE\61850 in the system folder of Mikrodispecink

SLIDE 6

IEC 61850 in the Mikrodispecink SCADA

www.elvac.eu | www.rtu.cz

Products for energetics

Three ways to configure driver: a) Fully manual b) With help of SCL file (description file of device or the whole substation) c) Almost fully automatic based on SCL file and config. file from Siemens SICAM PAS Assign IEC 61850 to systems (way a and b):

SLIDE 7

IEC 61850 in the Mikrodispecink SCADA

www.elvac.eu | www.rtu.cz

Products for energetics

Set parameters of devices - IEDs (way a): Configure all desired points (way a):

SLIDE 8

IEC 61850 in the Mikrodispecink SCADA

www.elvac.eu | www.rtu.cz

Products for energetics

Save all three tables (repeat on each table) (all ways):

SLIDE 9

IEC 61850 in the Mikrodispecink SCADA

www.elvac.eu | www.rtu.cz

Products for energetics

Create configuration CSV file and send it to the driver (all ways): To configure with help of SCL file (way b and c): Copy the SCL file to editor folder for 61850 configuration (EDITACE\61850). Rename copied file to form CfgNNNN.scd, where NNNN is the number of Mikrodispecink system assigned to this IEC 61850 configuration. The cid extension can be used instead of scd.

SLIDE 10

IEC 61850 in the Mikrodispecink SCADA

www.elvac.eu | www.rtu.cz

Products for energetics

Set parameters of devices - IEDs (way b): Configure all desired points (way b):

SLIDE 11

IEC 61850 in the Mikrodispecink SCADA

www.elvac.eu | www.rtu.cz

Products for energetics

Configuration according to Siemens SICAM PAS

HMI – Mikrodispecink KomX_61850 SCADA – Mikrodispecink KomX or Communicator data concentrator SICAM PAS IED IED IED

IEC 61850 level IEC 60870-5-104 level substation

SLIDE 12

IEC 61850 in the Mikrodispecink SCADA

www.elvac.eu | www.rtu.cz

Products for energetics

To configure with help of SCL file and SICAM PAS file (way c): Copy the SCL file to editor folder for 61850 configuration (EDITACE\61850). Rename copied file to form CfgNNNN.scd, where NNNN is the number of Mikrodispecink system assigned to this IEC 61850 configuration. The cid extension can be used instead of scd. Copy the XML file from SICAM PAS to the same folder as SCL file. Rename copied file to form IECNNNN.xml, where NNNN is the number of Mikrodispecink system assigned to this IEC 61850 configuration. Copy configuration of IEC 60870-5-104 protocol from SCADA Mikrodispecink to HMI Mikrodispecink.

SLIDE 13

IEC 61850 in the Mikrodispecink SCADA

www.elvac.eu | www.rtu.cz

Products for energetics

Assign IEC 61850 to systems and link it to IEC 60870-5-104 (way c): Set parameters of devices - IEDs (way c):

SLIDE 14

IEC 61850 in the Mikrodispecink SCADA

www.elvac.eu | www.rtu.cz

Products for energetics

Configure all desired points (way c):

SLIDE 15

IEC 61850 in the ELVAC products Work in progress – available at the end of year Future plans Work in progress: IEC 61850 client for connecting ELVAC RTUs to external devices. It will complement current support for IEC 60870-5-103, DNP3, Modbus protocols. It will allow to read data from IEC 61850 protections and to control them. Connection to controlling system (SCADA) will be realized by already existing ways – by IEC 60870-5-10x, DNP3 protocols. Possibility to deploy to existing COMIO-PC2 hardware (and therefore into RTUs already in the field). Configured by “RTU User Center” application.

www.elvac.eu | www.rtu.cz

IEC 61850 in the ELVAC RTUs

Products for energetics

SLIDE 16

IEC 61850 in the ELVAC products Future plans: IEC 61850 server, goose messaging. It will allow to fully integrate the ELVAC RTUs to the IEC 61850 infrastructure. For instance it will allow the ELVAC RTU to communicate to the IEC 61850 HMI. The new hardware (communication card) is needed. Temporarily called COMIO-PC3. COMIO-PC3 will have two ethernet ports. This will allow to implement IEC 62439-3 protocol (Parallel Redundancy Protocol). Configured by “RTU User Center” application or on the web interface of the RTU itself.

www.elvac.eu | www.rtu.cz

Products for energetics

IEC 61850 in the ELVAC RTUs

SLIDE 17

O Společnosti

Thank you for your attention

www.elvac.eu

Hasičská 53, 700 30 Ostrava - Hrabůvka Czech Republic Tel.: +420 597 407 100 E-mail: sales@elvac.eu www.elvac.eu, www.rtu.cz
